Technical Specifications - Ruijie RG-WS6512 Installation And Reference Manual

Hardware Installation and Reference Guide
Press and hold the Reset button for 3s. The system is rebooted with restored default
settings.
1.4

Technical Specifications

1.4.1 Dimensions and Weight
Dimensions and
Weight
Dimensions (W × D
× H)
Rack height
Weight
1.4.2 Port Specifications
Item
Fixed service port
Fixed management
port
Status LED
Button
RG-WS6512
440 mm ×340 mm ×43.6 mm (17.32 in. ×13.39 in. ×1.72in.)
(excluding the foot pads)
1 U
Net weight: 5.9 kg (13.01 lbs., one power module for factory
delivery)
RG-WS6512
One 10/100/1000Base-T MGMT port with auto-negotiation
Eight combo ports (when the combo port is used as an
electrical port, it supports 10/100/1000Base-T auto-
negotiation)
Four 10GE SFP + ports
One RJ45 console port
Two USB ports
One system LED
20 service port status LEDs
One reset button
3
Product Introduction
