Scout Boats 530 LXF Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
530 LXF
Owner's Manual
Scout Boats Inc.
2531 Hwy 78 West
Summerville, SC 29483
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 530 LXF and is the answer not in the manual?

Questions and answers

Related Manuals for Scout Boats 530 LXF

Summary of Contents for Scout Boats 530 LXF

  • Page 1 530 LXF Owner’s Manual Scout Boats Inc. 2531 Hwy 78 West Summerville, SC 29483...
  • Page 2 Rev 0 Print Date 06/09/20...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ......................7 BOAT INFORMATION ......................9 SPECIFICATIONS .......................10 CERTIFICATIONS & SPECIFICATIONS ...................11 OWNER’S / OPERATOR’S INFORMATION ................13 SCOUT LIMITED WARRANTY ....................15 SCOUT WARRANTY REGISTRATION TRANSFER ..............17 Chapter 1: SAFETY EQUIPMENT 1.1 General ........................19 1.2 Engine Alarms ......................19 1.3 Neutral Safety Switch ....................19 1.4 Engine Stop Switch .....................19 1.5 Required Safety Equipment ..................20...
  • Page 4 TABLE OF CONTENTS Chapter 4: HELM CONTROL SYSTEMS 4.1 General ........................45 4.2 Engine Throttle & Shift Controls ..................45 4.3 Neutral Safety Switch ....................48 4.4 Engine Power Tilt & Trim ....................48 4.5 Engine Stop Switch .....................49 4.6 Steering System ......................50 4.7 Joystick Controls ......................51 4.8 Trim Tabs ........................52 4.9 Bow Thruster (Optional) ....................53 4.10 Control Systems Maintenance ..................54...
  • Page 5 TABLE OF CONTENTS Chapter 8: RAW WATER SYSTEM 8.1 General ........................99 8.2 Raw Water System Operation ..................100 8.3 Baitwell ........................101 8.4 Air Conditioner Cooling Pump ..................102 8.5 SeaKeeper Cooling Pump ...................102 8.6 Generator Raw Water Supply ..................102 8.7 Raw Water System Maintenance ..................103 Chapter 9: DRAINAGE SYSTEMS 9.1 General ........................105...
  • Page 6 TABLE OF CONTENTS Chapter 13: ROUTINE MAINTENANCE 13.1 Exterior Hull and Deck .....................145 13.2 Upholstery, Canvas and Enclosures ................148 13.3 Interior .........................150 13.4 Engines & Fuel ......................150 13.5 Bilge ........................151 13.6 Drainage System .....................151 Chapter 14: SEASONAL MAINTENANCE 14.1 Storage and Lay-up ....................153 14.2 Freshwater System Winterizing .................155 14.3 Raw Water System Winterizing ..................156 14.4 Drainage &...

  • Page 7: Safety Information

    SAFETY INFORMATION Your Scout manual has been written to include a number of safety instructions to assure the safe op- eration and maintenance of your boat. These instructions are in the form of CAUTION, WARNING, DANGER and NOTICE statements. The following definitions apply: CAUTION HAZARDS OR UNSAFE PRACTICES WHICH COULD RESULT IN MINOR PERSONAL INJURY OR PRODUCT AND PROPERTY...
  • Page 8 S.O.S SAVE OUR SEAS S.O.S SAVE OUR SEAS Scout Boats has made a commitment to quality since the very begin- Scout Boats has made a commitment to quality since the very begin- ning. More importantly, we’ve also made a commitment to saving our ning.

  • Page 9: Boat Information

    BOAT INFORMATION Please fill out the following information section and leave it in your Scout Owner’s Manual. This in- formation will be important for you and Scout service personnel to know, if and when you may need to call Scout for technical assistance or service. BOAT MODEL: HULL SERIAL #:...

  • Page 10: Specifications

    SPECIFICATIONS Hull Length Overall ___________________________________________________ 53’ / 16.2 m Beam ____________________________________________________________ 14’ 8” / 4.47 m Dry Weight ____________________________________________________26,500lbs / 12,020 kg Dry Weight W/ Quint Yamaha 300’S (approx) ________________________18,200 lbs / 8,255 kg Dry Weight W/ Quad Yamaha 425’S (approx) ________________________31,500 lbs / 14,288 kg Dry Weight W/ Quint Mercury 400’S (approx) ________________________29,935 lbs / 13,578 kg Main Engine Fuel Tank Capacity _____________________________________ 875 gal / 3312.24 ltr Generator Diesel Fuel Tank Capacity __________________________________ 80 gal / 302.8 ltr...

  • Page 11: Certifications & Specifications

    To be in compliance with European directives for recreational boats as published by the Interna- tional Organization for Standardization (ISO) in effect at the time this boat was manufactured, we are providing the following information. Manufacturer: Scout Boats Name: 2531 Hwy 78 West Address:...
  • Page 12 NOTES...

  • Page 13: Owner's / Operator's Information

    OWNER’S / OPERATOR’S INFORMATION Warranty and Warranty Registration Cards The Scout Limited Warranty Statement is included with your boat. It has been written to be clearly stated and easily understood. If you have any questions after reading the warranty, please con- tact Scout Customer Service.
  • Page 14 • If you are away from home, or your selling as outlined in the Scout Boats Limited Warranty dealer is not an authorized Yamaha dealer, Statement. use the following toll-free numbers to find the nearest Yamaha dealer.

  • Page 15: Scout Limited Warranty

    (10) Any Scout Boat with a jack plate installed by anyone other than Scout boats, Inc., or an authorized dealer, or on any hull other than the 191, 201, 221, or 251 models. Any Scout Boat with a jack plate of 8”...
  • Page 16 Scout Boats, Inc. within 10 days of sale of his/her boat to the new owner. A notarized bill of sale and a $100 administration fee payable to Scout Boats, Inc.

  • Page 17: Scout Warranty Registration Transfer

    SCOUT WARRANTY REGISTRATION TRANSFER ARRANTY  EGISTRATION  RANSFER DATE  ____________________________  HULL IDENTIFICATION NO. SLP ____________________________________________________________  DATE OF PURCHASE  ____________________________________________________________________  NEW OWNER’S NAME  __________________________________________________________________  ADDRESS _____________________________________________________________________________  CITY  _____________________________________________  STATE____________  ZIP___________  EMAIL ________________________________________  PHONE  _______________________________  BRAND OF ENGINE_________________________________  HORSEPOWER______________________  I agree to the warranty terms and conditions pursuant to my particular model year boat.  ______________________________________________  SIGNATURE  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  PREVIOUS OWNER’S NAME  _____________________________________________________________  ADDRESS  ____________________________________________________________________________  CITY ______________________________________________  STATE_____________  ZIP__________  EMAIL  ________________________________________  PHONE  ______________________________  ORIGINAL DATE OF PURCHASE ...
  • Page 18 NOTES...

