INMARSAT FleetBroadband FB250
INMARSAT FleetBroadband FB250
Maritime Satellite Communication Terminal
Maritime Satellite Communication Terminal
JUE-250
JUE-250
OPERATION
OPERATION
MANUAL
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INMARSAT FleetBroadband FB250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JRC INMARSAT FleetBroadband FB250

Summary of Contents for JRC INMARSAT FleetBroadband FB250

  • Page 1 JUE-250 JUE-250 INMARSAT FleetBroadband FB250 INMARSAT FleetBroadband FB250 Maritime Satellite Communication Terminal Maritime Satellite Communication Terminal OPERATION OPERATION MANUAL MANUAL...
  • Page 3 ABOUT YOUR SAFETY CAUTIONS AGAINST HIGH VOLTAGE Radio and radar devices are operated by high voltages of anywhere from a few hundred volts up to many hundreds of thousands of volts. Although there is no danger with normal use, it is very dangerous if contact is made with the internal parts of these devices.
  • Page 4 FIRST AID ☆Note points for first aid Unless there is impending danger leave the victim where he or she is, then begin artificial respiration. Once you begin artificial respiration, you must continue without losing rhythm. Make contacts with the victim cautiously, there is a risk that you may get electrocuted. Switch off the machinery and then move the victim away slowly if you must.
  • Page 5 ☆If the victim has a pulse but is not breathing (1)Place the victim’s head facing backward (place something under the neck like a pillow). (2)Point the chin upward to widen the trachea. (3)Pinch the victim’s nose, take a deep breath, then put your mouth over the victim’s mouth and exhale completely, making sure that your mouth completely covers the victim’s mouth.
  • Page 6 ☆If the victim has no pulse and is not breathing If the victim has no pulse, his or her pupils are dilated, and if you cannot detect a heartbeat, the heart may have stopped; beginning artificial respiration is critical. (1) Put both hands on the diaphragm, with hands on top it and keeping both arms straight each other (If your elbows are bent;...
  • Page 7 PREFACE Thank you for purchasing the JRC Inmarsat FleetBroadband Mobile Earth Station, the JUE-250. The JUE-250 is an Inmarsat digital satellite communication terminal for Voice (4kbps Speech), Audio (64kbps 3.1kHz Audio), maximum 284kbps Standard IP service, 8kbps, 16kbps, 32kbps, 64kbps, or 128kbps Streaming IP service, and Short Messaging Service (SMS).

  • Page 8: Before Operation

    BEFORE OPERATION (1) About this operation manual Before operating this equipment, read the manual carefully to ensure correct operation. This book is useful for troubleshooting, too. (2) Concerning the symbols This manual uses the following symbols to explain the correct operation and to help prevent injury or damage to property.
  • Page 9 About Warning Label Below mentioned warning labels are put on the JUE-250, ADE and BDE. Do not take off, destroy, or modify these labels. <Warning Label of ADE > <Warning Label of BDE > Note 1) Note 2) Notes 1) IMEI 35887701 International Mobile Equipment Identity (IMEI) is an unique number used to identify an individual mobile equipment to a GSM or UMTS network.

  • Page 10: Before Using

    BEFORE USING • JRC is indemnified for any damages from incorrect operation, malfunction, and other troubles except as outlined in the product warranty and by limitation of law. • Some functions depend on the hardware and software version of your terminal equipment connected with your JUE-250.

  • Page 11: During Operation

    DURING OPERATION DANGER Do not touch any internal parts with your hands or tools. It may cause fire, electrical shock or malfunction. DURING OPERATION WARNING Please do not bring the power supply code close to the heat apparatus. The coating of the code may relieved, and it causes a fire and the electric shock.
  • Page 12 WARNING Do not troubleshoot or repair the internal equipment of the JUE-250 by yourself. Any electrical work by any person other than our trained maintenance staff may cause fire or abnormal operation of this equipment or electrical shock for you. This equipment meets the technical standard of the Ministry of Internal affairs and Communications.
  • Page 13 1. The Inmarsat Communication Systems 2. Introduction of the JUE-250 3. Appearance 4. Getting Started 5. How to use the Telephone / FAX 6. PC connection and LaunchPad calling 7. Using Audio port 8. Handset Menu System 9. Maintenance 10. After-sales service 11.

  • Page 15: Table Of Contents

    Inmarsat FleetBroadband JUE-250 Operation Manual Contents PREFACE ......................i BEFORE OPERATION ..................ii BEFORE USING ....................iv DURING OPERATION..................v 1. The Inmarsat Service systems..............1 1.1 Outline....................... 1 1.1.1 Coverage area..................1 1.1.2 The Inmarsat FleetBroadband service ........... 2 1.2 The Inmarsat Fleet Broadband FB250 services explanations....
  • Page 16 4. Getting started................... 27 4.1 Connecting terminals and power on ............28 4.1.1 Connecting terminals with cables ............28 4.1.2 Setting/removing SIM card..............30 4.1.3 Power ON..................... 31 4.1.4 Screen display of Handset..............33 4.2 Initial setting for communication ............35 4.2.1 Mode setting of GUEST and ADMIN ..........
  • Page 17 8.1. Status menu .................... 81 8.1.1 RX (Reception) menu ................82 8.1.2 TX (Transmission) menu ..............82 8.1.3 Position status display................83 8.1.4 Product menu ..................84 8.1.5 Unit Info menu..................85 8.1.6 ID menu ....................88 8.2 SMS menu....................89 8.2.1 New MSG menu 8.2.2 Inbox menu ..................
  • Page 18 E TCP Accelerator Installation Procedure ..........168 F Default value list..................175 G Trouble shooting and FAQ(TBD) ............176 H Cause Code ..................... 185 I Glossary ....................188 JRC Network....................193 Declaration on toxic & Hazardous substances or elements of Electronic Information Products ..................194...

  • Page 19: The Inmarsat Service Systems

    1. Inmarsat Service systems 1. Inmarsat Service systems 1.1 Outline 1.1.1 Coverage area The Inmarsat Satellites cover the earth’s surface except at the high latitude areas near the North Pole and the South Pole. Inmarsat terminals are available for any type of vehicle or ship, and are capable of communicating day and night.

  • Page 20: The Inmarsat Fleetbroadband Service

    1. Inmarsat Service systems 1.1.2 The Inmarsat FleetBroadband Service The Inmarsat network system consists of NCS, NOC, SCC, TT&C, and SAS. Functions of each facility are as follows: 1) Network Coordination Station (NCS) The NCS is designed for each Inmarsat service (i.e. Inmarsat-A, B, C) in each ocean region, which manages and coordinates the traffic in the region.
  • Page 21 1. Inmarsat Service systems 5) Satellite Access Station (SAS) The SASs located in Fucino (Italy) and Burum (Holland), which are the gateway systems operating inter-working with public network (including telephone and Internet). Inmarsat Satellite Mobile Earth 1) Network Coordination Station (NCS) Station (MES) 5) Satellite Access Station (SAS) headquarter...

  • Page 22: The Inmarsat Fleetbroadband Fb250 Services Explanations

    1. Inmarsat Service systems 1.2 The Inmarsat FleetBroadband FB250 services explanations Inmarsat FleetBroadband FB250 provides service shown below. Packet Switched service (PS), Circuit Switched service (CS), and Short Messaging Service (SMS) can be used simultaneously. Packet switched service (PS) •...

  • Page 23: Introduction Of The Jue-250

    2. Introduction of the JUE-250 2.1 Outline The JRC JUE-250 is a FleetBroadband FB250 digital satellite communication system that meets the latest Inmarsat FleetBroadband FB250 SDM. JUE-250 is designed for easy operation and installation due to the lightweight Above Deck Equipment (ADE) and compact Below Deck Equipment (BDE), equipped with simple to operate telephone, FAX, IP services.

  • Page 24: Cable Connection System Diagram And Components List

    2. Introduction of JUE-250 2.3 Cable connection system diagram and components List 2.3.1 Cable connection system diagram Fig. 2.3.1 Cable connection system diagram...

