- Page 1 RG-WS5708 Series Wireless Controller Hardware Installation and Reference Guide V1.1...
- Page 2 Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited. are registered trademarks of Ruijie Networks.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance http://www.ruijie.com.cn Ruijie Networks website: http://webchat.ruijie.com.cn Online customer services: http://www.ruijie.com.cn/service.aspx Customer service center: ...
-
Page 4: Chapter 1 Product Overview
Chapter 1 Product Overview The RG-WS5708 wireless LAN controller is introduced by Ruijie Networks to provide powerful WLAN access control for medium-large-sized wireless networks. The following table lists the number of various ports on the front panel of the wireless controller. -
Page 5: Product Image
1000Base-T: Mini-GBIC-GT 10-Gigabit SFP+ module: XG-SFP-SR-MM850 XG-SFP-LR-SM1310 The supported SFP modules may be updated at any time. For details, please contact us. Support 1000Base-X SFP Ports Support 1+1 power redundancy Power module: RG-PA300I Rated voltage range: 100 to 240 V AC Power Supply Maximum voltage range: 90 to 264 V AC Frequency: 50 to 60 Hz... -
Page 6: Front Panel
Front Panel Figure 1-2 Front Panel of RG-WS5708 1. System status LED 6. MGMT port Note 2. MGMT port LED 7. 10/100/1000Base-T auto-sensing 3. 10/100/1000Base-T auto-sensing Ethernet port Ethernet ports LEDs 8. 1000Base-X SFP ports 4. 1000Base-X LEDs 9. SFP+ port LEDs 5. -
Page 7: Power Supply
1. Ground rod 3. Fan tray slot Note 2. Power supply slots Power Supply The wireless controller uses RG-PA300I power modules. The RG-PA300I modules receive AC input. Rated voltage range: 100 V to 240 V AC Maximum voltage range: 90 V to 264 V AC ... -
Page 8: Led Indicators
LED Indicators State Meaning The wireless controller is NOT receiving power. Initialization in progress. Blinking green Status Continuous blinking indicates errors. Solid green The wireless controller is operational. Solid red The wireless controller is faulty. See Section 5.2 Troubleshooting The SFP port is NOT connected. 1F 2F 3F 4F Solid green The SFP port is connected at 1000 Mbps. -
Page 9: Chapter 2 Preparing The Installation
Chapter 2 Preparing the Installation Safety Recommendations To prevent device damage and bodily injury, please read carefully the safety recommendations described in this chapter. The recommendations do not cover all possible hazardous situations. Installation Safety Keep the chassis clean, free from any dust. ... -
Page 10: Preparing Installation Site
Direct or indirect touch through a wet object on high voltage and power line can bring a fatal danger. ESD Prevention To prevent damage from static electricity, note that: Properly ground the device. Take dust prevention measures in the room. ... - Page 11 0ºC to 45ºC 10% to 90% The ambient temperature and humidity are measured at a point 1.5 meters (4.9 feet) above the ground and 0.4 meters (1.3 feet) before the device when there is no protective board in the front or back of the rack. Cleanness Dust poses a serious threat to device operation.
-
Page 12: Grounding System
Grounding System A good grounding system protects your wireless controller against lightning strikes and interferences and ensures its normal operation and reliability. Please observe the grounding requirements and on-site environment. Make sure the wireless controller is properly grounded. Properly connecting the wireless controller ground wires guarantees the wireless controller against lightning strikes and interferences. -
Page 13: Fiber Connection
the rack, work bench or the wall on the equipment room. When a surge arrestor is being used, alternating current flows through the surge arrestor before entering the wireless controller. Surge arrestors are customer supplied. For details of surge arrestors, see related user guide. All interference sources, either from outside or inside of the device or application system, affect the device by capacitive coupling, inductive coupling, or electromagnetic waves. - Page 14 The listed tools are customer supplied.
