Beckhoff EtherCAT EK112 Series Manual

Beckhoff EtherCAT EK112 Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Documentation | EN
EK112x, EK15xx
EtherCAT Junctions
2023-08-14 | Version: 3.6

Advertisement

Table of Contents
loading

Related Manuals for Beckhoff EtherCAT EK112 Series

Summary of Contents for Beckhoff EtherCAT EK112 Series

  • Page 1 Documentation | EN EK112x, EK15xx EtherCAT Junctions 2023-08-14 | Version: 3.6...

  • Page 3: Table Of Contents

    Version identification of EtherCAT devices .................. 10 1.6.1 General notes on marking.................... 10 1.6.2 Version identification of EK Couplers................ 11 1.6.3 Beckhoff Identification Code (BIC) ...................  12 1.6.4 Electronic access to the BIC (eBIC).................  14 2 Product overview ............................  16 Junction with RJ45 connection...................... 16 2.1.1 EK1122, EK1122-0080 ....................
  • Page 4 Table of contents Instructions for ESD protection .......................  58 Explosion protection ........................ 59 5.2.1 ATEX - Special conditions (extended temperature range).......... 59 5.2.2 IECEx - Special conditions.................... 60 5.2.3 Continuative documentation for ATEX and IECEx............ 61 5.2.4 cFMus - Special conditions .................... 62 5.2.5 Continuative documentation for cFMus................

  • Page 5: Foreword

    Foreword Foreword Overview EtherCAT Junctions Connection RJ45 1 port EtherCAT junction, extended distance EK1121-0010 [} 22] 2 port EtherCAT junction EK1122 [} 16] 2 port EtherCAT junction, Fast-Hot-Connect EK1122-0080 [} 16] Connection M8 2 port EtherCAT junction EK1122-0008 [} 26] Connection Fiber optic 1 port EtherCAT multimode fiber optic junction EK1521 [} 28] 1 port EtherCAT singlemode fiber optic junction EK1521-0010 [} 30]...

  • Page 6: Notes On The Documentation

    , XTS and XPlanar are registered trademarks of and licensed by Beckhoff Automation GmbH. Other designations used in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owners. Patent Pending...

  • Page 7: Safety Instructions

    All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards.

  • Page 8: Guide Through Documentation

    Further components of documentation This documentation describes device-specific content. It is part of the modular documentation concept for Beckhoff I/O components. For the use and safe operation of the device / devices described in this documentation, additional cross-product descriptions are required, which can be found in the following table.

  • Page 9: Documentation Issue Status

    Foreword Documentation issue status Version Modifications • Update chapter “Technical data” • Update chapter “Mounting and wiring” • Update structure • New title page • Addenda EK1121-0010 • Update chapter “Technical data” • Update chapter “Application notes” • Update chapter “UL notes” •...

  • Page 10: Version Identification Of Ethercat Devices

    Associated and synonymous with each revision there is usually a description (ESI, EtherCAT Slave Information) in the form of an XML file, which is available for download from the Beckhoff web site. From 2014/01 the revision is shown on the outside of the IP20 terminals, see Fig. “EL5021 EL terminal, standard IP20 IO device with batch number and revision ID (since 2014/01)”.

  • Page 11: Version Identification Of Ek Couplers

    Version identification of EK Couplers The serial number/ data code for Beckhoff IO devices is usually the 8-digit number printed on the device or on a sticker. The serial number indicates the configuration in delivery state and therefore refers to a whole production batch, without distinguishing the individual modules of a batch.

  • Page 12: Beckhoff Identification Code (Bic)

    1.6.3 Beckhoff Identification Code (BIC) The Beckhoff Identification Code (BIC) is increasingly being applied to Beckhoff products to uniquely identify the product. The BIC is represented as a Data Matrix Code (DMC, code scheme ECC200), the content is based on the ANSI standard MH10.8.2-2016.
  • Page 13 Fig. 3: Example DMC 1P072222SBTNk4p562d71KEL1809 Q1 51S678294 An important component of the BIC is the Beckhoff Traceability Number (BTN, position 2). The BTN is a unique serial number consisting of eight characters that will replace all other serial number systems at Beckhoff in the long term (e.g.

  • Page 14: Electronic Access To The Bic (Ebic)

    Electronic access to the BIC (eBIC) Electronic BIC (eBIC) The Beckhoff Identification Code (BIC) is applied to the outside of Beckhoff products in a visible place. If possible, it should also be electronically readable. Decisive for the electronic readout is the interface via which the product can be electronically addressed.
  • Page 15 • For processing the BIC/BTN data in the PLC, the following auxiliary functions are available in Tc2_Utilities from TwinCAT 3.1 build 4024.24 onwards ◦ F_SplitBIC: The function splits the Beckhoff Identification Code (BIC) sBICValue into its components based on known identifiers and returns the recognized partial strings in a structure ST_SplitBIC as return value.