  • Page 25: Components List

    2. Introduction of JUE-250 2.3.2 Components list Table 2.3.2 JUE-250 Components list Name of equipment Type Q’ty JUE-250 GSC-451 (Standard GSC-452 Components) Handset NQW-267 Coaxial cable CFQ-5924A3(30m)* Power cable (PSU to BDE) 7ZCSC0222B JUE-250 Operation Manual 7ZPSC0256 JUE-250 Installation Manual 7ZPSC0258 JUE-250 Quick Operation Guide 7ZPSC0260...

  • Page 26: Dimensional Drawing (Jue-250 Standard Components)

    2. Introduction of JUE-250 2.4 Dimensional drawing (JUE-250 standard components) 2.4.1 ADE (Above Deck Equipment) [GSC-451] Unit: mm Mass. approx. 7.4kg Fig. 2.4.1...

  • Page 27: Bde (Below Deck Equipment)[Gsc-452]

    2. Introduction of JUE-250 2.4.2 BDE (Below Deck Equipment) [GSC-452] Unit: mm Mass. approx. 2.2kg Fig. 2.4.2...

  • Page 28: Handset [Nqw-267]

    2. Introduction of JUE-250 2.4.3 Handset [NQW-267] 4-Mounting holes Unit: mm Mass. approx. 0.5kg Fig. 2.4.3 Handset...

  • Page 29: Coaxial Cable [Cfq-5924A3]

    2. Introduction of JUE-250 2.4.4 Coaxial cable [CFQ-5924A3] Max.22mm Max.8mm *CFQ5924A15 and CFQ-3923A5 are available as optional components. Unit : mm Type Length Mass Minimum bending radius CFQ-5924A3 Under2.5kg 46mm 30m(±1.0m) (CFQ5924A15) (Under 1.4kg) (46mm) (15 m (±0.5m)) (CFQ-3923A5) (Under30.0kg) (150mm) (50 m (±1.5m)) Fig.
  • Page 30 2. Introduction of JUE-250...

  • Page 31: Appearance

    3. Appearance 3. Appearance In this section, the composition of the JUE-250 and terminal equipments are explained. Above Deck Equipment (ADE): Antenna unit and radome (Antenna Cover) Blow Deck Equipment (BDE): Main unit Coaxial cable: A Cable connects ADE to BDE Handset: Handset and cradle Terminal equipments: Accessories used for communication (user supplied PC, FAX, and telephone)

  • Page 32: Bde

    3. Appearance 3.2 BDE Main unit Main unit appearance Front view Rear view Fig. 3.2a Main unit appearance 1 Power Switch 3 SIM Card slot 2 LEDs Fig 3.2b Main unit front view Front view...
  • Page 33 3. Appearance Rear view 7. FUSE 6. Antenna cable 8. DC Power connector connector 5. WRF connector 4. Earth 13. TEL1/2 port 9.Audio Port 11. USB port 10. Ethernet port 12. Handset port Fig. 3.2c Main unit rear view 1 Power Switch Turns power on and off.
  • Page 34 3. Appearance 3 SIM card slot Mounts a SIM card. 4 Earth 5 WRF connector Connects with Wide-band Radio Frequency (WRF) communication equipment such as Chartco etc. 6 Antenna cable connector Connects with the coaxial cable from the antenna (ADE). 7 Fuse Melt down when over current are detected.

  • Page 35: Ade-Bde Connecting Cable

    3. Appearance 3.3 ADE - BDE connecting cable ＊This cable can be connected to ADE and BDE in either direction. 30m(standard) Fig. 3.3 ADE-BDE connecting cable...

  • Page 36: Handset

    3. Appearance 3.4 Handset The Handset consists of main body and cradle (Handset rest) The Handset is fixed on the cradle by a strong magnet. CAUTION Do not mount the Handset near CRT device or other devices; otherwise performance of the devices may be affected by the Handset’s magnetic field.

  • Page 37: Lcd/Led Section

    3. Appearance 3.4.1 LCD/LED section Functions of the LCD screens of the Handset. Common items for all screens are: 1 [Operational button] Displays operatable keys: 2 [Enter mode] Displays which key enter mode is accepted, Aa (alphabet mode), or nothing (numeric mode) is displayed.
  • Page 38 3. Appearance Table 3.4.1 Explanation of items displayed on screens Displayed items Contents 1 Operational button Displays when the scrolling-up/down or switching-left/right is available. Scroll the screen when up/down is displayed, with buttons. Switch the screen when left/right is displayed, with buttons.
  • Page 39 3. Appearance 5 Connecting IP 1)Displays an icon which shows connecting IP service . service Icon style IP service type Standard IP service only. Streaming IP service only. Both of above IP services. 6 Selected Displays selected satellite /communicating terminals. Satellite or •...
  • Page 40 3. Appearance 8 Status of equipment Displays the status of equipment. Normally, this area displays below contents under waiting communication or under transmitting. Status Displayed txt. Contents judgment Displayed only in Secret operation Handset code using status Normal LOCK protected with Terminal Lock Normal nnn/NNN Displays the used amount (nnn) and...
  • Page 41 3. Appearance Lighting of LEDs Ready lamp displays available services ALARM lamp indicates failure alert Green light: Red light: Failure has occurred in the system. (No light: The status is normal) Communication services are available. Blinking Green: ・ When no service is available ・...

  • Page 42: Functional Section

    3. Appearance 3.4.2 Function button section This section describes function buttons except those for entering characters. Buttons and its function Switching button Switches enter mode, between alphabets and numbers. SMS button Reads, creates, sends, and deletes Short Message Service（SMS). STATUS button Makes direct access to STATUS menu. STATUS OK button Registers entered contents.

  • Page 43: Communication Terminals

    3. Appearance 3.5 Communication terminals 3.5.1 Terminal requirements ＊Series connection (of terminal telephone and FAX) is not available on one port. Audio Port Port Ethernet Handset TEL2 /TEL1 Port Port RJ-11 RJ-11 RJ-45 Series B (Male) RJ-45 ISDN cable cable cable USB cable Ethernet...

  • Page 44: Usage Environment

    3. Appearance 3.5.2 Usage environment Table 3.5.2 Usage environment Item Contents Microsoft Windows XP Windows Vista Interface Ethernet, USB ISDN Terminal Switch type Euro ISDN Equipment Coding type of voice A-law Interface 3.6 Handset menu On the JUE-250, various menu screens can be displayed and set, from Handset. GUEST User cannot utilize the menus of ADMIN User GUEST User: General user...

  • Page 45: Getting Started

    4. Getting started 4. Getting started In section 4.1, connecting the Handset and terminal devices to Main unit, and setting SIM card are described. NOTE JUE-250 has two types of satellite tracking mode, Signal tracking mode and Gyro tracking mode. Press MENU+3 button (Satellite menu) on the Handset.

  • Page 46: Connecting Terminals And Power On

    4. Getting started 4.1 Connecting terminals and power on 4.1.1 Connecting terminals with cables GYRO I/F PC connected PC(s) connected to USB port with Ethernet port (Connection is depending on the Terminal Adaptor) Fig.4.1.1 The Cable connection of each terminal Note Use straight Ethernet cable when you connect Ethernet port with your PC, unlike JUE-33/410F uses cross Ethernet cable.
  • Page 47 4. Getting started Connecting PC to USB port Connect PC to USB port with USB cable. Connecting PC to Ethernet port Connect PC to Ethernet port with Ethernet cable. When you connect two or more LAN PCs via HUB, use straight LAN cable and connect each device.

  • Page 48: Setting/Removing Sim Card

    4. Getting started 4.1.2 Setting/removing SIM card Before turning on the power, setting SIM card is required in every time. Note ・ JUE-250 will not work without a valid SIM card, which is furnished from the Distribution Partner. ・ Make sure that power switch is correctly turned off, before you set/remove the SIM card to/from main unit.

  • Page 49: Power On

    4. Getting started 4.1.3 Power ON Before turning on the power, check the following; • Check the obstacles between antenna and satellite. • Check that SIM card is correctly set. • Check that the breaker of inboard power supply is turned on. •...
  • Page 50 4. Getting started Note When the REC level is low, the communication may fail due to the circuit design, by decreasing rate of successful call, even if “CS PS READY” is displayed on LCD screen. Initialization of the unit may take more than 5 minutes to complete. During this time, "CS PS READY"...

