Solder parts
In case of soldering the Solder part manually, it's highly recommended prolonging the solder
pad E on the outer side (e.g., for 1.5-2 mm) during the PCB design. Note that without this
modification, it's very difficult to solder the Solder part manually.
Recommended PCB footprint dimensions:
A
IA64ATQ-
12
SOLDER
IA100TQ-
16.5
SOLDER
IA144TQ-
22
SOLDER
Use the Surface Mount Technology (SMT) to solder the Solder parts to the user target
board instead of the original microcontroller. iSYSTEM provides this soldering service on
request too.
Emulation Adapter
M
IEA-SPC584B
56
IEA-SPC584B-
xxxx
B
C
1.505
13.0
1.125
17.0
1.125
23.0
N
P
56
56
Unit (mm)
D
E
13.0
2.3
17.0
2.15
23.0
2.15
Unit (mm)
R
S
32.6
56
K
L
14
14
19.55
19.55
25.05
25.05
T
V
36.4
47.5