  • Page 16: Product Overview

    Product overview Product overview Junction with RJ45 connection 2.1.1 EK1122, EK1122-0080 2.1.1.1 Introduction Fig. 4: EK1122-xxxx EK1122-0000 The 2-port EtherCAT junction enables configuration of EtherCAT star topologies. A modular EtherCAT star hub can be realized by using several EK1122 units in a station. Individual devices or complete EtherCAT strands can be connected at the junction ports.
  • Page 17 Product overview Fig. 5: Fast-Hot-Connect ports at the EK1122-0080 Connection Terminal point Description Designation X1/X2 RJ45 connection for EtherCAT networks (100BASE- TX Ethernet signal representation) Quick links • EtherCAT basics • Notes on Fast Hot Connect [} 19] • Application notes [} 34] •...
  • Page 18 Product overview 2.1.1.2 Technical data Technical data EK1122 EK1122-0080 Task within the EtherCAT system Coupling of EtherCAT junctions Coupling of EtherCAT junctions, Fast-Hot-Connect technology [} 19] Transmission medium Ethernet/EtherCAT cable (min. CAT5), shielded Cable length between two Bus max. 100 m (100BASE-TX) Couplers Protocol EtherCAT...
  • Page 19 Product overview 2.1.1.3 Notes re. EtherCAT Fast Hot Connect technology EtherCAT components that support Fast Hot Connect enable a faster fieldbus boot up following the establishment of a connection. The boot up depends in detail on the number of devices, the topology and activated Distributed Clocks.
  • Page 20 Product overview • With Fast Hot Connect devices the establishment of an Ethernet connection is accelerated compared to the normal Fast Ethernet connection. If in addition the use of Distributed Clocks functions is omitted in the entire topology, then the resynchronization time of the components is also dispensed with.
  • Page 21 Product overview Fig. 10: Marking in the TwinCAT System Manager A configuration of FHC groups is possible only if at least 1 corresponding junction is present e.g. EK1122-0080. Distributed Clocks If no Distributed Clocks functions are used, this is visible in the master settings by the absence of “DC in use”: Fig. 11: DC master setting This setting is automatically selected by the System Manager if there are no EtherCAT slaves in the...

  • Page 22: Ek1121-0010

    Product overview 2.1.2 EK1121-0010 2.1.2.1 Introduction Fig. 12: EK1121-0010 EK1121-0010 In combination with an EtherCAT Extended Distance device e. g. EK1101-0010, the single-port EK1121-0010 EtherCAT Extended Distance junction enables the bridging of distances up to 300 m. The EK1121-0010 can be installed at any point in an EtherCAT segment between the EtherCAT Terminals (ELxxxx).
  • Page 23 Product overview 2.1.2.2 Technical data Technical data EK1121-0010 Task within the EtherCAT system coupling of 100BASE-TX EtherCAT networks Transmission medium Ethernet/EtherCAT cable (copper, min. Cat. 5, 4-wire, AWG22), shielded Cable length between two Bus Couplers max. 300 m Protocol EtherCAT Data transfer rates 100 Mbit/s Configuration no address and configuration settings required...
  • Page 24 Product overview 2.1.2.3 Notes on Extended Distance connection Using components which support the Extended Distance connection, distances of up to 300 m can be bridged (for connections between two Extended Distance components). These components are marked with “extended distance” both in chapter “Technical data” and on the respective RJ45 sockets of the component. In the TwinCAT System Manager “Extended Distance”...
  • Page 25 Product overview Not permitted topologies with Extended Distance components The EK1121-0010 EtherCAT junction cannot be used as a 2 component because the EtherCAT port is not an output port. The following figure shows not permitted topologies with Extended Distance components. Fig. 14: Not permitted topologies with Extended Distance components Not permitted topologies with Extended Distance components No.

  • Page 26: Junctions With M8 Connection

    Product overview Junctions with M8 connection 2.2.1 EK1122-0008 2.2.1.1 Introduction Fig. 16: EK1122-0008 EK1122-0008 The 2-port EtherCAT junction enables configuration of EtherCAT star topologies. A modular EtherCAT star hub can be realized by using several EK1122 units in a station. Individual devices or complete EtherCAT strands can be connected at the junction ports.
  • Page 27 Product overview 2.2.1.2 Technical data Technical data EK1122-0008 Task within the EtherCAT system Coupling of EtherCAT junctions via M8 Transmission medium Ethernet/EtherCAT-cable (min. CAT 5), shielded Cable length between two stations 100 m (100BASE-TX) Protocol EtherCAT Data transfer rates 100 Mbit/s Configuration not required Bus interface 2 x M8...

