EPS-ADS
Intel® 12th Fanless Rugged Embedded System
Quick Reference Guide
Ed –03 July 2023
st
1
Copyright Notice
Copyright © 2023 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No. E2017DAR0A0R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPS-ADS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Avalue Technology EPS-ADS

  • Page 1 EPS-ADS Intel® 12th Fanless Rugged Embedded System Quick Reference Guide Ed –03 July 2023 Copyright Notice Copyright © 2023 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017DAR0A0R...
  • Page 2 These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.avalue.com.tw/ 2 EPS-ADS Quick Reference Guide...
  • Page 3: Table Of Contents

    ESPI connector (JESPI1) ...................... 27 2.4.14 Power button (PWRBTN1) ....................27 2.4.15 DC Input connector (JVIN1) ....................28 Installing Hard Disk (EPS-ADS) ................29 Installing PCIE card (EPS-ADS) ................31 Installing M.2 Key-B card (EPS-ADS) ..............32 EPS-ADS Quick Reference Guide...
  • Page 4 EPS-ADS Installing M.2 Key-E card (EPS-ADS) ..............33 Installing M.2 Key-M card (EPS-ADS) ..............34 2.10 Installing Din Rail Mounting (EPS-ADS) .............. 36 3.BIOS Setup ........................37 Introduction ......................38 Starting Setup ...................... 38 Using Setup ......................39 Getting Help......................40 In Case of Problems ....................
  • Page 5 Install VGA Driver ....................71 Install Audio Driver (For Realtek ALC888S HD Audio) ........72 Install LAN Driver ....................73 Install Serial IO Driver ..................75 Install ME Driver ....................76 Install IRST Driver ....................77 EPS-ADS Quick Reference Guide...
  • Page 6: Getting Started

    Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x EPS-ADS Intel® 12th Fanless Rugged Embedded System ⚫ Other major components include the following: ⚫...
  • Page 7: System Specifications

    4 x USB 3.2 Gen.1 (5Gbp/s) (front) USB Port (4 x USB 3.2 Gen.1 from Hub) 6 x COM (front) (4 x RS232/422/485 + 2 x RS232) COM Port (Select via BIOS, auto flow control via HW) EPS-ADS Quick Reference Guide...
  • Page 8 1 x 10/100/1000Base-Tx GbE compatible 2.5G LAN Port (i226-LM) ACT/LINK SPEED Definition Definition LED Indicator Light Off No Link Solid Orange 2.5G Solid Yellow Connection Solid Green 1G/100M Flashing Activity Light Off 1G LAN Port (i219-LM) 8 EPS-ADS Quick Reference Guide...
  • Page 9 Storage: SSD 1. Test Acceleration: 2G Vibration Test 2. Test frequency: 5~500 Hz Sine 3. Sweep:1 Oct/ per one minute. (logarithmic) (non-operation) 4. Test Axis: X, Y and Z axis Test time :30 min. each axis EPS-ADS Quick Reference Guide...
  • Page 10 IP 50 Wall mount kit Mounting Kit DIN RAIL Software Support OS Information Win 10/Win 11 64bit / Linux Certification Certification CE, FCC Class B Information LVD 62368-1 Note: Specifications are subject to change without notice. 10 EPS-ADS Quick Reference Guide...
  • Page 11: System Overview

    Power button 2-Pin Terminal Block Reset Reset button HDD indicator WWAN WWAN Indicator WLAN WLAN Indicator Mic-in Mic-in audio jack Line-out Line-out audio jack USB3.2 USB 3.2 connector x 4 COM1~6 Serial Port 1~6 connector EPS-ADS Quick Reference Guide 11...
  • Page 12 5-pin Phoenix type (default onboard) HDMI HDMI connector x 2 DP connector x 2 RJ-45 Ethernet x 2 USB3.2 USB 3.2 connector x 2 USB2.0 USB 2.0 connector x 2 System Fan Smart Fan connector 12 EPS-ADS Quick Reference Guide...
  • Page 13: System Dimensions

    Quick Reference Guide 1.5 System Dimensions (Unit: mm) EPS-ADS Quick Reference Guide 13...
  • Page 14: Hardware Configuration

    EPS-ADS 2. Hardware Configuration For advanced information, please refer to: 1- EBM-ADS included in this manual. Note: If you need more information, please visit our website: http://www.avalue.com.tw 14 EPS-ADS Quick Reference Guide...
  • Page 15: Eps-Ads Connector Mapping

