  • Page 1 mix 502, mix 802 Mixer...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 19.02.2024, ID: 370662, 370664 (V4)

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features............................... 10 Installation and starting up........................ 12 Connections and controls........................13 Technical specifications........................26 Plug and connection assignment....................30 Protecting the environment......................33 mix 502, mix 802 Mixer...
  • Page 4 mix 502, mix 802 Mixer...

  • Page 5: General Information

    Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
  • Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.

  • Page 7: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used for amplification, mixing and playback of signals from musical instruments and microphones. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 8 Safety instructions WARNING! Possible hearing damage due to high volumes on speakers or headphones! With speakers or headphones connected, the device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Do not operate the device permanently at a high volume level.
  • Page 9 Safety instructions NOTICE! Damage to the external power supply due to high voltages! The device is powered by an external power supply. The external power supply can be damaged if it is operated with the incorrect voltage or if high voltage peaks occur. In the worst case, excess voltages can also cause a risk of injury and fires. Make sure that the voltage specification on the external power supply matches the local power grid before plugging in the power supply.

  • Page 10: Features

    Features Features mix 502 5-channel mixer 1 × mono input (MIC, line) 2 × stereo input (line) 1 × master output (stereo) 1 × stereo RCA audio input 1 × stereo RCA audio output 2-band equalizer (mono channel) Pan control 48 V phantom power Headphone output separately adjustable Suitable power supply included...
  • Page 11 Features mix 802 8-channel mixer 4 × mono input (MIC, line) 2 × stereo input (line) 1 × master output (stereo) 1 × control room output 1 × stereo RCA audio input 1 × stereo RCA audio output 3-band equalizer Pan control 48 V phantom power Headphone output separately adjustable...

  • Page 12: Installation And Starting Up

    Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.

  • Page 13: Connections And Controls

    Connections and controls Connections and controls mix 502 – overview mix 502, mix 802 Mixer...
  • Page 14 Connections and controls mix 502 – view A ö 1 [MIC]/[LINE IN] | Mono input channel with [MIC] XLR input socket and 6.3-mm [LINE IN] jack socket. 2 [LINE IN X/X] | Stereo input channels, each with 2 × 6.3-mm jack sockets (L/R) for connecting a stereo source (keyboard, drum module, etc.) or an instrument (guitar, bass).
  • Page 15 Connections and controls mix 502 – view B & mix 502, mix 802 Mixer...
  • Page 16 Connections and controls 5 [CD/TAPE INPUT] | Stereo input for feeding the signal from a CD or MP3 player, designed as cinch socket pair. [CD/TAPE OUTPUT] | Stereo output for connecting an external recording device, designed as cinch socket pair. 6 [PHANTOM] | Switch to enable 48 V phantom power for condenser microphones connected to the XLR input of a mono + 48V] lights up yellow.
  • Page 17 Connections and controls [TRIM] | Rotary control for adjusting the gain. [EQ] | Rotary controls for adjusting treble and bass frequencies. [PAN] | Rotary control for adjusting the right/left balance in the stereo signal. [LEVEL] | Rotary control for adjusting the output signal volume. mix 502, mix 802 Mixer...
  • Page 18 Connections and controls mix 802 – overview mix 502, mix 802 Mixer...
  • Page 19 Connections and controls mix 802 – view A ö & 1 [MIC]/[LINE IN] | Mono input channels with [MIC] XLR input socket and 6.3-mm [LINE IN] jack socket, with rotary control for [TRIM] channel-specific gain. 2 [LINE IN X/X] | Stereo input channels, each with 2 × 6.3-mm jack sockets (L/R) for connecting a stereo source (keyboard, drum module, etc.) or an instrument (guitar, bass).
  • Page 20 Connections and controls 3 [MAIN OUT] | Stereo output with 2 × 6.3-mm jack sockets (unbalanced) for connecting a PA system, a PC or powered speakers. The main signal is present on this output with 0 dBu, and the volume is controlled by the [MAIN MIX] rotary control.
  • Page 21 Connections and controls mix 802 – view B mix 502, mix 802 Mixer...
  • Page 22 Connections and controls 8 [CD/TAPE TO PHONES] | Press [CD/TAPE TO PHONES] to route the [CD/TAPE INPUT] input signal to the headphone output. Then the signal is not present on the main output. [CD/TAPE TO MIX] | Press [CD/TAPE TO MIX] to route the [CD/TAPE INPUT] input signal to the main mix. The volume is then controlled via the [MAIN MIX] rotary control.
  • Page 23 Connections and controls 11 Mono channels 1 … 4 [EQ] | Rotary controls for adjusting treble, mids and bass [FX] | Rotary control for adjusting the channel effects share of the overall volume. [PAN] | Rotary control for adjusting the right/left balance in the stereo signal. [LEVEL] | Rotary control for adjusting the output signal volume.
  • Page 24 Connections and controls Connection example – club gig HI-HAT HH CTRL SNARE CRASH 1 CRASH 2 RIDE KICK L/MONO AUX IN – OUTPUT TOM 1 TOM 2 TOM 3 TOM 4 MIDI IN MIDI OUT KIT INST SONG DEMO UTY CLICK HIGH MPS-600 CLICK...
  • Page 25 Connections and controls Connection example – PC home recording HI-HAT HH CTRL SNARE CRASH 1 CRASH 2 RIDE KICK L/MONO AUX IN – OUTPUT TOM 1 TOM 2 TOM 3 TOM 4 MIDI IN MIDI OUT KIT INST SONG DEMO UTY CLICK MPS-600 CLICK TEMPO...

  • Page 26: Technical Specifications

    Technical specifications Technical specifications Input connections Microphone input Type 1 … 4 × XLR panel socket, 3-pin, balanced Level max. +12 dBu @ +10 dB gain Impedance 2.6 kΩ Signal gain +10 … +60 dB Line input Type 1 … 4 × 6.3-mm jack socket, balanced or unbal‐ anced Level max.
  • Page 27 Technical specifications Stereo output (main) Type 2 × 6.3-mm jack socket, unbalanced Level max. +28 dBu Impedance 120 Ω Stereo output (line) Type 2 × cinch sockets Stereo aux (t.mix 802) Type 2 × 6.3-mm jack socket Level max. +22 dBu Impedance 20 kΩ...
  • Page 28 Technical specifications <10 Hz … 160 kHz (0 dB / –3 dB) Signal-to-noise ratio 110 dB / 112 dB, A-weighted Total harmonic distortion (THD) 0.005% / 0.004%, A-weighted Phantom power 48 V Equalizer HIGH range 12 kHz /15 dB MID range 2.5 kHz /15 dB LOW range 80 Hz /15 dB...
  • Page 29 Technical specifications Further information t.mix mix 502 t.mix mix 802 Built-in effects unit 19-inch rack-mountable Microphone channels Number of stereo inputs Number of buses 1 (post) Phantom power Built-in power supply Parametric Digital interface mix 502, mix 802 Mixer...

  • Page 30: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 31 Plug and connection assignment 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground 1/4" TRS phone plug (stereo, unbalanced) Signal (left) Signal (right) Ground mix 502, mix 802 Mixer...
  • Page 32 Plug and connection assignment XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) XLR plug (unbalanced) Ground, shielding Signal Bridged to pin 1 RCA connection Drawing and table indicate the pin assignment of an RCA plug. Signal Ground, shielding mix 502, mix 802...

  • Page 33: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 34 Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it.
  • Page 36 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
