Summary of Contents for thomann the t.mix xmix 1402 USB
- Page 1 xmix 1402 USB mixer user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 01.02.2018, ID: 422792...
-
Page 3: Table Of Contents
Table of contents Table of contents General information......................4 1.1 Further information......................4 1.2 Notational conventions....................4 1.3 Symbols and signal words................... 4 Safety instructions......................... 6 Features............................8 Installation and starting up....................9 Connections and controls....................10 Technical specifications....................17 Plug and connection assignment................. -
Page 4: General Information
Our products are subject to a process of continuous development. Thus, they are subject to change. 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. - Page 5 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a possible dangerous situation that can result in minor injury if it is not avoided.
-
Page 6: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used for amplification, mixing and playback of signals from musical instruments and microphones. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 7 Safety instructions CAUTION! Possible hearing damage With loudspeakers or headphones connected, the device can produce volume levels that may cause temporary or permanent hearing impair- ment. Do not operate the device permanently at a high volume level. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment.
-
Page 8: Features
Features Features 12-channel mixer with built-in FX processor 8 mono channels (MIC, line) with low cut 3-band EQ and pan control 2 stereo channels with 2-band EQ and balance control Control room output L/R (1/4" jack) Additional RCA connections (stereo in / rec out) 1 ×... -
Page 9: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. -
Page 10: Connections And Controls
Connections and controls Connections and controls Mono channel strip 1 [MIC] Balanced XLR mono input to connect a microphone. 2 [LINE] 1/4" phone input to connect a line level audio source (keyboards, drum modules etc., balanced or unbalanced). 3 [80 Hz HPF] High pass filter to attenuate rumble noise and other low frequency interfer- ence. - Page 11 Connections and controls Stereo channel strip 14, 16 [STEREO IN] RCA sockets for connecting stereo sources. 15, 17 [REC OUT] Line outputs with RCA sockets for connecting recording devices. 18, 19 [L] 1/4" phone input to connect the left signal of a stereo line level audio source (keyboards, drum modules etc.).
- Page 12 Connections and controls 32 [PEAK] The LED lights up on channel overload. If this happens in channel 9/10 press the [PAD] switch. When overload occurs in channel 11/12 reduce the output level of the signal source connected here. 33 The channel fader sets the strength of the channel signal in the overall signal.
- Page 13 Connections and controls Master section [AUX SEND] At this line level output the signal set with the [AUX]channel controls is present, maybe to create a monitor mix. [FX SEND] At this line level output the signal set with the [FX]channel controls is present, maybe to be sent to an external effects device.
- Page 14 Connections and controls [+48V] LED This LED is lit when the phantom power is on. [+48V] switch When this switch is in ON position, a phantom voltage of 48 V is present at the XLR sockets in the mono channels for using condenser mics.
- Page 15 Connections and controls Rear panel 53.54 [MAIN OUTPUTS] Balanced 1/4" phone outputs for connecting power amplifiers, effects or recording devices. 55.56 [MAIN OUTPUTS] Balanced XLR outputs for connecting power amplifiers, effects or recording devices. 57 [POWER] Mains switch to turn the device on or off. 58 IEC chassis plug for mains connection with fuse holder.
- Page 16 Connections and controls Connection pattern – PC home recording mixer...
-
Page 17: Technical Specifications
Technical specifications Technical specifications Max. output level (1% THD @ 1 kHz) MAIN OUTPUT XLR: +26 dBu ± 1 dBu 1/4" phone socket, balanced: +26 dBu ± 1 dBu Max. output level (1% THD @ 1 kHz) MAIN OUTPUT XLR: +21 dBu ± 1 dBu 1/4"... -
Page 18: Plug And Connection Assignment
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equipment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... - Page 19 Plug and connection assignment XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) XLR plug (unbalanced) Ground, shielding Signal Bridged to pin 1 RCA connection Drawing and table indicate the pin assignment of an RCA plug. Signal Ground, shielding xmix 1402 USB...
-
Page 20: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging material For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 21 Notes xmix 1402 USB...
- Page 22 Notes mixer...
- Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