  • Page 51: Screen Display Of Handset

    4. Getting started 4.1.4 Screen display of Handset Turn on JUE-250 by pushing power switch of Main unit. Initializing A LED of Main unit starts blinking. About 10 seconds later, initializing is started Initialize and blinking [Initialize] text is displayed. Satellite searching [SAT SEARCH] text is displayed in the lowest, [Status] line.
  • Page 52 4. Getting started ( Screen transition when power switch is turned off) Turn off the power switch. Power-off screen Quitting operation is on the way in the JUE-250. Characters on the screen Power OFF blink. Blinking Screen and all LEDs are turned off. Operation is completed.

  • Page 53: Initial Setting For Communication

    4. Getting started 4.2 Initial setting for communication Setting flow Mode setting of GUEST and ADMIN (Chapter 4.2.1, p36) Handset TEL/FAX USB port connection Ethernet port Audio port Go to Chapter7 (p75) Using Audio port Go to Chapter5 (p39) Go to Chapter6 (p59) How to use the telephone/FAX PC connection and LaunchPad calling Fig.

  • Page 54: Mode Setting Of Guest And Admin

    4. Getting started 4.2.1 Mode setting of GUEST and ADMIN GUEST user can perform the daily operation of the JUE-250. ADMIN user can access additional functions like setup of the JUE-250 and information control as a system manager. When power switch is pressed only, the user logs in as a GUEST user. To operate the ADMIN user-limited menu described [5.1.5] or after [8.9] of this Manual, Log-in with secret code of ADMIN user is required.

  • Page 55: Setting Service Type (Admin User Only)

    4. Getting started 4.2.2 Setting service type (ADMIN user only) In this section, setting the Service types for [TEL1] and [TEL2] ports are explained. Select the Service type of the port with following the terminal device (telephone or FAX) being connected to each port.

  • Page 56: Satellite Display

    4. Getting started 4.2.3 Satellite search selection In this section, setting of Satellite search type is explained. Select [3 Satellite] from [Top menu], and select [1 Satellite] from displayed [Satellite] menu screen. Current setting is displayed with mark on its line head. To change it, move the cursor by buttons, and press button.

  • Page 57: How To Use The Telephone/Fax

    5. How to use the telephone/FAX 5. How to use the telephone / FAX In chapter 5.1(p42), the telephone functions with Handset listed below are explained. (The capped number of each function is the chapter No.) 5.1.7 Forwarding a call from Handset to 5.1.1 Making a call/ Answering the phone terminal telephone...
  • Page 58 5. How to use the telephone/FAX Dial-up procedure for forced setting of service type Just adding on the head of dialing sequence, user can easily set the service type (Voice or FAX) to TEL1/2 port, regardless of setup done at [8.9.2.1 Port Cont setting item selection menu (p113)].
  • Page 59 5. How to use the telephone/FAX Before using Handset You can operate the JUE-250 with the Handset both on-hooked and off-hooked to the cradle. 1. Off-hook the Handset from the cradle(Off-hook mode) To display and/or set the status of JUE-250 Press a direct button (refer to [8 Handset, Top menu](p79).

  • Page 60: Handset

    5. How to use the telephone/FAX 5.1 Handset 5.1.1 Making a call / Answering the phone Making a call Hook off the Handset and press the number followed by button. When the party answers the call, [Communication screen] is displayed . Converse with the party. Return Handset to the cradle when the telephone call ends.

  • Page 61: Using Phone Book (Speed Dial)

    5. How to use the telephone/FAX 5.1.2 Using Phone Book (Speed dial) Register the phone numbers before the Phone Book (Speed dial) is used. Refer to [5.1.9 Entry, change and deletion of Phone Book](p52). To make a call with Speed dial from Handset Press button in Idle screen.

  • Page 62: Using Redial Menu

    5. How to use the telephone/FAX 5.1.3 Using Redial menu Redial menu displays the dial number of the last 30 calls. Example) To display 0081-422-45-9111 with the Redial list, scroll through the screen with buttons, and place a call to the number using the Redial function. Press buttons with the display on [Idle screen], the screen will change to [Redial List screen].

  • Page 63: Adjusting Voice Volume, Screen Brightness, And Ringer Volume

    5. How to use the telephone/FAX 5.1.4 Adjusting voice volume, backlight brightness, and ringer volume Quick adjustment of voice volume ( Handset status: Off- hook mode) To adjust the voice volume, press buttons on the left side of the Handset, during the communication.

  • Page 64: Adjusting Ringer Volume And Pattern, And Voice Volume

    5. How to use the telephone/FAX 5.1.5 Adjusting ringer volume /pattern/voice volume/backlight brightness (ADMIN user only) Adjusting the ringer volume Ringer volume can be adjusted from the menu of the Handset. Refer to below flow chart, open the menu screens and begin setup. APAC E143.5 Idle screen 14:03 UTC...
  • Page 65 5. How to use the telephone/FAX Adjusting the voice volume and the backlight brightness by the buttons of Handset Voice volume can be adjusted using the buttons on the left side of Handset (refer to [5.1.4 Adjusting voice volume and the backlight brightness](p45). To change the default voice volume, follow the way shown below.

  • Page 66: Holding On The Line

    5. How to use the telephone/FAX 5.1.6 Holding on the line To place a call on hold, press the Off-hook button ( ) of the Handset. To restart conversation, press it again. * The line is not disconnected even though the Handset is returned to the cradle when the OFF HOOK button is pressed during a conversation.

  • Page 67: Forwarding A Call From Handset To Terminal Telephone

    5. How to use the telephone/FAX 5.1.7 Forwarding a call to other terminal To pass a call to one of the terminal telephones (connected to BDE), press the extension number during communication. Extension numbers of the JUE-500 are designated as follows. Terminal telephone connected with TEL port 1…..* * Terminal telephone connected with TEL port...

  • Page 68: Using A Secret Code

    5. How to use the telephone/FAX 5.1.8 Using a Secret Code Turn on the Secret Code To use the Secret Code, port setting is required. Note Once the Secret Code is set on a telephone terminal, call without entering Secret Code is impossible. (Only receiving a call is possible).
  • Page 69 5. How to use the telephone/FAX Secret Code calling *If you have not set up the Secret Code, open previous page and set it up. Idle screen (terminal locked) APAC E143.5 Press any button. [LOCK] is appeared the place where usually [CS PS 14:03 UTC READY] is displaying.

  • Page 70: Entry, Change And Deletion Of Phone Book

    5. How to use the telephone/FAX 5.1.9 Entry, change and deletion of Phone Book ■ Telephone number entry Calling procedure with Speed Dial number is explained at [5.1.2 Using Phone Book (Speed Dial)](p43). Maximum 99 Speed Dial numbers can be registered. The procedures of registration and setting are explained below.
  • Page 71 5. How to use the telephone/FAX ■Changing party name and telephone number Example) Speed Dial number: 15, person’s name: TOMMY, phone number: 0123456789. Change the phone number to 09870987654321098765. Idle screen Press button to open [Phone Book list display screen]. APAC E143.5 14:03 UTC The procedure between this screen and [Phone Book operation...
  • Page 72 5. How to use the telephone/FAX ■Deleting data Example) Deleting Speed Dial No.08, company’s name “RRC”. Idle screen Press button and go to [Phone Book list display APAC E143.5 screen]. The procedure between this screen and [Phone 14:03 UTC Book operation selecting screen] is the same as [Telephone number entry](p52).

  • Page 73: Displaying Call Log

    5. How to use the telephone/FAX 5.1.10 Displaying Call Log Call Log (Call Logging History) stores maximum 100 records of outgoing/incoming calls, respectively. 1. VOICE Making and receiving a call from/to Handset or terminal telephone connected to TEL1/2 or ISDN port 2.
  • Page 74 5. How to use the telephone/FAX Idle screen Press MENU. APAC E143.5 14:03 UTC Top menu screen READY 5 Redial Select [6 Call Log], then press OK. 6 Call Log READY Call Log menu screen 1 VOI C E Select the communication type, and press OK. 2 FA X Select either one from 1 to 5, then the screen changes to 3 S TAN D AR D...

