INSTALLATION AND OPERATION GUIDE FOR
HARGROVE VENT FREE GAS LOGS
Installation and service must be provided by a qualified installer, service agency or the gas supplier.
NOTE:
ADEQUATE FIREPLACE VENTILATION IS REQUIRED FOR SAFETY.
READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
WARNING:
If the information in this manual is not followed
exactly, a fire or explosion may result, causing
property damage, personal injury, or loss of life.
WHAT TO DO IF YOU SMELL GAS
1. Open a window.
2. Do not try to light any appliance.
3. Do not touch any electrical switch; do not use the
phone in your building.
4. Immediately call your gas supplier from a
neighbor's phone.
instructions.
5. If you cannot reach your gas supplier, call the fire
department.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
IMPORTANT:
Installation and service must be performed by a
qualified professional installer, service agency, or the
gas supplier. Improper installation, adjustments,
alteration, service, or maintenance can cause
personal injury or property damage. Refer to this
manual.
Cumberland Char - Heritage Char - Yukon Char
DESIGN CERTIFIED to
UNVENTED – ANSI Z21.11.2
VENTED - ANSI Z21.60/CGA 2.26
Follow the gas supplier's
This appliance operates as an unvented room
heater when fitted to a solid fuel burning
masonry fireplace or UL 127 approved factory
built fireplace with the flue damper closed. It
may also be installed in an approved unvented
fireplace.
WARNING:
THIS IS AN UNVENTED GAS FIRED HEATER.
IT USES AIR (OXYGEN) FROM THE ROOM IN
WHICH IT IS INSTALLED. PROVISIONS FOR
ADEQUATE COMBUSTION AND VENTILATION
AIR MUST BE PROVIDED. REFERENCE FUEL
GAS CODE NFPA 54, ANSI Z223.1 REFER TO
PAGE 2 OF THE INSTALLATION
INSTRUCTIONS.
This appliance is designed to supplement a
current heating system. It is not designed to
be used as a primary heat source.
NOTE:
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases. Solid-fuels
shall not be burned in a fireplace where a
decorative appliance is installed.
VF
REV 031017
