- Page 1 245 XSF Owner’s Manual Scout Boats Inc. 2531 Hwy 78 West Summerville, SC 29483...
- Page 2 THIS PAGE WAS LEFT BLANK INTENTIONALLY Print Date 1-29-2009...
-
Page 3: Safety Information
SAFETY INFORMATION Your Scout manual has been written to include a number of safety instructions to assure the safe operation and maintenance of your boat. These instructions are in the form of DANGER, WARNING, CAUTION, and NOTICE statements. The follow- ing definitions apply: HAZARDS OR UNSAFE PRACTICES WHICH COULD RESULT IN MINOR PERSONAL INJURY... - Page 4 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 5: Boat Information
BOAT INFORMATION Please fill out the following information section and leave it in your Scout Owner’s Manual. This information will be important for you and Scout service personnel to know, if and when you may need to call Scout for technical assistance or service. BOAT MODEL: HULL SERIAL #:... -
Page 6: Specifications
SPECIFICATIONS HULL LENGTH OVERALL __________________________________________________ 24’5” BEAM ___________________________________________________________________ 8’6” DRY WEIGHT W/O ENGINE (approx) _______________________________________ 2,600 lbs FUEL CAPACITY _____________________________________________________ 100 gallons WATER CAPACITY ____________________________________________________ 10 gallons DEADRISE _______________________________________________________________ 20 MAXIMUM HORSEPOWER ________________________________________________ 300 hp DRAFT ____________________________________________________________________ 17” OUTBOARD SHAFT _________________________________________________________ 25” MAXIMUM PERSONS / GEAR WEIGHT _________________________ 8 persons or 1,400 lbs MAXIMUM WEIGHT / PERSONS, MOTOR, GEAR ____________________________ 2,500 lbs... -
Page 7: Certifications & Specifications
To be in compliance with European directives for recreational boats as published by the International Organization for Standardization (ISO) in effect at the time this boat was manufactured, we are providing the following information. Manufacturer: Scout Boats Name: 2531 Hwy 78 West... - Page 8 (7) Any Scout Boat sold to a customer, (who happens to be the original owner), by anyone other than an authorized Scout Boats, Inc. dealer. (8) Any Scout Boat that has been used on a trailer that does not adequately support the hull or any trailer that may be considered undersized, including any and all roller type trailers.
- Page 9 Scout Boats, Inc. within 10 days of sale of his/her boat to the new owner. A notarized bill of sale and a $100 administration fee payable to Scout Boats, Inc.
- Page 10 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 11: Owner's / Operator's Information
OWNER’S / OPERATOR’S INFORMATION Registration and Numbering are worthwhile even for experienced boaters to sharpen your Federal law requires that all undocumented vessels equipped skills or bring you up to date on current rules and regulations. with propulsion machinery be registered in the state of principal They can also help in providing local navigational information use. - Page 12 If you need any additional information about your Yamaha place. After which, the transferee will be treated as the original or warranty coverage which your dealer cannot provide, purchaser as outlined in the Scout Boats Limited Warranty please refer to your engine owner’s manual for the address Statement.
-
Page 13: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION ................................3 BOAT INFORMATION ................................. 5 SPECIFICATIONS ..................................6 CERTIFICATIONS & SPECIFICATIONS ..........................7 OWNER’S / OPERATOR’S INFORMATION ..........................11 Chapter 1: PROPULSION SYSTEM 1.1 General ....................................17 1.2 Drive System Corrosion ............................... 17 1.3 Engine Lubrication ................................18 1.4 Engine Cooling System ................................ - Page 14 TABLE OF CONTENTS Chapter 6: RAW WATER SYSTEM 6.1 General ....................................39 6.2 Raw Water System Operation .............................. 39 6.3 Livewell ....................................40 6.4 Raw Water System Maintenance ................................ 41 Chapter 7: DRAINAGE SYSTEMS 7.1 General ....................................43 7.2 Cockpit Drains ..................................43 7.3 T-Top Drains ..................................
- Page 15 TABLE OF CONTENTS Chapter 12: OPERATION 12.1 General ....................................61 12.2 Rules of the Road ................................61 12.3 Pre-Cruise Check ................................64 12.4 Operating Your Boat ................................65 12.5 Docking, Anchoring and Mooring ............................ 66 12.6 Controls, Steering or Propulsion System Failure ......................68 12.7 Collision ....................................