  • Page 28: Junctions With Fiber Optic Connection

    Product overview Junctions with fiber optic connection 2.3.1 EK1521 2.3.1.1 Introduction Fig. 17: EK1521 In conjunction with an EK1100 EtherCAT coupler, the 1-port EtherCAT multimode fiber optic junction enables conversion from 100Base-TX to 100Base-FX physics (glass fiber). In this way distances of up to 2 km can be bridged in conjunction with the EK1501 EtherCAT Coupler for multimode optical fibers.
  • Page 29 Product overview 2.3.1.2 Technical data Technical data EK1521 Task within the EtherCAT system Coupling of EtherCAT junctions Cable length between two Bus Couplers 2,000 m (100BASE-FX) multimode glass fiber Protocol All EtherCAT protocols Data transfer rates 100 Mbit/s Delay typ. 1 µs Configuration no address and configuration settings required Optical Data EK1521...

  • Page 30: Ek1521-0010

    Product overview 2.3.2 EK1521-0010 2.3.2.1 Introduction Fig. 18: EK1521-0010 In conjunction with an EK110x EtherCAT coupler, the 1-port EtherCAT single-mode fiber optic junction enables conversion from 100Base-TX to 100Base-FX physics (glass fiber). In conjunction with the EK1501-0010 EtherCAT coupler for single-mode optical glass fiber, distances of up to 20 km can be bridged. Even cable redundant systems with optical fiber can be realized using the 1-port EtherCAT single-mode fiber optic junction.
  • Page 31 Product overview 2.3.2.2 Technical data Technical data EK1521-0010 Task within the EtherCAT system Coupling of EtherCAT junctions Cable length between two Bus Couplers 20,000 m (100BASE-FX) single mode glass fiber Protocol All EtherCAT protocols Data transfer rates 100 Mbit/s Delay typ. 1 µs Configuration no address and configuration settings required Optical Data...

  • Page 32: Junctions With Pof Connection

    Product overview Junctions with POF connection 2.4.1 EK1561 2.4.1.1 Introduction Fig. 19: EK1561 In connection with an EK1100 EtherCAT coupler, the EK1561 single-port POF junction makes it possible to convert from 100BASE-TX physics to 100BASE-FX physics (POF - Polymeric Optical Fiber). Distances of up to 50 m between two couplers can be bridged using the EK1561 and the EK1541 EtherCAT coupler for POF.
  • Page 33 Product overview 2.4.1.2 Technical data Technical data EK1561 Task within the EtherCAT system Coupling of EtherCAT junctions via POF Cable length between two stations max. 50 m (100BASE-FX) POF Protocol All EtherCAT protocols Data transfer rates 100 Mbit/s Delay approx. 1 µs Configuration no address and configuration settings required Optical Data EK1561...

  • Page 34: Commissioning/Application Notes

    Commissioning/application notes Commissioning/application notes Application notes RJ45 junction 3.1.1 EK1121-0010 - Settings and port assignment For normal operation the EK1121-0010 can be used with default settings. The port ID used in the TwinCAT System Manager is mapped on the EK1121-0010 as follows: Fig. 20: EK1121-0010 port ID Fig. 21: Internal and external port assignment for EK1121-0010 Version: 3.6...

  • Page 35: Ek1122 - Settings And Port Assignment

    Commissioning/application notes 3.1.2 EK1122 - Settings and port assignment For normal operation the EK1122 can be used with default settings. The port ID used in the TwinCAT System Manager is mapped on the EK1122 as follows: Fig. 22: EK1122 port ID Fig. 23: Internal and external port assignment for EK1122 EK112x, EK15xx Version: 3.6...

  • Page 36: Application Notes M8 Junction

    Commissioning/application notes Application notes M8 junction 3.2.1 EK1122-0008 - Settings and port assignment For normal operation no settings are required at the EK1122-0008. The port ID used in the TwinCAT System Manager is mapped on the EK1122-0008 as follows: Fig. 24: Port ID for EK1122-0008 Fig. 25: Internal and external port assignment for EK1122-0008 Version: 3.6 EK112x, EK15xx...

  • Page 37: Application Notes Fiber Optic Junction

    Commissioning/application notes Application notes fiber optic junction Mounting rail installation Mounting Please ensure that the EK1521, EK1521-0010 engages properly on the DIN rail. See mounting rail installation [} 67] and recommended mounting rails [} 64]. EK112x, EK15xx Version: 3.6...

