TFP-312x Series Conventional Fire Alarm Panels

Conventional Fire Alarm Panels

Installation & User Manual

TFP-312X INSTALLATION & USER MANUAL

* Sub Models

TFP-3122

TFP-3124

TFP-312x Series

Release Date: 05/12/2022

Rev. Date: 31/07/2024 – Rev. No:04

Doc. Ref.: HM.Z.KLV.7639

2-Zone Conventional Fire Alarm Panel

4-Zone Conventional Fire Alarm Panel

Table of Contents

Need help?

Do you have a question about the TFP-312 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Teknim TFP-312 Series

Page 1 TFP-312x Series Conventional Fire Alarm Panels TFP-312x Series Conventional Fire Alarm Panels Installation & User Manual Release Date: 05/12/2022 Rev. Date: 31/07/2024 – Rev. No:04 Doc. Ref.: HM.Z.KLV.7639 TFP-312X INSTALLATION & USER MANUAL * Sub Models TFP-3122 2-Zone Conventional Fire Alarm Panel TFP-3124 4-Zone Conventional Fire Alarm Panel...
Page 2: Table Of Contents
TFP-312x Series Conventional Fire Alarm Panels Table of Contents Introduction ........................3 Warnings ........................3 Technical Specifications ....................4 TFP-312X Series Conventional System ................. 5 Panel Properties ..................... 5 Panel User Interface ....................6 Installation ........................10 Recommended Cables ..................10 Mounting ......................
Page 3 TFP-312x Series Conventional Fire Alarm Panels 10 Manufacturer and Service ................... 18 11 Appendices ........................20 11.1 Appendix-Mechanical ................... 20 11.2 Appendix-Electrical ....................25 11.3 Appendix-Level ..................... 26 11.4 Appendix-Communication ..................27 11.4.1 Connection of ETHERNET Communication Module ........27 11.4.2 Connection of LTE Communication Module ...........
Page 4: Introduction
This manual contains the installation instructions, technical properties and panel configuration information related to TFP-312x Series Teknim Conventional Panels. TFP-312x Teknim conventional panels may be viewed under 2 options as 2 or 4 zone devices. 32 detectors or fire alarm buttons can be connected per zone.
Page 5: Technical Specifications
TFP-312x Series Conventional Fire Alarm Panels Technical Specifications Supply Voltage 230 / 110 VAC (+%10 /-%15) Frequency 50 / 60 Hz (±%5) Main Input Fuse Output Voltage 24 Vdc ± %2 Output Fuse 1.5A Cable Type 3 x 1,5mm² (Phase, Neutral, Earth) 1 x 12V, 7Ah dry type leak-proof Battery (Recommended Yuasa NP7-12, 12V7Ah)
Page 6: Tfp-312X Series Conventional System
TFP-312x Series Conventional Fire Alarm Panels TFP-312X Series Conventional System TFP-312x series conventional systems are fire detection systems, which are designed with 2 or 4 zones and in which 32 detectors or fire alarm buttons can be connected per zone. The system also provides features like 2 supervised siren outputs, 1 dry contact fault relay, 1 dry contact alarm relay, and 1 x 24 AV AUX output.
Page 7: Panel User Interface
TFP-312x Series Conventional Fire Alarm Panels Panel User Interface This chapter describes the indicators and buttons on the panel. Figure 1 Control Panel User Interface All buttons have multiple functions as shown in the figure titled “Control Panel User Interface”. These functions vary according to the access level, the mode of the panel, and the amount of pressing the button.
Page 8 TFP-312x Series Conventional Fire Alarm Panels Table 1 Main Button Functions Access Level 1 Button Engineering Mode Normal Short Long Short Long Access level 2 and engineering mode is Alarm On/Off Used for number 1. entered to start evacuation. Silence Used for number 2.