- Page 16 TABLE OF CONTENTS Appendix C: MAINTENANCE SCHEDULE AND LOG ..........................95 Appendix D: BOATING ACCIDENT REPORT .............................. 101 Appendix E: FLOAT PLAN .................................... 105 Appendix F: TROUBLESHOOTING GUIDE ..............................107...
-
Page 17: Propulsion System
Chapter 1: PROPULSION SYSTEM 1.1 General Your Scout is designed to be powered with a 2-cycle or 4-cycle outboard motor. 4-cycle outboard engines do not use an oil injection system and are not equipped with remote oil tanks. They have an oil sump in the crankcase that must be kept full of the type of oil recommended by the engine manufacturer. -
Page 18: Engine Lubrication
1.3 Engine Lubrication 2-cycle outboard motors are lubricated by a variable ratio oil injection system. The oil tank is mounted below the cockpit floor near the transom. Always monitor the oil level before each cruise by checking the gauge or indicator lights in the helm (not available on all engine installations) or visually checking the oil level using the reference marks on the tank. -
Page 19: Performance Issues And Propellers
Note: Most Scout boats are equipped with Yamaha engines and multifunction instruments. A brief • Boats operated at high altitudes (above 2000 feet). Engines... - Page 20 engine trim indicator is built into the tachometer. Please refer NEVER EXCEED THE MAXIMUM RECOMMENDED the engine owner’s manual for more information on the opera- OPERATION RPM OF THE ENGINE. MAINTAINING tion of the outboard power tilt and trim. MAXIMUM, OR CLOSE TO MAXIMUM RPM FOR EXTENDED PERIODS CAN REDUCE THE LIFE OF Engine Alarms THE ENGINE.
-
Page 21: Helm Control Systems
Chapter 2: HELM CONTROL SYSTEMS General The helm controls consist of three systems: the engine throttle and shift controls, the steering system, and the trim tab control switches. These systems provide the operator with the ability to control the direction and attitude of the boat from the helm station. -
Page 22: Neutral Safety Switch
• Starter lockout, which prevents the engine from being by a qualified marine mechanic before using the boat. If the started in gear. engine starts in gear during this test, immediately move the control lever to the neutral position and turn the engine off. •... -
Page 23: Engine Stop Switch
THE ENGINE COWLING WILL HIT THE WAVE GATE WHEN THE ENGINE IS TILTED TO THE FULL UP OR TRAILERING POSITION. THIS CAN CAUSE SEVERE DAMAGE TO THE ENGINE COWLING AND WAVE GATE. ALWAYS MONITOR THE ENGINE AS IT TILTS AND FOLD DOWN THE WAVE GATE BEFORE TILTING THE ENGINE TO THE FULL UP POSITION. -
Page 24: Control Systems Maintenance
the switch while awaiting the trim plane reaction. By the time the effect is noticeable the trim tab plane will have moved too far and thus the boat will be in an overcompensated position. When running at a speed that will result in the boat falling off plane, lowering the tabs slightly, bow down, will improve the running angle and operating efficiency. - Page 25 Marine growth can interfere with the proper operation of the To discourage any marine growth on tab or actuator, antifoul- trim tab planes and actuators. To reduce problems due to ing paint can be applied. When applying paint to the actuator, make sure it is fully retracted.
- Page 26 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 27: Chapter 3: Fuel System
Chapter 3: FUEL SYSTEM General The gasoline fuel system used in Scout boats is designed to meet or exceed the requirements of the U.S. Coast Guard, the Boating Industry Association, and The American Boat and Yacht Council in effect at the time of manufacture. -
Page 28: Outboard Fuel System
Fuel Vent There is a fuel vent fitting on the starboard side of the hull. While the tank is being filled, the air displaced by the fuel escapes through the vent. When the tank is full, fuel will be ejected from the fuel vent. After fueling, replace the fill cap, and wash the areas around the fuel fill and below the fuel vent. -
Page 29: Fueling Instructions
Fueling Instructions SPILLED FUEL IS DANGEROUS AND CAN YELLOW FIBERGLASS OR IGNITE. MAKE SURE YOU DO NOT SPILL ANY FUEL. IF FUEL IS SPILLED ON THE DECK, USE A CLOTH TO REMOVE THE FUEL AND PROPERLY DISPOSE OF THE CLOTH ON FUEL IS VERY FLAMMABLE. - Page 30 Contaminated fuel may cause serious damage to your engine. The filter must be checked for corrosion and deterioration DO NOT DRAIN ANY FUEL INTO THE BILGE WHEN SERVICING THE FUEL SYSTEM. THIS COULD LEAD frequently. The filter must be changed at least once a season TO A FIRE OR EXPLOSION.