  • Page 19: Safety Equipment

    Chapter 1: SAFETY EQUIPMENT 1.1 General Your boat and outboard engines have been equipped with safety equipment designed to en- hance the safe operation of the boat and to meet U.S. Coast Guard safety standards. The Coast Guard or state, county and municipal law enforce- ment agencies require certain additional accessory safety equipment on each boat.

  • Page 20: Required Safety Equipment

    Safety Equipment Visual Distress Signals Notice: You should carry an extra stop switch lan- All boats used on coastal waters, the Great Lakes, yard and instruct at least one other crew territorial seas and those waters connected di- member on the operation of the stop switch rectly to them, must be equipped with Coast Guard and location of the extra lanyard.

  • Page 21: Bilge & Fuel Fires

    Safety Equipment • Electric Distress Light (Night use only) Refer to the “Federal Requirements And Safety The electric distress light is accepted for Tips For Recreational Boats” pamphlet or Contact night use only and must automatically flash the U.S. Coast Guard Boating Safety Hotline, the international SOS distress signal.

  • Page 22: Carbon Monoxide Monitoring System

    Safety Equipment 1.7 Carbon Monoxide Monitoring System DANGER CARBON MONOXIDE IS COLORLESS, ODORLESS AND DANGEROUS. ALL ENGINES, GENERATORS AND FUEL BURNING APPLIANCES EXHAUST CARBON MONOXIDE (CO). DIRECT AND PROLONGED EXPOSURE TO CO WILL CAUSE BRAIN DAMAGE OR DEATH. SIGNS OF EXPOSURE TO CO INCLUDE NAUSEA, DIZZINESS AND DROWSINESS.

  • Page 23: First Aid

    Safety Equipment Typical First Aid Kit Never disable the CO detector because you think 1.8 First Aid the alarm may be false. Always contact the detec- It is the operator’s responsibility to be familiar tor manufacturer or your local fire department for with the proper first-aid procedures and be able assistance in finding and correcting the situation.

  • Page 24: Additional Safety Equipment

    Safety Equipment Marine Radio In many emergency situations, the Coast Guard can provide assistance in obtaining medical advice A marine radio is the most effective method of for treatment of serious injuries or illness. If you receiving information and requesting assistance. are within VHF range of a Coast Guard Station, VHF marine radios are used near shore and single make the initial contact on channel 16 and follow...
  • Page 25 Safety Equipment 1.10 Caution & Warning Labels The caution and warning labels shown are examples of the labels that could be on your boat. The actual labels and their location could vary on your boat. 420 LXF Schematics WARNING LEAKING FUEL IS A FIRE AND EXPLOSION HAZARD.
  • Page 26 NOTES...

  • Page 27: Operation

    Chapter 2: OPERATION boat as well. Always modify the boat speed in ac- 2.1 General cordance with the sea conditions, boat traffic and Before you start the engines on your Scout, you weather conditions. should have become familiar with the various component systems and their operation and have Remember, it is the operator’s responsibility to performed a “Pre-Cruise System Check.”...
  • Page 28 Operation Overtaking Situations When one motor boat is overtaking another mo- tor boat, the boat that is being passed has the right-of-way. The overtaking boat must make the adjustments necessary to provide clearance for a safe passage of the other vessel. The boats should sound the appropriate signals.
  • Page 29 Operation...

  • Page 30: Pre-Cruise Check

    Operation • Have a tool kit aboard. The kit should include 2.3 Pre-Cruise Check the following basic tools: Before Starting the Engines: • Check the weather forecast and sea conditions Hammer Electrician’s tape before leaving the dock. Decide if the planned cruise can be made safely.

  • Page 31: Operating Your Boat

    Operation 2.4 Operating Your Boat WARNING After Starting the Engines: DO NOT OPERATE THE BOAT UNLESS IT IS COMPLETELY • Visibly check the engines to be sure there are A S S E M B L E D. K E E P A L L FA S T E N E R S T I G H T. K E E P no apparent water, fuel or oil leaks.

  • Page 32: Docking, Anchoring & Mooring

    Operation • As different types of engines are used to • Turn off all electrical equipment except the power the boat, have the dealer describe the automatic bilge pumps. operating procedures for your boat. For more • If you are going to leave the boat for a long instructions on “How To Operate The Boat,”...
  • Page 33 Operation Maneuvering to a Dock or Slip Notice: Your boat is equipped with triple or quad After Bow Spring Cleat Stern Cleat engines and electronic control systems. Bow Cleat Depending on the control system options selected, the following conditions could apply that will affect the handling of your boat as you maneuver to the dock: Securing The Boat Along Side A Dock (Typical)
  • Page 34 Operation Securing Dock Lines untie it. Back the boat away from the mooring until you can see the buoy. Move the boat slowly Securing a boat that is tied along side the dock away from the mooring. typically requires a bow and stern line and two spring lines.

  • Page 35: Controls, Steering Or Propulsion System Failure

    FOLLOW THE EMERGENCY PROCEDURES RECOMMENDED DANGER BY THE ENGINE MANUFACTURER. THE MOORING CLEATS ON SCOUT BOATS ARE NOT DESIGNED OR INTENDED TO BE USED FOR TOWING PURPOSES. THESE CLEATS ARE SPECIFICALLY DESIGNED AS MOORING CLEATS FOR SECURING THE BOAT TO A DOCK, PIER, ETC. DO NOT USE THESE FITTINGS FOR TOWING OR ATTEMPTING TO FREE A GROUNDED VESSEL.

  • Page 36: Flooding Or Capsizing

    Operation boat and the safety of your passengers and other WARNING boats in the area. WHEN TOWING OPERATIONS ARE UNDERWAY, HAVE You must always make sure the helm is properly EVERYONE ABOARD BOTH VESSELS STAY CLEAR OF THE TOW manned and is never left unattended while trolling. LINE AND SURROUNDING AREA.

  • Page 37: Teak Surfing

    Operation The following is a list of safety precautions WARNING for tower operation: • Do not operate the boat from the tower in GOOD COMMON SENSE, JUDGMENT AND EXTREME CAUTION MUST BE EXERCISED WHEN OPERATING A BOAT WITH rough sea conditions. The boat’s motions are SOMEONE IN THE TOWER.

  • Page 38: Trash Disposal

    TRAILER BUNKS AND PADS ARE ADJUSTED SO THEY ARE NOT PUTTING EXCESSIVE PRESSURE ON THE LIFTING STRAKES You should contact your dealer or the Scout Boats AND ARE PROVIDING ENOUGH SUPPORT FOR THE HULL. HULL DAMAGE RESULTING FROM IMPROPER TRAILER SUPPORT IS Customer Service Department if you are planning NOT COVERED BY THE SCOUT WARRANTY.

  • Page 39: Propulsion System

    Chapter 3: PROPULSION SYSTEM 3.1 General Your Scout is designed to be powered with 4-cycle outboard motors. Each engine is equipped with an oil sump in the crankcase that must be kept full of the type of oil recommended by the engine manufacturer.

