Summary of Contents for thomann t.mix xmix 1002 FX USB

  • Page 1 xmix 1002 FX USB Mixer...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 19.02.2024, ID: 422793 (V2)
  • Page 3: Table Of Contents

    Table of contents Table of contents General information......................5 1.1 Symbols and signal words................... 5 Safety instructions......................... 6 Features............................8 Installation and starting up....................9 Connections and controls....................10 Technical specifications....................16 Plug and connection assignment................. 18 Protecting the environment................... 20 xmix 1002 FX USB Mixer...
  • Page 4 xmix 1002 FX USB Mixer...
  • Page 5: General Information

    Our products and documentation are subject to a process of continuous develop‐ ment. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
  • Page 6: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used for amplification, mixing and playback of signals from musical instruments and microphones. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 7 Safety instructions NOTICE! Danger of short circuit due to use of unbalanced XLR cables! The device has a phantom voltage input. Using unbalanced cables with the phantom power may damage the device. Use only balanced cables. Before switching on phantom power, always make sure that no unbalanced wired cables are connected. NOTICE! Risk of fire due to installation of a wrong fuse! Using fuses of a different type than compatible with the device may cause a fire and seriously damage the device.
  • Page 8: Features

    Features Features 8-channel mixer with built-in FX processor 4 mono channels (MIC, line) with low cut 3-band EQ and pan control 2 stereo channels with 2-band EQ and balance control Control room output L/R (1/4" jack) Additional input via RCA (stereo in / rec out) 1 ×...
  • Page 9: Installation And Starting Up

    Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 10: Connections And Controls

    Connections and controls Connections and controls Mono channel strip MIC 1 1 [MIC] | Balanced XLR mono input for connecting a microphone. 2 [LINE] | 6.3-mm jack input for connecting a line level audio source (key‐ ö boards, drum modules etc., balanced or unbalanced). 3 [80 Hz HPF] | High pass filter to attenuate rumble noise and other low-fre‐...
  • Page 11 Connections and controls Stereo channel strip 14, 16 [STEREO IN] | Cinch sockets for connecting stereo sources. STEREO I N REC OUT 15, 17 [REC OUT] | Line outputs with cinch sockets for connecting recording devices. 18, 19 [L] | 6.3-mm jack input for connecting the left stereo signal from a line level audio source (keyboards, drum modules etc.).
  • Page 12 Connections and controls Effects section, AUX 34 [PARAMETER] | Rotary control for setting the main parameter of the currently PAR AMETER selected effect. 35 [FX TO AUX] | Rotary control for adjusting the effects portion present on the [AUX SEND] output. FX TO AU X SIGNAL 36 [FX RETURN TO MIX] | Rotary control for adjusting the effects portion in the...
  • Page 13 Connections and controls +48V +48V POWER CR & P HONES (PFL) CR & P HONES [+48V] LED | This LED lights up when the phantom power is on. [+48V] switch | When this switch is in the ON position, a phantom voltage of 48 V is present on the XLR sockets in the mono channels for using condenser microphones.
  • Page 14 Back D AT E C O D E : S E R IA L N o : Thomann GmbH MAIN OUTPUTS Hans- Thomann- Str. 1 96138 B urgebrach German y Made in China C A U T I O N...
  • Page 15 Connections and controls Connection example – PC home recording xmix 1002 FX USB Mixer...
  • Page 16: Technical Specifications

    Technical specifications Technical specifications Input connections Power supply C14 rubber panel plug Microphone input Type 4 × XLR panel socket, 3-pin, balanced Level max. + 4 dBu ± 1 dBu Impedance 6 kΩ, balanced 3 kΩ ±200 Ω, unbalanced Line input Type 4 ×...
  • Page 17 Technical specifications Effects 16 in total 2 × hall reverb 2 × room reverb 2 × plate reverb 1 × spring reverb 2 × delay 2 × chorus Flanger Phaser Gated reverb Flanger reverb Vocal echo Signal gain mono Mic input, adjustable 44 dB (–16 ~ –60 dB) channel Line...
  • Page 18: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equipment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 19 Plug and connection assignment XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) XLR plug (unbalanced) Ground, shielding Signal Bridged to pin 1 RCA connection Drawing and table indicate the pin assignment of an RCA plug. Signal Ground, shielding xmix 1002 FX USB...
  • Page 20: Protecting The Environment

    Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it.
  • Page 21 Notes xmix 1002 FX USB Mixer...
  • Page 22 Notes xmix 1002 FX USB Mixer...
  • Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