-
Page 31: Electrical System
Chapter 4: ELECTRICAL SYSTEM General Your Scout is equipped with a 12-volt DC electrical system and an optional battery charging system. The battery charger draws current from shore power outlets at dockside. The DC system draws current from two onboard batteries. Your boat and engine charging system is designed for 12-volt, lead acid wet cell marine batteries. - Page 32 Your boat has provision for two batteries. One engine crank- ing battery and one deep cycle house battery. These batter- ies should be of the size and capacity recommended by the manufacturer of your engine. See the engine owner’s manual. These specifications should be considered to be the minimum size battery required.
- Page 33 Pump Aerator/Recirc Switch 2 (Optional) Additional DC Switch Panels Trim Tab Switch The switch is a three-position switch. The middle position is Located in the helm. This switch controls the trim tab planes “OFF.” When the switch is in the RECIRC position it activates located on the transom of the boat.
-
Page 34: Ac System
AC System AC Battery Charger (Optional) The battery charging system is fed 120-volt AC current by a power cable connected to a shore side outlet and the shore power inlet located on the rear of the console, below the helm. It is wired totally separate from the 12-volt DC system and charges all batteries simultaneously when connected. -
Page 35: Electrical System Maintenance
The wires that supply DC charging current to the batteries are protected by an internal fuse in the battery charger and external fuses, one for each battery output wire, located near each bat- tery. The external fuses protect the DC charging circuit from the batteries to the charger. - Page 36 CORROSION ALLOWED TO BUILD ON THE ELECTRICAL CONNECTORS CAN CAUSE A POOR CONNECTION RESULTING IN SHORTS, GROUND FAULTS OR POOR GROUND CONNECTIONS. E L E C T R I C A L C O N N E C TO R S S H O U L D B E CHECKED AT LEAST ANNUALLY AND CLEANED AS REQUIRED.
-
Page 37: Chapter 5: Fresh Water System
Chapter 5: FRESH WATER SYSTEM General The optional fresh water system consists of a potable water tank, distribution lines and a distribution pump. The pump is equipped with an automatic pressure switch and is located behind a panel in the head compartment. The tank is filled through a labeled deck fill located on the port gunnel. -
Page 38: Fresh Water System Maintenance
DO NOT ALLOW THE WATER PUMP TO RUN DRY. THE PUMP WORKS ON DEMAND AND WILL NOT SHUT OFF AUTOMATICALLY WHEN THE TANK IS EMPTY. THIS CAN RESULT IN DAMAGE TO THE PUMP. ALWAYS TURN THE WASHDOWN SWITCH OFF WHEN THE FRESH WATER SYSTEM IS NOT IN USE. -
Page 39: Raw Water System
Chapter 6: RAW WATER SYSTEM General In the raw or sea water systems, the livewell water supply pump is mounted to a seacock on a thru-hull fitting located in the stern bilge compartment and the water system pressure pump is connected to an auxiliary fitting on the pump. If your boat is equipped with the optional aft port livewell, it will be equipped with two seacocks and two livewell water supply pumps. -
Page 40: Livewell
when the washdown is not in use. Make sure the Washdown pump is activated to supply flush water to the porcelain head if your boat is equipped with this option. When activated, the pressure switch will automatically control the pump. As the pressure builds in the system, the pump will shut off. -
Page 41: Raw Water System Maintenance
• Make sure all seacocks are closed before servicing any Raw Water System Maintenance component of the raw water system. The following items should be done routinely to help maintain your raw water system: • Check hoses, particularly the sea water supply lines, for SHOULD A HOSE RUPTURE, TURN THE PUMP OFF IMMEDIATELY. - Page 42 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 43: Chapter 7: Drainage Systems