  • Page 75: Using Telephone/Fax With Tel1/2 Port

    5. How to use the telephone/FAX Call Log detailed information screen (VOICE/FAX service is selected) …. Day/Month/Year of the call 01/JAN/2008 … Hour/Second/Minute of the call (UTC fixed) 23:59:59 ….Party’s telephone number (maximum 21-digit) 012345678901 23456789 SAT: ….Satellite used APAC E143.5 ….Communication duration 240m59s ….Secret Code User’s Name*...
  • Page 76 5. How to use the telephone/FAX Dial-up procedure for forced setting of service type Just adding on the head of dialing sequence, user can easily set the service type (Voice or FAX) to TEL1/2 port, regardless of setup done at [8.9.2.1 Port Cont setting item selection menu (p113)].

  • Page 77: Pc Connection And Launchpad Calling

    6 PC connection and Launchpad calling 6. PC connection and LaunchPad calling This section explains the connection for USB and Ethernet port to PCs, and procedures for making a call using LaunchPad. Install the LaunchPad into your PC from attached CD-ROM, before you use LaunchPad at [6.3 Making a call using LaunchPad].

  • Page 78: Usb Port Pc Connection

    6 PC connection and Launchpad calling 6.1 USB port PC connection To connect PC with JUE-250 USB port, below works are required. Driver installation (attached CD-ROM is used) Connecting the USB ports (main unit port to PC port) Note ・ The USB connection is displayed as a network (LAN) connection on your PC. The IP address range is the same as described in [6.2 Ethernet port PC connection, IP addressing on the JUE-250](p67)
  • Page 79 6 PC connection and Launchpad calling 5. [Choose Install Location] window is displayed. Click [Next]. Click Fig.6.1.1c [Choose Install Location] window 6. [Choose Components] window is displayed. Click [Install]. Click Fig.6.1.1d [Choose Components] window [Installing] window is displayed and installation is started. Wait until the end of installation is shown.
  • Page 80 6 PC connection and Launchpad calling 8. [Welcome to the Device Driver Installation Wizard!] window is displayed. Click [Next]. Click Fig.6.1.1f [Welcome to the Device Driver Installation Wizard!] window 9. [Software Installation] window is displayed. Click [Continue Anyway]. Click Fig.6.1.1g [Software Installation] window 10.
  • Page 81 6 PC connection and Launchpad calling 11. [Installation Complete] window is displayed. Click [Next]. Click Fig.6.1.1i [Installation Complete] window 12. [Completing the Japan Radio Company USBLAN Driver (v3)-(Licensed) Setup ] window is displayed. Click [Finish]. Click Fig.6.1.1j [Completing the Japan Radio Company USBLAN Driver (v3) -(Licensed) Setup] window...

  • Page 82: Connecting Usb Ports

    6 PC connection and Launchpad calling 6.1.2 Connecting USB ports Note Make sure that the main unit is idle status. 1. Connect the USB ports of the main unit and of the PC, with USB cable. 2. [Welcome to the Found New Hardware Wizard] window is displayed.
  • Page 83 6 PC connection and Launchpad calling 4. [The software you are installing for this hardware:...] window is displayed. Click [Continue Anyway]. Click Fig.6.1.2c [The software you are installing for this hardware:...] window 5. [Completing the Found New Hardware Wizard] window is displayed. Click [Finish].

  • Page 84: Ethernet Port Pc Connection

    6 PC connection and Launchpad calling 6.2 Ethernet port PC connection The JUE-250 provides the DHCP server function, which allocates necessary IP address to the PC which is connected to Ethernet, to make Ethernet communication with Main Unit possible. User is requested to setup [Obtain an IP automatically] and [Obtain DNS server address automatically] on the PC, to make use of the function.
  • Page 85 6 PC connection and Launchpad calling 4. Make sure both of [Obtain an IP address automatically] and [Obtain DNS server address automatically] are checked, then click [OK]. Reboot your PC. Make sure these checkmarks Click Fig. 6.2b Internet Protocol (TCP/IP) Properties window IP addressing on the JUE-250 ・...

  • Page 86: Connecting To Internet Using Launchpad

    6 PC connection and Launchpad calling 6.3 Connecting to Internet using LaunchPad By using LaunchPad, communications with services of Standard IP, Streaming IP, or SMS can be used very easily and quickly. Installation of LaunchPad is preliminarily required for this chapter, set the attached CD into your PC and install it.
  • Page 87 6 PC connection and Launchpad calling [Connecting] screen is displayed during Standard IP Data connection is requesting. Fig.6.3.1c [Connecting] window 3. If connection is succeeded, [Connect] icon is changed to [Disconnect], [Connect Standard] icon is changed to [Disconnect Standard], and text of [Status] column is changed to [Standard Data connection open...].
  • Page 88 6 PC connection and Launchpad calling [Disconnection] Click [Disconnect] icon. Click Fig.6.3.1e [Connection control] window (to disconnect the service)

  • Page 89: Streaming Ip

    6 PC connection and Launchpad calling 6.3.2 Streaming IP （Below procedure is for 32kbps Streaming IP service. For 8kbps, 16kbps, 64kbps or 128kbps, difference is only using icons）. [Connection] 1. Open LaunchPad by double-clicking on the LaunchPad icon on your desktop, and then click [+], which is located on the [Connect] button.
  • Page 90 6 PC connection and Launchpad calling 3. Confirmation window is displayed, then click [Yes]. Click Fig.6.3.2c Confirmation window [Connecting] screen is displayed during Streaming IP Data connection is requesting. Fig.6.3.2d [Connecting] window 4. If connection is succeeded, [Connect] icon is changed to [Disconnect], [Connect 32 Streaming] icon is changed to [Disconnect 32 Streaming], and text of [Status] column is changed to [Streaming Data connection open...].
  • Page 91 6 PC connection and Launchpad calling [Connection] Streaming Data connection is opened. Use your desirable tool. [Disconnection] Click [Disconnect] icon. Click Fig.6.3.2f [Connection control] window (for disconnection)

  • Page 92: Sms

    6 PC connection and Launchpad calling 6.3.3 SMS Sending SMS procedures are mentioned below. [Sending] 1. Open LaunchPad by double clicking on the LaunchPad-short cut icon on your desktop, and click [Text] button. Click Fig.6.3.3a Main window of LaunchPad 2. Position the cursor to the large column of [Compose new message] field, and create the message.

  • Page 93: Using Audio Port

    7. Using Audio port 7. Using Audio port In this section, a continued setting for using telephone on Audio port is explained. Continued from [4.2 Initial setting for communication] Edit CS READY 765 9 8 7 6 5 4 3 2 1 0 9 8 CS PS READY Fig.
  • Page 94 7. Using Audio port When a TA originates a call, JUE-250 originates a call in according to a “transfer capability” informed from TA. When the “transfer capability” from TA is “Speech”, JUE-250 originates “Inmarsat 4kbps Voice” call. When a call arrives to JUE-250, JUE-250 informs a Multiple Subscriber Number (MSN) programmed by user to TA.
  • Page 95 7. Using Audio port Setting MSN using Handset [MSN edit menu] Idle screen Press MENU button. APAC E143.5 14:03 UTC Top menu screen READY Select [9 ADMIN] and press button. 8 Alarm Pack 9 ADMIN ADMIN menu screen READY Select [3 Port] and press button.
  • Page 96 7. Using Audio port Dial-up procedure from Audio port 00 Country Code Area Code Subscriber’s number Example) Placing a call to +81-422-45-9111, in Japan→0081422459111 NOTE The telephone connected to Audio port cannot forwarding a call to TEL1 port, TEL2 port, or Handset port.

  • Page 97: Handset Menu System

    8. Handset Menu system 8. Handset Menu system All screens of Handset of the JUE-250 and their functions are as follows. Table. 8. Contents of Handset menu Chapter No/Name of screen Contents -TOP menu Displays the list of items of this group. 8.1 Status menu Displays the list of the items of equipment status.

  • Page 98: Top Menu

    8. Handset Menu system TOP menu To open TOP menu, just push MENU button TOP menu screen 8.1…… 1 Status … List of JUE-250 status 8.2…… 2 SMS … 8.3…… 3 Satellite ….List of Satellite 8.4…… 4 Phone Book ….Phone Book 8.5……...

  • Page 99: Status Menu

    8. Handset Menu system In this section, menus for all users are described. 8.1 Status menu (Short cut is MENU+ 1 ) In this menu, user can display the status of the JUE-250, receiving/transmitting status, latitude/longitude of the ship and the version of each device. The figure shown below is the whole flow chart of this menu.

