Scout Boats 355 LXF Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
355 LXF
Owner's Manual
Scout Boats Inc.
2531 Hwy 78 West
Summerville, SC 29483
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 355 LXF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Scout Boats 355 LXF

Summary of Contents for Scout Boats 355 LXF

  • Page 1 355 LXF Owner’s Manual Scout Boats Inc. 2531 Hwy 78 West Summerville, SC 29483...
  • Page 2 Rev 0 Print Date 5/22/2018...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ......................9 BOAT INFORMATION ......................11 SPECIFICATIONS .......................12 CERTIFICATIONS & SPECIFICATIONS ...................13 OWNER’S / OPERATOR’S INFORMATION ................15 SCOUT LIMITED WARRANTY ....................17 SCOUT WARRANTY REGISTRATION TRANSFER ..............19 Chapter 1: Safety Information 1.1 General ........................21 1.2 Engine Alarms ......................21 1.3 Neutral Safety Switch ....................21 1.4 Engine Stop Switch .....................21 1.5 Required Safety Equipment ..................22...
  • Page 4 TABLE OF CONTENTS Chapter 4: Helm Control Systems 4.1 General ........................49 4.2 Engine Throttle & Shift Controls ..................49 4.3 Neutral Safety Switch ....................52 4.4 Engine Power Tilt & Trim ....................52 4.5 Engine Stop Switch .....................53 4.6 Steering System ......................54 4.7 Joystick Controls ......................56 4.8 Trim Tabs ........................57 4.9 Bow Thruster (Optional) ....................58 4.10 Control Systems Maintenance ..................58...
  • Page 5 TABLE OF CONTENTS Chapter 8: Raw Water System 8.1 General ........................101 8.2 Raw Water System Operation ..................102 8.3 Baitwell ........................103 8.4 Air Conditioner Cooling Pump ..................104 8.5 SeaKeeper Cooling Pump ...................104 8.6 Raw Water System Maintenance ..................105 Chapter 9: Drainage Systems 9.1 General ........................107 9.2 Cockpit &...
  • Page 6 TABLE OF CONTENTS Chapter 13: Routine Maintenance 13.1 Exterior Hull and Deck .....................145 13.2 Upholstery, Canvas and Enclosures ................148 13.3 Interior .........................150 13.4 Engines & Fuel ......................150 13.5 Bilge ........................151 Chapter 14: Seasonal Maintenance 14.1 Storage and Lay-up ....................153 14.2 Winterizing ......................155 14.3 Recommissioning ....................158 Appendix A: Schematics ........................159...
  • Page 7 TABLE OF CONTENTS Appendix C: Maintenance Log ......................165 Appendix D: Boating Accident Report ....................171 Appendix E: Float Plan ........................175 Appendix F: Troubleshooting Guide ......................177...
  • Page 8 NOTES...

  • Page 9: Safety Information

    SAFETY INFORMATION Your Scout manual has been written to include a number of safety instructions to assure the safe op- eration and maintenance of your boat. These instructions are in the form of CAUTION, WARNING, DANGER and NOTICE statements. The following definitions apply: CAUTION HAZARDS OR UNSAFE PRACTICES WHICH COULD RESULT IN MINOR PERSONAL INJURY OR PRODUCT AND...
  • Page 10 SAFETY INFORMATION S.O.S SAVE OUR SEAS Scout Boats has made a commitment to quality since the very begin- ning. More importantly, we’ve also made a commitment to saving our natural resources. Our boating and fishing waters are beautiful but often abused and neglected. With care, we can turn the tide in favor of preserving our shinning seas for generations to come.

  • Page 11: Boat Information

    BOAT INFORMATION Please fill out the following information section and leave it in your Scout Owner’s Manual. This in- formation will be important for you and Scout service personnel to know, if and when you may need to call Scout for technical assistance or service. BOAT MODEL: HULL SERIAL #:...

  • Page 12: Specifications

    SPECIFICATIONS HULL LENGTH OVERALL _________________________________________ 34’ 11” / 10.64 m BEAM ___________________________________________________________ 10’ 9” / 3.28 m DRY WEIGHT W/O ENGINES (approx) _____________________________ 9,800 lbs / 4,445 kg DEADRISE _________________________________________________________ 22 Degress FUEL TANK CAPACITY ___________________________________________ 310 gal / 1,173 L FRESH WATER CAPACITY ___________________________________________ 23 gal / 87 L WASTE TANK ______________________________________________________11 gal / 42 L TRANSOM BAITWELL _______________________________________________55 gal / 208 L...

  • Page 13: Certifications & Specifications

    To be in compliance with European directives for recreational boats as published by the Interna- tional Organization for Standardization (ISO) in effect at the time this boat was manufactured, we are providing the following information. Manufacturer: Scout Boats Name: 2531 Hwy 78 West Address:...
  • Page 14 NOTES...

  • Page 15: Owner's / Operator's Information

    OWNER’S / OPERATOR’S INFORMATION Warranty and Warranty Registration Cards The Scout Limited Warranty Statement is included with your boat. It has been written to be clearly stated and easily understood. If you have any questions after reading the warranty, please con- tact Scout Customer Service.
  • Page 16 Yamaha outboard to an authorized the warranty has taken place. After which, the Yamaha outboard dealer. transferee will be treated as the original purchaser as outlined in the Scout Boats Limited Warranty • If you are away from home, or your selling Statement.

  • Page 17: Scout Limited Warranty

    In order to receive warranty service, the selling dealer must register the boat on www.dealerscircle.com, and the purchaser must take his/her boat to an authorized Scout Boats, Inc. dealer. Depending on the nature of the claim, Scout Boats, Inc. may require the boat to be returned to our factory at 2531 Highway 78 West, Summerville, SC 29483, in which case all transportation, haul-out, and/or loading charges shall be prepaid and the sole responsibility of the original purchaser.
  • Page 18 Scout Boats, Inc. within 10 days of sale of his/her boat to the new owner. A notarized bill of sale and a $100 administration fee payable to Scout Boats, Inc. must also be included with the notification of customer’s intent to re-sell his/her boat.

  • Page 19: Scout Warranty Registration Transfer

    SCOUT WARRANTY REGISTRATION TRANSFER ARRANTY  EGISTRATION  RANSFER  DATE  ____________________________  HULL IDENTIFICATION NO. SLP ____________________________________________________________  DATE OF PURCHASE  ____________________________________________________________________  NEW OWNER’S NAME  __________________________________________________________________  ADDRESS _____________________________________________________________________________  CITY  _____________________________________________  STATE____________  ZIP___________  EMAIL ________________________________________  PHONE  _______________________________  BRAND OF ENGINE_________________________________  HORSEPOWER______________________  I agree to the warranty terms and conditions pursuant to my particular model year boat.  ______________________________________________  SIGNATURE  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  PREVIOUS OWNER’S NAME  _____________________________________________________________  ADDRESS  ____________________________________________________________________________  CITY ______________________________________________  STATE_____________  ZIP__________  EMAIL  ________________________________________  PHONE  ______________________________  ORIGINAL DATE OF PURCHASE ...
  • Page 20 NOTES...