Chapter 7: DRAINAGE SYSTEMS General All water is drained by gravity to overboard thru-hull fittings located in the hull above the water line. It is important to check the drain system frequently to insure it is free flowing and that the hoses on the thru-hull fittings are secure and not leaking. -
Page 44: Livewells, Fishboxes, Coolers And Storage Compartment Drains
It is important to check the drain plug regularly to make sure it is tight. A LOOSE DRAIN PLUG WILL ALLOW SEA WATER TO ENTER THE BILGE AND COULD CAUSE THE BOAT TO SINK. IT IS VERY IMPORTANT TO CHECK THE DRAIN PLUG FREQUENTLY TO INSURE IT IS PROPERLY TIGHTENED. -
Page 45: Ventilation System
Chapter 8: VENTILATION SYSTEM Head Compartment Ventilation Ventilation to the head compartment area is provided by an opening port window and a vent in the door. Port Window An opening port window is located in the side of the head compartment. - Page 46 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 47: Chapter 9: Exterior Equipment
Spare anchors and weights for floating markers will bounce and damage the hull or rope locker if they SCOUT BOATS ARE NOT EQUIPPED WITH are stored in the anchor/rope locker. Always store and secure HARDWARE DESIGNED FOR TOWING PURPOSES. -
Page 48: Hull
line of the type recommended or supplied by the windlass manufacturer. THE ANCHOR MUST BE POSITIONED SO IT DOES NOT REST DIRECTLY AGAINST THE SIDES OF THE LOCKER AND BE PROPERLY SECURED AT ALL TIMES WHEN IT IS STORED IN THE ANCHOR LOCKER. -
Page 49: Cockpit Features
system. A teak inlay enhances the appearance of the boat and provides an excellent nonskid surface. The teak inlay is a syn- thetic teak called Plasteak. Other than cleaning the surface pe- riodically with soap and water, Plasteak is maintenance free. A telescopic boarding ladder is recessed into the swim platform. - Page 50 IN CERTAIN CONDITIONS, OPEN EXTERIOR DOORS AND HATCHES THAT ARE NOT SECURED PROPERLY CAN SLAM CLOSED UNEXPECTEDLY AND CAUSE INJURY TO PASSENGERS OR DAMAGE TO THE BOAT. SOME DOORS AND HATCHES ARE EQUIPPED WITH SPECIAL FASTENERS, HATCH LIFTERS, OR SNAPS AND/OR STRAPS, TO SECURE THEM IN THE OPEN POSITION.
- Page 51 Stern Bilge Access There is a removable access hatch below the stern seat that provides access to the fuel filter, aft bilge pump, automatic switch for the bilge pump, and other equipment mounted in the stern bilge. OPERATING THE BOAT UNDER POWER WITH THE WAVE GATE AND TRANSOM ACCESS OPEN MAY ALLOW PERSONS TO FALL OVERBOARD AND INTO THE BOAT PROPELLERS OR TO BE LOST IN...
- Page 52 Leaning Post with Seats Up and in Leaning Post Position Bimini Top The canvas for Scout boats is custom fit to each boat. The bimini top is designed with a relatively flat profile and a snug fit.
- Page 53 Scout that is designed to mount only on the center console because Boats Limited Warranty. Additionally, Scout Boats will not be it will cause excessive flexing to the console and cockpit sole responsible for any damage resulting from the installation of a fabrication not installed at the Scout factory.
- Page 54 Refer to the Routine Maintenance section for more informa- tion on maintaining aluminum fabrications and precautions for adding additional equipment and fasteners.
-
Page 55: Chapter 10: Interior Equipment
Chapter 10: INTERIOR EQUIPMENT 10.1 Head Compartment The head compartment is equipped with compartments for the batteries, pressure pump and storage. Additional compartments provide access to mounting areas and service access for helm accessories, control systems and electronics. The access panel for the electronics is secured with screws that must be removed to open the panel for service or installing electronics. - Page 56 The portable head must be properly winterized before winter lay-up or for cold weather use. Please refer to the manu- facturer owner’s manual for winterizing and cold weather instructions Porcelain Marine Head (Optional) The manual marine head is connected to the pressurized fresh or raw water system (depending on the options installed on your boat) which provides flush water to the toilet.
