Schematic

Figure 5 is the schematic for this EVM.
J1
Vin Up to 18 V
DNP
IN
DNP
J4
IN_S
TP5 TP6
J7
GND GND
GND
SBVU050 – December 2018
Submit Documentation Feedback
U1
TP1
6
IN
IN_S
C1 C2
TP3
2.2uF 2.2uF
4
EN
EN
GND R2
J6
100k
GND
TPS7A2601DRVR
TP7 TP8
GND GND
GND
Figure 5. TPS7A26EVM-021 Schematic
Copyright © 2018, Texas Instruments Incorporated
1
OUT
C3
J3
2.2uF
2
FB/NC
R1 GND
3
TP4
PG
10.0k
5
GND
7
PG_S
PAD
DNP
GND
J9
OUTPUT VOLTAGE
R4 R5 R6
1.10M 301k 165k
GND
TP2
J2
Vout Selected by J9
Iout Up to 500 mA
OUT_S
DNP C4
OUT
DNP
2.2uF
J5
GND
OUT_S
R3
C5
0.01uF 499k
J8
GND
GND
R7
57.6k
TPS7A26EVM-021 Evaluation Module
Schematic