  • Page 21: Safety Information

    Chapter 1: Safety Information 1.1 General Your boat and outboard engines have been equipped with safety equipment designed to en- hance the safe operation of the boat and to meet U.S. Coast Guard safety standards. The Coast Guard or state, county and municipal law enforce- ment agencies require certain additional accessory safety equipment on each boat.

  • Page 22: Required Safety Equipment

    Safety Equipment Visual Distress Signals Notice: You should carry an extra stop switch lan- All boats used on coastal waters, the Great Lakes, yard and instruct at least one other crew territorial seas and those waters connected di- member on the operation of the stop switch rectly to them, must be equipped with Coast Guard and location of the extra lanyard.

  • Page 23: Bilge & Fuel Fires

    Safety Equipment • Electric Distress Light (Night use only) Refer to the “Federal Requirements And Safety The electric distress light is accepted for Tips For Recreational Boats” pamphlet or visit the night use only and must automatically flash U.S. Coast Guard Boating Safety web site, www. the international SOS distress signal.

  • Page 24: Carbon Monoxide Monitoring System

    Safety Equipment 1.7 Carbon Monoxide Monitoring System DANGER CARBON MONOXIDE IS COLORLESS, ODORLESS AND DANGEROUS. ALL ENGINES, GENERATORS AND FUEL BURNING APPLIANCES EXHAUST CARBON MONOXIDE (CO). DIRECT AND PROLONGED EXPOSURE TO CO WILL CAUSE BRAIN DAMAGE OR DEATH. SIGNS OF EXPOSURE TO CO INCLUDE NAUSEA, DIZZINESS AND DROWSINESS.

  • Page 25: First Aid

    Safety Equipment Typical First Aid Kit to carbon monoxide into fresh air immediately. 1.8 First Aid Never disable the CO detector because you think It is the operator’s responsibility to be familiar the alarm may be false. Always contact the detec- with the proper first-aid procedures and be able tor manufacturer or your local fire department for to care for minor injuries or illnesses of your pas-...

  • Page 26: Additional Safety Equipment

    Safety Equipment In many emergency situations, the Coast Guard There are specific frequencies to use in an emer- can provide assistance in obtaining medical advice gency. The VHF emergency channel is 16 in for treatment of serious injuries or illness. If you the United States.
  • Page 27 Safety Equipment Caution and warning labels must remain legible for 1.10 Caution & Warning Labels the safety of you and your passengers. If a label The caution and warning labels shown are ex- becomes missing or damaged it must be replaced. amples of the labels that could be on your boat.
  • Page 28 NOTES...

  • Page 29: Operation

    Chapter 2: Operation boat as well. Always modify the boat speed in ac- 2.1 General cordance with the sea conditions, boat traffic and Before you start the engines on your Scout, you weather conditions. should have become familiar with the various component systems and their operation and have Remember, it is the operator’s responsibility to performed a “Pre-Cruise System Check.”...
  • Page 30 Operation Overtaking Situations When one motor boat is overtaking another mo- tor boat, the boat that is being passed has the right-of-way. The overtaking boat must make the adjustments necessary to provide clearance for a safe passage of the other vessel. The boats should sound the appropriate signals.
  • Page 31 Operation...

  • Page 32: Pre-Cruise Check

    Operation • Have a tool kit aboard. The kit should include 2.3 Pre-Cruise Check the following basic tools: Before Starting the Engines: • Check the weather forecast and sea conditions Hammer Electrician’s tape before leaving the dock. Decide if the planned cruise can be made safely.

  • Page 33: Operating Your Boat

    Operation 2.4 Operating Your Boat WARNING After Starting the Engines: • Visibly check the engines to be sure there are DO NOT OPERATE THE BOAT UNLESS IT IS COMPLETELY no apparent water, fuel or oil leaks. A S S E M B L E D. K E E P A L L FA S T E N E R S T I G H T. K E E P ADJUSTMENTS ACCORDING TO SPECIFICATIONS.

  • Page 34: Docking, Anchoring & Mooring

    Operation Notice: CAUTION For more instructions on safety, equipment and boat handling, enroll in one of the sev- eral free boating courses offered. For infor- TO PREVENT DAMAGE TO THE BOAT, CLOSE ALL SEACOCKS BEFORE LEAVING THE BOAT. mation on courses offered in your area go to the U.S. Coast Guard Boating Safety web site at www.uscgboating.org.
  • Page 35 Operation Maneuvering to a Dock or Slip Notice: Your boat is equipped with twin or triple After Bow Spring Cleat engines and electronic control systems. Stern Cleat Depending on the control system options Bow Cleat selected, the following conditions could apply that will affect the handling of your boat as you maneuver to the dock: Securing The Boat Along Side A Dock (Typical)
  • Page 36 Operation Securing Dock Lines untie it. Back the boat away from the mooring until you can see the buoy. Move the boat slowly Securing a boat that is tied along side the dock away from the mooring. typically requires a bow and stern line and two spring lines.

  • Page 37: Controls, Steering Or Propulsion System Failure

    DANGER maximum power settings when running without one engine. THE MOORING CLEATS ON SCOUT BOATS ARE NOT DESIGNED OR INTENDED TO BE USED FOR TOWING CAUTION PURPOSES. THESE CLEATS ARE SPECIFICALLY DESIGNED AS MOORING CLEATS FOR SECURING THE BOAT TO A DOCK, PIER, ETC.

  • Page 38: Flooding Or Capsizing

    Operation the tower raises the boat’s center of gravity and WARNING the boat’s motion is greatly exaggerated for the person in a tower. R U N N I N G A G R O U N D C A N C A U S E S E R I O U S I N J U RY TO PASSENGERS AND DAMAGE TO A BOAT AND ITS If you are fishing in an area that is crowded with UNDERWATER GEAR.

  • Page 39: Trash Disposal

    Operation Teak surfing is an extremely dangerous activity and you should never allow anyone to “Teak Surf” behind your boat or be in the water near the ladder or swim platform while the engine is operating. WARNING TEAK SURFING (HOLDING ONTO THE SWIM PLATFORM WHILE BOAT IS UNDERWAY) IS EXTREMELY DANGEROUS AND CAN CAUSE SEVERE INJURY OR DEATH.