  • Page 40: Engine Lubrication

    Propulsion System tors as high as possible. This will decrease the CAUTION risk of marine growth around the cooling inlets, propeller and exhaust ports and damage from NEVER RUN AN OUTBOARD MOTOR WITHOUT WATER galvanic corrosion. FLOWING TO THE WATER PUMP. SERIOUS DAMAGE TO THE WATER IMPELLER OR ENGINE COULD RESULT.
  • Page 41 Propulsion System Notice: Before changing propellers to correct boat performance problems, be sure other factors such as engine tuning, bottom and running gear growth, etc. are not the source of per- formance changes. Always be sure the load conditions are those normally experienced, before changing propellers.

  • Page 42: Engine Instrumentation

    Some or all of the following gauges may be save them from serious costly damage. present. Most Scout boats are equipped with Yamaha en- Tachometers gines and Command Link Plus LCD multifunction ®...
  • Page 43 Propulsion System Speedometer Yamaha Command Link Plus speedometers can ® indicate boat speed via the engine pickup or an optional GPS or depth sounder triducer, if these options are installed in your boat. Refer to the engine gauge and electronics operating manuals for more information on the speedometer options available for your boat.
  • Page 44 Propulsion System Compass All boats are equipped with a compass on the top of the instrument panel. The compass cannot be adjusted accurately at the factory as it must be compensated for the influence of the electrical equipment and electronics unique to your boat. Therefore, the compass should be adjusted by a professional after the electronics and additional electrical accessories are installed and before op-...

  • Page 45: Helm Control Systems

    Chapter 4: HELM CONTROL SYSTEMS 4.1 General The helm controls consist of three systems: the engine throttle and shift controls, the steering system and the trim tab control switches. These systems provide the operator with the ability to control the direction and attitude of the boat from the helm station.
  • Page 46 NOTES...
  • Page 47 Helm Control Systems The most common features activated or monitored by the keypad are: • Starter lockout, which prevents the engine from being started in gear. • Gear lockout, which allows engine RPM to be advanced in neutral safely. • Battery voltage warning indicator that warns the operator of high or low voltage supplied to the system (audible alarm).

  • Page 48: Neutral Safety Switch

    4.3 Neutral Safety Switch Every control system has a neutral safety switch incorporated into it. This device prohibits an en- gine from being started while the shift lever is in any position other than the neutral position. If the engine will not start, slight movement of the shift lever may be necessary to locate the neutral position and disengage the safety cutout switch.

  • Page 49: Engine Stop Switch

    Helm Control Systems of the outboards within the first 20 range of travel. This is the range used while operating your boat on plane. The term “tilt” is generally used when referring to adjusting the outboards further up for shallow water operation or trailering. Some control systems provide a means to set the engine trim angle to automatically adjust accord- ing to the engine speed.

  • Page 50: Steering System

    4.6 Steering System Power Assist Hydraulic Steering Power assisted steering systems on triple engine boats without the joystick option are hydraulic and comprised of two hydraulic circuits: a manual sys- tem, which is the control element and a hydraulic power assist pump, which is the working element. The manual system is hydraulic and made of three main components: the helm assembly, hydraulic hoses and the steering cylinders.

  • Page 51: Joystick Controls

    Helm Control Systems Typical Yamaha Quint Engine Electronic Controlled Steering For safety and improved tight quarter maneuver- ing, the controlling software on most systems senses engine speed and adjusts maximum steer- ing angle and steering wheel resistance to preset limits as the engine speed increases or decreases. The steering angles and steering wheel resistance at specific engine speeds are programed into the system at the factory and are not adjustable.

  • Page 52: Trim Tabs

    boat moves in the direction the joystick is pushed with the engine speed increasing the further the stick is pushed, up to preset limits. Turning the knob on the top of the joystick rotates the boat in the direction the knob is turned. Another button on the joystick or engine control key pad raises the preset engine speed for maneuvering in high winds and/or strong tides.

  • Page 53: Bow Thruster (Optional)

    Helm Control Systems side to side running attitude being careful not to over trim. After depressing a trim tab switch, always wait a few seconds for the change in the trim plane to take effect. Avoid depressing the switch while awaiting the trim plane reaction.

  • Page 54: Control Systems Maintenance

    systems may need to have all air purged from 4.10 Control Systems Maintenance the system. Only use hydraulic steering fluid Control Maintenance recommended by the steering system manu- Periodic inspection of the control systems and all facturer. Difficult steering and premature seal connections should be made.
  • Page 55 Helm Control Systems and clean marine growth from the actuators and planes. There is a single Trim Tab Hub in the aft starboard section of the bilge (shown to the right). Each trim tab has its own control wire that runs to its respective location on the control hub shown in the attached picure.
  • Page 56 NOTES...

  • Page 57: Fuel System 5.1 General

    Chapter 5: FUEL SYSTEM 5.1 General The Gasoline fuel system used in Scout boats is designed to meet or exceed the emission control standards of the Environmental Protection Agency (EPA) and the requirements of the U.S. Coast Guard, the Boating Industry Association and the American Boat and Yacht Council in effect at the time of manufacture.

  • Page 58: Outboard Fuel System

    Fuel System Fuel Tank Vent Each fuel tank is equipped with a fuel tank vent system incorporated into each fuel fill. The fuel fill cap is designed to seal out water and allow the fuel tank to vent to the atmosphere when the cap is closed.
  • Page 59 NOTES...

  • Page 60: Diesel Generator Fuel System

    Fuel System 5.3 Diesel Generator Fuel System The diesel fuel system for the generator is com- pletely separate from the gasoline system. The port and star oard diesel fuel tanks are located under the deck on the port and star oard side of the console and each ha e their own inspection ports The diesel fuel system is not equipped with an anti-siphon valve and there is a fuel return line...

  • Page 61: Fueling Instructions

    5.4 Fueling Instructions WARNING WARNING GASOLINE FUEL VAPORS THAT ACCUMULATE IN THE BILGE, AFT SYSTEMS ROOM, ELECTRICAL SYSTEMS ROOM OR CABIN WHILE FUELING CAN EXPLODE!! FUEL VAPORS FUEL IS VERY FLAMMABLE. BE CAREFUL WHEN FILLING ARE HEAVIER THAN AIR AND CAN ACCUMULATE IF THEY THE FUEL TANKS.

  • Page 62: Fuel System Maintenance

    Fuel System To fill the fuel tank, follow this procedure: 5.5 Fuel System Maintenance • The fuel caps are threaded or hinged and do Outboard Gasoline Fuel System not require a key. Press the release button on Periodically inspect all primer bulbs, connections, the side of hinged caps and swing it open or clamps and hoses for leakage, damage or deterio- twist the threaded caps counterclockwise until...
  • Page 63 Diesel Generator Fuel System WARNING Algae can grow in the accumulated water in die- sel fuel tanks. This condition is most prevalent in DO NOT DRAIN ANY FUEL INTO THE BILGE WHEN SERVICING warm climates. Periodically adding a high quality THE FUEL SYSTEM.
  • Page 64 NOTES...