  • Page 38: Principles Of Fiber-Optic Technology

    Commissioning/application notes 3.3.1 Principles of fiber-optic technology When using fiber-optic cables for the transmission of data, there are various factors that influence the signal transmission and have to be observed in order to guarantee reliable transmission. Important principles of fiber-optic technology are described below. Attenuation Less light reaches the end of a connection with fiber-optic cables than is input at the start of the connection.
  • Page 39 Commissioning/application notes Further influences on the signal transmission In addition to the main influences (attenuation and dispersion) that limit the transmission link, care must be taken when installing and maintaining fiber-optic transmission links. Sharp kinks and micro-bends in the fiber-optic lead to additional reflections in the fiber, as a result of which the influences of the attenuation and dispersion are increased.
  • Page 40 In the next step, the attenuation budget, i.e. the attenuation over the entire transmission link, must be calculated. A multimode fiber in the strength 50/125 µm from Beckhoff (ZK1091-1001-xxxx) is used for this example. A maximum attenuation of 0.8 dB/km at a wavelength of 1300 nm is specified in the data sheet for the fiber-optic cable.
  • Page 41 Commissioning/application notes Attenuation budget Parameter Number Value Fiber loss attenuation (0.8 dB/km) 2.1 km 1.68 dB Connector insertion attenuation 0.5 dB (0.25 dB) Splice insertion attenuation (0.3 dB) 0.9 dB Attenuation budget 3.08 dB If the attenuation budget is now subtracted from the power budget, a power buffer of 4.42 dB results. This is greater than 3 dB and is therefore sufficient as a buffer for most applications, so that an additional splice or slight soiling of the fiber would not lead to failure of the data transmission.
  • Page 42 Commissioning/application notes Evaluation of a fiber-optic transmission link by means of measurement A fiber-optic transmission link can be described and evaluated with parameters from data sheets. In order to obtain a real result for the attenuation over the entire link, however, the link must be measured using an optical power meter (OPM).

  • Page 43: Ek1521-00X0 - Settings And Port Assignment

    Commissioning/application notes 3.3.2 EK1521-00x0 - Settings and port assignment For normal operation the EK1521, EK1521-0010 can be used with default settings. The port ID used in the TwinCAT System Manager is mapped on the EK1521, EK1521-0010 as follows: Fig. 28: Port ID for EK1521, EK1521-0010 Fig. 29: Internal and external port assignment EK1521, EK1521-0010 EK112x, EK15xx Version: 3.6...

  • Page 44: Notes On Suitable Optical Fiber Cables

    Commissioning/application notes 3.3.3 Notes on suitable optical fiber cables General information on optical fiber types Optical fiber are available as multimode and single mode types with different step and graded indices. Step and graded index Optical fiber cables consist of 2 concentric materials, the core and cladding, plus a protective (colored) jacket.

  • Page 45: Application With Ek1521 And Ek1521-0010

    Commissioning/application notes 3.3.4 Application with EK1521 and EK1521-0010 Application with EK1521 and EK1521-0010 The EK1521, EK1521-0010 is intended for application with optical fiber cables with the following characteristics: • SC duplex connector • EK1521: Duplex multimode 50/125 µm or 62.5/125 µm (inner/outer core diameter). The use of both diameters is possible.
  • Page 46 Commissioning/application notes Connecting and releasing the optical fiber cable at the junction NOTICE Risk of damage to the cable! To disconnect the optical fiber cable always pull the connector to release the locking mechanism - never pull the optical fiber cable itself. Crossover cables Not that crossover cables may have to be used for connecting the EK1521, EK1521-0010 with the EK1501/ EK1501-0010.

  • Page 47: Application Notes Pof Junction

    Commissioning/application notes Application notes POF junction Mounting rail installation Mounting Please ensure that the EK1561 engages properly on the DIN rail. See mounting rail installation [} 67] and recommended mounting rails [} 64]. 3.4.1 EK1561 - Settings and port assignment For normal operation the EK1561 can be used with default settings. The port ID used in the TwinCAT System Manager is mapped on the EK1561 as follows: Fig. 30: EK1561 port ID Fig. 31: Internal and external port assignment for EK1561...

  • Page 48: Notes Regarding Suitable Pof Cables

    Commissioning/application notes 3.4.2 Notes regarding suitable POF cables General information about POF cables The standard polymer fiber is 1 mm thick and consists of a 0.98 mm thick core made of polymethyl methacrylate (PMMA) as well as a thin sheath. In order to enable the guidance of light using the effect of total reflection in the core, the usually very thin sheath consists of fluorinated PMMA, which has a low refractive index.

  • Page 49: Application With Ek1561

    For the connection of the EK1561 it is recommended to use the connector set ZS1090-0008 [} 51] (Versatile Link Duplex connectors) in conjunction with a duplex polymer fiber with an outside diameter of 2 x 2.2 mm (Z1190), which are available from Beckhoff. Installation notes •...
  • Page 50 Commissioning/application notes NOTICE TX / Rx channel assignment During cable assembly [} 51] note the assignment of the optical channels in the connection socket. In the EK1561, the light-emitting transmitter channel (Tx) is the upper outlet in the connection socket. Figure: Transmitter channel in the EK1561 Be sure to observe the safety instructions [} 94] for class 1 lasers! NOTICE Use of blind plugs...

