Teknim TFB-1166 Installation & User Manual page 4

TFP-211X
TFP-121X
TEST
1) In the first case press in the
middle point of Manual Call Point
FEATURES
Nominal
Supply
Model Operating
Voltage
Voltage
TFB
24 VDC 15-32 VDC
1166
MANUFACTURER AND SERVICE
Bilgi Elektronik San. ve Tic. A.Ş.
Dudullu Organize Sanayi Bölgesi 1.Cadde İsmet Tarman İş Merkezi
No:1 Daire:32 Ümraniye-İSTANBUL
Telephone: +90 216 455 88 46 Fax: +90 216 455 99 06
www.bilgielektronik.com.tr
* 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information see: www.recyclethis.info.
The product only works with TFP-121X, TFP-211X and TFP-213X
TFP-213X
2) Alarm status is observed in Fire
Panel. In this case, the LED on the
button will turn solid RED.
Average /
Cable
Alarm
Selection
Consumption
Between
100uA. /
0.8 mm² to
4,5mA.
2.5 mm²
sales@bilgielektronik.com.tr
IMPORTANT WARNING!
Intelligent Addressable Fire Alarm panels.
3) Insert the key, push it upwards and observe
that the panel is reset after resetting the
button. In this case, the LED on it starts
flashing Blue light at 20 seconds intervals.
Temperature and
Type of Frangible Element
Humidity
A, Indoor Usage
-10 ~ +70
(Surface + Under Surface
≤93% @ +40°C
support@bilgielektronik.com.tr
Body Material,
Dimensions,
Weight
RED ABS
86x55x88mm
Mounted)
146 gr