    In RS-232 Mode Signal PIN PIN Signal NDCD# NDSR# NRXD NRTS# NTXD NCTS# NDTR# NRI# In RS-422 Mode Signal PIN PIN Signal TxD1- TxD1+ RxD1+ RxD1- In RS-485 Mode Signal PIN PIN Signal DATA1- DATA1+ EPS-ADS Quick Reference Guide 15...
  • Page 16: Serial Port 5~6 Connector (Com5~6)

    EPS-ADS 2.1.2 Serial Port 5~6 connector (COM5~6) Signal PIN PIN Signal DCD# DSR# RTS# CTS# DTR# 2.1.3 Power button (EX PWR) Signal PWR_BTN_IN 2.1.4 DC Input connector (DC-IN) Signal VIN+ VIN+ CHASSIS_GND VIN- VIN- 16 EPS-ADS Quick Reference Guide...
  • Page 17: Ebm-Ads Overviews

    Quick Reference Guide 2.2 EBM-ADS Overviews EPS-ADS Quick Reference Guide 17...
  • Page 18: Ebm-Ads Jumper & Connector List

    Reset button JVIN1 DC Input connector 1 x 5 terminal block, pitch 5.08 mm SATA_PWR1 SATA power connector 2 x 1 wafer, pitch 2.00 mm DP connector SATA1 Serial ATA connector 1 NGFF_B_1 M.2 KEY-B connector 18 EPS-ADS Quick Reference Guide...
  • Page 19 Quick Reference Guide NGFF_E_1 M.2 KEY-E connector NGFF_M_1 M.2 KEY-M connector MINI_PCIE1 Full size Mini-PCI-e connector SO_DIMM1/2 DDR5 SODIMM socket 1/2 EPS-ADS Quick Reference Guide 19...
  • Page 20: Setting Jumpers & Connectors

    EPS-ADS 2.4 Setting Jumpers & Connectors 2.4.1 Multi-function select (SW1) SW1.1 AT mode  ATX mode*  *Default SW1.2 M.2 keyB 3.8V  M.2 keyB 3.3V*  20 EPS-ADS Quick Reference Guide...
  • Page 21: Clear Cmos (Jrtc1)

    Quick Reference Guide 2.4.2 Clear CMOS (JRTC1) Normal* Clear CMOS * Default 2.4.3 Serial port 1/2 pin9 signal select (JRI1/2) JRI1 JRI2 Ring* +12V * Default EPS-ADS Quick Reference Guide 21...
  • Page 22: Serial Port 1~4 - Rs232/422/485 Mode Select (Jcom_Sel1~4)

    EPS-ADS Serial port 1~4 – RS232/422/485 mode select (JCOM_SEL1~4) 2.4.4 RS232* JCOM_SEL4 JCOM_SEL1 RS422, RS485 * Default 2.4.5 Fan connector (JFAN1) Signal +12V TACH_FAN0 PWM_FAN0 22 EPS-ADS Quick Reference Guide...
  • Page 23: Serial Port 3/4/5/6 Connector (Jcom3/4)

    In RS-232 Mode Signal PIN PIN Signal NDCD# NDSR# NRXD NRTS# NTXD NCTS# NDTR# NRI# In RS-422 Mode Signal PIN PIN Signal TxD1- TxD1+ RxD1+ RxD1- In RS-485 Mode Signal PIN PIN Signal DATA1- DATA1+ EPS-ADS Quick Reference Guide 23...
  • Page 24: Serial Port 3/4/5/6 Connector (Jcom5/6)

    EPS-ADS 2.4.7 Serial port 3/4/5/6 connector (JCOM5/6) JCOM5 JCOM6 Signal PIN PIN Signal COM_DCD# COM_RXD COM_TXD COM_DTR# COM_DSR# COM_RTS# COM_CTS# COM_RI# 2.4.8 SATA power connector (SATA_PWR1) Signal 24 EPS-ADS Quick Reference Guide...
  • Page 25: On-Board Header For Usb2.0 (Jusb1)

    Quick Reference Guide 2.4.9 On-board header for USB2.0 (JUSB1) Signal PIN PIN Signal +5VSB +5VSB USB_R_DN5 USB_R_DN4 USB_R_DP5 USB_R_DP4 2.4.10 Front Panel connector (JFP1) Signal Signal FP_PWR_LED+ HDD_LED# PWR_LED# PM_SYSRST# PWRBTN_TO_EC# EPS-ADS Quick Reference Guide 25...
  • Page 26: Bios Spi Connector (Bios_Spi1)