  • Page 51: Notes Regarding Assembly Of Pof Cables With The Connector Set Zs1090-0008

    Notes regarding assembly of POF cables with the connector set ZS1090-0008 Fig. 33: Duplex connector set ZS1090-0008 The duplex connector set ZS1090-0008 from Beckhoff consists of 10 duplex Versatile Link connectors and several sheets of abrasive paper and polishing paper. Step-by-step instructions for assembling the POF cable The following step-by-step guide describes the correct assembly of a POF cable with a Versatile Link duplex connector.
  • Page 52 Commissioning/application notes 2. Attaching the connector Push the two cable ends into the connector and the connector back until it stops. The fibers should now protrude no more than 1.5 mm from the front openings. Close the connector by folding the upper and lower halves together until they engage. Fig. 35: Cable inserted in the connector Fig. 36: Closed connector When inserting the wires into the connector ensure the optical channels are crossed (Tx1 →...
  • Page 53 Commissioning/application notes 3. Grinding and polishing Any fibers protruding more than 1.5 mm from the connector should be shortened with a cutter knife or a pair of scissors. Now push the connector fully into the sanding gauge, so that the ends to be polished protrude from the lower side.
  • Page 54 Commissioning/application notes Fig. 40: Fine-polished fibers in the connector Version: 3.6 EK112x, EK15xx...

  • Page 55: Error Handling And Diagnostics

    Error handling and diagnostics Error handling and diagnostics Diagnostic LEDs EK1121-0010, EK1122, EK1122-0008 Fig. 41: EK1121-0010, EK1122, EK1122-0008, LEDs LEDs for fieldbus diagnostics Display State Description LINK / ACT green no connection on the EtherCAT strand (X1/X2) linked EtherCAT device connected flashing active Communication with EtherCAT device...

  • Page 56: Diagnostic Leds Ek1521, Ek1521-0010

    Error handling and diagnostics Diagnostic LEDs EK1521, EK1521-0010 LEDs for fieldbus diagnostics Display State Description LINK / ACT green no connection on the EtherCAT strand (X1) linked EtherCAT device connected flashing active Communication with EtherCAT device LED diagnostics EtherCAT state machine Color Meaning green...

  • Page 57: Diagnostic Leds Ek1561

    Error handling and diagnostics Diagnostic LEDs EK1561 LEDs for fieldbus diagnostics Color Display State Description LINK / green no connection on the EtherCAT strand ACT (X1) linked EtherCAT device connected flashing active Communication with EtherCAT device LED diagnostics EtherCAT state machine Color Meaning green...

  • Page 58: Mounting And Wiring

    • Each assembly must be terminated at the right hand end with an EL9011 or EL9012 bus end cap, to ensure the protection class and ESD protection. Fig. 42: Spring contacts of the Beckhoff I/O components Version: 3.6 EK112x, EK15xx...

  • Page 59: Explosion Protection

    80°C at the wire branching points, then cables must be selected whose temperature data correspond to the actual measured temperature values! • Observe the permissible ambient temperature range of -25 to 60°C for the use of Beckhoff fieldbus components with extended temperature range (ET) in potentially explosive areas! •...

  • Page 60: Iecex - Special Conditions

    • EN 60079-31:2013 (only for certificate no. IECEx DEK 16.0078X Issue 3) Marking Beckhoff fieldbus components that are certified in accordance with IECEx for use in areas subject to an explosion hazard bear the following markings: Marking for fieldbus components of certificate IECEx DEK 16.0078 X...

  • Page 61: Continuative Documentation For Atex And Iecex

    Pay also attention to the continuative documentation Ex. Protection for Terminal Systems Notes on the use of the Beckhoff terminal systems in hazardous areas according to ATEX and IECEx, that is available for download within the download area of your product on the Beckhoff homepage www.beckhoff.com!

  • Page 62: Cfmus - Special Conditions

    • CAN/CSA C22.2 No. 60079-7:2016 • CAN/CSA C22.2 No.61010-1:2012 Marking Beckhoff fieldbus components that are certified in accordance with cFMus for use in areas subject to an explosion hazard bear the following markings: FM20US0111X (US): Class I, Division 2, Groups A, B, C, D...

  • Page 63: Continuative Documentation For Cfmus

    Continuative documentation about explosion protection according to cFMus Pay also attention to the continuative documentation Control Drawing I/O, CX, CPX Connection diagrams and Ex markings, that is available for download within the download area of your product on the Beckhoff homepage www.beckhoff.com! UL notice CAUTION Application Beckhoff EtherCAT modules are intended for use with Beckhoff’s UL Listed EtherCAT...

  • Page 64: Recommended Mounting Rails

    Mounting and wiring Recommended mounting rails Terminal Modules und EtherCAT Modules of KMxxxx and EMxxxx series, same as the terminals of the EL66xx and EL67xx series can be snapped onto the following recommended mounting rails: • DIN Rail TH 35-7.5 with 1 mm material thickness (according to EN 60715) •...