  • Page 65: Electrical System

    Chapter 6: ELECTRICAL SYSTEM 6.1 General Scout Boats Marine Standard Wiring Code Your Scout is equipped with 120 volt AC and 12 volt DC electrical systems. The AC system can COLOR draw current from one of two sources, either shore...

  • Page 66: Batteries And Battery Switches

    Electrical System Electrical Systems Room & Battery Switch Panel behind Port Aft Facing Seat boxes on each side of the aft systems room. These 6.3 Batteries and Battery Switches circuit breakers protect the electronic steering and The DC electrical system on your boat is designed auxiliary engine charging circuits for each engine.
  • Page 67 Electrical System Quint Engine Battery Switch Panel, Motorized Battery Switches, Remote Battery Switches, Parallel Switches & Circuit Breakers There are five motorized battery switches and remote switches and the battery switches that three or four parallel switches in the DC elec- indicate battery switch mode and status.
  • Page 68 Electrical System Cabin DC Panel Remote Battery Switches to Manual Mode. If auto operation is attempted, Always consult your dealer before changing the the LED lights will flash for 3 seconds, then stop. type of batteries. The knob on the battery switches must be set to “AUTO OFF”...

  • Page 69: Battery Switch Panel Circuit Breakers & Other Dc Circuit Protection

    Electrical System Quad Engine Battery Switch Panel Heavy Duty & “Push to Reset” Circuit Breakers Heavy Duty Circuit Rocker Style Breakers “Push to Reset” Circuit Breakers STBD Charge 6.4 Battery Switch Panel Circuit Breakers Provides protection for the battery charger out- &...
  • Page 70 Electrical System electronic equipment. This breaker is supplied cur- rent when the House battery switch is activated. Hard Top Provides protection and electrical current to the primary circuit for hardtop accessories. Other “push to reset” breakers in the hardtop switch panel and in-line fuses or circuit breakers near the accessories protect the individual circuits.

  • Page 71: Ignition Switch Panels

    Yamaha Command Link Plus Ignition ® Most Scout boats equipped with triple Yamaha engines are equipped with Command Link Plus ® Typical Yamaha Triple Engine ignition panels that offer advanced technology and Key Activated Ignition Switch &...

  • Page 72: Volt Accessory Switch Panels

    Electrical System Accessory Switch Panel In Garmin Display CZone Display Monitoring Screen Starting and stopping procedure output module. The control output modules are Make sure the engines are shutdown with the shift where the switching of input and output current levers in the neutral position and your hand is on load to the selected accessories takes place.
  • Page 73 Electrical System Hardtop Switch Panel Hardtop Accessory Switch Panel The main accessory digital switch panel is located in the hardtop liner above the helm. The following is a description of the accessories controlled by the main accessory switch panel: Nav/Anchor Lights Pressing the switch in once will activate the navi- gation lights.
  • Page 74 Electrical System Notice: Shade In/Shade Out (Optional) The bilge pumps will start automatically Two momentary switches that control the re- when there is sufficient water in the bilge tractable sunshade integrated into the rear of to activate the float switch. Each automatic the hardtop.
  • Page 75 Electrical System Typical Switch Panel In Helm Electronics Touch Screen Display Panel Typical Helm Electronics Display Panel Bilge Light Switches Activates the light in the aft systems room and Switches electrical systems room. Accessory switches are integrated into the elec- tronic display panels at the helm.
  • Page 76 Electrical System Aft Spreader Activates the overhead light at the rear of the hardtop that illuminates the aft cockpit. Hardtop Lights Activates the overhead lights above the helm and on the rear of the console, above the footrest. Press the mode switch with the lights on to change the color.
  • Page 77 Electrical System Discharge Pump Accessed by the power control feature in the CZone display. Activates the waste discharge pump that empties the waste tank. Refer to the Marine Head System in the Interior Equipment chapter for addi- tional information on the operation of the overboard discharge system.

  • Page 78: Czone Digital Control System

    Electrical System CZone Switch Display CZone Display & Control Features 6.7 CZone Digital Control System The CZone display/control screens are the pri- The CZone digital switching system provides mary interface between the CZone digital switch reduced complexity and increased switching op- network and the user.
  • Page 79 Electrical System The following are some features that can be modified, monitored or controlled with the CZone control features on the Garmin display panels. Modes of Operation • Allows user to assign control of multiple DC or AC circuits to a single switch. •...
  • Page 80 Electrical System Tank Levels • View tank level information for water and waste tanks. • View gas and diesel fuel tank level information. Data • Displays network information. • Displays temperature and pressure values. • Monitors all circuits connected to the CZone network.

  • Page 81: Cabin Dc Breaker Panel

    Electrical System Cabin DC Breaker Panel, Stereo, DVD Player & Air Conditioner Control Panel The following is a description of the acces- 6.8 Cabin DC Breaker Panel sories controlled by switches and circuit DC Power is distributed to the CZone networks and breakers in the cabin DC panel: other 12 volt circuits through individual “push to rest”...
  • Page 82 Electrical System Refer to the Scout CZone operation manual for Head additional instructions for operating the generator. Protects the circuit that supplies 12 volt electrical current to the toilet control switches for the electric DC Panel “Push TO Reset” Breakers head system.

  • Page 83: Dc Power Management

    Electrical System 24 HR NEAMA 6.9 DC Power Management A continuous power circuit breaker that protects Modern outboard powered boats are typically the circuit that supplies continuous 12 volt electri- equipped with a full array of electronics, fuel in- cal power to the CZone network. This breaker is jected engines, spreader lights, stereo amplifiers, always supplied current when the house battery or other accessories that consume a significant...