  • Page 40: Transporting Your Boat

    Operation 2.14 Transporting Your Boat If you trailer your boat, make sure that your tow vehicle is capable of towing the weight of the trailer, boat and equipment and the weight of the passengers and equipment inside the vehicle. This may require that the tow vehicle be spe- cially equipped with a larger engine, transmission, brakes and trailer tow package.
  • Page 41 Operation • The SAFETY CHAINS must be attached CAUTION crisscrossing under the coupler to the frame of the tow vehicle. If the ball was to break, BOATS HAVE BEEN DAMAGED BY TRAILERS THAT DO NOT the trailer would follow in a straight line and PROPERLY SUPPORT THE HULL.
  • Page 42 NOTES...

  • Page 43: Propulsion System

    Chapter 3: Propulsion System 3.1 General Your Scout is designed to be powered with 4-cycle outboard motors. Each engine is equipped with an oil sump in the crankcase that must be kept full of the type of oil recommended by the engine manufacturer.

  • Page 44: Engine Lubrication

    Propulsion System tors as high as possible. This will decrease the CAUTION risk of marine growth around the cooling inlets, propeller and exhaust ports and damage from NEVER RUN AN OUTBOARD MOTOR WITHOUT WATER galvanic corrosion. FLOWING TO THE WATER PUMP. SERIOUS DAMAGE TO THE WATER IMPELLER OR ENGINE COULD RESULT.
  • Page 45 Propulsion System Notice: Before changing propellers to correct boat performance problems, be sure other factors such as engine tuning, bottom and running gear growth, etc. are not the source of per- formance changes. Always be sure the load conditions are those normally experienced, before changing propellers.

  • Page 46: Engine Instrumentation

    Tachometers display the speed of the engines in save them from serious costly damage. revolutions per minute (RPM). This speed is not the boat speed or necessarily the speed of the Most Scout boats are equipped with Yamaha en- propeller. gines and Command Link Plus LCD multifunction ®...
  • Page 47 Propulsion System Speedometer Yamaha Command Link Plus speedometers can ® indicate boat speed via the engine pickup or an optional GPS or depth sounder triducer, if these options are installed in your boat. Refer to the engine gauge and electronics operating manuals for more information on the speedometer options available for your boat.
  • Page 48 Propulsion System Compass All boats are equipped with a compass on the top of the instrument panel. The compass cannot be adjusted accurately at the factory as it must be compensated for the influence of the electrical equipment and electronics unique to your boat. Therefore, the compass should be adjusted by a professional after the electronics and additional electrical accessories are installed and before op-...

  • Page 49: Helm Control Systems

    Chapter 4: Helm Control Systems 4.1 General The helm controls consist of three systems: the engine throttle and shift controls, the steering system and the trim tab control switches. These systems provide the operator with the ability to control the direction and attitude of the boat from the helm station.
  • Page 50 Helm Control Systems fuel. If an engine fails, the selector switch can be used to operate the boat on the two remaining engines or just the center engine, if it is available. When only the port and starboard engines are selected, the port lever will control the port engine and starboard lever controls the starboard engine.
  • Page 51 Helm Control Systems • An engine synchronization feature that auto- matically keeps all engines at the same RPM while cruising. Refer to Engine Synchronizing in this section and the control systems owner’s manual for more information regarding engine synchronization. • Trolling feature that allows the operator to increase or decrease engine speed in 50 RPM increments while operating at trolling speeds.

  • Page 52: Neutral Safety Switch

    Helm Control Systems 4.3 Neutral Safety Switch Every control system has a neutral safety switch incorporated into it. This device prohibits an en- gine from being started while the shift lever is in any position other than the neutral position. If an engine will not start, slight movement of the shift lever may be necessary to locate the neutral posi- tion and disengage the safety cutout switch.

  • Page 53: Engine Stop Switch

    Helm Control Systems The term “trim” generally refers to the adjustment of the outboards within the first 20 range of travel. This is the range used while operating your boat on plane. The term “tilt” is generally used when referring to adjusting the outboards further up for shallow water operation or trailering.

  • Page 54: Steering System

    Helm Control Systems 4.6 Steering System Power Assist Hydraulic Steering Power assisted steering systems on twin or triple engine boats without the joystick option are hy- draulic and comprised of two hydraulic circuits: a manual system, which is the control element and a hydraulic power assist pump, which is the work- ing element.
  • Page 55 Helm Control Systems Typical Yamaha Triple Engine Electronic Controlled Steering between the steering wheel and the engines. Each engine is turned independently, allowing improved tight quarter maneuvering and the convenience of an optional Joystick control at the helm. For safety and improved tight quarter maneuver- ing, the controlling software on most systems senses engine speed and adjusts maximum steer- ing angle and steering wheel resistance to preset...

  • Page 56: Joystick Controls

    Helm Control Systems 4.7 Joystick Controls A joystick control system is an option on triple engine boats and standard equipment on quads. The joystick can only be used at slow speeds. It is engaged by moving the shift and throttle con- trols to the neutral position and pressing the ON/ OFF button on the base of the joystick control or the keypad on the main engine controls.

  • Page 57: Trim Tabs

    Helm Control Systems 4.8 Trim Tabs The recessed trim tabs are mounted to the hull below the swim platform and integrated transom engine mounting system. A dual rocker switch is used to control the trim tabs. The switch controls bow up and down movements. It also controls starboard and port up and down movements.

  • Page 58: Bow Thruster (Optional)

    Helm Control Systems 4.9 Bow Thruster (Optional) The optional bow thruster provides the opera- tor additional control of the bow while docking or anchoring the boat in tight quarters or high winds and strong currents. The joystick control panel is located in the helm and controls the bow thruster that is mounted to the hull in the bilge near the bow.
  • Page 59 Helm Control Systems The fluid level for the hydraulic steering should be checked frequently and maintained at the proper level. The steering fluid level should be maintained at no less than 1/2” below the bottom of the fill plug hole on the hydraulic power assist pump reservoir located in the mechanical systems compartment.
  • Page 60 Helm Control Systems If the boat is kept in the water, the trim tabs must be equipped with a sacrificial anode to prevent galvanic corrosion. Galvanic corrosion is the cor- rosion process occurring when different metals are submerged in an electrolyte. Seawater is an electrolyte and submerged metal components must be properly protected.

  • Page 61: Fuel System

    Chapter 5: Fuel System 5.1 General The gasoline fuel system used in Scout boats sold in the United States is designed to meet or exceed the emission control standards of the Environmental Protection Agency (EPA) and the requirements of the U.S. Coast Guard, the Boating Industry Association and the American Boat and Yacht Council in effect at the time of manufacture.

  • Page 62: Fuel Delivery System

    Fuel System Triple Engine Fuel System - Port Engine Fuel Filter, Fuel Triple Engine Fuel System - Fuel Selector Valves & Center Engine Fuel Filter Selector Valve & Primer Bulbs Fuel Tank Vent Your boat is equipped with a fuel tank vent sys- tem incorporated into the fuel fill.
  • Page 63 Fuel System There is a primer bulb in each fuel line that is used to prime the fuel system after service or as required. See Fuel System Maintenance and the engine owner’s manual for additional information on the fuel filters and outboard engine fuel system. The fuel tank is designed with a main and auxiliary fuel supply.