-
Page 15: Chapter 3 Installing The Wireless Controller
Chapter 3 Installing the Wireless Controller Before installing the wireless controller, make sure you have carefully read the requirements described in Chapter 2. Installation Flowchart Before You Begin Before you install the wireless controller, verify that: The installation site provides sufficient ventilation. ... - Page 16 Installing the Wireless Controller Precautions Please observe the following precautions before you install the wireless controller. When connecting a wire to a binding post, make sure their colors are the same. Make sure the power supply is properly connected. ...
-
Page 17: Verifying The Installation
Place the wireless controller on the table and leave sufficient space around the wireless controller for proper ventilation. Verifying the Installation To prevent bodily injury and device damage, make sure the wireless controller is disconnected. Verify that the ground wire is connected. ... -
Page 18: Chapter 4 System Debugging
Chapter 4 System Debugging Setting up the Configuration Environment Setting up the Environment Connect a PC to the Console port of the wireless controller with a console cable. See Figure 4-1. Figure 4-1 Setting up Configuration Environment Connecting the Console Cable Step 1: Connect the DB-9 end of the console cable to the COM port on your PC. - Page 19 Click Cancel. The Connection Description dialog will appear. In the Name box, enter the new connection name and click OK. The Connect to dialog will appear. From the Connect using drop-down list, select a COM port to be used.
- Page 20 Click OK. The COM1 Properties dialog will appear. Select the following settings: Bits per second: 9600 Data bits: 8 Parity: None Stop bits: 1 Flow control: None...
- Page 21 Click OK and HyperTerminal window will appear. Powering up the Wireless Controller Checking before power-up...
- Page 22 The wireless controller is well grounded. The power cord is properly connected. The input voltage matches the specifications of the wireless controller. The console cable is properly connected. The terminal for configuration, such as a PC, is started, and terminal parameters are set.
-
Page 23: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting Troubleshooting Flowchart Handling Common Problems Troubles Possible Causes Solution Contact Ruijie Technical Assistance Center Forgot login password for help Verify that the power outlet functions Status LED does not light The wireless controller is not receiving correctly. - Page 24 The connected twisted pairs are faulty. RJ45 Ethernet port The cable length exceeds 100 meters. Replace twisted pairs. cannot be connected or The Ethernet port is configured for other Check speed and duplex settings on the port. receives/sends error purposes. The speed and duplex Make sure it shares the same operation mode frames settings are not the same with...
-
Page 25: Appendix A Connectors And Media
Appendix A Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX. Compliant with IEEE 802.3ab, 1000BASE-T requires Category 5e 100-ohm UTP or STP (STP is recommended) with a maximum distance of 100 meters (328 feet). 1000BASE-T requires all four pairs of wires be connected for data transmission, as shown in Figure A-1. - Page 26 Fiber Connection You can choose to use single mode or multimode fibers according to the transceiver module types. Figure A-3 shows connection of fiber cables. Figure A-3 Fiber Connection...
-
Page 27: Appendix B Mini-Gbic Module Specifications
Appendix B Mini-GBIC Module Specifications Ruijie provides various Gigabit SFP transceivers (Mini-GBIC modules) for interfaces of wireless access controllers. You can select the most suitable SFP modules as needed. This appendix describes the models and specifications of some of the Gigabit SFP transceivers for your reference. -
Page 28: Appendix C 10-Gigabit Sfp+ Series Module Specifications
Appendix C 10-Gigabit SFP+ Series Module Specifications Ruijie provides various 10-Gigabit SFP+ transceivers such as XG-SFP-SR-MM850 and XG-SFP-LR-SM1310 for your choice. The 10-Gigabit SFP+ transceiver module is a hot-swappable input/output (I/O) device that slide into a 10-Gigabit Ethernet SFP+ port/slot to connect the fiber network. This appendix describes the models and specifications of some of the 10-Gigabit SFP+ transceivers for your reference.