  • Page 84: Volt Ac Electrical System

    Electrical System 6.10 120 volt AC Electrical System The AC electrical system is supplied 120 & 240 volt, 60 cycle current by a shore power outlet at dockside. It is wired totally separate from the 12 volt DC system and is equipped with an onboard isolation system.
  • Page 85 Electrical System Shore Power Inlet Breaker & ELCI Inlet Panels ELCI Inlet Panel & TEST/RESET Buttons Power & Fault LED Lights Turn the dockside disconnect circuit breaker to the ON position. Then turn the circuit breaker at the boat inlet plug on and check for proper polarity. If reverse polarity has been achieved, the red fault indicator in the shore power inlet panel and the red reverse polarity light in the AC main distribution...
  • Page 86 Electrical System If the reversed polarity light is lit or the ELCI continues to trip and the red “FAULT” LED is lit after being reset there is a problem with the AC electrical system and it is unsafe to use. Make sure all AC accessory circuits are OFF and turn the Shore Power main breakers OFF.
  • Page 87 Electrical System AC Main Distribution Panel A. CZone Network/AC Accessory Switches D. Phase 1/Phase 2 Power Supply Voltage B. Network Status LED Indicator Lights E. Shore Power/Generator Main Circuit Breakers C. Reverse Polarity/AC Power Status LED Indicator Lights Accessory Circuit Breakers AC Main Distribution Panel is below 105 volts or above 125 volts in either phase.
  • Page 88 Electrical System vating the main breakers with the AC accessories the circuit is activated and operating properly. A activated could cause the main breakers to trip. red light indicates a fault has been detected in an To avoid this surge, always make the accessory activated circuit.
  • Page 89 Electrical System breaker ON button until it resets and locks in the ON position. Refer to the battery charger owner’s manual for more information on the features and operation of the battery charger. The charge to the engine batteries can be moni- tored by using the DC volt meters in the cabin DC panel, the volt meters in the engine gauge display panels, LED lights on the charger and volt meters...

  • Page 90: Generator

    Electrical System Stove Supplies 120 volt AC electrical current to the stove in the galley. Cabin Refrigerator Supplies 120 volt electrical current directly to the galley refrigerator when AC power is available and chosen over the 12 volt power supply. See the refrigerator manual for more information.
  • Page 91 Electrical System water. There is an expansion tank for the engine coolant mounted to the generator that is accessed by opening the sound shield door. Make sure the fluid level in the expansion tank is kept between the maximum and minimum lines of the tank. You should also check the exhaust port for water flow each time the generator is started.

  • Page 92: Bonding System & Galvanic Isolator

    Electrical System 6.12 Bonding System & Galvanic Isolator Your boat is equipped with a bonding system that interconnects all underwater hardware and thru-hull fittings to ensure that they are of the same electrical potential. Sacrificial anodes are attached to the bonding system at the trim tabs and engines.
  • Page 93 Electrical System protector will reduce corrosion and improve elec- and sprayed with a metal and electrical protector. trical continuity. Inspect all engine wiring. Inspect all wiring for proper support, sound in- Check the electrolyte level in wet cell batteries sulation and tight terminals, paying particular regularly and add distilled water as necessary.

  • Page 94: Ac Line Load Estimator

    Electrical System on your boat requires and managing the electrical 6.14 AC Line Load Estimator load on the AC circuit. An owner’s manual for Depending on the AC power load your boat re- each AC accessory installed on your boat at the quires and the power available from the shore factory has been included with your boat.

  • Page 95: Fresh Water System

    Chapter 7: FRESH WATER SYSTEM 7.1 General The fresh water system consists of a potable water tank, distribution lines and two distribution pumps. Each pump is equipped with an automatic pressure switch and is located in a compartment behind the aft head compartment bulkhead. The tank is located below the port side of the cabin berth.
  • Page 96 Fresh Water System in a home. Automatic pressure sensors keep the system pressurized. If the system has been re- cently filled or has not been used for an extended period, air bubbles may accumulate at the pump and the system may have to be reprimed. Whenever the boat is left unattended, the fresh water pumps should be turned OFF using the Czone control feature.

  • Page 97: Water Heater

    Fresh Water System To use a washdown hose, make sure the fresh water system is activated. Pull the nozzle and hose out of the fitting to the desired length. When washdown operations are complete, turn OFF the nozzle and pull the hose out slightly to release the reel lock.
  • Page 98 Fresh Water System • Remove the filter screens from the faucet spouts and eliminate any accumulation of de- bris. A build up of debris can cause the pump to cycle excessively. • Periodically remove the lid on the drain sump and clean the water strainer for the sump pump and the sump.

  • Page 99: Raw Water System 8.1 General

    Chapter 8: RAW WATER SYSTEM Raw Water System Sea Chest 8.1 General A sea chest is located in the aft systems room bilge supplies seawater to the raw water pumps. Two intake thru-hull fittings for the sea chest are equipped with ball valves to turn the raw water main supply to the sea chest ON or OFF.

  • Page 100: Raw Water System Operation

    Raw Water System baitwell pump priming procedure for all other pumps connected to the sea chest. The sea chest water intake fittings are equipped with scoops that will supply pressurized water to the sea chest and help prime the system while the boat is underway during normal operation.

  • Page 101: Baitwell

    Raw Water System 8.3 Baitwell Seawater is provided to the baitwell by a 12 volt centrifugal pump. The pump is not controlled by a pressure sensitive switch and designed to supply a constant flow of water to the well. It is activated with the CZone control feature.

  • Page 102: Air Conditioner Cooling Pump

    Raw Water System 8.4 Air Conditioner Cooling Pump The air conditioning unit is self-contained and seawater cooled. A 120 volt AC centrifugal pump supplies seawater that cools the condensing unit as it circulates through the system and is discharged overboard. The air conditioner seawater pump is located in the aft systems compartment near the sea chest.

  • Page 103: Raw Water System Maintenance

    Raw Water System Sea Chest Intake Thru-Hull Valve, Sea Strainer & Sea Strainer Cap water to cool the heat exchanger and exhaust • Periodically remove and clean the water strain- system on the generator. Refer to Raw Water ers located in the intake lines for the sea chest. System Maintenance in this chapter for informa- To clean the strainers, make sure the genera- tion on cleaning the sea strainers.
  • Page 104 Raw Water System Verifying Generator and Air Conditioner Air Conditioner Cooling System Cooling System Operation After Cleaning • Make sure the sea chest and air conditioner cooling pump supply valves are open. Sea Chest Strainers Generator Cooling System • Activate the air conditioner and monitor the •...

  • Page 105: Drainage Systems

    Chapter 9: DRAINAGE SYSTEMS Port & Starboard Cockpit Scupper Drains 9.1 General Most water is drained by gravity to overboard thru-hull fittings located in the hull above the water line. It is important to check the drain system frequently to ensure it is free flowing and that the hoses on thru-hull fittings are secure and not leaking.

  • Page 106: Hardtop & Tower Drains

    Drainage System Fishboxes and Baitwell Drains The aft fish boxes below the cockpit sole are drained overboard by a diaphragm pump out sys- tem. There is a diaphragm pump and overboard discharge thru-hull valve for each fishbox located in the aft systems room. The pumps are activated with the CZone control feature.

  • Page 107: Bilge Drainage & Alarm

    Drainage System 9.4 Bilge Drainage & Alarm There are three bilge pumps, aft, forward and emergency. The aft and forward bilge pumps are activated both manually, by switches in the hardtop switch panel or CZone display, and au- tomatically by switches built into each pump that sense the water level at the pump.

  • Page 108: Cabin Drainage

    Drainage System Bilge High Water Alarm An automatic float switch located in the aft bilge near the bilge pumps will sound an alarm if the bilge water level rises above the normal operating range of the bilge pump automatic switches. The alarm automatic switch is protected by a “push to reset”...