  • Page 64: Fueling Instructions

    OR IS AN ALCOHOL BLEND OF HIGHER CONCENTRATION THAN RECOMMENDED BY THE ENGINE MANUFACTURER. tions, Scout boats are equipped with special fuel ANY DAMAGE DONE TO THE FUEL SYSTEM THAT IS THE systems that reduce the flow of fuel vapors from...

  • Page 65: Fuel System Maintenance

    Fuel System To fill the fuel tank, follow this procedure: 5.4 Fuel System Maintenance The fuel caps are designed to be opened by hand Periodically inspect all primer bulbs, connections, and do not require a key. Turn the cap coun- clamps and hoses for leakage, damage or deterio- terclockwise to remove it for fueling.
  • Page 66 Fuel System WARNING WARNING DO NOT DRAIN ANY FUEL INTO THE BILGE WHEN SERVICING TO REDUCE THE POSSIBILITY OF A FIRE OR EXPLOSION, THE FUEL SYSTEM. THIS COULD LEAD TO A FIRE OR MAKE SURE ALL ELECTRICAL SWITCHES ARE IN THE “OFF” EXPLOSION.

  • Page 67: Electrical System

    Chapter 6: Electrical System 6.1 General Scout Boats Marine Standard Wiring Code Your Scout is equipped with 120 volt AC and 12 COLOR volt DC electrical systems. The AC system draws current from shore power outlets at dockside. The Brown (Br) Pumps DC system draws current from onboard batteries.

  • Page 68: Batteries And Battery Switches

    Electrical System Triple Engine Battery Switch Panel Heavy Duty & “Push to Reset” Circuit Breakers CAUTION DANGER NEVER USE WET CELL BATTERIES. WET CELL BATTERIES PROPER FUSE OR BREAKER PROTECTION MUST BE E M I T D A N G E R O U S H Y D R O G E N G A S W H I L E B E I N G PROVIDED FOR ALL 12 VOLT EQUIPMENT ADDED.
  • Page 69 Electrical System Remote Battery & Parallel Switches Battery switches are identified by red knobs and the parallel switch knobs are yellow. The engine batteries are dedicated to starting and operating the engines. The house battery bank is dedicated to powering DC accessories, air conditioner, and the electronics.

  • Page 70: Battery Switch Panel Circuit Breakers

    Electrical System switches are in the ON position. The LED lights at switches, then start the engine with the dead battery the remote switches and on the battery switches normally. Press and hold the Parallel remote switch will be off and the battery switches will indicate for eight seconds to disengage the Parallel switches.
  • Page 71 Electrical System Triple Engine Battery Switch Panel Heavy Duty & “Push to Reset” Circuit Breakers Mid Eng CZone Provides protection for the battery charger out- Protects the circuit that supplies primary DC power put wire that supplies DC charging current to the to the CZone output control modules.

  • Page 72: Other Dc Circuit Protection

    Electrical System Mid VM Protects the circuit that supplies 12 volt electrical current to the volt meter that monitors the center engine battery on triple engine boats. This circuit is energized when the port engine battery switch is ON. This breaker is reserved for additional 12 volt equipment on twin engine boats.

  • Page 73: Ignition Switch Panels

    Yamaha Command Link Plus Ignition ® Most Scout boats equipped with triple Yamaha engines are equipped with Command Link Plus ® ignition panels that offer advanced technology and durability. This is a “key” activated ignition panel which energizes the ignition system of multiple outboards with only one key.

  • Page 74: Volt Accessory Switch Panels

    Electrical System the buttons are active. Once the panel is activated, Refer to the CZone Control System section in this press the IGNITION button, then the START/STOP chapter and the Scout CZone operation manual button for the port engine. It is not necessary to for additional information on the digital switching hold the button, just press it once and release it.
  • Page 75 Electrical System Hardtop Accessory Switch Panel Windlass Up/Windlass Down If the retractable sunshade option is not installed, these switches are reserved for additional 12 volt Two momentary switches that control the windlass, accessories. which is mounted to the deck forward of the rope locker.
  • Page 76 Electrical System Fwd Bilge High Water Alarm A red LED light illuminates and an alarm sounds if the Manually activates the forward bilge pump located bilge water level rises above the normal operating in the bilge below the cabin sole. The pump moves range of the bilge pump automatic switches.
  • Page 77 Electrical System Typical Accessory Switch Panel In Garmin Display Typical Helm Electronics Display Panel Accent Light Switches Activates and controls the lights in the cockpit Switches below the gunnels that illuminate the cockpit sole. Accessory switches are integrated into the elec- tronic display panels at the helm.
  • Page 78 Electrical System Bilge Pump Aft Flex Light Hardtop Manually activates the aft bilge pump located Activates and controls the overhead lights above in the stern bilge near the transom. The pump the helm and on the rear of the console, above moves water out through a thru-hull fitting in the the footrest.
  • Page 79 Electrical System Additional DC Switches and Accessories Trim Tab Switches Located in the helm. These switches control the trim tab planes located on the transom of the boat. They are protected by circuit breakers located in the battery switch panel. Refer to the Helm Con- trol Systems chapter for detailed information on the operation of the trim tab controls.
  • Page 80 Electrical System Discharge Pump Accessed by the power control feature in the CZone display or programed into the electronics display panel. Activates the waste discharge pump that empties the waste tank. Refer to the Marine Head System in the Interior Equipment chapter for addi- tional information on the operation of the overboard discharge system.

  • Page 81: Czone Digital Control System

    Electrical System CZone Switch Display CZone Display & Control Features 6.8 CZone Digital Control System The CZone display/control screens are the pri- The CZone digital switching system provides re- mary interface between the CZone digital switch duced complexity and increased switching options network and the user.
  • Page 82 Electrical System The following are some features that can be modified, monitored or controlled with the CZone control features on the Garmin display panels. Modes of Operation • Allows user to assign control of multiple DC circuits to a single switch. •...
  • Page 83 Electrical System CZone DC Electrical System Control Output Module Circuit Protection Accessory circuits activated by the digital switches are protected by spade type fuses located in the CZone output modules. The circuits controlled by each module are numbered and labeled for the accessory activated and protected by the module.

