4 TECHNICAL DATA

4.1

TECHNICAL SPECIFICATIONS

FREQUENCY
ANTENNA(S)
HOUSING
DIMENSIONS (L X W X H)
POWER
CURRENT CONSUMPTION
TEMPERATURE RANGE
RELATIVE HUMIDITY
READ/WRITE DISTANCE
WEIGHT
4.2

FIRMWARE

The product is delivered ex-works with a specific firmware version. Refer to the label attached to the product to find the firmware
version installed ex-works.
4.3

ANTENNAS

The reader is equipped with the following antenna:
HF antenna (13.56 MHz)
Dimensions: 42 x 44 mm / 1.65 x 1.73 inch
Number of turns: 3
For more information, refer to the related product data sheet or other technical documents.
© 2023 ELATEC GmbH – TWN4 MultiTech 2 HF user manual – DocRev03 – EN – 07/2023
13.56 MHZ (HF)
Integrated
Material: ABS UL94-V0
Color: black or white
Approx. 88.00 x 56.00 x 18.50 mm / 3.46 x 2.20 x 0.73 inch
USB: 4.3 V - 5.5 V
RS-232: requires 5 V external power supply
PS2 classified power source according to IEC 62368-1, short-circuit current < 8 A
RF field on: 200 mA typically
Operating: -25 °C up to +70 °C (-13 °F up to +158 °F)
Storage: -40 °C up to +75 °C (-40 °F up to +167 °F)
5% to 95% non-condensing
Up to 100 mm / 4 inch, depending on environment and transponder
Approx. 115 g / 4.06 oz (with cable)