-
Page 57: Chapter 11: Safety Equipment
Chapter 11: SAFETY EQUIPMENT 11.1 General Your boat and outboard engine have been equipped with safety equipment designed to enhance the safe operation of the boat and to meet U.S. Coast Guard safety standards. The Coast Guard or state, county, and municipal law enforcement agencies require certain additional accessory safety equipment on each boat. -
Page 58: Required Safety Equipment
Throwable devices must be immediately available for and must automatically flash the international SOS distress use. All Scout boats must be equipped with at least one Type signal. Under Inland Navigation Rules, a high intensity I, II or III PFD for each person on board, plus one throwable white light flashing at regular intervals from 50-70 times device (Type IV). -
Page 59: First Aid
Refer to the “Federal Requirements And Safety Tips For Rec- keep other vessels informed of your presence and course. Your reational Boats” pamphlet or Contact the U.S. Coast Guard Scout is equipped with the navigation lights required by the Boating Safety Hotline, 1-800-368-5647, for information on U.S. -
Page 60: Caution And Warning Labels
WARNING - “LEAKING 11.8 Caution and Warning Labels FUEL IS A FIRE AND EX- PLOSION HAZARD” “245 XSF” - Designator” is on the port & stbd sides of the windshield Next to hatch in head com- partment WIRING COLOR CODE Label is on the console next to the helm. -
Page 61: Chapter 12: Operation
Chapter 12: OPERATION 12.1 General 12.2 Rules of the Road Before you start the engine on your Scout, you should have As in driving an automobile, there are a few rules you must become familiar with the various component systems and their know for safe boating operation. - Page 62 Night Operation Recreational boats are required to display navigation lights between sunset and sunrise and other periods of reduced vis- ibility such as fog, rain, haze, etc. When operating your boat at night you should: • Make sure your navigation lights are on and working properly.
-
Page 64: Pre-Cruise Check
12.3 Pre-Cruise Check THERE MUST BE AT LEAST ONE PERSONAL Before Starting the Engine FLOTATION DEVICE ON BOARD FOR EVERY PERSON ON BOARD AND ONE THROW-OUT FLOTATION DEVICE. CHECK THE U.S. COAST • Check the weather forecast. Decide if the planned cruise GUARD STANDARDS FOR THE CORRECT TYPE can be made safely. -
Page 65: Operating Your Boat
12.4 Operating Your Boat YOU SHOULD NEVER OPERATE YOUR BOAT WHILE UNDER THE INFLUENCE OF ALCOHOL AND DRUGS. TO REDUCE THE RISK OF A FIRE OR EXPLOSION, DO NOT START THE ENGINE WHEN FUEL FUMES MAKE SURE ONE OTHER PERSON ON THE ARE PRESENT. -
Page 66: Docking, Anchoring And Mooring
Note: If the engine has been run at high speed for a long are new to boat handling, you should take lessons from an period of time, allow the engine to cool down by experienced pilot to learn how to maneuver your boat in tight running the engine in the idle position for 3 to 5 quarters in less than ideal conditions. - Page 67 that prevent the boat from hitting the dock. The bow lines are typically secured with enough slack to allow the boat to ride the tide. The stern lines are crossed. One line runs from the port aft boat cleat to the starboard dock cleat and the other line runs from the starboard aft boat cleat to the port cleat on the dock.
-
Page 68: Controls, Steering Or Propulsion System Failure
THE MOORING CLEATS ON SCOUT BOATS ARE NOT DESIGNED OR INTENDED TO BE USED You must always make sure the helm is properly manned FOR TOWING PURPOSES. -
Page 69: Water Skiing
If you are fishing in an area that is crowded with other fishing MOVING PROPELLERS ARE DANGEROUS. boats, it may be difficult to follow the rules of the road. This THEY CAN CAUSE DEATH, LOSS OF LIMBS, OR situation can become especially difficult when most boats are OTHER SEVERE INJURY. -
Page 70: Trash Disposal
• Make sure the trailer is a match for your boat’s weight and 12.13 Trash Disposal hull design. More damage can be done to a boat by the The discharge of plastic trash or trash mixed with plastic is stresses of road travel than by normal water operation. A illegal anywhere in the marine environment. - Page 71 • Make sure the tow BALL and TRAILER COUPLER are the same size and bolts and nuts are tightly secured. • The COUPLER MUST BE COMPLETELY OVER THE BALL and the LATCHING MECHANISM LOCKED DOWN. • Make sure the TRAILER IS LOADED EVENLY from front to rear as well as side to side and has the correct weight on the hitch.
