INSTALLATION AND OPERATION GUIDE FOR
HARGROVE VENT FREE GAS LOGS
Installation and service must be provided by a qualified installer, service agency or the gas supplier.
NOTE:
ADEQUATE FIREPLACE VENTILATION IS REQUIRED FOR SAFETY.
READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
WARNING:
If the information in this manual is not followed
exactly, a fire or explosion may result, causing
property damage, personal injury, or loss of life.
WHAT TO DO IF YOU SMELL GAS
1. Open a window.
2. Do not try to light any appliance.
3. Do not touch any electrical switch; do not use the
phone in your building.
4. Immediately call your gas supplier from a
neighbor's phone.
instructions.
5. If you cannot reach your gas supplier, call the fire
department.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
IMPORTANT:
Installation and service must be performed by a
qualified professional installer, service agency, or the
gas supplier. Improper installation, adjustments,
alteration, service, or maintenance can cause
personal injury or property damage. Refer to this
manual.
Cumberland Char - Heritage Char - Yukon Char
DESIGN CERTIFIED to
UNVENTED – ANSI Z21.11.2
VENTED - ANSI Z21.60/CGA 2.26
Follow the gas supplier's
This appliance operates as an unvented room
heater when fitted to a solid fuel burning
masonry fireplace or UL 127 approved factory
built fireplace with the flue damper closed. It
may also be installed in an approved unvented
fireplace.
WARNING:
THIS IS AN UNVENTED GAS FIRED HEATER.
IT USES AIR (OXYGEN) FROM THE ROOM IN
WHICH IT IS INSTALLED. PROVISIONS FOR
ADEQUATE COMBUSTION AND VENTILATION
AIR MUST BE PROVIDED. REFERENCE FUEL
GAS CODE NFPA 54, ANSI Z223.1 REFER TO
PAGE 2 OF THE INSTALLATION
INSTRUCTIONS.
This appliance is designed to supplement a
current heating system. It is not designed to
be used as a primary heat source.
NOTE:
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases. Solid-fuels
shall not be burned in a fireplace where a
decorative appliance is installed.
VF
REV 122021
Advertisement
Table of Contents
Related Manuals for Hargrove ETCC30N1G
Summary of Contents for Hargrove ETCC30N1G
- Page 1 INSTALLATION AND OPERATION GUIDE FOR HARGROVE VENT FREE GAS LOGS Cumberland Char - Heritage Char - Yukon Char DESIGN CERTIFIED to UNVENTED – ANSI Z21.11.2 VENTED - ANSI Z21.60/CGA 2.26 Installation and service must be provided by a qualified installer, service agency or the gas supplier.
-
Page 2: Important Pre-Installation And Fireplace Safety Information
IMPORTANT PRE-INSTALLATION AND FIREPLACE SAFETY INFORMATION To determine the safest and most efficient location for your Vent Free Fireplace, you must take into consideration the following guidelines. This appliance operates as an unvented room heater certified under ANSI Z21.11.2a when fitted to a masonry or factory built fireplace with the flue damper open or closed. - Page 3 PREINSTALLATION REUIREMENTS COMBUSTION AND VENTILATION AIR REQUIREMENT WORKSHEET WARNING: IF THE AREA IN WHICH THE HEATER MAY BE OPERATED IS SMALLER THAN THAT DEFINED AS UNCONFINED SPACE OR IF THE BUILDING IS OF UNUSUALLY TIGHT CONSTRUCTION, PROVIDE ADEQUATE COMBUSTION AND VENTILATION AIR BY ONE OF THE METHODS DESCRIBED IN THE NATIONAL FUEL GAS CODE, ANSI Z223.1 SECTION 5.3 OR APPLICABLE LOCAL CODES.