  • Page 100: Rx(Reception) Menu

    8. Handset Menu system 8.1.1 RX(Reception) menu ( MENU+ 1 +1 +1 to 3 ) In this menu, user can display the Reception level (REC), and Channel type (CH TYPE). REC level display screen RECeiving level is displayed in number value. REC: 1 Sta t u s Communication is not available...

  • Page 101: Position Status Display

    8. Handset Menu system 8.1.3 Position status display ( MENU+ 1 +3 ) In this menu, user can display the latitude and longitude of ship’s position. N stands for North latitude, S for South latitude, E for East longitude, and W for West longitude. N and S are displayed in upper line, and E and W in the lower.

  • Page 102: Product Menu

    8. Handset Menu system 8.1.4 Product menu MENU+ 1 +4 +1 to 3 ) In this menu, user can display the IMEI (International Mobile Equipment Identity), JRC No, (manufacturer’s serial No.), and Delivery date of the JUE-250. IMEI display screen...

  • Page 103: Unit Info Menu

    8. Handset Menu system 8.1.5 Unit Info menu ( MENU+ 1 +5+ 1 to 4 ) In this menu, user can display the software version, maintenance No. and status of ADE/BDE. Refer to Appendix [A.4 Unit Info menu] (p138) when GYRO is used. 1.
  • Page 104 8. Handset Menu system 3.ADE status display screen 1 Sta t u s 2 S M S EIRP: 5 U n i t I n f o ….Transmitting output (dBw) 14.0 6 I D …. ADE temperature (degree) ADE : 15 1 Ve r s i o n ….HPA temperature (degree) HPA : 18...
  • Page 105 ….Received channel type T025Q Cable loss: ….Offset value of cable calibration Unit Info menu screen 10.0 ….IMEI (International Mobile Equipment IMEI:123456- Identity number) 78-901234-5 JRC No: …..Manufacturer’s serial number GV12345 Delivery: ….Delivery date 01/JAN/2008 UE Class: ..User Equipment class IMSI: IMSI: ….IMSI (International Mobile Subscriber...

  • Page 106: Id Menu

    8. Handset Menu system 8.1.6 ID menu ( MENU+ 1 +6+ 1 to 2) In this menu, user can display the ID of IMSI/MSISDN. 1 Sta t u s 2 S M S 5 U n i t I n f o 6 I D IMSI/MSISDN menu screen IMSI display screen (left)

  • Page 107: Sms Menu

    8. Handset Menu system 8.2 SMS menu MENU+ 2 ) In this menu, user can read, create, send, and delete SMS. Note Delete unnecessary message constantly because receiving SMS new message and sending message from Handset are become impossible when the memory usage amount becomes equal to total message capacity. Capacity confirmation method: [8.2.5 setting menu] (p96) Deleting method for New (received) message: refer to [8.2.2 Inbox menu](p93) Sent message: refer to [8.2.3 Sent menu] (p94)
  • Page 108 8. Handset Menu system Capital input mode When Aa is displayed in [Input mode] area, below characters are being input. Pushed times (Key) 0 “ ‘ ¥ & － < >  Alphabet input mode When aA is displayed in [Input mode] area, below characters are being input. Pushed times (Key) 0 “...
  • Page 109 8. Handset Menu system 8.2.1 New MSG menu MENU+ 2+ 1 ) In this menu, user can create, send, and save (as unsent) new messages. Unsent messages are saved in the [4. Draft] menu. Message is sent 1 Sta t u s 2 S M S 3 S a t e l l i t e Sending screen...
  • Page 110 8. Handset Menu system When the sending is succeeded: the sent message is saved in [Sent] of SMS menu Address edit screen When the [Message editing flow] (p91) is completed and Ad d r e s s ？ pressed, the screen transits to [Send/Save selection screen].

  • Page 111: Inbox Menu

    8. Handset Menu system 8.2.2 Inbox menu MENU+ 2 +2) In this menu, user can read, reply, forward, and delete the received messages. 1 Sta t u s 2 S M S 3 S a t e l l i t e 1 N ew M S G 2 I n b o x / 1 2 3...

  • Page 112: Sent Menu

    8. Handset Menu system 8.2.3 Sent menu MENU+ 2+ 3 ) In this menu, user can read, resend, forward, and delete the sent messages. 1 Sta t u s 2 S M S 2 I n b o x /123 3 S e n t / 1 2 3 ＯＫ...

  • Page 113: Draft Menu

    8. Handset Menu system 8.2.4 Draft menu MENU+ 2+4 ) In this menu, user can read, edit, send, and delete the unsent messages. 1 Status 2 SMS 3 S e n t / 1 2 3 4 D r a ft / 1 2 3 ＯＫ...

  • Page 114: Setting Menu

    8. Handset Menu system 8.2.5 Setting menu MENU+ 2+ 5 ) In this menu, user can read the used amount of mailboxes, delete all messages at once, and set the details of SMS service. ＯＫ 1 Sta t u s Capacity screen Displaying used amount 2 S M S...

  • Page 115: Satellite Menu

    8. Handset Menu system 8.3 Satellite menu ( MENU+ 3 ) In this menu, user can display the status of satellite including ocean region, and spot beam No. Refer to Appendix [A.5 Satellite menu], when GYRO is used. Top menu screen Satellite menu screen 1 S a t e l l i t e 1 Sta t u s...

  • Page 116: Phone Book (Speed Dial) Menu

    8. Handset Menu system 8.4 Phone Book (Speed dial) menu ( MENU+ 4 ) In this menu, the user can display and edit the Phone Book. Refer to [5.1.2 Using Phone Book (Speed dial)](p43) about dial-up procedure. Press button from [Idle screen], or select [4.Phone Book] from Top menu screen, then [Address display screen] is displayed.

  • Page 117: Editing The Phone Book Address

    8. Handset Menu system 8.4.1 Editing the Phone Book address ( MENU+ 4 + MENU ) In this menu, the user can register, change, and delete the address (name of party) and telephone number. Press MENU button with the [Address display screen] or [Telephone number display screen] opened, then [Operation selecting screen] is displayed.

  • Page 118: Redial Menu

    8. Handset Menu system 8.5 Redial menu ( MENU+ 5 ) In this menu, the user can display the Redial numbers up to 30. First, [Redial history list screen] is displayed. The screen displays Redial history number (01 to 30), and telephone number (if the number is longer than 10-digit, first several digits are not displayed).

  • Page 119: Call Log (Communication History) Menu

    8. Handset Menu system 8.6 Call Log (Communication history) menu MENU+6+1～5 In this menu, user can display the Call Log (Communication history) of respective communication type. Call Log is displayed in 5 service types, VOICE, FAX, STANDARD, STREAMING, and SMS. They are divided into three kinds of screens, BOTH (send and receive), SND (send only), and RCV (receive only).

  • Page 120: Call Log List Menu

    8. Handset Menu system 8.6.1 Call Log list menu ( MENU+6+1+1 to5) In this menu, user can display the detailed information of selected communication log. Call Log list menu screen (Day/Month/Year) 001 TEL1 0 1 / J A N / 2 0 0 5 6 C a l l L o g 7 S e l f Te s t 1 V O I C E...

  • Page 121: Call Log Authentication And Deletion

    8. Handset Menu system 8.6.2 Call Log authentication and deletion ( MENU+6+ MENU) In this menu, ADMIN user can delete the Call-Log. To delete, ADMIN user must once press through [Call-Log authentication screen] entering secret code.. 6 C a l l L o g Call Log deletion screen Call Log authentication screen 7 S e l f Te s t...

  • Page 122: Alarm Pack Menu

    8. Handset Menu system 8.8 Alarm Pack menu ( MENU+8 ) In this menu, user can display the latest 10 alarms. Select [Alarm Pack] from Top menu screen and press button, then [Alarm history view menu screen] (Displays the Day/Month/Year) is displayed. It displays from the latest one. To confirm the more detailed time, [Alarm history detailed menu] (displays recorded Hour/Minute/Second of each alarm) is displayed with the button pressed.

