Package Contents
1. Blade Set of 5
RPL-F2304-62-BD-**
2. Hanger Assembly
Mounting Bracket
Downrod Assembly:
6-inch Hanger Assembly
RPL-HGR-ASM-6-**
3. Canopy w/Canopy Ring
RP L-CAN-RND-**
4. Coupling Cover
RPL-F2304COUCVR-**
5. Motor Assembly
6. Blade Holder Set (Upper and Lower)
RPL-F2304BLDHDER**
Hardware Bag
RPL-F2304-PARTS
Before discarding packaging materials be certain all parts have been removed.
Place the parts from the hardware bag into a small container to keep them from being lost.
8 Lucid Instructions
#10 x 38mm Pan Head Phillip Screws (2)
5 x 14 x 1mm Flat Washer (2)
3/16" Star Washer (2)
Attach the ABS blade to upper
blade holder 3/16" x 9mm
Attach the upper blade holder to
lower blade holder 3/16"x 8mm
*Each hardware bag comes with 1 spare screw
7. Adapter Plate
RPL-F2304-ADP-**
8. LED Module
F4IN-120V-R1-30
9. Control Receiver
w/Hardware
F-R3-2304-062
10. PC Shade
RPL-F2304-GLA
11. Remote Control
F-RCBT-WT
** denotes finish code of fan
D: Attach the upper + lower blade holder
to motor housing 3/16"x16mm
E: Safety Cable
6.5x19x2mm Flat Washer (1)
3/16"( 5.2x8.4x1.0mm) Spring Washer (1)
#10x76mm
(16)
F: Wire Connectors
(included with receiver)
(16)
G: LED Screws
5/32" x 1/4" Philip head screws (4)
Pan Head Phillip Wood Screws (1)
(8)
(3)
FR-W2304-62L
(16)