  • Page 109: Drainage System Maintenance

    Drainage System • Flush the air conditioner condensation pan and 9.6 Drainage System Maintenance drain hose with fresh water at least once each It is essential that the following items be done season to remove mold and debris. This is periodically to maintain proper drainage of your particularly important because mold tends to boat:...
  • Page 110 NOTES...

  • Page 111: Ventilation System

    Chapter 10: VENTILATION SYSTEM Ventilation 10.1 Windshield Ventilation through the windshield is provided by vent panels above the windshield. The vent panes are always open unless closed with optional canvas panels. 10.2 Carbon Monoxide & Proper Ventilation WARNING FAILURE TO PROPERLY VENTILATE THE BOAT WHILE THE ENGINES ARE RUNNING MAY PERMIT CARBON MONOXIDE TO ACCUMULATE WITHIN THE CABIN AND OPEN AREAS OF YOUR BOAT.
  • Page 112 Ventilation System created by a boat nearby whose exhaust fumes are entering your boat. Boats also have a problem due to the “station wagon effect” where engine exhaust fumes are captured in the vacuum or low pressure area, usually the cockpit and cabin, that can be created by the forward speed of the boat.

  • Page 113: Maintenance

    Ventilation System 10.4 Maintenance DANGER • Periodically lubricate all hinges and latch as- semblies with a light oil. ACTIVATION OF THE CARBON MONOXIDE DETECTOR INDICATES THE PRESENCE OF CARBON MONOXIDE (CO) • Periodically clean and coat gasket materials WHICH CAN BE FATAL. EVACUATE THE CABIN IMMEDIATELY. with silicone to help keep them pliable.
  • Page 114 NOTES...

  • Page 115: Exterior Equipment

    Any problems Stern Mooring Cleat Up should be corrected immediately. WARNING SCOUT BOATS ARE NOT EQUIPPED WITH HARDWARE DESIGNED FOR TOWING PURPOSES. THE MOORING CLEATS ARE NOT TO BE USED FOR TOWING ANOTHER VESSEL OR HAVING THIS BOAT TOWED.
  • Page 116 Exterior Equipment chain binder to a link in the chain. Before getting underway after hauling the anchor, always make sure the binder is properly attached to the anchor chain link and the hatch is closed and latched. Rope Locker The anchor rope locker, windlass and windlass remote switch connector are concealed in a re- cess below a hatch in the deck.

  • Page 117: Hull

    Exterior Equipment control at the helm or the foot switch at the bow. The windlass control switches are activated and protected by fuses in the CZone modules and a circuit breaker in the battery switch panel. Hinged covers protect the foot switches from being ac- cidently activated.

  • Page 118: Cockpit Features

    Exterior Equipment 11.4 Cockpit Features General Most hatches in the cockpit sole are secured with twist latches and flush mounted handles that store flush in the hatch. Automatic push to close latch- es secure other cockpit and center console doors and drawers in the closed position.
  • Page 119 Exterior Equipment WARNING THE BEACH PLATFORM SHOULD BE RAISED AND THE GATE CLOSED WHENEVER THE ENGINES ARE RUNNING. NEVER LOWER PLATFORM OR OPEN THE GATE WHILE UNDERWAY OR IN ROUGH SEA CONDITIONS. IN CERTAIN SITUATIONS, A LOWERED PLATFORM COULD ALLOW A SUBSTANTIAL AMOUNT OF WATER TO ENTER THE COCKPIT CREATING A POTENTIALLY DANGEROUS CONDITION.
  • Page 120 Exterior Equipment WARNING THE TRANSOM DOOR AND GATE SHOULD BE CLOSED AND PROPERLY LATCHED WHENEVER THE ENGINES ARE RUNNING. NEVER OPEN THE TRANSOM DOOR WHILE UNDERWAY OR IN ROUGH SEA CONDITIONS. IN CERTAIN SITUATIONS, AN OPEN TRANSOM DOOR COULD ALLOW A SUBSTANTIAL AMOUNT OF WATER TO ENTER THE COCKPIT CREATING A POTENTIALLY DANGEROUS CONDITION.
  • Page 121 Exterior Equipment Aft Systems Room Access Hatch A hatch in the center, rear of the cockpit provides access to the fuel valves, fuel filters, pumps, sea- water strainers, generator and other equipment in the stern bilge. The fuel supply manifolds, valves and filters are located on each side of the com- partment.
  • Page 122 Exterior Equipment Port Aft Transom Compartment The retractable shore power cord and reel and electrohydraulic system for the beach platform are located in this compartment. A hinged door with a “push to close” latch provides access to the compartment. Bow Seats and Storage Compartments The bow seat cushions are secured to the hatch lids with special friction latches.
  • Page 123 Exterior Equipment is accessed by raising the table to the lounge or table position and provides additional storage for dunnage. If the boat is equipped with an optional bow thruster, the thruster battery will be mounted in this compartment. The hatch is equipped with a flush, twist lock latch that secures the hatch in the closed position.

  • Page 124: Leaning Post Equipment

    Exterior Equipment To avoid damage to the table and pedestal, always make sure the table is in the full down position and sitting firmly in the cockpit recess whenever the boat is operating above slow speed. This is particularly important when the boat is being run offshore.
  • Page 125 Exterior Equipment Slide Out Storage Drawers The slide out storage drawers and cutting board are secured in the closed position with flush mounted, “push to close” latches. To open, pull the latch handle to release the latch and slide the drawer out. To close, push the drawer in until the latch catches.
  • Page 126 Exterior Equipment Electric Grill (Optional) An electric, stainless steel grill is located below an opening hatch on the top of the station. A gas hatch lifter assists in raising the hatch and holds it in the open or closed positions. The grill is recessed into the counter top and oper- ates on 120 volt AC power only.

  • Page 127: Console & Helm

    Exterior Equipment Helm Seats The helm and passenger seats are equipped with a flip up bolster to provide more room between the seats and the helm. The bolsters convert the seats to a leaning post style seat with a backrest, allow- ing the operator and passenger to sit or stand at the helm.
  • Page 128 Exterior Equipment Windshield Your boat is equipped with a tinted glass wind- shield and windshield wiper. The front and side panels are tempered safety glass. The windshield wiper should only be used when the windshield is wet. The windshield glass can be scratched by activating the wiper when there is dried salt or dirt on the windshield.
  • Page 129 Exterior Equipment DANGER CARBON MONOXIDE (CO) CAN CAUSE BRAIN DAMAGE OR DEATH. CARBON MONOXIDE CAN BE PRESENT IN THE CABIN. SIGNS OF CARBON MONOXIDE POISONING INCLUDE NAUSEA, HEADACHE, DIZZINESS, DROWSINESS, AND LACK OF CONSCIOUSNESS. GET TO FRESH AIR IF ANYONE SHOWS SIGNS OF CARBON MONOXIDE POISONING.