  • Page 123: Unit Selection Menu For Alarm Pack

    8. Handset Menu system 8.8.1 Unit selection menu for Alarm Pack ( MENU+8) 1. ADE alarm display screen EIRP: ….Transmitting output (dBw） 7 S e l f Te s t 14.0 8 Al a r m P a c k ….
  • Page 124 CH TYPE ….Received channel type T025Q Cable loss: ….Offset value of cable calibration 10.0 ….IMEI (International Mobile Equipment IMEI:123456- Identity number) 78-901234-5 JRC No: …..Manufacturer’s serial number GV12345 Delivery: ….Delivery date 01/JAN/2008 UE Class ….User Equipment Class IMSI: IMSI: ….IMSI (International Mobile Subscriber...

  • Page 125: Admin Menu

    8. Handset Menu system 8.9 ADMIN menu MENU+ 9 [ADMIN menu] which displays all menus for sets up status of the JUE-250. Select [9 ADMIN menu] from [Top menu], and display each menu screen. Identification screen is opened when user without ADMIN authority enters in this menu. Top menu screen Port Cont menu screen Setup menu screen...

  • Page 126: Setup Menu

    8. Handset Menu system 8.9.1 Setup menu ( MENU+ 9 +1 ) [Set up menu] consists of; 1 Delivery: Delivery date of the JUE-250 2 Local Time: Time difference between Local time and Universal time 3 LED: Setting of Brightness level of main unit LEDs 4 Tracking: Selecting tracking system, AUTO (signal tracking) or GYRO tracking ADMIN menu screen Top menu screen...

  • Page 127: Delivery Setting

    8. Handset Menu system 8.9.1.1 Delivery setting ( MENU+ 9 +1 +1) In this menu, the user can set up the delivery date of the JUE-250. Select [1.Delivery] from Setup menu to display setting screens in order of Day, Month, and Year. Day setting screen 8 Al a r m P a c k Day?

  • Page 128: Local Time Setting

    8. Handset Menu system 8.9.1.2 Local Time setting ( MENU+ 9 +1 +2 ) In this menu, the user can set up the time differences between UTC (Universal Time Coordinated) and Local time. To display screens, select [2. Local Time] from [1.Setup]. First, ±...

  • Page 129: Led Setting

    8. Handset Menu system 8.9.1.3 LED setting ( MENU+ 9 +1 +3) In this menu, the user can set the ON/OFF of LEDs on main unit. Select [3. LED] from [Setup menu]. Then present setting is displayed on [LED menu setting screen]. To change the setting select ON or OFF by buttons and press 8 Al a r m P a c k...

  • Page 130: Port Cont Menu

    8. Handset Menu system 8.9.2 Port Cont menu ( MENU+ 9 +2) In this menu, the user can execute the various setting to communication ports (Handset, TEL1, or TEL2) respectively. 1. Secret Code: Sets operation limit to each port 2. Volume: Sets volume of voice output to each port. 3.

  • Page 131: Port Cont Setting Item Selection Menu

    8. Handset Menu system 8.9.2.1 Port Cont setting item selection menu (MENU+9+2+1 to 3) In this menu, user can select setting items (on/off of using Secret code, voice volume, and service type). Setting item of [Secret (code)] and [Volume] are common to each port, but [Type] (service type) is only available on TEL1/2 port.

  • Page 132: Port Menu

    8. Handset Menu system 8.9.3 Port menu ( MENU+ 9 +3) In this menu, the user can set the advanced setting of Handset, ISDN port, and Ethernet port. 1. Handset (8.9.3.1) ・ Selecting brightness of Back Light ・ Selecting LED brightness ・...

  • Page 133: Handset Advanced Setting Menu

    8. Handset Menu system 8.9.3.1 Handset advanced setting menu (MENU+9+3+1+1 to 6) In this menu, the user can set the advanced settings of Handset (brightness of LCD screen backlight/LEDs, volume /pattern of ringer tone, voice volume, and key click sound). Backlight menu screen Select brightness of LCD screen Top menu screen...

  • Page 134: Isdn Msn Setting Menu

    8. Handset Menu system 8.9.3.2 ISDN MSN setting menu (MENU+9+3+2+1 to 2) In this menu, the user can set the MSN of ISDN port. Top menu screen ISDN MSN setting menu screen 8 Al a r m P a c k 9 AD M I N READY 1 Voice-MSN...

  • Page 135: Ethernet Setting Menu

    8. Handset Menu system 8.9.3.3 Ethernet setting menu (MENU+9+3+3) In this menu, the user can change the IP address and set the use/non-use of DHCP function of Ethernet port. IP address editing screen TOP menu screen Press any numeric key, then initially displayed 8 Alarm Pack 192168128100 numbers are once erased altogether.

  • Page 136: User Reg. Menu

    8. Handset Menu system 8.9.4 User Reg. menu ( MENU+ 9 +4) In this menu, the user can register User name and Secret Code. Input range of Secret Code is 0001 to 9000. Top menu screen User Reg. list display User Reg.

  • Page 137: User Reg. Operation Selecting Menu

    8. Handset Menu system 8.9.4.1 User Reg. operation selecting menu ( MENU+ 9 +4 ) To register, edit, and delete the User name or Secret Code, press MENU with [User Reg. menu list screen] or [Secret Code list display screen] displayed (enter 4-digit Secret Code). [Registering new user] Example) Registering a new user (Name: MARK, Code: 9871) on No.02.

  • Page 138: Auto Dcn. (Auto Disconnection) Menu

    8. Handset Menu system [Edit User name and/or Secret Code] Even when either the User name only or the Secret Code only is to be changed, both of the edit screens are displayed. On the edit screen where change is not necessary, just press button and go to the next screen.
  • Page 139 8. Handset Menu system [Deleting User name and Secret Code] Example) Deleteing the data of No.02 Press MENU with the User Reg. list which displays No.02. User Reg. operation selecting screen Select [Delete] by cursor and press MENU Edit 8 AL AR M P a c k 9 AD M I N Delete READY...
  • Page 140 8. Handset Menu system 8.9.5 Auto DCN.(Auto disconnection) menu ( MENU+ 9 +5) In this menu, the user can set the limit of connection time (Max Time). Select [5. Auto DCN.] menu from [ADMIN] menu. Setting Max Time (Max Connecting time) is useful to prevent the user from accidentally forgetting to disconnect the line.

  • Page 141: Max Time Menu

    8. Handset Menu system 8.9.5.1 Max Time menu ( MENU+ 9 +5 +1 +1 to 5) Setting screen of Max Time (connecting time limit) is displayed when service type is set at [Max Time menu] screen. Time unit is minute. Enter 1 to 3-digit number and then press OK. Then the screen returns to previous one.

  • Page 142: Sim Menu

    8. Handset Menu system 8.9.6 SIM Menu ( MENU+ 9 +6) In this menu, the user can set up the items of SIM card. The screen is displayed when [6 SIM Menu] is selected from ADMIN menu. TOP Menu screen ADMIN menu screen ＯＫ...

  • Page 143: Chg Pin1Menu

    8. Handset Menu system 8.9.6.1 Chg PIN1 Menu MENU+ 9 +6+1） In this menu, the user can change the Personal Identification Number (PIN), which is necessary for SIM card operation. (To operate this menu, user should set PIN Input to [Enable] in [8.9.6.2 PIN Input setting menu (p126)], preliminarily.) PIN changing procedure 1) Select [1 Chg PIN1] and press OK, then SIM PIN1 input screen is displayed.
  • Page 144 8. Handset Menu system 8.9.6.2 PIN Input setting （ MENU+ 9 +6+2） In this menu, Enable/Disable of PIN entry can be set. Setting [Enable], PIN entry is required when turning OFF/ON of the power source. Setting [Disable], PIN entry is not required when turning OFF/ON of the power source. Set [Enable] prior to changing the PIN at previous chapter, [8.9.6.1 Chg PIN1 menu] PIN Input setting procedure 1) Select [2 PIN Input] and press OK, then PIN Input setting screen is displayed.

  • Page 145: Pin Input Setting

    8. Handset Menu system Releasing PIN locking and new PIN setting procedure When the PIN is locked, SIM PUK1 input screen is displayed. Input 8-digits of SIM PUK which you obtained at purchasing SIM card. (If the input error of SIM PUK is occurred 10 times continuously, the SIM card is invalid.) The screen transition hereafter is the same to PIN changing procedure.

  • Page 146: Other Screen

    8. Handset Menu system 8. 10 Other screen (Short cut is not available) This screen is displayed when a fault is detected. TX alarm screen The screen pops up when TX alarm (the transmission stopped because of a trouble in transmitting system) is raised.