- Page 4 PREINSTALLATION SPECIFICATIONS BTU RATINGS AND PRESSURE REQUIREMENTS 18” SETS 24”-30” SETS LOG SET SIZE GAS TYPE Natural Propane Natural Propane 30,000 BTU/Hr. 27,000 BTU/Hr. 35,000 BTU/Hr. 31,000 BTU/Hr. MAX. HEAT INPUT 21,000 BTU/Hr. 20,000 BTU/Hr. 25,000 BTU/Hr. 23,000 BTU/Hr. MIN. HEAT INPUT GAS INLET PRESSURE 10.5 ins.
- Page 5 PREINSTALLATION SPECIFICATIONS MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS AND MANTLE CLEARANCES IMPORTANT: To insure a safe installation into a masonry or factory built fireplace, the following instructions must be carefully observed. If installing in a pre-manufactured fireplace follow the clearance requirements accompanying that fireplace. Refer to Fig.
-
Page 6: Pre-Installation Checklist
State or local codes may only allow operation of this unit in a vented application. Check your state and local codes. All Hargrove vent free room heaters comply with IAS U.S. Requirement 5-95. The installation must conform with state and local codes or, in absence of local codes, to the National Fuel Gas Code, ANSI Z223.1... -
Page 7: Gas Connection
GAS CONNECTION WARNING: ANY MODIFICATION TO THIS UNVENTED GAS HEATER OR ITS CONTROLS CAN BE DANGEROUS. IMPROPER INSTALLATION OR USE OF THE HEATER CAN CAUSE SERIOUS INJURY OR DEATH FROM FIRE, BURNS, EXPLOSION OR CARBON MONOXIDE POISONING. BACK VIEW Manual SUPPLY Valve LINE... -
Page 8: Gas Pressure Check
GAS PRESSURE CHECK NOTE: The appliance and the appliance main gas valve must be disconnected from the gas supply system during any pressure testing of that system at test pressures in excess of 0.5 psig (3.5 kPa). The appliance must be isolated from the gas supply piping system by closing its equipment shut-off valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 0.5 psig (3.5 kPa). - Page 9 LOG PLACEMENT BRACKET INSTRUCTIONS FOR THE CUMBERLAND, HERITAGE, AND YUKON CHAR Back log bracket (behind the log) Back log bracket Back log bracket (in front of the log) (in front of the log) Front log bracket (behind the log) Front log bracket (behind the log) The brackets may be bent too close for the log to be put into place.
-
Page 10: Log Installation
LOG INSTALLATION HERITAGE CHAR (HCV) LOG DIAGRAM Fig. 2 18” - 5302GOVF Fig. 1 5309GOVF 24” - 5304GOVF 30” - 5306GOVF 5307GOVF 18” - 5301GOVF 5314GOVF 24” - 5303GOVF 5310GOVF 30” - 5305GOVF 5311GOVF 5312GOVF 18” - 5320GOVF 24” & 30”- 5322GOVF FAILURE TO POSITION LOGS PROPERLY MAY IMPORTANT: ASSURE THAT... - Page 11 LOG INSTALLATION CUMBERLAND CHAR (CCV) LOG DIAGRAM Fig. 1 18” - 5108GOVF 24” - 5111GOVF 5110GOVF 18” - 50170GOVF 5112GOVF 30” - 5115GOVF 24” & 30”- 5018GOVF 5109GOVF 5113GOVF 18” - 5107GOVF 24” - 5114GOVF 30” - 5116GOVF Step 1 – Identify each of the 7 logs in the set by comparing them to the log pictures below. (Fig 1 &2) Step 2 –...
- Page 12 LOG INSTALLATION YUKON CHAR XL LOG DIAGRAM Fig. 1 3411GO-24” & 30” 18” - 5402GO 5410GO 5409GO-18” 24” - 5404GO 30” - 5406GO 5408GO 18” - 5401GO 18” - 54170GO 5407GO 24” - 5403GO 24” & 30”- 5418GO 30” - 5405GO 5208GO 1215CL 3506GO...