  • Page 65: Installation On Mounting Rails

    Mounting and wiring Installation on mounting rails WARNING Risk of electric shock and damage of device! Bring the bus terminal system into a safe, powered down state before starting installation, disassembly or wiring of the bus terminals! The Bus Terminal system and is designed for mounting in a control cabinet or terminal box. Assembly Fig. 43: Attaching on mounting rail The bus coupler and bus terminals are attached to commercially available 35 mm mounting rails (DIN rails...
  • Page 66 Mounting and wiring Disassembly Fig. 44: Disassembling of terminal Each terminal is secured by a lock on the mounting rail, which must be released for disassembly: 1. Pull the terminal by its orange-colored lugs approximately 1 cm away from the mounting rail. In doing so for this terminal the mounting rail lock is released automatically and you can pull the terminal out of the bus terminal block easily without excessive force.

  • Page 67: Mounting And Demounting - Terminals With Front Unlocking

    Mounting and wiring Fig. 45: Power contact on left side NOTICE Possible damage of the device Note that, for reasons of electromagnetic compatibility, the PE contacts are capacitatively coupled to the mounting rail. This may lead to incorrect results during insulation testing or to damage on the terminal (e.g. disruptive discharge to the PE line during insulation testing of a consumer with a nominal voltage of 230 V).
  • Page 68 Mounting and wiring and press (1) the terminal module against the mounting rail until it latches in place on the mounting rail (2). • Attach the cables. Demounting • Remove all the cables. • Lever the unlatching hook back with thumb and forefinger (3). An internal mechanism pulls the two latching lugs (3a) from the top hat rail back into the terminal module.

  • Page 69: Installation Positions

    Mounting and wiring Installation positions NOTICE Constraints regarding installation position and operating temperature range Please refer to the technical data for a terminal to ascertain whether any restrictions regarding the installation position and/or the operating temperature range have been specified. When installing high power dissipation terminals ensure that an adequate spacing is maintained between other components above and below the terminal in order to guarantee adequate ventilation! Optimum installation position (standard)
  • Page 70 Mounting and wiring Fig. 47: Other installation positions Version: 3.6 EK112x, EK15xx...

  • Page 71: Connection System

    Mounting and wiring Connection system WARNING Risk of electric shock and damage of device! Bring the bus terminal system into a safe, powered down state before starting installation, disassembly or wiring of the bus terminals! Overview The bus terminal system offers different connection options for optimum adaptation to the respective application: •...

  • Page 72: Wiring

    Mounting and wiring Conductor cross sections between 0.08 mm and 2.5 mm can continue to be used with the proven spring force technology. The overview and nomenclature of the product names for ESxxxx and KSxxxx series has been retained as known from ELxxxx and KLxxxx series. High Density Terminals (HD Terminals) Fig. 50: High Density Terminals The terminals from these series with 16 terminal points are distinguished by a particularly compact design,...
  • Page 73 Mounting and wiring Terminals for standard wiring ELxxxx/KLxxxx and for pluggable wiring ESxxxx/KSxxxx Fig. 51: Connecting a cable on a terminal point Up to eight terminal points enable the connection of solid or finely stranded cables to the bus terminal. The terminal points are implemented in spring force technology.

  • Page 74: 5.10 Ethercat Cabling - Wire-Bound

    - RJ45 connector, field assembly ZS1090-0005 - EtherCAT cable, field assembly ZB9010, ZB9020 Suitable cables for the connection of EtherCAT devices can be found on the Beckhoff website! E-Bus supply A bus coupler can supply the EL terminals added to it with the E-bus system voltage of 5 V; a coupler is thereby loadable up to 2 A as a rule (see details in respective device documentation).

  • Page 75: 5.11 M8 Connector Cabling

    A list of the EtherCAT cable, power cable, sensor cable, Ethernet-/EtherCAT connectors and the field assembled connectors can be found at the following link: https://www.beckhoff.com/en-us/products/i-o/ accessories/ You can find the corresponding data sheets at the following link: https://www.beckhoff.com/en-us/support/ download-finder/data-sheets/ EtherCAT cable Fig. 53: ZK1090-3131-0xxx...
  • Page 76 Mounting and wiring M8 Connector pin assignment Signal Description Pin (M8) Transmit Data+ Transmit Data- Receive Data+ Receive Data- Shield Shielding Housing Version: 3.6 EK112x, EK15xx...

  • Page 77: 5.12 Nut Torque For Connectors

    Mounting and wiring 5.12 Nut torque for connectors Fig. 54: X1 and X2 of EK1122-0008 For usage of the EtherCAT connectors M8 of EK1122-0008 the following have to be noticed: M8 connectors It is recommended to pull the M8 connectors tight with a nut torque of 0.4 Nm. When using the torque control screwdriver ZB8800 is also a max.