  • Page 130: Hardtop

    Exterior Equipment Hardtop forward of the front legs. The hard top frame is 11.7 Hardtop not designed to support the weight of additional The hardtop consists of a laminated fiberglass top accessories in this area and could be damaged. mounted to a welded, powder coated aluminum The port and starboard supports on each side of frame that is bolted to the console windshield the helm are the wire chase for lights and anten-...

  • Page 131: Aftermarket Hardtop Or Tower

    Exterior Equipment Press and hold the SUNSHADE IN switch to re- tract the sunshade. Limit switches in the electric actuators that extend and retract the sunshade will automatically stop the actuators when the sunshade reaches the fully extended or retracted positions.
  • Page 132 NOTES...

  • Page 133: Interior Equipment

    Chapter 12: INTERIOR EQUIPMENT Head Compartment Separate Head Compartment Shower 12.1 Head Compartment The head compartment is equipped with a sink with a hot and cold water faucet. There is storage below the countertop under the vanity. The cabinet door will be held closed by the friction latch while at anchor or at the dock.
  • Page 134 Interior Equipment Helm Access Panel Above Aft Berth Fresh Water Pump Access Panel In Aft Berth Marine Head System The 12 volt marine toilet is connected to the pres- surized fresh water system which results in less odor in the head compartment. It has an auto- matic pumping device that fills and empties the bowl.
  • Page 135 Interior Equipment out by a waste dumping station or the overboard diaphragm discharge system. The fluid level in the waste/holding tank is moni- tored by the monitoring feature in the CZone dis- play or a lighted LED symbol in the in the center of the toilet control panel.
  • Page 136 Interior Equipment Head System Maintenance The vent hose for the holding tank is equipped with a charcoal filter to reduce odor from the hold- The head should be cleaned and inspected for ing tank. The filter, located behind a removable leaks regularly.

  • Page 137: Main Cabin & Galley

    Interior Equipment 12.2 Main Cabin & Galley The main cabin is equipped with a galley and double berth that converts to a dinette. Natural lighting and fresh air is provided by large opening windows on each side of the cabin. Additional lighting is provided by lights in the cabin headliner.
  • Page 138 Interior Equipment Cabin Lights All lights in the cabin are powered by the DC elec- trical system and protected by fuses in the CZone DC output modules. Most of the cabin lights are controlled by switches on the cabin walls. Other lights have switches on the light fixture.
  • Page 139 Interior Equipment Stove The galley is equipped with a dual burner electric stove that is built into the galley counter top. To activate the burner, make sure the Stove circuit breaker in the AC distribution panel is activated and there is nothing but pots or pans on the cook top, then use the touch control for each burner to activate the burners and control the temperature.
  • Page 140 Interior Equipment A retractable table converts the forward cabin into a dinette or a double berth. The table is also equipped with a leaf that can be folded on top of the table to provide additional room in the dinette and cup holders on the table. The table is mounted on an electrically actuated pedestal that is controlled by a rocker switch on the port side of the cabin.
  • Page 141 Interior Equipment Cabin AC Panel AC & DC Breaker Panel The cabin DC breaker panel is built into the cabinet in the aft verth. The Fusion Head Unit, Generator START/STOP switch, conditioner control panel and volt meters are located in the panel. “Push to Reset” circuit breakers continuos power...

  • Page 142: Cabin Air Conditioner

    Interior Equipment A by-product of combustion, carbon monoxide is invisible, tasteless, odorless, and is produced by all engines and some heating and cooking appli- ances. The most common sources of CO on boats are the engines, auxiliary generators and propane or butane stoves.

  • Page 143: Cabin Woodwork

    Interior Equipment conditioning pump and cleaning the sea strainers. You also should refer to the air conditioner owner’s manual for additional operating and maintenance instructions. Notice: Air conditioners use seawater as a cooling medium. The boat must be in the water and the raw water supply system must be properly activated prior to use.
  • Page 144 NOTES...

  • Page 145: Routine Maintenance

    Chapter 13: ROUTINE MAINTENANCE rate first, protecting the more noble underwater 13.1 Exterior Hull and Deck hardware against galvanic corrosion. Anodes Hull Cleaning-Below The Water Line provide protection against galvanic corrosion for When the boat is removed from the water, clean the engines, thru-hull fittings, trim tabs and other the outer bottom surface immediately.
  • Page 146 Routine Maintenance Stainless Steel Hardware effects as they have on an automobile finish. The wax will fill minute scratches and pores thus When using the boat in saltwater, the hardware helping to prevent soiling and will extend the life should be washed with soap and water after each of the gel coat or paint.
  • Page 147 Routine Maintenance anodized aluminum will penetrate the anodized overlooked when the boat is washed and will not coating and attack the aluminum. be rinsed by the rain. Consequently, the powder coating near fasteners and hardware mounted Pay special attention to the area just below the just below the top is more likely to be attacked by top.

  • Page 148: Upholstery, Canvas And Enclosures

    Routine Maintenance Notice: • Dried on dirt - Wash with a soft cloth dampened You should contact Scout Customer Service with water. before making any modifications to alumi- num fabrications. Unauthorized modifica- • Variations in surface gloss - Wipe with a water tions can void the warranty.
  • Page 149 Routine Maintenance After several years, the acrylic canvas may lose curtains. After cleaning the curtains and allowing some of its ability to shed water. If this occurs, them to dry, apply a non-lemon furniture polish wash the fabric and let it dry thoroughly. Then or an acrylic glass and clear plastic protector to treat the outside surface with a commercially extend the life of the curtains.

  • Page 150: Interior

    Routine Maintenance Remember, the coating on Lexan is scratch In most cases, Corian can be repaired if acciden- resistant scratch proof. Always tally damaged. Minor damage, including scratches, handle the curtains with care and never roll up general or chemical stains, scorches or burns, curtains that are salty or dirty.

  • Page 151: Bilge

    Routine Maintenance provide additional information on fuel degradation your generator owner’s manual. They should be and fuel stabilizers recommended for your engine. followed exactly. In many states, most gasoline is blended with Proper generator operation requires a good supply ethanol alcohol. Ethanol is a strong solvent and of clean, dry fuel.
  • Page 152 NOTES...

  • Page 153: Seasonal Maintenance

    For more recommendations rating of the fuel. Severely degraded fuel can for your specific area, check with your local damage the engines and boat fuel tank and Scout dealer. 530 LXF Sling Locations...
  • Page 154 Seasonal Maintenance • Drain water from the fresh water system. • Make sure the hitch is properly supported. • Check the tires once each season. Add enough • Consult the engine owner’s manual for detailed air for the correct amount of inflation for the information on preparing the engines for tires as necessary.