  • Page 147: Maintenance

    9. Maintenance 9. Maintenance The life of the JUE-250 depends on how well the equipment is maintained. Check the following items from time to time to ensure the best performance of your JUE-250. 1) Keep the input voltage within the specified range (+19VDC to +31VDC). 2) When the equipment is in good order, at times record the transmitting power (EIRP) and the receiving level (REC).

  • Page 148: Self Test

    Turn off and on the main unit when [Fail] is displayed, and retry the Self test. In case [Fail] is displayed on the Result column again, stop using the JUE-250 and contact the dealer or JRC sales office.

  • Page 149: After-Sales Service

    JRC and the purchaser. Service out of the guarantee term; If the function is recoverable by a repair, JRC will arrange a changed service on customer’s demand. To request a guarantee or non-guarantee service, please inform us of;...
  • Page 150 10. After-sales Service Disposal of the JUE-250 Follow the rule of the pertinent local government when you abandon the JUE-250(ADE). For details, contact the dealer or a concerned local government.

  • Page 151: Specification

    11. Specification 11. Specification MAIN (ADE, BDE) 1. MES Type Class 9 2. Inmarsat type approval B9JR01 3. Frequency Transmit 1626.5 to 1660.5 MHz Receive 1525.0 to 1559.0 MHz 4. Maximum E.I.R.P +15.1dBW + 1/-2dB 5. G/T -15.5dBK 6. Modulation QPSK For voice communication / 4-QPSK...
  • Page 152 11. Specification 11. Environmental Conditions 1) Temperature -25˚C to +55˚C -15˚C to +55˚C 2) Relative Humidity Up to +40˚C, 95% 3) Vibration IEC 60945 4th Edition compliant 4) Ship’s Motion Motion: Amplitude Period Roll +30˚ Pitch +10˚ +8˚ 50 s Surge +0.2g Sway...

  • Page 153: A Changing Procedures Of Using Gyro Tracking

    Appendix A Changing procedures of using GYRO tracking Appendix A Changing procedures of using GYRO tracking A.1 Cable connection system diagram (Corresponded to Chapter 2.3.1) Changed Fig. A.1 Cable connection system diagram (when GYRO is used)
  • Page 154 Appendix A Changing procedures of using GYRO tracking A.2 Procedure of setting GYRO tracking system (Corresponded to Chapter 8.9.1.4) Procedure of changing tracking system from [Auto](signal tracking) to [GYRO(NSK)] or [GYRO(NMEA)] is described in this chapter. (In JUE-250, the tracking system is easily changed from Handset, although setting of dip switch must be changed in JUE-33).
  • Page 155 Appendix A Changing procedures of using GYRO tracking A.3 Screen display of Handset (Corresponded to Chapter 4.1) Turn on JUE-250 by pushing power switch of Main unit. Initializing A LED of Main unit starts blinking. About 10 seconds later, initializing is started Initialize and blinking [Initialize] text is displayed.
  • Page 156 Appendix A Changing procedures of using GYRO tracking A.4 Unit Info menu (Corresponded to Chapter 8.1.5) In this menu, user can display the software version, maintenance No. and status of ADE/BDE. By set to GYRO tracking, [2 Mainte No.] and [4 BDE] screens are changed. Unit Refer to p85 1 Sta t u s...
  • Page 157 Cable loss: 4 B D E ….Offset value of cable calibration 10.0 ….IMEI (International Mobile Equipment IMEI:123456- Identity number) 78-901234-5 Unit JRC No: …..Manufacturer’s serial number GV12345 Delivery: ….Delivery date 01/JAN/2008 UE Class: ….User Equipment Class ….IMSI (International Mobile Subscriber...
  • Page 158 Appendix A Changing procedures of using GYRO tracking A.5 Satellite menu(Corresponded to 8.1.3) ( MENU+ 3 ) Editing the Heading value is required after changed to GYRO tracking system. Top menu screen 1 Sta t u s 2 S M S 3 S a t e l l i t e ＯＫ...

  • Page 159: B Handset Menu Tree

    Appendix B Handset menu tree Appendix B Handset menu tree B.1 Menu for all users (1) Fig.B.1 Menu for all users (1)
  • Page 160 Appendix B Handset menu tree B.2 Menu for all users (2) SMS menu detail Fig.B.2 Menu for all users (2) SMS menu detail...
  • Page 161 Appendix B Handset menu tree B.3 Menu for ADMIN users Fig.B.3 Menu for ADMIN users...
  • Page 162 Appendix B Handset menu tree This page is remained as a blank.

  • Page 163: C Jue-250 Software Updating Procedure

    Appendix C JUE-250 software updating procedure Appendix C JUE-250 software updating procedure Update JUE-250 software with following procedure a) to d). a) Confirm the connection JUE-250 software updating is executed by a PC with dedicated application for PC. Prepare a PC and connect it to your JUE-250. (For details, refer “1. Confirm the connection”) * Windows XP/Vista OS is required.
  • Page 164 Appendix C JUE-250 software updating procedure 1. Confirm the connection PC dedicated software is used for JUE-250 software updating. Prepare a PC and connect it to Ethernet port of JUE-250, with LAN cable. About the connecting procedure, refer to [6.2 Ethernet port PC connection] (p66) in this manual. Power supply LAN cable Handset...
  • Page 165 Appendix C JUE-250 software updating procedure 2. Download the latest software for JUE-250 The latest software of JUE-250 is uploaded on the HP of Inmarsat. The URL is as follows: http://www.inmarsat.com/Support/FleetBroadband/Firmware.aspx If the software’s version on the HP is larger than the JUE-250’s software version, download the software from HP.
  • Page 166 Appendix C JUE-250 software updating procedure 3. Update JUE-250 software Note ・Do not turn OFF the power supply of JUE-250 and/or PC during the software forwarding or updating ・Software forwarding or updating takes up to 20 minutes. Activate your JUE-250 and confirm that initialization is completed. * [Initialize] is displayed during initialization on the Handset screen.
  • Page 167 Appendix C JUE-250 software updating procedure Following dialog box is displayed. Click [OK] button. Select [Complete upgrade now] and click [OK] button. [JUE-250 Upgrader] is activated.
  • Page 168 Appendix C JUE-250 software updating procedure 5.1. If the PC cannot connect with BDE If your PC cannot connect with BDE, below screen is displayed. In this case, assumable cause is changed BDE’s IP address. Set the current BDE’s IP address into the textbox which displays below IP address, and then select [Tool] –...
  • Page 169 Appendix C JUE-250 software updating procedure [Upgrade] button turns to active when installation is ready. Click [Upgrade] button. After that, click [Yes] button in confirmation window. Forwarding of the file is started.
  • Page 170 Appendix C JUE-250 software updating procedure Following dialog box is displayed when file forwarding is completed. JUE-250 reboots automatically after several tens of seconds, and starts software updating. Click [OK] button to close this dialog box. [SW UPDATE] is displayed on the Handset screen during software updating. SW UPDATE JUE-250 reboots when software updating is successfully completed.
  • Page 171 Appendix C JUE-250 software updating procedure 9.1. When software update is failed Update is failed when following phenomenon is generated. A) [Upload file failed ] dialog box is displayed on the PC. B) b) [BDE Update Error] or [ADE Update Error] is displayed on the Handset screen. BDE Update ADE Update Error X...
  • Page 172 Appendix C JUE-250 software updating procedure 9.2. Recovery procedure when software update is failed Turn OFF the power supply of JUE-250. Quit [JUE-250 Upgrader], if it is still activating. Turn ON the power supply of JUE-250 with pressing the right side button of the Handset. Right side button Right side button Leave your finger from PTT button when Ready LED of main unit starts to blink.
  • Page 173 Appendix C JUE-250 software updating procedure 9.3. Software downgrading procedure If you have any problems caused by upgrading, you can downgrade the software. A) Turn OFF the power supply of JUE-250. B) Quit [JUE-250 Upgrader], if it is still activating. C) Turn ON the power supply of JUE-250 with pressing the right side button of the Handset.
  • Page 174 Appendix C JUE-250 software updating procedure 4. Confirm the updated software version Check that the software version is correctly updated or not, from the following the Handset menu, <1> Status - <5> Unit Info - <2> Mainte No. - SYS When the update is succeeded, SYS No.

