HARGROVE GAS LOGS
ROBERT SHAW 7000MV (RME-PO-HB)
MILLIVOLT GAS VALVE SYSTEM
INSTALLATION INSTRUCTIONS
This gas pilot safety valve provides 100% shut-off of
both pilot and main burner gas supply in the event of
pilot flame failure.
manual gas control knob to provide for pilot lighting.
f i r e - p a r t s . c o m
It also has a control knob that controls flame height.
If the pilot flame goes out during normal operation, or
if there is insufficient pilot flame to provide proper
thermocouple output, the safety valve will close,
stopping the flow of all gas. This valve is designed for
use on all domestic heating gases up to 1/2" PSI.
CAUTIONS
1. This valve should be installed only by an
experienced service technician trained in gas
safety equipment.
2. Turn off gas supply before installing valve.
3. All piping must meet applicable local codes
and ordinances and the national fuel gas code
(ANSI Z223.1/NFPA NO. 54)
4. All wiring must meet applicable electrical
codes and ordinances.
5. Check out the complete system after
installing the valve.
6. Prior to installation, verify conformance
with
burner manufacturer's installation
instructions.
7. Make sure all piping is free of foreign matter.
This valve is equipped with a
FOR YOUR SAFETY
IF YOU SMELL GAS:
1. OPEN WINDOWS
2. DON'T TOUCH ELECTRICAL
SWITCHES
3. EXTINGUISH ALL OPEN FLAMES
4. IMMEDIATELY CALL YOUR GAS
SUPPLIER
FLAMMABLE VAPORS MAY BE
DRAWN BY AIR CURRENTS FROM
OTHER AREAS OF YOUR HOUSE
TO THIS APPLIANCE.
FOR YOUR SAFETY
DO
NOT
STORE
GASOLINE OR
OTHER
FLAMMABLE
AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
OR
USE
VAPORS

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROBERT SHAW 7000MV and is the answer not in the manual?

Questions and answers

Summary of Contents for Hargrove ROBERT SHAW 7000MV

  • Page 1 HARGROVE GAS LOGS ROBERT SHAW 7000MV (RME-PO-HB) MILLIVOLT GAS VALVE SYSTEM INSTALLATION INSTRUCTIONS This gas pilot safety valve provides 100% shut-off of FOR YOUR SAFETY both pilot and main burner gas supply in the event of pilot flame failure. This valve is equipped with a IF YOU SMELL GAS: manual gas control knob to provide for pilot lighting.
  • Page 2 INSTALLATION INSTRUCTIONS ! WARNING ! Fire hazard. Do not disassemble or attempt repair of this unit. Disassembly, reassembly or internal adjustment could cause valve to malfunction, resulting in personal injury, death or property damage. If the control valve does not operate properly following installation or service, replace the unit. DO NOT INSTALL THE RSMVNG-C BEHIND THE DO NOT INSTALL RSMV-C BEHIND THE H-BURNER PAN IN THE FIREPLACE.
  • Page 3 INSTALLATION INSTRUCTIONS Thermopile and Pilot Burner Assembly 1. Attach the pilot generator (thermopile and pilot burner assembly) to the pilot bracket using the (2) #10-32 x 1/4" screws. (Fig.3) 2. Connect the pilot bracket to the back side of the burner pan using the (2) #8X1/2 screws. (Fig.3) 3.
  • Page 4 LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. be necessary to depress the knob slightly at the pilot A.
