Summary of Contents for Ruijie RG-WS6108
- Page 1 Ruijie RG-WS6108 Wireless Controllers Hardware Installation and Reference Guide Document Version: V1.2 Date: 2023.12.12 Copyright © 2023 Ruijie Networks...
- Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
-
Page 3: Preface
Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com ... - Page 4 2. Signs The signs used in this document are described as follows: Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation.
-
Page 5: Table Of Contents
2.3 Installation Tools ........................10 3 Installing Wireless Controller ......................11 3.1 Installation Flowchart ....................... 11 3.2 Mounting Wireless Controller ....................11 3.2.1 Mounting RG-WS6108 in Cabinet ................11 3.2.2 Mounting RG-WS6108 on Workbench ................ 12 3.3 Installing Power Cable ......................12... - Page 6 3.4 EMS & Secure Grounding ....................... 12 3.5 Connecting Console ........................ 13 3.6 Verification ..........................13 4 Configuration Guide ........................- 15 - 4.1 Setting up Configuration Environment ................- 15 - 4.2 Powering on Wireless Controller ..................- 16 - 4.2.1 Verification Before Power-on ..................
-
Page 7: Product Overview
Hardware Installation and Reference Guide Product Overview Product Overview The RG-WS6108 wireless LAN controller is introduced by Ruijie Networks to provide powerful access control capability for medium-large-sized wireless networks. Product Appearance Figure 1-1 Front Panel of RG-WS6108 Figure 1-2 Rear Panel of RG-WS6108 Note The nameplate is at the bottom of the wireless controllers. -
Page 8: Technical Specifications
H) Rack Height 1 RU Weight Net weight: 2.9 kg (6.39 lbs) Port Specification RG-WS6108 Fixed Service Port Six 10/100/1000Base-T Ethernet ports with auto-negotiation. Port 1 can serve as a management port. Two combo ports. When the electrical port works, 10/100/1000Base-T auto-negotiation is supported. - Page 9 Hardware Installation and Reference Guide Product Overview Power Supply RG-WS6108 and Consumption Max. Power 40 W Consumption Input Voltage 100 V AC to 240 V AC，50 Hz to 60 Hz Output Voltage 12 V/3.33 A Environment and RG-WS6108 Reliability Operating temperature: –10°C to +40°C (14°F to 104°F) Storage temperature: –40°C to +70°C (–40°F to +158°F)
- Page 10 Hardware Installation and Reference Guide Product Overview Note A combo port consists of an optical port and an electrical port. The optical port and electrical port cannot work at the same time. If one port is enabled, the other is disabled.
-
Page 11: Preparation For Installation
Keep the device within the restricted-access area. The device should be installed by professionals or technicians. Preparing Installation Site RG-WS6108 is for indoor use only. To ensure its normal operation and prolong its life span, the installation site should meet the following requirement:... -
Page 12: Temperature And Humidity Requirements
High temperature greatly reduces reliability of the device and shortens its service life. Table 2-1 Required Temperature and Humidity for the RG-WS6108 Relative Temperature Relative Temperature... -
Page 13: Static Discharge Damage Prevention
2.2.3 Static Discharge Damage Prevention Although mu ch has been done in RG-WS6108 to prevent static electricity, great damage may be caused to ic electricity exceeds a certain limit. Electrostatic induction may come the circuitry when the stat from the following sources: ... -
Page 14: Installation Site Requirements
Hardware Installation and Reference Guide Preparation for Installation Provide the power system with effective anti-interference measures. It is recommended that the wireless controller be installed far away from the grounding device. Keep the wireless controller away from high-power radio stations, radar stations, and high- frequency high-current devices. -
Page 15: Installing Wireless Controller
Now the wireless controller is ready for installation. Mount it to either of these two places. A cabinet A workbench 3.2.1 Mounting RG-WS6108 in Cabinet RG-WS6108 is designed according to the specification of 19-inch standard cabinet. Use the supplied mounting accessory for installation. -
Page 16: Mounting Rg-Ws6108 On Workbench
10 cm clearance is reserved for dissipation. No weight is placed on the top of the wireless controller. Installing Power Cable RG-WS6108 supports AC (100 VAC to 240 VAC; 50/60 Hz). Make sure that your power supply meets the requirement. Note ... -
Page 17: Connecting Console
Hardware Installation and Reference Guide Installing Wireless Controller Connecting Console RG-WS6108 supplies an EIA/TIA-232 configuration console for local configuration. If you configure RG-WS6108 through Web, skip this part. Table 3-1 Console Attributes Parameter Description Connector RJ-45 Interface Standard Asynchronous EIA/TIA-232... - Page 18 Hardware Installation and Reference Guide Installing Wireless Controller Check the wireless controller is connected correctly to other devices such as the configuration terminal. Caution To shut down the device, turn off the power switch on the rear panel of the device. Do not directly disconnect the 220 V power supply, such as directly cutting off the power or unplugging the power cord.
-
Page 19: Configuration Guide
Hardware Installation and Reference Guide Configuration Guide Configuration Guide Setting up Configuration Environment When you use the wireless controller for the very first time, you will need to configure it through a console port as follows: As shown in the following figure, connect the serial port of a character terminal or microcomputer to the console port through an RS232 cable. -
Page 20: Powering On Wireless Controller
Hardware Installation and Reference Guide Configuration Guide Figure 4-3 Setting Communication Parameters for Serial Port. After building the configuration environment, you may power on the wireless controller Powering on Wireless Controller 4.2.1 Verification Before Power-on Before powering on the wireless controller, please check the following items:... -
Page 21: Power-On
Hardware Installation and Reference Guide Configuration Guide If the power cable and the grounding cable are connected correctly. If the power supply voltage meets the requirement. If the configuration cable is connected correctly, the microcomputer or terminal is turned on, and the setting is complete. -
Page 22: Configuring Wireless Controller
Hardware Installation and Reference Guide Configuration Guide 0.000000] Linux version 2.6.32.13-Cavium-Octeon (ngcf@ngcf75) (gcc version 4.3.3 (Cavium Networks Version: 2_0_0 build 95) ) #1 SMP Thu May 8 04:34:42 CST 2014 0.000000] CVMSEG size: 2 cache lines (256 bytes) 0.000000] Cavium Inc. SDK-2.3 0.000000] bootconsole [early0] enabled 0.000000] CPU revision is: 000d910a (Cavium Octeon II) 0.000000] Checking for the multiply/shift bug... -
Page 23: Troubleshooting
You may use the power indicator on the front panel to decide if the power supply system is operating normally. For description of indicators, see Chapter 1. If a fault occurs, check the following items: If RG-WS6108 power switch is in the on position. If the power supply is turned on. ...