  • Page 78: 5.13 Note - Power Supply

    Mounting and wiring 5.13 Note - Power supply WARNING Power supply from SELV/PELV power supply unit! SELV/PELV circuits (Safety Extra Low Voltage, Protective Extra Low Voltage) according to IEC 61010-2-201 must be used to supply this device. Notes: • SELV/PELV circuits may give rise to further requirements from standards such as IEC 60204-1 et al, for example with regard to cable spacing and insulation.
  • Page 79 Mounting and wiring Fig. 56: Potential diagram EKxxxx GND concept Fig. 57: GND concept EKxxxx Fuse protection Coupler supply, fuse 1: depending on the required current consumption and hence the configured terminals typical max. 1 A EK112x, EK15xx Version: 3.6...
  • Page 80 Mounting and wiring Power contacts, fuse 2: permitted max. 10 A (slow-blow) The coupler electronics and the power contacts can be supplied together from the same source. In this case the fuse should be dimensioned for 10 A max. Version: 3.6 EK112x, EK15xx...

  • Page 81: 5.15 Positioning Of Passive Terminals

    Mounting and wiring 5.15 Positioning of passive Terminals Hint for positioning of passive terminals in the bus terminal block EtherCAT Terminals (ELxxxx / ESxxxx), which do not take an active part in data transfer within the bus terminal block are so called passive terminals. The passive terminals have no current consumption out of the E-Bus.

  • Page 82: 5.16 Disposal

    Mounting and wiring 5.16 Disposal Products marked with a crossed-out wheeled bin shall not be discarded with the normal waste stream. The device is considered as waste electrical and electronic equipment. The national regulations for the disposal of waste electrical and electronic equipment must be observed. Version: 3.6 EK112x, EK15xx...

  • Page 83: Basics

    Please refer to the EtherCAT System Documentation for the EtherCAT fieldbus basics. Basic function principles of EtherCAT junctions Some Beckhoff EtherCAT devices can be used for junctions in the EtherCAT segment. These include EK1122, EK1521, EP1122 or also CU112x. In the following examples only the EK1122 is used. The technical and system characteristics of the other devices are similar.
  • Page 84 Basics • this frame passes each slave once, • is reversed by the last slave in the logical sequence • and is returned to the master through each EtherCAT slave via two return lines of the Ethernet cable without further processing. At short cycle times in the order of 50 µs at 20,000 Ethernet frames are in transit in the EtherCAT system every second, plus acyclic organizational frames.
  • Page 85 Ethernet frame is in transit on this line and in the bus segment downstream of the separation point. Implementation: EL terminal A standard EtherCAT slave such as a Beckhoff EL terminal has two ports: • one for incoming frames (port 0 [A]) • and one for outgoing frames (e.g. port [D]).
  • Page 86 Basics Implementation: EK1121-0010 EtherCAT junction, Extended Distance As in the EK1100, three ESC ports can be connected in these junctions: Two via E-bus within the terminal and one via the RJ45 sockets with Ethernet configuration. Implementation: EK1122 EtherCAT junction In the EK1122 all four ESC ports can be connected - two via the internal E-bus and two via the RJ45 sockets with Ethernet configuration.
  • Page 87 Basics The TwinCAT online topology shows the wiring scheme, see Fig. Online Topology. The EK1122 is selected, so that further information is shown. The green bars above the slaves indicate the correct RUN state in all slaves. Fig. 64: Online topology An error is now generated by disconnecting the connection between the upper RJ45 socket (X1) and the EL3102 device.
  • Page 88 Basics Fig. 65: Example configuration with interrupted cable The System Manager messages can be interpreted as follows: • Address 1002 - EK1122: “OP LNK:MIS D”: The slave is in OP state, although a link is missing at port D (3) that should be present according to the configuration •...
  • Page 89 Basics Fig. 66: Topology display for interrupted line In Fig. “Example configuration [} 86]” and Fig. “Example configuration with interrupted cable” [} 88] note the display of acyclic frames, see the following Fig. Comparison of the frame displays in the System Manager. Fig. 67: Comparison of the frame displays in the System Manager The image on the left shows a small number (2) of acyclic frames sent by the master during the respective second - all slaves are operating properly.

  • Page 90: Ethercat State Machine

    ADS (see figures on this page). System Manager functions can also be triggered via PLC or ADS. Please refer to the relevant sections in the Beckhoff Information System and the notes on EtherCAT diagnostics.

  • Page 91: Coe - Interface: Notes

    CoE - Interface: notes This device has no CoE. Detailed information on the CoE interface can be found in the EtherCAT system documentation on the Beckhoff website. EKxxxx - Optional Distributed Clocks support Basic principles Distributed Clocks (DC) The EtherCAT Distributed Clocks system comprises local clocks that are integrated in the EtherCAT slaves and are synchronized by the EtherCAT master via special datagrams.
  • Page 92 Basics Fig. 69: DC tab for indicating the Distributed Clocks function Once of these local clocks is the reference clock, based on which all other clocks are synchronized. See also explanatory notes in the Basic EtherCAT documentation. The reference clock must be the first DC-capable EtherCAT slave.
  • Page 93 Basics Device XML revision in the configuration Serial number of the component BK1150 from BK1150-0000-0016 from firmware 01: xxxx01yy CU1128 from CU1128-0000-0000 from firmware 00: xxxx00yy EK1100 from EK1100-0000-0017 from firmware 06: xxxx06yy EK1101 from EK1101-0000-0017 from firmware 01: xxxx01yy EK1501 from EK1501-0000-0017 from firmware 01: xxxx01yy...