- Page 72 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 73: Routine Maintenance
Chapter 13: ROUTINE MAINTENANCE make sure the contact surfaces are clean, shinny metal and free 13.1 Exterior Hull and Deck of paint and corrosion. Never paint over the anode. Hull Cleaning-Below The Water Line When the boat is removed from the water, clean the outer bot- Boats stored in saltwater will normally need to have the an- tom surface immediately. - Page 74 ONE DRAWBACK TO METAL PROTECTORS IS DO NOT WAX NONSKID AREAS AS THIS COULD THAT THEY CAN MAKE THE METAL SLIPPERY. MAKE THEM SLIPPERY AND CONSEQUENTLY THEREFORE, THEY SHOULD BE NOT BE USED INCREASE THE POSSIBILITY OF INJURY. ON TOWER LADDERS, STEERING WHEELS AND OTHER AREAS WHERE A GOOD GRIP AND SURE FOOTING IS IMPORTANT.
-
Page 75: Upholstery, Canvas And Enclosures
If excessive chipping and peeling occurs, it could be an indica- The age of gasoline can effect engine performance. Chemical tion of an electrical fault in the boat or aluminum fabrication. changes occur as the gasoline ages that can cause deposits and You should contact a qualified marine electrician to inspect varnish in the fuel system as well as reduce the octane rating your boat immediately and correct the problem if you suspect... - Page 76 • Stubborn spots and stains - Spray with either Fantastik leak at the seams than with acrylic or vinyl coated polyester. Cleaner or Tannery Car Care Cleaner and rub with a Paraffin wax that matches the top can be used to seal the seams ®...
-
Page 77: Interior
Strataglass can be cleaned by rinsing off dirt or salt deposits If you leave the boat for a long period of time, put all cushions with fresh water, then washing with a clean cloth and mild soap. on their sides, open all interior cabin and locker doors, and hang Chamois dry to remove water spots and improve clarity. - Page 78 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 79: Seasonal Maintenance
Chapter 14: SEASONAL MAINTENANCE 14.1 Storage and Lay-up BOATS CAN BE DAMAGED FROM IMPROPER LIFTING AND TRANSPORTING WITH FORK LIFTS. Before Hauling: CARE AND CAUTION MUST BE EXERCISED WHEN TRANSPORTING A BOAT WITH A FORK LIFT. • Pump out the head holding tank. Flush the holding tank NEVER HOIST THE BOAT WITH A SUBSTANTIAL using clean soap, water and a deodorizer. -
Page 80: Winterizing
When storing the boat on a lift or cradle: • Thoroughly clean the interior of the boat. Vacuum all carpets and dry clean drapes and upholstery. • The cradle must be specifically for boat storage. • Remove cushions, open as many locker doors as possible. •... - Page 81 the solution. Run the pumps one at a time until the antifreeze Clean the aluminum frame with soap and water and dry thor- solution is visible at all raw water faucets and discharge fit- oughly. Apply an aluminum metal protector to the entire frame tings and drains.
-
Page 82: Recommissioning
After Launching: 14.3 Recommissioning • Carefully check all water systems and the engine bolts DO NOT OPERATE THE BOAT UNLESS IT IS for leaks. Operate each system one at a time checking for COMPLETELY ASSEMBLED. KEEP ALL FASTENERS TIGHT. KEEP ADJUSTMENTS ACCORDING TO leaks and proper operation. -
Page 83: Appendix A: Schematics
Appendix A: SCHEMATICS 245 XSF ELECTRICAL SYSTEM LEGEND A. Port Bow Light B. Stbd Bow Light C. Port Foward Speaker D. Port Aft Speaker E. Stbd Foward Speaker F. Stbd Aft Speaker G. House Battery H. Cranking Battery Switch Panel J. -
Page 84: Main Wiring Harness
Main Wiring Harness... -
Page 85: Battery Select Panel
Battery Select Panel... -
Page 86: Hydraulic Steering System
245 XSF HYDRAULIC SYSTEM LEGEND A. Sea Star Hydraulic Tilt Helm 1.7 Square Inch PRT # HH5741 B. Sea Star Hydraulic Lines with Baulkhead Fittings. (20ft.) C. Sea Star Hydraulic Front Mount Cylinder Hydraulic Steering System... -
Page 87: Fuel System
245 XSF FUEL SYSTEM LEGEND A. Fuel Tank B. Deck Fuel Fill w/Built in Vent C. Fuel Tank Vent and Fill D. Sending Unit E. Fuel Pick Up F. Fuel-Water Seperator, Yamaha 10- Micron Filter PRT# MAR-FUELF-IL-TR Fuel System... -
