Ruijie RG-WS6512 Installation And Reference Manual page 8

Hardware Installation and Reference Guide
1.4.3 Power Supply and Consumption
Item
Max. power
consumption
Power pedundancy
Input voltage
Output voltage
Note
A combo port consists of an optical port and an electrical port. The optical port and
electrical port cannot work at the same time. If one port is enabled, the other is disabled.
You can select the port type as required.
1.4.4 Environment and Reliability
Item
Temperature
Humidity
Regulatory
Compliance
MTBF
RG-WS6512
70 W
Two power modules (one power module for factory delivery)
100V AC~240V AC，50Hz~60Hz
12V/5.83A
RG-WS6512
Operating temperature: 0°C to 45°C (32°F to 113°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
At a height between 3000 m (9842.52 ft.) to 5000 m (16404.20 ft.)
above the sea level, every time the altitude increases by 200 m
(722 ft.), the maximum temperature decreases by 1°C (1.8°F).
Operating humidity: 10% to 90% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing)
IEC 62368-1, EN 62368-1, EN 55032, EN 55035, EN 61000-3-3, EN
IEC 61000-3-2, and ETSI EN 300 386
≥ 200,000 hours
4
Product Introduction