  • Page 155: Freshwater System Winterizing

    Seasonal Maintenance Preparing The Boat For Storage: 14.2 Freshwater System Winterizing • Remove the bilge drain plug(s), if installed. The entire fresh water system must be completely (Some boats do not have bilge drain plugs) drained and winterized using the following pro- cedure.

  • Page 156: Raw Water System Winterizing

    Seasonal Maintenance 11. Connect one end of a five foot length of hose 14.3 Raw Water System Winterizing to the vent fitting on the sea chest and place The raw water washdown and seawater supply the other end in a 5 gallon bucket filled with pumps and systems must be completely drained potable water antifreeze.

  • Page 157: Drainage & Other Water System Winterizing

    Seasonal Maintenance You should refer to the generator owner’s manual SeaKeeper Raw Water Cooling System. or contact your dealer for specific instructions on If your boat is equipped with an optional Sea- winterizing your generator. Keeper stabilizer system, it will have specific lay up and winterizing procedures.

  • Page 158: Winterizing Bilge Components & Engines

    Seasonal Maintenance Baitwell and Recirculation System Outboard Engines Install the baitwell drain plug and pour potable The engines should be flushed with fresh water for water antifreeze in the baitwell until it covers the at least 15 minutes prior to winter storage. This intake for the recirculation pump.

  • Page 159: Recommissioning

    Seasonal Maintenance to powder coated aluminum to protect it during 14.7 Recommissioning storage periods. WARNING CAUTION DO NOT OPERATE THE BOAT UNLESS IT IS COMPLETELY A S S E M B L E D. K E E P A L L FA S T E N E R S T I G H T. K E E P ALWAYS MAKE SURE THE LEG DRAIN HOLES ARE CLEAR ADJUSTMENTS ACCORDING TO SPECIFICATIONS.
  • Page 160 Seasonal Maintenance • Pump the antifreeze from the fresh and raw • Start the generator and monitor the exhaust port for a steady stream of water. It may take water systems and flush several times with 20 or 30 seconds for the muffler to fill and fresh water.

  • Page 161: Appendix A: Schematics

    Appendix A: SCHEMATICS Hull Harness 12V System - 1...
  • Page 162 Schematics Hull Harness 12V System - 2...

  • Page 163: Glossary Of Terms

    Schematics Deck Harness 12V...
  • Page 164 Schematics Deck Harness 110V...
  • Page 165 Schematics Hardtop Harness 12V...
  • Page 166 Schematics Lower Aft Console Harness 12V System...
  • Page 167 Schematics Lower Forward Console Harness 12V System...
  • Page 168 Schematics Upper Console Harness 12V System...
  • Page 169 Schematics Fresh Water System...
  • Page 170 Schematics Raw Water System...
  • Page 171 Schematics Drainage System...
  • Page 172 Schematics Waste System...
  • Page 173 Schematics Fuel System...
  • Page 174 Schematics Props and Engines Mercury Propulsion System...
  • Page 175 Schematics Mercury Steering System...
  • Page 176 Schematics 420 Yamaha Propulsion System Yamaha Propulsion System Props and Engines...
  • Page 177 Schematics Yamaha Steering System...
  • Page 178 NOTES...
  • Page 179 Appendix B: GLOSSARY OF TERMS ft: In, near, or toward the stern of a boat. Bow Rail: Knee high rails of solid tubing to aid in preventing people from falling overboard. Aground: A boat stuck on the bottom. Bridge: The area from which a boat is steered Amidships: In or toward the part of a boat midway and controlled.
  • Page 180 Glossary of Terms Ground Tackle: A general term including anchors, eck: The floor-like platform of a boat that lines, and other gear used in anchoring. covers the hull. Grounds: A boat touches the bottom. Displacement: The volume of water displaced by the hull.
  • Page 181 Glossary of Terms Limber Hole: A passage cut into the lower edges Pitching: The fore and aft rocking motion of a of floors and frames next to the keel to allow bilge boat as the bow rises and falls. water to flow to the lowest point of the hull where Pitch: The measure of the angle of a propeller it can be pumped overboard.
  • Page 182 Glossary of Terms Scupper: An opening in the hull side or transom affrail: Rail around the rear of the cockpit. of the boat through which water on deck or in the cockpit is drained overboard. Thru-hull: A fitting used to pass fluids (usually Seacock: Safety valves installed just inside the water) through the hull surface, either above or thru-hull fittings and ahead of the piping or hose...

  • Page 183: Appendix C: Maintenance Log

    Appendix C: MAINTENANCE LOG Date Hours Dealer Service/Repairs...
  • Page 184 Maintenance Schedule Log Date Hours Dealer Service/Repairs...
  • Page 185 Maintenance Schedule Log Date Hours Dealer Service/Repairs...
  • Page 186 Maintenance Schedule Log Date Hours Dealer Service/Repairs...
  • Page 187 Maintenance Schedule Log Date Hours Dealer Service/Repairs...
  • Page 188 Maintenance Schedule Log Date Hours Dealer Service/Repairs...

  • Page 189: Boating Accident Report

    BOATING ACCIDENT REPORT Appendix D:                                       ...
  • Page 190 Boating Accident Report                                      ...
  • Page 191 Boating Accident Report                                                  ...
  • Page 192 NOTES...

  • Page 193: Appendix E: Float Plan

    Appendix E: FLOAT PLAN Scout recommends filling out a float plan each time you use your boat for an offshore day trip or a long cruise. Leave this information with a responsible person ashore, like a close friend or relative that you know well. 1.
  • Page 194 NOTES...

  • Page 195: Troubleshooting Guide

    Appendix F: TROUBLESHOOTING GUIDE PROBLEM CAUSE AND SOLUTION CONTROL SYSTEMS • Steering system is low on fluid. Fill and bleed system. Hydraulic steering is slow to respond & erratic and/or the • Steering system has air in it. Fill and bleed system. steering wheel feels bumpy.
  • Page 196 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ENGINE PROBLEMS An engine is running too hot. • The engine raw water pick up strainer is clogged with marine growth. Clean pick up. • The engine raw water pump impeller is worn or damaged. Repair the pump.
  • Page 197 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS The baitwell pump runs, but does not pump water. • The sea chest supply valve is not open. Open valve. • The sea chest intake strainers are clogged with weeds or debris.
  • Page 198 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS The automatic switch on the bilge pump does not activate • The fuse or circuit breaker for the automatic switch has tripped or blown. Replace the fuse or reset the circuit the pump .
  • Page 199 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS The air conditioner runs for a short time & then cuts out. • The intake strainers for the sea chest are clogged with weeds or debris. Clean the sea strainers. • The air conditioner pump raw water supply valve is closed. Open the valve.
  • Page 200 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS • Outlet breaker in AC distribution panel is off. Activate breaker. No AC power at outlets • Ground fault interrupter on the GFI outlet has tripped. Push reset button on outlet to reset. •...
  • Page 202 Scout Boats Inc. 2531 Hwy 78 West Summerville, SC 29483...

Table of Contents