    EPS-ADS 2.4.11 BIOS SPI connector (BIOS_SPI1) Signal PIN PIN Signal +3.3VSB SPI_CS0# SPI_CLK SPI_MISO SPI_MOSI BIOS_HOLD# BIOS_WP# 2.4.12 Audio connector (JLIN1) Signal LINE1-R-IN LINE1-L-IN HD_AGND LINE1-JD 26 EPS-ADS Quick Reference Guide...
  • Page 27: Espi Connector (Jespi1)

    Quick Reference Guide 2.4.13 ESPI connector (JESPI1) Signal Signal +3.3VSB ESPI_IO0 PLT_RST# ESPI_IO1 ESPI_CS0# ESPI_IO2 ESPI_CLK ESPI_IO3 ESPI_ALEAT# ESPI_RST 2.4.14 Power button (PWRBTN1) Signal PWR_BTN_IN EPS-ADS Quick Reference Guide 27...
  • Page 28: Dc Input Connector (Jvin1)

    EPS-ADS 2.4.15 DC Input connector (JVIN1) Signal +VIN +VIN GND_CHASSIS 28 EPS-ADS Quick Reference Guide...
  • Page 29: Installing Hard Disk (Eps-Ads)

    Quick Reference Guide 2.5 Installing Hard Disk (EPS-ADS) Step1. Insert and fasten 4 screws on each side of the system to secure brackets. Step2. Fix HDD using the 4 screws in the Accessory Kit. EPS-ADS Quick Reference Guide 29...
  • Page 30 EPS-ADS Step3. Place back the cover and fasten 6 screws back to complete. 30 EPS-ADS Quick Reference Guide...
  • Page 31: Installing Pcie Card (Eps-Ads)

    Quick Reference Guide 2.6 Installing PCIE card (EPS-ADS) Step1. Fasten screw to secure PCIE card. Step2. Place back the cover and fasten 6 screws back to complete. EPS-ADS Quick Reference Guide 31...
  • Page 32: Installing M.2 Key-B Card (Eps-Ads)

    EPS-ADS 2.7 Installing M.2 Key-B card (EPS-ADS) Step1. Insert M.2 Key-B card into designated locations and fasten with the screw to complete installation. 32 EPS-ADS Quick Reference Guide...
  • Page 33: Installing M.2 Key-E Card (Eps-Ads)

    Quick Reference Guide 2.8 Installing M.2 Key-E card (EPS-ADS) Step1. Insert M.2 Key-E card into designated locations and fasten with the screw to complete installation. Step2. Place back the cover and fasten 6 screws back to complete. EPS-ADS Quick Reference Guide 33...
  • Page 34: Installing M.2 Key-M Card (Eps-Ads)

    EPS-ADS 2.9 Installing M.2 Key-M card (EPS-ADS) Step1. Insert M.2 Key-M card into designated locations and fasten with the screw to complete installation. Step2. Fix M.2 M-Key card using the 2 screws in the Accessory Kit. 34 EPS-ADS Quick Reference Guide...
  • Page 35 Quick Reference Guide Step3. Place back the cover and fasten 6 screws back to complete. EPS-ADS Quick Reference Guide 35...
  • Page 36: Installing Din Rail Mounting (Eps-Ads)

    EPS-ADS 2.10 Installing Din Rail Mounting (EPS-ADS) (Horizontal Din Rail) (Vertical Din Rail) Step1. Insert Din Rail into designated locations and fasten with the 4 screws to complete installation. 36 EPS-ADS Quick Reference Guide...
  • Page 37: Bios Setup

    Quick Reference Guide 3.BIOS Setup EPS-ADS Quick Reference Guide 37...
  • Page 38: Introduction

    If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. 38 EPS-ADS Quick Reference Guide...
  • Page 39: Using Setup

    Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “➢” pointer marks all sub menus. EPS-ADS Quick Reference Guide 39...
  • Page 40: Getting Help

    Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 40 EPS-ADS Quick Reference Guide...
  • Page 41: Bios Setup

    <Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. EPS-ADS Quick Reference Guide 41...
  • Page 42: System Language

    Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 42 EPS-ADS Quick Reference Guide...
  • Page 43: Cpu Configuration

    Number of cores to enable in each processor package. Note: Number of Cores and E-cores are Active Performance-cores looked at together. When both are {0,0}, Pcode will enable all cores. Disabled Hyper-Threading Enable or Disable Hyper-Threading Technology. Enabled[Default] EPS-ADS Quick Reference Guide 43...
  • Page 44: Performance-Core Information

    Allows more than two frequency ranges to be Intel® SpeedStep™ Enabled[Default] supported. Enable/Disable intel® Speed Shift Technology Intel® Speed Shift Disabled support. Enabling will expose the CPPC v2 interface Technology Enabled[Default] to allow for hardware controlled P-states. 44 EPS-ADS Quick Reference Guide...
  • Page 45: Pch-Fw Configuration

