Product Standard Configuration; Bms Function - Pytes E-BOX Series User Manual

1.1 Product standard configuration

Items
E-BOX SERIES
[1]
Power Cable
[2]
Communicate
Cable
Earthing cable
Mounting Brackets
[1] The power cable and battery are packaged separately in North American and come in two different specifications:
0.16m, Both Amphenol Surlok Connector, or 2m, Amphenol Surlok Connector and M8 Connector.
Please refer to the actual receipt of goods.
[2] 0.35m in length for E-Box 48100R; 0.22m in length for ESS48-2U-L and E-Box 4850G
[3] Available in E-Box 48100R package only.

1.2 BMS function

Protection and Alarm
Charge/Discharge End
Charging over Voltage
Discharging under Voltage
Charge/Discharge Over Current
High/Low Temperature
Short Circuit
Power Cable Reverse
Quantity
LFP pack; including
BMS,three interfaces
(CAN/RS-485/RS232),
2 Link ports, LED power
1pc
indicator and insulated
coating metal case.
Connect battery to
1set battery;0.16m; Positive
and negative
Connect battery to
1pc
battery; CAN or RS485
communicate
1pc
Fix the battery on the
[3]
4pcs
wall
Specifications
1m
Management and Monitor
Cell Balance
Intelligent Charge algorithm
Charge/Discharge current Limit
Capacity Retention Calculation
Administrator Monitor
Record
06
Pictures
(For reference only)