  • Page 175: D Fb Launchpad Installation Procedure

    Appendix D FB LaunchPad Installation Procedure Appendix D FB LaunchPad Installation Procedure Note - Launch Pad can be running on Windows XP/Vista - If the FB LaunchPad 1.0.x version or 1.1.x version is installed to your PC, uninstall it prior to this installation.
  • Page 176 Appendix D FB LaunchPad Installation Procedure 4. Select the edition. Click the radio button next to ”Personal”, then click Next. 5. Select the install folder. Click Next. Note Don’t change the default install folder.
  • Page 177 Appendix D FB LaunchPad Installation Procedure 6. Click Next. 7. Following screen is displayed and Pre-installation summary is shown. Click Install if the summary is acceptable.
  • Page 178 Appendix D FB LaunchPad Installation Procedure 8. Following screen is displayed when installation is started. 9. Following screen is displayed when the installation is completed. Click Done to close the installer. Now, FB LaunchPad installation is completed.
  • Page 179 Appendix D FB LaunchPad Installation Procedure D.2. If FB LaunchPad 1.4.X version is already installed The user data in the LaunchPad later than or equal to 1.4.0 version can be retained by this procedure. 1. Double-click the icon to open the FB LaunchPadInstaller.exe, which is stored in the attached CD-ROM: 2.
  • Page 180 Appendix D FB LaunchPad Installation Procedure 4. Select “OK”. Uninstaller will activate to uninstall the old version. 5. Click Uninstall. 6. Following screen is displayed when uninstall is started.
  • Page 181 Appendix D FB LaunchPad Installation Procedure 7. Following screen is displayed when uninstall is completed. Click Done to close the uninstaller. Installer will activate again. 8. Select the edition. Click the radio button next to ”Personal”, then click Next.
  • Page 182 Appendix D FB LaunchPad Installation Procedure 9. Select the install folder. Click Next. Note Don’t change the default install folder. 10. Click Next.
  • Page 183 Appendix D FB LaunchPad Installation Procedure 11. Following screen is displayed and Pre-installation summary is shown. Click Install if the summary is acceptable. 12. Following screen is displayed when installation is started.
  • Page 184 Appendix D FB LaunchPad Installation Procedure 13. At the last of the installation, following window will be popped-up. Select Yes if you need to retain UserData. 14. Following screen is displayed when the installation is completed. Click Done to close the installer. Now, FB LaunchPad installation is completed.
  • Page 185 Appendix D FB LaunchPad Installation Procedure NOTE After the activation of the Launch Pad, the initial screen may turn to abnormal as shown below. In this case, set the [Hardware acceleration] in the Graphic accelerator setting screen of Windows to [None]. [Hardware acceleration] can be displayed by: Windows menu [Start] - [Control Panel] - [Display] -[Setting] tab - [Advance] button- [Troubleshoot] tab...

  • Page 186: E Tcp Accelerator Installation Procedure

    Appendix E TCP Accelerator Installation Procedure Appendix E TCP Accelerator Installation Procedure 1. About TCP Accelerator TCP Accelerator (also known as TCP PEP) is a free software which has been tested and proven to improve the performance of TCP applications over the FleetBroadband network. TCP Accelerator boosts the upload speed of all TCP traffic by up to 300% (depending on file size), with an average increase across all applications of 40% - 80%.
  • Page 187 Appendix E TCP Accelerator Installation Procedure 2.2 Installing TCP Accelerator 1. Unzip SetupXP-Rxx.x-xxx.zip or SetupVista-Rxx.x-xxx.zip in the CD-ROM, and execute .exe file in unzippped file. The Setup Wizard launches automatically, and the following screen is displayed: 2. Click on Next. The “Welcome to the InstallShield Wizard for TCP PEP” screen is displayed, as shown below:...
  • Page 188 Appendix E TCP Accelerator Installation Procedure 3. Click on Next. The “Terms and Conditions” screen is displayed, as shown below: 4. Select the “I accept the terms in the license agreement” radio button, and click Next. The Destination Folder screen is displayed, as shown below:...
  • Page 189 Appendix E TCP Accelerator Installation Procedure 5. If you want the program files to be installed in the default directory, click on Next. To select a different directory, click on Change…, and select the required directory, then click on Next. The “Preparing to Install”...
  • Page 190 Appendix E TCP Accelerator Installation Procedure If the program fails Windows Logo testing, the following screen is displayed: If you see this screen, click on Continue Anyway. Note that you may see this screen more than once: click on Continue Anyway each time.
  • Page 191 Appendix E TCP Accelerator Installation Procedure 6. When the installation is complete, the following screen is displayed: 7. Click on Finish to complete the installation. The following screen is displayed: 8. Click on Yes to restart the computer.
  • Page 192 Appendix E TCP Accelerator Installation Procedure...

  • Page 193: F Default Value List

    Appendix F Default value list Appendix F Default value list Setting from Handset Item Default Chapter Title SMS Service Center Address (SCA) User, 0 8.2.5 3 SCA Validity date of the message 1 Day 8.2.5 4 Validity Behavior of the message after it delivered to 8.2.5 5 Class the destination...

  • Page 194: G Trouble Shooting And Faq(Tbd)

    Appendix G Trouble shooting and FAQ Appendix G Trouble shooting and FAQ FAQ Contents 1. Reception of radio wave from a satellite・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ 2.
  • Page 201 Appendix G Trouble shooting and FAQ 7. Actions to be taken when abnormal status is indicated on Handset Table G7. Displayed character strings and contents Display Contents Status Abnormal ADE? ＊ ） ADE abnormal. Abnormal GPS dose not receive the signal POSITION? ＊...
  • Page 202 Appendix G Trouble shooting and FAQ...

  • Page 203: H Cause Code

    Appendix H Cause Code Appendix H Cause Code Cause code indicates cause of disconnection of the communication. H.1 Cause Code for CS communication (TEL, FAX) --These Cause codes are quoted from 3GPP TS24.008 Annex H Normal class No. (HEX) Reason No.
  • Page 204 Appendix H Cause Code Protocol error (e.g., unknown message) class No. (HEX) Reason No. (HEX) Reason 0060 invalid mandatory information 0064 conditional IE error message type non-existent or not 0061 0065 message not compatible with protocol state implemented message type not compatible with 0062 0066 recovery on timer expiry...
  • Page 205 Appendix H Cause Code H.3 Cause code for Short Messaging Service --These Cause codes are quoted from 3GPP TS24.011 Annex E RP-cause definition SM-transfer Following cause codes are used for mobile originating short message and mobile terminating short message. No. (HEX) Reason No.

  • Page 206: I Glossary

    Appendix I Glossary Appendix I Glossary ADE ......................Above Deck Equipment AOR......................Atlantic Ocean Region APN ........................ Access Point Name ASCII............American Standard Code for Information Interchange *A standard alphanumeric character set based on 7-bit codes. BDE ......................Below Deck Equipment Bit ..........
  • Page 207 Appendix I Glossary DHCP ................Dynamic Host Configuration Protocol DNS ......................Domain Name System DP ........................Distribution Partner DTE ...................... Data Terminal Equipment EEPROM (Electrically Erasable and Programmable ROM) *Read only Memory that is able to delete and rewrite electrically. EIA .....................Electronic Industries Association EIRP.................
  • Page 208 Appendix I Glossary ITU .................International Telecommunication Union Kbytes .......................... 1024 bytes LCD ......................Liquid Crystal Display LED ......................Light Emitting Diode LMSS....................Land Mobile Satellite Service LNA ......................Low Noise Amplifier LT ..........................Local Time MES......................Mobile Earth Station *The generic name used to describe an Inmarsat-approved terminal which is allowed to access the network, and applicable to both maritime and land mobile communications.
  • Page 209 Appendix I Glossary PPP ......................Point-to-Point-Protocol Protocol *A defined set of communications standards which lay down the parameters to which all users must abide. Protocols in general use are X.25 and X.400. PS......................... Packet Switched PSDN ....................Packet Switched Data Network PSTN ...................
  • Page 210 Appendix I Glossary UTC ....................Universal Coordinated Time A term which, for practical purposes, has the same meaning as Greenwich Mean Time (GMT).

  • Page 211: Jrc Network
