Ruijie RG-WS6512 Installation And Reference Manual page 6

Hardware Installation and Reference Guide
Description
Note
The nameplate is at the bottom of the access controller.
1.3 Product LED Indicators
LED
System logo LED
LEDs for 1000 Mbps
copper ports (1 to 8)
LEDs for 1000 Mbps
optical ports (1F to 8F)
LEDs for 10 Gbps optical
ports (1F to 4F)
Pressing the Button to Reboot the System
Press the Reset button. The system is rebooted.
1. System logo LED
2. Reset button
3. RJ45 console port
4. USB 2.0 port
5. 10/100/1000Base-T auto-
sensing Ethernet ports
Status
Initializing upon power-on/Upgrading: blinking green
Proper running upon initialization completion: steady
green
Abnormal running: steady red
1000 Mbps link: steady green
100/10 Mbps link: steady yellow
Data receiving/transmitting: blinking
Link: steady green
Data receiving/transmitting: blinking green
Link: steady green
Data receiving/transmitting: blinking green
6. 1000Base-X SFP combo ports
7. 10GBASE-SR/LR SFP+ ports
8. QR code for Ruijie AP and AC
initialization guide
9. Power modules
10. Grounding screw
2
Product Introduction