    C States Disabled CPU to go to C states when it’s not 100% utilized 3.6.2.2 PCH-FW Configuration 3.6.2.2.1 Firmware Update Configuration Item Option Description Disabled[Default], Me FW Image Re-Flash Enable/Disable Me FW Image Re-Flash function. Enabled EPS-ADS Quick Reference Guide 45...
  • Page 46: Ptt Configuration

    3.6.2.3 Trusted Computing Item Options Description Enables or Disables BIOS support for security device. Disable, Security Device Support O.S. will not show Security Device. TCG EFI protocol Enable[Default] and INT1A interface will not be available. 46 EPS-ADS Quick Reference Guide...
  • Page 47: Apci Settings

    Enable Hibernation Enabled[Default], option may not be effective with some Select the highest ACPI sleep state the Suspend Disabled, ACPI Sleep State system will enter when the SUSPEND S3 (Suspend to RAM)[Default] button is pressed. EPS-ADS Quick Reference Guide 47...
  • Page 48: Super Io Configuration

    Set Parameters of Serial Port 3 (COMC). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COMF). 48 EPS-ADS Quick Reference Guide...
  • Page 49: Serial Port 1 Configuration

    Disabled RS232[Default], Set COM Port as RS232, RS422 or UART 232 422 485 RS422 RS485 mode. RS485 3.6.2.5.2 Serial Port 2 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled EPS-ADS Quick Reference Guide 49...
  • Page 50: Serial Port 3 Configuration

    3.6.2.5.3 Serial Port 3 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled RS232[Default], Set COM Port as RS232, RS422 or UART 232 422 485 RS422 RS485 mode. RS485 3.6.2.5.4 Serial Port 4 Configuration 50 EPS-ADS Quick Reference Guide...
  • Page 51: Serial Port 5 Configuration

    Disabled RS232[Default], Set COM Port as RS232, RS422 or UART 232 422 485 RS422 RS485 mode. RS485 3.6.2.5.5 Serial Port 5 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled EPS-ADS Quick Reference Guide 51...
  • Page 52: Serial Port 6 Configuration

    EPS-ADS 3.6.2.5.6 Serial Port 6 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.6 NCT6126D HW Monitor 52 EPS-ADS Quick Reference Guide...
  • Page 53: Smart Fan Mode Configuration

    Select: Mode 01 to Mode 20 10/Mode 11/Mode 12/Mode 13/Mode Or Manual(No Smart Fan). 14/Mode 15/Mode 16/Mode 17/Mode 18/Mode 19/Mode 20 Set Fan Duty SYS Fan Manual Mode Duty Manually(1~255). 3.6.2.7 S5 RTC Wake Settings EPS-ADS Quick Reference Guide 53...
  • Page 54: Serial Port Console Redirection

    Wake system from S5 Fixed Time Select Dynamic Time, System will wake on the current time Dynamic Time + Increase minute(s). 3.6.2.8 Serial Port Console Redirection Item Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled 54 EPS-ADS Quick Reference Guide...
  • Page 55: Usb Configuration

    Auto[Default] Floppy enumerates devices according to their media Mass Storage Devices Forced FDD format. Optical drives are emulated as ‘CDROM’, drives with no media will be Hard Disk CD-ROM emulated according to a drive type. EPS-ADS Quick Reference Guide 55...
  • Page 56: Network Stack Configuration

    EPS-ADS 3.6.2.10 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 3.6.2.11 NVMe Configuration 56 EPS-ADS Quick Reference Guide...
  • Page 57: Chipset

    Quick Reference Guide 3.6.3 Chipset 3.6.3.1 System Agent (SA) Configuration Item Option Description Enabled[Default] VT-d VT-d capability. Disabled EPS-ADS Quick Reference Guide 57...
  • Page 58: Memory Configuration

    3.6.3.1.1 Memory Configuration 3.6.3.1.2 Graphics Configuration Item Option Description Select which of IGFX/PEG/PCI Graphics device Auto[Default] Primary Display should be Primary Display Or select SG for IGFX Switchable Gfx. GTT Size Select the GTT Size. 8MB[Default] 58 EPS-ADS Quick Reference Guide...
  • Page 59: Dmi/Opi Configuration

    Quick Reference Guide 3.6.3.1.3 DMI/OPI Configuration 3.6.3.2 PCH-IO Configuration Item Option Description Disabled PCH LAN Controller Enable/Disable onboard NIC. Enabled[Default] EPS-ADS Quick Reference Guide 59...
  • Page 60: Pci Express Configuration