Page 9 TFP-312x Series Conventional Fire Alarm Panels Panel fault and alarm states are provided with led indicators. There is an internal buzzer for audible warning. LEDs and buzzer can be tested without level switching. The table titled “Led Indicators” explains the functions of the LEDs on the panel. Table 2 LED Indicators Blink Colour...
Page 10 TFP-312x Series Conventional Fire Alarm Panels Fault / Disable / Test LEDs of the siren and zones have different LED indicators in different modes of the system. Indicator information of these LEDs is explained in the table titled "Special LED Indicators". Table 3 Special LED Indicators Normal Blink...
Page 11: Installation
TFP-312x Series Conventional Fire Alarm Panels Installation This chapter describes the mechanical and electrical connection methods for TFP-312x series panels. Caution: Do not start mounting before having read the entire manual! Recommended Cables It is recommended that cables with the properties described in "Table 4 Properties of the Recommended Cables"...
Page 12: Battery Charge Voltage Check
Zone Lines TFP-312x Teknim conventional panels may be viewed under 2 options as 2- or 4-zone devices. Detection circuits provide power (24 VDC) to the detectors and buttons and at the same time ensures that signals like fire alarm, short circuit, and broken line are transmitted to the panel Maximum 32 detectors or alarm buttons can be connected to a zone line.
Page 13: User Levels
TFP-312x Series Conventional Fire Alarm Panels User Levels Some features of the panel are restricted with user levels and the panel has 4 user levels. Level 1 Level 1 is defined as the predefined user level with the most basic features. When the Access Level LED is off, Level 1 is entered.
Page 14: Using Panel
TFP-312x Series Conventional Fire Alarm Panels Using Panel In this chapter, information on using the panel is given. Disable Mode Disable mode is used to isolate an unused zone or siren from the system. Disable mode settings can be adjusted from access levels-2, 3 and 4. In order to deactivate a zone or a siren, "Disable"...
Page 15: Siren Resound Option
Restore access level to 1. System Error TFP-312x Teknim conventional panels are microcontroller-based systems. As per EN54-2 Article 13.3, the microcontroller is controlled by another completely independent system. In the case that the microcontroller fails to carry out program flow for any reason, the panel automatically takes itself into secure status.
Page 16: Operation Codes
TFP-312x Series Conventional Fire Alarm Panels Open-circuit or short-circuit faults of the zones that might occur in installation is shown in more detail by the panel for the convenience of the installer. When the "Enter" button is pressed, the panel shows the details of the zone faults in more detail for 3 seconds.
Page 17: Adding The Panel To The Mobile App
Following step must be applied to add the panel to the mobil app. 1. Download the Teknim mobil app from GooglePlay or AppStore. 2. After opening the application, click on the "register" option that appears on the screen and fill in the required fields.
Page 18: Maintenance
TFP-312x Series Conventional Fire Alarm Panels Maintenance Maintenance and repair on Teknim TFP-312x series fire systems should be carried out by authorize people in accordance with the instructions. Situations Requiring Maintenance, Repair or Servicing In case of malfunction or in the following situations, contact your dealer or authorized service station.
Page 19: Issues To Be Considered
The device should be carried carefully so as not to subject it to any external impacts and to prevent liquid penetration. Malfunctions arising due to improper handling are outside the scope of warranty. 10 Manufacturer and Service Teknim Elektronik San. ve Tic. A.Ş. Dudullu Organize Sanayi Bölgesi 1.Cadde İsmet Tarman İş Merkezi No:1 Daire:32 Ümraniye-İSTANBUL Telephone: +90 216 455 88 46 Fax: +90 216 455 99 06 www.teknim.com...