  • Page 84: Cabin Dc Breaker Panel

    Electrical System 6.9 Cabin DC Breaker Panel DC Power is distributed to the CZone networks and other 12 volt circuits through individual “push to rest” circuit breakers located in the cabin DC panel. Other heavy duty circuit breakers protect the high amperage circuits for some accessories.
  • Page 85 Electrical System 12V Outlets UW LTS Protects the circuit that supplies 12 volt electrical Protects the circuit that supplies 12 volt electrical current to the 12 volt accessory plugs. This breaker current to the transom underwater lights when the is supplied current when the House battery switch House battery switch is activated.
  • Page 86 Electrical System Typical DC Panel Heavy Duty, Slot Reset, Circuit Breakers Stereo Memory The following circuits are supplied power A continuous power circuit breaker that protects and protected by the restricted OFF circuit the circuit that supplies continuous 12 volt elec- breakers in the DC Panel: trical power to the memory circuit in the stereo and electronics.

  • Page 87: Dc Power Management

    Electrical System overload the capacity of the charging system for 6.10 DC Power Management extended periods while operating the boat below Your boat is typically equipped with a full array of cruising speed. Always monitor the volt meters electronics, fuel injected engines, stereo amplifier, while operating at slow speeds and turn off unnec- a DC air conditioning system, spreader lights and essary equipment that draw high amperage loads...

  • Page 88: Volt Ac Electrical System

    Electrical System 6.11 120 volt AC Electrical System The AC electrical system is supplied 120 volt, 60 cycle current by a shore power outlet at dockside. It is wired totally separate from the 12 volt DC system and is equipped with an onboard isola- tion system.
  • Page 89 Electrical System in contact with the water and connect the cable to the boat plug inlet and then to the dockside outlet, making sure the connection plugs include a three-prong plug with a ground wire. Tighten the lock rings on both the shore and the boat connector plugs.

  • Page 90: Ac Main Distribution Panel

    Electrical System “FAULT” LED is continuously illuminated the ELCI DANGER has tripped the inlet breaker due to a ground fault condition. Some faults are self correcting. If it REVERSED POLARITY WILL DAMAGE THE SYSTEM AND trips, try resetting the ELCI/inlet breaker once. EXPOSE PASSENGERS TO ELECTROCUTION HAZARDS.
  • Page 91 Electrical System AC Main Distribution Panel breaker to trip. To avoid this surge, always turn diately turn OFF all cabin AC breakers, the shore the Shore main breaker to the OFF position before main inlet breaker and dockside outlet breaker. plugging or unplugging the shore power cord.
  • Page 92 Electrical System WARNING GFI OUTLETS DO NOT PROVIDE 100% PROTECTION FROM E LE CT RI C SHO CK. E VEN T H O UG H GR O UN D FA U LT INTERRUPTERS PROVIDE PROTECTION BY REDUCING EXPOSURE TIME FROM LINE TO GROUND SHOCK HAZARDS, IT IS STILL POSSIBLE TO RECEIVE AN ELECTRIC SHOCK FROM DEFECTIVE APPLIANCES OR POWER TOOLS AND MISUSED ELECTRICAL EQUIPMENT.

  • Page 93: Bonding System & Galvanic Isolator

    Electrical System Battery Chargers & Galvanic Isolator 6.13 Bonding System & Galvanic Isolator Your boat is equipped with a bonding system that interconnects all underwater hardware and thru-hull fittings to ensure that they are of the same electrical potential. Sacrificial anodes are attached to the bonding system at the trim tabs and engines.

  • Page 94: Electrical System Maintenance

    Electrical System other boats in the circuit, a galvanic isolator is installed in the shore ground circuit that isolates your boat’s bonding system from the other boats. It prevents the flow of low voltage galvanic current while still providing a path for dangerous short circuit currents in the AC system to the shore safety ground.
  • Page 95 Electrical System AC Electrical System Maintenance Ground fault interrupt outlets and ELCI should Periodically inspect all wiring for nicks, chafing, be tested monthly to ensure proper operation by brittleness, improper support, etc. Examine the pressing the test/reset buttons. The reverse po- shore power cord closely for cracks in the insula- larity system should also be inspected and tested tion and corrosion in electrical connectors.

  • Page 96: Ac Line Load Estimator

    Electrical System each AC accessory installed on your boat at the 6.15 AC Line Load Estimator factory has been included with your boat. Ad- Depending on the AC power load your boat re- ditionally, you should make sure you have the quires and the power available from the shore manuals for accessories installed by your dealer supply, you may not be able to operate all 120 volt...

  • Page 97: Fresh Water System

    Chapter 7: Fresh Water System 7.1 General The fresh water system consists of a potable water tank, distribution lines and a distribution pump. The pump is equipped with an automatic pressure switch and is located near the water tank in a com- partment below the starboard side cabin berth.

  • Page 98: Fresh Water System Maintenance

    Fresh Water System CAUTION DO NOT ALLOW THE FRESH WATER PUMP TO RUN DRY. THE FRESH WATER PUMP WORKS ON DEMAND AND WILL NOT SHUT OFF AUTOMATICALLY WHEN THE TANK IS EMPTY. THIS CAN RESULT IN DAMAGE TO THE PUMP. ALWAYS TURN THE FRESH WATER PUMP OFF WHEN THE SYSTEM IS NOT IN USE.
  • Page 99 Fresh Water System • Add a commercially available potable water • Fill the water tank half full with fresh water conditioner to the water tank to keep it fresh. and pour the mixture into the water tank. Top off the tank. •...
  • Page 100 NOTES...

  • Page 101: Raw Water System

    Chapter 8: Raw Water System Optional Air Conditioner & Baitwell Pumps If your boat is equipped with the optional 12 volt 8.1 General air conditioning system, turn on the cabin air con- In the raw or seawater systems, the baitwell wa- ditioner.

  • Page 102: Raw Water System Operation

    Raw Water System Washdown & SeaKeeper Pumps If your boat is equipped with an optional SeaKeep- er, activate the SeaKeeper. Monitor the discharge fitting in the hull side. Water should begin to flow from the discharge fitting within 30 seconds. If water does not flow, the system may have an air lock or debris in the strainer restricting the water flow.

  • Page 103: Baitwell

    Raw Water System CAUTION DO NOT ALLOW THE WATER PUMP TO RUN DRY. THE PUMP WORKS ON DEMAND AND WILL NOT SHUT OFF AUTOMATICALLY IF NO WATER IS AVAILABLE. THIS CAN RESULT IN DAMAGE TO THE PUMP. ALWAYS TURN THE RAW WATER PUMP OFF WITH THE CZONE CONTROL FEATURE WHEN THE SYSTEM IS NOT IN USE.

  • Page 104: Air Conditioner Cooling Pump

    Raw Water System To drain the baitwell, turn off the baitwell pumps and remove the standpipe in the drain fitting at the bottom of the baitwell. When the baitwell has completely drained, use the washdown hose to flush the baitwell and drain of debris. The baitwell seacock valve should be closed when- ever the baitwell is not in use.

