Note: Your controller's default SSID is a
combination of the controller's series letters
and the last four characters of the controller's
MAC address, for example, FT-012A. You can
find the MAC address on the label on the back
of the controller.
3. Enter the default password. For more information,
contact your supplier.
4. To ping the controller, at the command line, enter
ping, followed by the controller's IP address.
Note: For more information on your
controller's default IP address, see
network default IP address, subnet mask, and
gateway.
Primary network default IP address,
subnet mask, and gateway
Table 1: Default IP address, subnet mask, and gateway
for a primary network setup
Item Address
IP address 192.168.4.1
Subnet mask 255.255.255.0
Gateway 192.168.10.1
Interfacing with a controller's web
server
About this task:
To interface with a controller's web server, complete the
following steps:
1. Launch a HTML5 web browser, such as Chrome™,
Firefox , Microsoft Edge
®
2. In the web browser's address bar, enter your
controller's IP address, then press the Enter key or
Return key.
Interfacing with controller objects using
CPT
Use CPT to program EasyIO controller logic with the
Sedona framework.
1. To download the CPT application, contact Support
for the latest release.
FT LED states
Table 2: FT LED states
LED label LED color
STS Blue
6 FT-04A Quick Start Guide
Primary
, or Safari .
® ®
Normal state State
1 Hz blinks 1 Hz blinks
Fast blink
2. Unzip the folder and double-click the cpt.exe file.
Note: If CPT is already installed on your
computer and you want to update it to a new
release, do not click and launch the cpt.exe
file to avoid personal settings data loss.
Instead, unzip the package and drop all the
files into the existing CPT folder to merge and
overwrite outdated files.
To connect to a controller, click File, then click
3.
Open App.
4. In the Project Management window, on the
Recent tab, click New.
5. In the App Desc field, enter a name for the
controller.
6. In the Host field, enter the controller's IP address.
Note: The default IP address is 192.168.4.1
Note: For more information about your
controller's IP address, refer to the Controller
series IP address, subnet mask, and data
folder section of the EasyIO CPT User Guide
(LIT-12013978).
7. From the Data Folder list, select the folder for your
controller type.
Note: For FS Series controllers, select
SedonaFG.
Note: For more information about your
controller's data folder, refer to the Controller
series IP address, subnet mask, and data
folder section of the EasyIO CPT User Guide
(LIT-12013978).
8. Click Save.
9. Click Open.
10. In the Authentication dialog, enter your password
in the Password field.
Note: By default, there is no password.
To increase security, when you log on,
complete the steps in Creating a new CPT
admin password for a controller in EasyIO
Hardening Guide (LIT-12013986).
What to do next:
For more information on CPT, Refer to EasyIO CPT User
Guide (LIT-12013978).
Description
Normal operation
Controller in fault condition or controller in
bootloader mode