Page 20 TFP-312x Series Conventional Fire Alarm Panels 1922 Teknim Elektronik San. ve Tic. A.Ş. Dudullu Organize Sanayi Bölgesi 1.Cadde İsmet Tarman İş Merkezi No:1 Daire:32 Ümraniye-İSTANBUL 1922-CPR-1994 1922-CPR-1995 EN 54-2:1997, EN 54-2:1997/AC:1999, EN 54-2:1997, EN 54-2:1997/AC:1999, EN 54-2:1997/A1:2006 EN 54-2:1997/A1:2006 Control and indicating equipment for fire detection...
Page 21: Appendices
TFP-312x Series Conventional Fire Alarm Panels 11 Appendices The Appendices are divided into 5 categories a Mechanical, Electrical, Level, Communication and Maintenance Tables. 11.1 Appendix-Mechanical Figure 2 Panel Front Cover Screws Front cover mounting screw. TFP-312X INSTALLATION & USER MANUAL...
Page 22 TFP-312x Series Conventional Fire Alarm Panels 220mm Figure 3 Mounting Screw Holes Mounting Screw Hole TFP-312X INSTALLATION & USER MANUAL...
Page 23 TFP-312x Series Conventional Fire Alarm Panels SMPS BRACKET Figure 4 Bracket Mounting SMPS is under the bracket. Unscrew the bracket to reach the SMPS. ✓ TFP-312X INSTALLATION & USER MANUAL...
Page 24 TFP-312x Series Conventional Fire Alarm Panels Figure 5 Electrical Connections Battery Connection Connector. Main Supply Connector 195~250VAC 50Hz. SMPS Connector. Button for Startup from battery. Main Fuse 2A. Neutral (N) ⏚ Earth ( Phase (L) Earth Connector. TFP-312X INSTALLATION & USER MANUAL...
Page 25 TFP-312x Series Conventional Fire Alarm Panels Battery Pole BAT. To the Battery Connector Figure 6 Battery Connections ✓ Secure the battery to the panel using the battery cable bel shown in B1. ✓ B2 and B3 are connected to the B4 battery supply socket with the battery supply cable. ✓...
Page 26: Appendix-Electrical
TFP-312x Series Conventional Fire Alarm Panels 11.2 Appendix-Electrical The panel has 1 siren outputs of 24VDC 300mA with automatic return and fuse protection. It is necessary to use a 4.7K resistor as the end-of-line resistor. FIRE ALARM BUTTON LOAD 150 Ohm 1W Base MCP Alarm 4.7KΩ...
Page 27: Appendix-Level
TFP-312x Series Conventional Fire Alarm Panels 11.3 Appendix-Level Figure 8 Access Level-3 Access Level-3 Activation Key (Turn the switch to the "1" position) Computer Communication Connector Hardware Reset TFP-312X INSTALLATION & USER MANUAL...
Page 28: Appendix-Communication
TFP-312x Series Conventional Fire Alarm Panels 11.4 Appendix-Communication 11.4.1 Connection of ETHERNET Communication Module D1 and D3 connectors are connected using the flat cable above. Figure 9 ETHERNET Communication Module Connection connector of the communication modules with the panel RJ45 conncetor for internet connection Panel connector TFP-312X INSTALLATION &...
Page 29: Connection Of Lte Communication Module
TFP-312x Series Conventional Fire Alarm Panels 11.4.2 Connection of LTE Communication Module D1 and D3 connectors are connected using the flat cable above. Figure 10 LTE Communication Module Connection connector of the communication modules with the panel SIM card slot D3 Panel connection connector GSM antenna connection connector TFP-312X INSTALLATION &...
Page 30: Qr Code
TFP-312x Series Conventional Fire Alarm Panels 11.4.3 QR Code Figure 11 QR Code Mobile App QR Code. TFP-312X INSTALLATION & USER MANUAL...
Page 31: Appendix-Maintenance Table
TFP-312x Series Conventional Fire Alarm Panels 11.5 Appendix-Maintenance Table Date Tested Device Device Position Remarks TFP-312X INSTALLATION & USER MANUAL...
Page 32 TFP-312x Series Conventional Fire Alarm Panels Date Tested Device Device Position Remarks TFP-312X INSTALLATION & USER MANUAL...
Page 33 TFP-312x Series Conventional Fire Alarm Panels Date Tested Device Device Position Remarks TFP-312X INSTALLATION & USER MANUAL...