  • Page 105: Raw Water System Maintenance

    Raw Water System Seawater is supplied to the pump from a thru hull fitting located in the stern bilge. A sea strainer be- tween the pump and thru hull fitting protects the system from contaminants that could damage the pump or the air conditioning system. Make sure the pump receives adequate seawater by periodically cleaning the sea strainer.
  • Page 106 Raw Water System • To prevent corrosion, spray pumps and thru-hull CAUTION valves with a protective oil periodically. • The fishboxes and baitwell should be drained THE RAW WATER SYSTEM MUST BE PROPERLY WINTERIZED and cleaned after each use. PRIOR TO WINTER LAY-UP. SEE SECTION ON WINTERIZING FOR PROPER PROCEDURES.

  • Page 107: Drainage Systems

    Chapter 9: Drainage Systems Port & Starboard Cockpit Scupper Drains 9.1 General Most water is drained by gravity to overboard thru-hull fittings located in the hull above the water line. It is important to check the drain system frequently to ensure it is free flowing and that the hoses on thru-hull fittings are secure and not leaking.

  • Page 108: Hardtop Drains

    Drainage System Fishboxes and Baitwell Drains The aft fish boxes below the cockpit sole are drained overboard by a diaphragm pump out sys- tem. There is a diaphragm pump and overboard discharge thru-hull valve for each fishbox located in the aft systems compartment. The pumps are activated with the CZone control feature.

  • Page 109: Bilge Drainage

    Drainage System 9.4 Bilge Drainage The aft and forward bilge pumps are activated both manually, by a switch in the hardtop switch panel and automatically, by a switch in the pump. The automatic switches are connected to the batter- ies circuits are protected by fuses located in the CZone modules or circuit breakers in the cabin DC panel.

  • Page 110: Cabin Drainage

    Drainage System • Flush all gravity drains with fresh water to 9.5 Cabin Drainage keep them clean and free flowing. Cabin Sole The cabin sole drains by gravity to the bilge • Flush the air conditioner condensation pan and through access hatches and other non sealed drain hose with fresh water at least once each components in the sole.

  • Page 111: Ventilation System

    Chapter 10: Ventilation System 10.1 Cabin Ventilation Cabin Windows Opening tempered glass windows are located on each side of the cabin. The windows are equipped with a screen and secured in the closed position by two cam latches. To open a side window, release the latches and swing the window open.
  • Page 112 Ventilation System created by a boat nearby whose exhaust fumes are entering your boat. Boats also have a problem due to the “station wagon effect” where engine exhaust fumes are captured in the vacuum or low pressure area, usually the cockpit and cabin, that can be created by the forward speed of the boat.

  • Page 113: Maintenance

    Ventilation System 10.4 Maintenance DANGER • Periodically lubricate all hinges and latch as- semblies with a light oil. ACTIVATION OF THE CARBON MONOXIDE DETECTOR INDICATES THE PRESENCE OF CARBON MONOXIDE • Periodically clean and coat gasket materials (CO) WHICH CAN BE FATAL. EVACUATE THE CABIN with silicone to help keep them pliable.
  • Page 114 NOTES...

  • Page 115: Exterior Equipment

    Stern Mooring Cleat Up WARNING SCOUT BOATS ARE NOT EQUIPPED WITH HARDWARE DESIGNED FOR TOWING PURPOSES. THE MOORING CLEATS ARE NOT TO BE USED FOR TOWING ANOTHER VESSEL OR HAVING THIS BOAT TOWED. 11.2 Rope Locker & Windlass...
  • Page 116 Exterior Equipment underway after hauling the anchor, always make sure the binder is properly attached to the anchor chain link and the hatch is closed and latched. Rope Locker The rope locker and anchor line are accessed through a hatch below the center bow cushion. A gas charged spring supports the hatch in the open position.
  • Page 117 Exterior Equipment Windlass Compartment 1. Windlass 4. Bow Roller 2. Chain Binder 5. Anchor Line Cleat 3. Anchor Chain windlass. The line should be made fast to the lass. Refer to the Operation chapter for tips on cleat provided to relieve the load on the windlass. anchoring your boat.

  • Page 118: Hull

    Exterior Equipment Engine Mounting System & Platform 11.3 Hull To use the ladder, make sure the engines are off Engine Mounting System and the steering wheel is turned straight ahead or slightly to port to move the propellers as far away Your Scout is equipped with an engine mounting from the ladder location as possible.
  • Page 119 Exterior Equipment Unassisted Boarding Situations When using the platform boarding ladder in an un- assisted boarding situation in deep water, hold the swim platform and boarding ladder and brace your feet against the hull for stability. Then rotate the cam lock to the unlocked position and lift the ladder out of the bracket.

  • Page 120: Cockpit Features

    Exterior Equipment 11.4 Cockpit Features General Most hatches in the cockpit sole are secured with twist latches and flush mounted handles that store flush in the hatch. Automatic push to close latches secure other cockpit doors and drawers in the closed position. Gas charged springs are used to help raise most hatches and hold them in the open position.
  • Page 121 Exterior Equipment the boat is underway. Never leave the transom door unlatched. Notice: Periodically inspect the transom door and gate fittings for wear, damage or loose fit. Any problems should be inspected and cor- rected immediately. WARNING THE TRANSOM DOOR AND GATE SHOULD BE CLOSED AND PROPERLY LATCHED WHENEVER THE ENGINES ARE RUNNING.
  • Page 122 Exterior Equipment be secured in the closed position with the main latch and safety pin when not being used. Never leave the side door unlatched. Notice: Periodically inspect the door hinges and hard- ware for wear, damage or loose fit. Any prob- lems found should be corrected immediately. Side Telescopic Boarding Ladder The side boarding ladder is mounted to a special bracket in the side of the cockpit when it is in the...
  • Page 123 Exterior Equipment WARNING THE SIDE BOARDING DOOR AND GATE SHOULD BE CLOSED AND PROPERLY LATCHED WHENEVER THE ENGINES ARE RUNNING. NEVER OPEN THE DOOR WHILE UNDERWAY OR IN ROUGH SEA CONDITIONS. IN CERTAIN SITUATIONS, AN OPEN DOOR COULD ALLOW A SUBSTANTIAL AMOUNT OF WATER TO ENTER THE COCKPIT CREATING A POTENTIALLY DANGEROUS CONDITION.
  • Page 124 Exterior Equipment Aft Below Deck Fishboxes Two below deck fishboxes are located on each side of the cockpit. Each fishbox hatch is equipped with a gas charged hatch lifter that holds the hatch open. Flush, twist lock latches secure the hatches in the closed position.
  • Page 125 Exterior Equipment Stern Bench Seat Closed Stern Bench Seat Open Stern Bench Seat Your boat is equipped with a forward facing bench seat in the rear of the cockpit. The seat is designed to fold flush against the cockpit when it is not in use.
  • Page 126 Exterior Equipment Bow Seats Bow Storage Compartments Bow Seats and Storage Compartments There are storage/cooler compartments located in the bow below the port and starboard seats. Another hatch below the forward seat provides ac- cess to the rope locker. The hatches are equipped with gas charged springs that hold them in the open or closed position.
  • Page 127 Exterior Equipment Bow Table and Sun Lounge (Optional) Your boat could be equipped with a retractable table that converts the bow area into either a sitting area with no table, a sitting area with a table, or a sun lounge/fishing deck. The table is mounted on an electrically actuated pedestal that is controlled by switches in a panel on the side of the cockpit.