    EPS-ADS 3.6.3.2.1 PCI Express Configuration 3.6.3.2.1.1 M.2 KeyE (PCI-E Port 1) Item Option Description Enabled[Default], M.2 KeyE (PCI-E Port 1) Control the PCI Express Root Port. Disabled 60 EPS-ADS Quick Reference Guide...
  • Page 61: Mini Card (Pci-E Port 2)

    Disabled[Default] all links to L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. Auto Disabled, L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2[Default] Disabled Enable/Disable Precision Time Enabled[Default] Measurement. EPS-ADS Quick Reference Guide 61...
  • Page 62: Intel I225/I226 Lan Chip (Pci-E Port 4)

    Configure PCIe Speed. Gen2 Gen3 The number of milliseconds reference code will wait for link to exit Detect state for enabled Detect Timeout ports before assuming there is no device and potentially disabling the port. 62 EPS-ADS Quick Reference Guide...
  • Page 63: Keyb (Pci-E Port 5~6)

    Configure PCIe Speed. Gen2 Gen3 The number of milliseconds reference code will wait for link to exit Detect state for enabled Detect Timeout ports before assuming there is no device and potentially disabling the port. EPS-ADS Quick Reference Guide 63...
  • Page 64: Sata Configuration

    The Mode Enable/Disable (Loop Back). Disabled[Default] Enabled[Default] SATA Port Enable or Disable SATA Port. Disabled Hard Disk Drive[Default] Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. 64 EPS-ADS Quick Reference Guide...
  • Page 65: Hd Audio Configuration

    3.6.3.2.3 HD Audio Configuration Item Option Description Control Detection of the HD-Audio device. Disable = HDA Disabled HD Audio will be unconditionally disabled Enabled = HDA will be Enabled[Default] unconditionally enabled 3.6.3.3 Board & Panel Configuration EPS-ADS Quick Reference Guide 65...
  • Page 66: Security

    Disabled[Default] Enabled/Disabled M.2 KeyB 5G Card M.2 KeyB 5G Workaround Enabled Workaround. SUSCLK[Default] PCH GPD8 Set PCH GPD8 funciton for some 5G card. Output low Disabled[Default] SHOW DMI INFO SHOW DMI INFO. Enabled 3.6.4 Security 66 EPS-ADS Quick Reference Guide...
  • Page 67: Secure Boot

    Quick Reference Guide ⚫ Administrator Password Set setup Administrator Password ⚫ User Password Set User Password 3.6.4.1 Secure Boot 3.6.5 Boot EPS-ADS Quick Reference Guide 67...
  • Page 68: Save And Exit

    This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. 68 EPS-ADS Quick Reference Guide...
  • Page 69: Drivers Installation

    Quick Reference Guide 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. EPS-ADS Quick Reference Guide 69...
  • Page 70: Install Chipset Driver

    Windows 11 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Install. Step 4. Click Finish to complete setup. Step1. Click Next. Step 2. Click Accept. 70 EPS-ADS Quick Reference Guide...
  • Page 71: Install Vga Driver

    Windows 11 operation system. Step 3. Click Start. Step 1. Click Begin installation to Step 4. Click Finish to complete setup. continue installation. Step 2. Click I agree. EPS-ADS Quick Reference Guide 71...
  • Page 72: Install Audio Driver (For Realtek Alc888S Hd Audio)

    Windows 11 operation system. If the warning message appears while the installation process, click Continue to go on. Step1. Click Next to Install. Step 2. Select Finish to complete Installation. 72 EPS-ADS Quick Reference Guide...
  • Page 73: Install Lan Driver

    Windows 11 operation system. Step 3. Click Next. Step 1. Click Install Drivers and Step 4. Click Next. Software to continue installation. Step 2. Click Next. Step 5. Click Install. EPS-ADS Quick Reference Guide 73...
  • Page 74 EPS-ADS Step 6. Click Finish to complete setup. 74 EPS-ADS Quick Reference Guide...
  • Page 75: Install Serial Io Driver

    Windows 11 operation system. Step 3. Click Next. Step 1. Click Next to continue setup. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete the setup. EPS-ADS Quick Reference Guide 75...
  • Page 76: Install Me Driver

    Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 3. Click Next Step 4. Click Finish to complete the setup Step 1. Click Next to continue setup. Step 2. Click Next. 76 EPS-ADS Quick Reference Guide...
  • Page 77: Install Irst Driver

    Windows 11 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Complete setup. EPS-ADS Quick Reference Guide 77...
