  • Page 1 SC 70W­A22 English Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 2 Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 3 SC 70W­A22 Original operating instructions Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 4 Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...

  • Page 5: Information About The Documentation

    Information about the documentation About this documentation • Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free handling and use of the product. • Observe the safety instructions and warnings in this documentation and on the product. •...
  • Page 6 Diameter Saw blade Wireless data transfer Li-ion battery Hilti Li-ion battery type series used. Observe the information given in the section headed In- tended use. Product information products are designed for professional users and only trained, authorized personnel are permitted to operate, service and maintain the products. This personnel must be specifically informed about the possible hazards.
  • Page 7 ▶ Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. ▶ Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
  • Page 8 ▶ When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. ▶...
  • Page 9 ▶ When restarting a saw in the workpiece, centre the saw blade in the kerf so that the saw teeth are not engaged into the material. If a saw blade binds, it may walk up or kickback from the workpiece as the saw is restarted.
  • Page 10 ▶ If the battery is too hot to touch it may be defective. In this case, place the power tool in a non- flammable location, well away from flammable materials, where the battery can be kept under observation and allowed to cool down. Contact Hilti Service after the battery has cooled down. Additional safety instructions for circular saws ▶...
  • Page 11 English Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 12 English Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 13 Description Product overview English Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 14 ▶ Do not use the product to cut tree branches or trunks. ▶ Use only Hilti Li­ion batteries of the B 22 series with this product. ▶ Use only Hilti battery chargers of the C4/36 series for charging these batteries.

  • Page 15: Technical Data

    Circular saw, saw blade, hex key, fence, vacuum cleaner hose connector, operating instructions (optional: guide rail adapter) Spare parts, consumables and accessories approved by Hilti for use with the product can be found at your local Hilti Store or online at: www.hilti.group.

  • Page 16: Operation

    Battery Battery operating voltage 21.6 V Ambient temperature for operation −17 ℃ … 60 ℃ Storage temperature −20 ℃ … 40 ℃ Battery charging starting temperature −10 ℃ … 45 ℃ Noise information and vibration values determined in accordance with EN 62841 The sound pressure and vibration values given in these instructions have been measured in accordance with a standardized test and may be used to compare one power tool with another.
  • Page 17 5.1.4 Removing the saw blade WARNING Risk of burning injury. A hot accessory tool, clamping flange or clamping screw and the sharp edges of the saw blade present hazards. ▶ Wear protective gloves when changing saw blades. 1. Remove the battery. 2.
  • Page 18 1. Remove the battery. 2. Clean the mounting flange and the clamping flange. 3. Fit the mounting flange onto the arbor the right way round. 4. Open the pivoting guard. 5. Fit the new saw blade. 6. Install the outer clamping flange the right way round. 7.
  • Page 19 5.1.7 Setting the miter cut angle 1. Remove the battery. 2. Release the cutting angle adjustment clamping lever. 3. Pivot the product into the desired position. The cutting angle preset makes it easy to set the maximum angle (22.5°, 45°, 50°) 4.
  • Page 20 5.1.9 Installing / adjusting the fence 1. Remove the battery. 2. Screw the clamping screw into the base plate, leaving enough space to slide the fence through. 3. Slide the fence guide under the clamping screw. 4. Set the fence to the correct width for the cut. 5.
  • Page 21 5.2.2 Switching off ▶ Release the on/off switch to stop the machine. 5.2.3 Longitudinal cuts at 0° 1. Place the circular saw on the guide rail with the groove marked “0°” on the rib on the rail. 2. While pressing the safety lock, switch the product on by pressing the on/off button. 3.

  • Page 22: Care And Maintenance

    To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare parts, consumables and accessories approved by Hilti for use with the product can be found at your local Hilti Store or online at: www.hilti.group.

  • Page 23: Troubleshooting

    ▶ Check the tool and batteries for damage before use after long periods of storage. Troubleshooting ▶ If the trouble you are experiencing is not listed in this table or you are unable to remedy the problem by yourself, please contact Hilti Service. The circular saw is not in working order Malfunction...
  • Page 24 ▶ Cover the terminals with a non-conductive material (such as electrical tape) to prevent short circuiting. ▶ Dispose of your battery out of the reach of children. ▶ Dispose of the battery at your Hilti Store, or consult your local governmental garbage disposal or public health and safety resources for disposal instructions.

  • Page 25: Rohs (Restriction Of Hazardous Substances)

    There is a link to the RoHS table, in the form of a QR code, at the end of this document. Manufacturer’s warranty ▶ Please contact your local Hilti representative if you have questions about the warranty conditions. English Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 26 English Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 27 Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
  • Page 28 Hilti = registered trademark of Hilti Corp., Schaan 20190409 Printed: 30.04.2019 | Doc-Nr: PUB / 5206173 / 000 / 03...