  • Page 128: Leaning Post Equipment

    Exterior Equipment Tip Out Basket 11.5 Leaning Post Equipment Tackle & Storage Drawers The leaning post station is equipped with helm seats, rear facing bench seat, cooler, tip out basket and storage drawers for dunnage and/or tackle storage. The optional SeaKeeper is mounted below the rear facing seat if your boat is equipped with this feature.
  • Page 129 Exterior Equipment Helm Seats In Leaning Post Position Helm Seats In Seat Position Helm Seats Arm rests on each side of the seats provide a more The three helm seats are equipped with a flip up comfortable position and swing up into the backrest bolster to provide more room between the seats cushion to make it easier to enter and exit the helm and the helm.

  • Page 130: Console & Helm

    Exterior Equipment 11.6 Console & Helm Helm The steering, engine controls, engine instruments and switches for exterior equipment, navigation lights and other 12 volt DC accessories are located in the helm display panels and in the hardtop liner above the helm. Molded-in electronics storage is located forward of the engine controls.
  • Page 131 Exterior Equipment Cabin Door The cabin door is on the port side of the console. A lockable, push to close latch secures the door when it is closed. It is very important that the door is secured properly in the closed position whenever the boat is operated above idle speed.
  • Page 132 Exterior Equipment Forward Console Sun Lounge Forward Console Sun Lounge A double lounge seat with underside storage is located on the console, forward of the windshield. The lounge will accommodate two people and has arm rests built into each side and a center arm rest.

  • Page 133: Hardtop

    Exterior Equipment Hardtop The hardtop is not designed to support the addi- 11.7 Hardtop tional weight of heavy items like a life raft. GPS, The hardtop consists of a laminated fiberglass top VHF, and other electronics antennas must be mounted to a welded, powder coated aluminum mounted to the top in the proper location.

  • Page 134: Aftermarket Hardtop Or Tower

    Exterior Equipment Retractable Aft Sunshade (Optional) The optional retractable sunshade extends to pro- vide shade for the rear cockpit. Electric actuators on each side of the hardtop extend or retract the awing. Skylights built into the hardtop provide additional natural lighting for the helm area when the sunshade is extended.

  • Page 135: Interior Equipment

    Chapter 12: Interior Equipment 12.1 Cabin & V-Berth The main cabin is equipped with a marine head, sink, refrigerator, storage cabinets and dinette that converts to a berth. Natural lighting and fresh air is provided by open- ing windows on each side of the cabin. Additional lighting is provided by lights in the cabin headliner and reading lights at the berth.
  • Page 136 Interior Equipment Sink The cabin sink is equipped with a cold water faucet. Water is supplied to the sink by a 12 volt pump located in a compartment below the starboard berth cushion. When activated by the CZone con- trol feature, the system will operate much like the water system in a home.
  • Page 137 Interior Equipment Other hatches below the port and starboard di- nette seat cushions provide access to the water system valves, fresh water pump, battery switch panel and other equipment mounted in the berth area. Another hatch in the cabin sole provides access to the overboard diaphragm discharge pump for the waste tank and the thru-hill dis- charge valve.
  • Page 138 Interior Equipment Cabin AC/DC Panel & Stereo Cabin Breaker Panel Refer to the Electrical Systems chapter for more information on the operation of the components The cabin AC/DC breaker panel is built into the and circuit breakers in the cabin breaker panel. rear cabin bulkhead near the cabin door.
  • Page 139 Interior Equipment Equipment Access Doors and Hatches Access doors and removable panels in the rear cabin bulkhead provide access to the back of the helm to service equipment or install additional electronics or accessories. Special brackets on the starboard and bottom access doors provide secure storage for the dinette table and pedestal.

  • Page 140: Marine Head System

    Interior Equipment 12.2 Marine Head System Marine Head System The 12 volt marine toilet is connected to the pres- surized fresh water system which results in less odor in the cabin. It has an automatic pumping device that fills and empties the bowl. Once a button on the control is pressed, the entire cycle is completely automatic.
  • Page 141 Interior Equipment Use the following procedure to pump out the hold- ing tank with the overboard diaphragm discharge pump system: • Open the waste discharge valve in the forward bilge. • Use the CZone control feature to activate the overboard diaphragm discharge pump. •...

  • Page 142: Cabin Air Conditioner (Optional)

    Interior Equipment 12.3 Cabin Air Conditioner (Optional) The cabin air conditioner operates 12 volt DC power. The unit cools only and will not function as a heating unit. You should always keep the cabin door closed when operating the air conditioner. If the cabin door is left open, it could cause the air conditioner unit to run continuously and not cycle enough to defrost the coiling condenser.

  • Page 143: Cabin Woodwork

    Interior Equipment NOTICE: While underway at cruise speed, the engine Air conditioners use surface water as a cool- charging systems will provide enough current to ing medium. The boat must be in the water maintain the batteries with the DC air conditioner and the raw water supply system must be operating.
  • Page 144 NOTES...

  • Page 145: Routine Maintenance

    Chapter 13: Routine Maintenance rate first, protecting the more noble underwater 13.1 Exterior Hull and Deck hardware against galvanic corrosion. Anodes Hull Cleaning-Below The Water Line provide protection against galvanic corrosion for When the boat is removed from the water, clean the engines, thru-hull fittings, trim tabs and other the outer bottom surface immediately.
  • Page 146 Routine Maintenance Stainless Steel Hardware effects as they have on an automobile finish. The wax will fill minute scratches and pores thus When using the boat in saltwater, the hardware helping to prevent soiling and will extend the life should be washed with soap and water after each of the gel coat or paint.
  • Page 147 Routine Maintenance anodized aluminum will penetrate the anodized overlooked when the boat is washed and will not coating and attack the aluminum. be rinsed by the rain. Consequently, the powder coating near fasteners and hardware mounted Pay special attention to the area just below the just below the top is more likely to be attacked by top.