-
Page 13: Ember Placement
EMBER PLACEMENT WARNING: IMPROPER INSTALLATION OF THE EMBER MATERIAL MAY LEAD TO CARBON MONOXIDE POISONING. EMBER PIECE Actual Size Fig. 1 Fig. 2 Front Grate Front Burner/Burner Ports 1. Tear the Ember Material into individual pieces (Fig 1). 2. Slightly stretch each Ember piece so it can be placed on the front burner ports and be supported by the front grate and burner (Fig. - Page 14 VOLCANIC CINDER PLACEMENT The Volcanic Cinder is the large bag of black rock that is included in the log set. The purpose of it is to cover the fireplace floor surrounding the set. The Volcanic Cinder will also cover the metal Lighting Instruction tags and help keep them out of sight. You may use the Volcanic Cinder to cover...
-
Page 15: Lighting Instructions
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING A. This appliance has a pilot which is lighted by a WARNING: If you do not follow these instructions spark igniter system. When lighting the pilot, follow exactly, a fire or explosion may result causing these instructions exactly. - Page 16 OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING A. This appliance has a pilot which is lighted by a WARNING: If you do not follow these instructions spark igniter system. When lighting the pilot, follow exactly, a fire or explosion may result causing these instructions exactly.
-
Page 17: Operation
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING A. This appliance has a pilot which is lighted by a WARNING: If you do not follow these spark instructions exactly, a fire or explosion may igniter system. When lighting the pilot, follow these result causing property damage, personal instructions exactly. -
Page 18: To Turn Off Gas To Appliance
OPERATION TO TURN OFF GAS TO APPLIANCE TEMPORARY SHUTDOWN PROCEDURE: To turn off main burner only, depress the knob and turn it clockwise as far as it will go. Do not force. COMPLETE SHUT-DOWN PROCEDURE: Turn off all electrical power in firebox. Turn gas control knob clockwise to the “OFF”... - Page 19 PARTS AND ASSEMBLY IDENTIFICATION – MANUAL AND VARIABLE VALVE WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this heater may result in property damage or personal injury. Manual Vent Free Burner Assembly Variable Vent Free Burner Assembly ITEM DESCRIPTION...
- Page 20 PARTS AND ASSEMBLY IDENTIFICATION – MILLIVOLT VALVE WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this heater may result in property damage or personal injury. Millivolt Vent Free Burner Assembly ITEM DESCRIPTION ET(HC,CC)18(N,P)2C...
-
Page 21: Troubleshooting
TROUBLE-SHOOTING Hargrove Manufacturing test fires all Vent Free burner systems before shipment. Each test consists of lighting the pilot, checking for proper ignition, and leak testing at each connection. Even though all of these precautions are taken sometimes problems do arise. The following Trouble-Shooting chart lists several problems with their probable cause and remedy. - Page 22 TROUBLE-SHOOTING OBSERVE PROBLEM POSSIBLE CAUSE REMEDY 1. Turn on gas supply or open D. When ignitor button is 1. Gas supply turned off or manual manual shutoff valve. pressed there is spark at ODS shutoff valve closed. 2. Turn control knob to PILOT pilot, but not ignition.
-
Page 23: Limited Warranty
8. Purchaser or user agrees to hold Hargrove Mfg Corp. harmless from any and all claims by the buyer as a result of injury or damage to an ultimate user or other person caused by the product sold herein by the seller to the buyer, whether the injury or damage results from the assembly, installation, operation, shipment, storage, or manufacture of this product. - Page 24 527 CMR 30.00 UNVENTED PROPANE OR NATURAL GAS-FIRED SPACE HEATERS Section 30.01: Purpose 30.02: Scope 30.03: Definitions 30.04: Installation 30.04: Maintenance and Operation 30.01: Purpose The purpose of 527 CMR 30.00 is to provide requirements for the installation, maintenance, and operation of unvented propane or natural gas-fired space heaters.
- Page 25 space heaters. Said permits shall be conditioned upon final inspection and approval of installation by the head of the fire department and the local or state gas inspector having jurisdiction. A copy of the manufacturer’s installation/operating literature shall be submitted with each permit application.