  • Page 94: Appendix

    NOTICE Only use TwinCAT 3 software! A firmware update of Beckhoff IO devices must only be performed with a TwinCAT 3 installation. It is recommended to build as up-to-date as possible, available for free download on the Beckhoff website. To update the firmware, TwinCAT can be operated in the so-called FreeRun mode, a paid license is not required.
  • Page 95 Appendix Above all, each EtherCAT slave carries its device description (ESI) electronically readable in a local memory chip, the so-called ESI EEPROM. When the slave is switched on, this description is loaded locally in the slave and informs it of its communication configuration; on the other hand, the EtherCAT master can identify the slave in this way and, among other things, set up the EtherCAT communication accordingly.

  • Page 96: Device Description Esi File/Xml

    The device revision is closely linked to the firmware and hardware used. Incompatible combinations lead to malfunctions or even final shutdown of the device. Corresponding updates should only be carried out in consultation with Beckhoff support. Display of ESI slave identifier...
  • Page 97 Appendix Fig. 73: Scan the subordinate field by right-clicking on the EtherCAT device If the found field matches the configured field, the display shows Fig. 74: Configuration is identical otherwise a change dialog appears for entering the actual data in the configuration. Fig. 75: Change dialog In this example in Fig.
  • Page 98 Appendix Changing the ESI slave identifier The ESI/EEPROM identifier can be updated as follows under TwinCAT: • Trouble-free EtherCAT communication must be established with the slave. • The state of the slave is irrelevant. • Right-clicking on the slave in the online display opens the EEPROM Update dialog, Fig. EEPROM Update Fig. 76: EEPROM Update The new ESI description is selected in the following dialog, see Fig.

  • Page 99: Firmware Explanation

    • offline: The EtherCAT Slave Information ESI/XML may contain the default content of the CoE. This CoE directory can only be displayed if it is included in the ESI (e.g. “Beckhoff EL5xxx.xml”). The Advanced button must be used for switching between the two views.
  • Page 100 Appendix Fig. 79: Firmware Update Proceed as follows, unless instructed otherwise by Beckhoff support. Valid for TwinCAT 2 and 3 as EtherCAT master. • Switch TwinCAT system to ConfigMode/FreeRun with cycle time >= 1 ms (default in ConfigMode is 4 ms). A FW-Update during real time operation is not recommended.

  • Page 101: Fpga Firmware *.Rbf

    Appendix • Check the current status (B, C) • Download the new *efw file (wait until it ends). A password will not be necessary usually. • After the download switch to INIT, then PreOP • Switch off the slave briefly (don't pull under voltage!) •...
  • Page 102 Appendix Fig. 80: FPGA firmware version definition If the column Reg:0002 is not displayed, right-click the table header and select Properties in the context menu. Fig. 81: Context menu Properties The Advanced Settings dialog appears where the columns to be displayed can be selected. Under Diagnosis/Online View select the '0002 ETxxxx Build' check box in order to activate the FPGA firmware version display.
  • Page 103 Older firmware versions can only be updated by the manufacturer! Updating an EtherCAT device The following sequence order have to be met if no other specifications are given (e.g. by the Beckhoff support): • Switch TwinCAT system to ConfigMode/FreeRun with cycle time >= 1 ms (default in ConfigMode is 4 ms).
  • Page 104 Appendix • In the TwinCAT System Manager select the terminal for which the FPGA firmware is to be updated (in the example: Terminal 5: EL5001) and click the Advanced Settings button in the EtherCAT tab: • The Advanced Settings dialog appears. Under ESC Access/E²PROM/FPGA click on Write FPGA button: Version: 3.6 EK112x, EK15xx...

  • Page 105: Simultaneous Updating Of Several Ethercat Devices

    Appendix • Select the file (*.rbf) with the new FPGA firmware, and transfer it to the EtherCAT device: • Wait until download ends • Switch slave current less for a short time (don't pull under voltage!). In order to activate the new FPGA firmware a restart (switching the power supply off and on again) of the EtherCAT device is required.

  • Page 106: Support And Service

    Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: www.beckhoff.com You will also find further documentation for Beckhoff components there.
  • Page 108 More Information: www.beckhoff.com/ek1xxx Beckhoff Automation GmbH & Co. KG Hülshorstweg 20 33415 Verl Germany Phone: +49 5246 9630 info@beckhoff.com www.beckhoff.com...
