FlexSet-IP 280S Component Descriptions

The following table defines controls, buttons and keys found on the FlexSet-IP 280S.
Dial Pad (Key Pad)
FlexSet Display
Fixed keys
Handset
Loudspeaker
Microphone
Ring and Message
Waiting Lamp
Programmable
Keys (DSS)
System Defined
(Fixed) Keys
Navigator Keys
Soft keys
Volume Buttons
FlexSet Overview
FlexSet-IP 280S Component Descriptions
Digit buttons used for dialing phone numbers or extension numbers.
The display is composed of three lines: System lines (1
rd
options (on 3 line) according to FlexSet status.
Enter, ABC, Menu and ESC.
Works as typical phone handset.
Output sound device used in hands free operation, paging and ringing.
Input sound device used in hands free operation.
Lamp flashes at a slow rate, indicating that a message is waiting.
Lamp flashes at a fast rate when the FlexSet is ringing.
22 user programmable keys on FlexSet-IP 280S with LED Indicators. Used to activate
telephony features or speed dial telephone numbers according to the user's needs. LED lights
when key or feature is activated.
Four system-wide programmed keys (market dependent) for basic features: Speaker, Loop,
Transfer and Hold.
Up/down, right/left arrows used to move from one option to another on the display. Used for
selecting without choosing or activating the option.
Keys used to directly activate the feature of each key.
Adjust the volume of the speakerphone, handset and ringer. See Volume Adjustment on page
40.
st
5
nd
and 2 lines), and available function