Page 88: Water System
245 XSF WATER SYSTEM LEGEND A. Fresh Water Fill and Vent B. Fresh Water Tank C. Fresh Water Pump D. Toilet Fresh Water Supply E. Fresh Water Quick Connect F. Tolit Raw Water Supply G. Aerator w/ Seacock H. Raw Water Washdown Pump Raw Water Quick Connect J. -
Page 89: Drainage System
245 XSF DRAINAGE SYSTEM LEGEND A. Anchor Box Drain (overboard) B. Fwd Cooler Box Drain (stringer) C. Port Fish Box Drain (overboard) D. Storage Box (stringer) E. Stbd Fish Box Drain (overboard) F. Console Cooler Box Drain (stringer) G. Toilet w/holding tank (optional) H. - Page 90 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 91: Glossary Of Terms
Appendix B: GLOSSARY OF TERMS Bow Rail: Knee high rails of solid tubing to aid in preventing ft: In, near, or toward the stern of a boat. people from falling overboard. Aground: A boat stuck on the bottom. Bridge: The area from which a boat is steered and con- trolled. - Page 92 Ground Tackle: A general term including anchors, lines, and eck: The floor-like platform of a boat that covers the other gear used in anchoring. hull. Grounds: A boat touches the bottom. Displacement: The volume of water displaced by the hull. The displacement weight is the weight of this volume of water.
- Page 93 Limber Hole: A passage cut into the lower edges of floors and Pitch: The measure of the angle of a propeller blade. Refers frames next to the keel to allow bilge water to flow to the lowest to the theoretical distance the boat travels with each revolution point of the hull where it can be pumped overboard.
- Page 94 Seacock: Safety valves installed just inside the thru-hull Topsides: The side skin of a boat between the waterline or fittings and ahead of the piping or hose running from the fit- chine and deck. tings. Transom: A flat stern at right angles to the keel. Shaft Log: Pipe through which the propeller shaft passes.
-
Page 95: Maintenance Schedule And Log
Appendix C: MAINTENANCE SCHEDULE AND LOG Appendix C: MAINTENANCE SCHEDULE AND LOG MAINTENANCE Clean hull below the waterline Bottom paint hull Check sacrificial anodes Replace sacrificial anodes Wash boat canvas & hardware Wax exterior gelcoat Clean & protect hardware Polish & protect plastic glass Clean exterior upholstery Clean cabin &... -
Page 96: Maintenance Log
MAINTENANCE LOG Service/Repairs Date Dealer Hours... - Page 97 MAINTENANCE LOG Service/Repairs Date Dealer Hours...
- Page 98 MAINTENANCE LOG Service/Repairs Date Dealer Hours...
- Page 99 MAINTENANCE LOG Service/Repairs Date Dealer Hours...
- Page 100 MAINTENANCE LOG Service/Repairs Date Dealer Hours...
-
Page 101: Boating Accident Report
Appendix D: BOATING ACCIDENT REPORT ... - Page 102 BOATING ACCIDENT REPORT ...
- Page 103 BOATING ACCIDENT REPORT ...
- Page 104 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 105: Float Plan
Appendix E: FLOAT PLAN Scout recommends filling out a float plan each time you use your boat for an offshore day trip or a long cruise. Leave this information with a responsible person ashore, like a close friend or relative that you know well. 1. - Page 106 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
-
Page 107: Troubleshooting Guide
Appendix F: TROUBLESHOOTING GUIDE PROBLEM CAUSE AND SOLUTION CONTROL SYSTEMS Hydraulic Steering is slow to respond & erratic. • Steering system is low on fluid. Fill and bleed system. • Steering system has air in it. Fill and bleed system. •... -
Page 108: Engine Problems
Troubleshooting Guide PROBLEM CAUSE AND SOLUTION ENGINE PROBLEMS The engine is running too hot. • The engine raw water pick up strainer up is clogged with marine growth. Clean pick up • The engine raw water pump impeller is worn or damaged. Repair the pump. -
Page 109: Accessory Problems
Troubleshooting Guide PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS The baitwell pump runs, but does not pump water. • The strainer on the intake scoop is clogged preventing the water from getting to the pump. Put the boat in reverse to clean the strainer. - Page 110 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