  • Page 148: Upholstery, Canvas And Enclosures

    Routine Maintenance Notice: • Dried on dirt - Wash with a soft cloth dampened You should contact Scout Customer Service with water. before making any modifications to alumi- num fabrications. Unauthorized modifica- • Variations in surface gloss - Wipe with a water tions can void the warranty.
  • Page 149 Routine Maintenance After several years, the acrylic canvas may lose curtains. After cleaning the curtains and allowing some of its ability to shed water. If this occurs, them to dry, apply a non-lemon furniture polish wash the fabric and let it dry thoroughly. Then or an acrylic glass and clear plastic protector to treat the outside surface with a commercially extend the life of the curtains.

  • Page 150: Interior

    Routine Maintenance Remember, the coating on strataglass is scratch In most cases, Corian can be repaired if acciden- resistant and not scratch proof. Always handle tally damaged. Minor damage, including scratches, the curtains with care and never roll up curtains general or chemical stains, scorches or burns, that are salty or dirty.

  • Page 151: Bilge

    Routine Maintenance provide additional information on fuel degradation 13.6 Drainage System and fuel stabilizers recommended for your engine. It is essential that the following items be done periodically to maintain proper drainage of your In many states, most gasoline is blended with boat: ethanol alcohol.
  • Page 152 NOTES...

  • Page 153: Seasonal Maintenance

    Chapter 14: Seasonal Maintenance lines. Therefore, if your boat is not being run 14.1 Storage and Lay-up enough to require at least one full tank of Before Hauling: fresh fuel a month or during winter storage, a • Pump out the head holding tank. Flush the fuel stabilizer should be added to the gasoline holding tank using clean water, soap and a to help protect the fuel system from these...
  • Page 154 Seasonal Maintenance Lifting Notice: Read the owner’s manual for the trailer for It is essential that care be used when lifting your the correct amount of inflation for the tires. boat. Make sure the spreader bar at each sling is at least as long as the distance across the widest When storing the boat on a lift or cradle: point of the boat that the sling will surround.

  • Page 155: Winterizing

    Seasonal Maintenance • Thoroughly wash the fiberglass exterior, 14.2 Winterizing especially the antifouling portion of the Fresh Water System bottom. Remove as much marine growth as The entire fresh water system must be completely possible. Lightly wax the exterior fiberglass drained and winterized using the following pro- components.
  • Page 156 Seasonal Maintenance Raw Water System Baitwell Recirculation System The raw water washdown and seawater supply Install the baitwell drain plug and pour potable pumps and systems must be drained and winter- water antifreeze in the baitwell until it covers the ized using the following procedure.
  • Page 157 Seasonal Maintenance winterized by following winterizing procedure in clear of debris. Remove the tower sun shade, if the manufacturer’s owner’s manual. installed, and belly band or removable cushions. Then thoroughly clean and store in a safe, dry The air conditioner condensation drain system place.

  • Page 158: Recommissioning

    Seasonal Maintenance Proper storage is very important to prevent serious • Pump the antifreeze from the fresh and raw damage to the boat. If the boat is to be stored water systems and flush several times with indoors, make sure the building has enough ven- fresh water.

  • Page 159: Appendix A: Schematics

    Appendix A: Schematics...
  • Page 160 NOTES...

  • Page 161: Appendix B: Glossary Of Terms

    Appendix B: Glossary Of Terms ft: In, near, or toward the stern of a boat. Bow Rail: Knee high rails of solid tubing to aid in preventing people from falling overboard. Aground: A boat stuck on the bottom. Bridge: The area from which a boat is steered Amidships: In or toward the part of a boat midway and controlled.
  • Page 162 Glossary of Terms Ground Tackle: A general term including anchors, eck: The floor-like platform of a boat that lines, and other gear used in anchoring. covers the hull. Grounds: A boat touches the bottom. Displacement: The volume of water displaced by the hull.
  • Page 163 Glossary of Terms Limber Hole: A passage cut into the lower edges Pitching: The fore and aft rocking motion of a of floors and frames next to the keel to allow bilge boat as the bow rises and falls. water to flow to the lowest point of the hull where it can be pumped overboard.
  • Page 164 Glossary of Terms Scupper: An opening in the hull side or transom affrail: Rail around the rear of the cockpit. of the boat through which water on deck or in the cockpit is drained overboard. Thru-hull: A fitting used to pass fluids (usually Seacock: Safety valves installed just inside the water) through the hull surface, either above or thru-hull fittings and ahead of the piping or hose...

  • Page 165: Appendix C: Maintenance Log

    Appendix C: Maintenance Log Date Hours Dealer Service/Repairs...
  • Page 166 Maintenance Schedule Log Date Hours Dealer Service/Repairs...
  • Page 167 Maintenance Schedule Log Date Hours Dealer Service/Repairs...
  • Page 168 Maintenance Schedule Log Date Hours Dealer Service/Repairs...
  • Page 169 Maintenance Schedule Log Date Hours Dealer Service/Repairs...
  • Page 170 Maintenance Schedule Log Date Hours Dealer Service/Repairs...

  • Page 171: Boating Accident Report

    Boating Accident Report Appendix D:                                       ...
  • Page 172 Boating Accident Report                                      ...
  • Page 173 Boating Accident Report                                                  ...
  • Page 174 NOTES...

  • Page 175: Appendix E: Float Plan

    Appendix E: Float Plan Float Plan Scout recommends filling out a float plan each time you use your boat for an offshore day trip or a long cruise. Leave this information with a responsible person ashore, like a close friend or relative that you know well. 1.
  • Page 176 NOTES...

  • Page 177: Troubleshooting Guide

    Appendix F: Troubleshooting Guide PROBLEM CAUSE AND SOLUTION CONTROL SYSTEMS • Steering system is low on fluid. Fill and bleed system. Hydraulic steering is slow to respond & erratic and/or the • Steering system has air in it. Fill and bleed system. steering wheel feels bumpy.
  • Page 178 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ENGINE PROBLEMS • The engine raw water pick up strainer is clogged with marine An engine is running too hot. growth. Clean pick up. • The engine raw water pump impeller is worn or damaged. Repair the pump.
  • Page 179 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS • The sea chest supply valve is not open. Open valve. The baitwell pump runs, but does not pump water. • The sea chest intake strainers are clogged with weeds or debris.
  • Page 180 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS • The fuse or circuit breaker for the automatic switch has The automatic switch on the bilge pump does not activate tripped or blown. Replace the fuse or reset the circuit the pump .
  • Page 181 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS The air conditioner runs for a short time & then cuts out. • The intake strainers for the sea chest are clogged with weeds or debris. Clean the sea strainers. • The air conditioner pump raw water supply valve is closed. Open the valve.
  • Page 182 Trouble Shooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS • Outlet breaker in AC panel is off. Activate breaker. No AC power at outlets • Ground fault interrupter on the GFI outlet has tripped. Push reset button on outlet to reset. •...
  • Page 184 Scout Boats Inc. 2531 Hwy 78 West Summerville, SC 29483...

Table of Contents

Save PDF
