Wired Remote

Single Outlet
1. Press the 'Start/Stop' button on the remote to turn
the shower on.
2. The white LED display will flash until the selected
temperature has been reached. When the LED
display is constant, step into your shower and enjoy!
3. Press the 'Start/Stop' button on the remote or main
controller to turn the shower off.
Dual Outlet (divert)
1. Press the wired remote button to turn the shower on.
2. Water will flow from the primary outlet as determined
during the 'Wired remote setup' procedure. Refer to
Wired Remote Installation and User Guide.
3. If required, push and hold the button for 2 seconds
to stop the 1st outlet and start the 2nd outlet.
4. The white LED display will flash until the selected
temperature has been reached.
5. When the LED display is constant, your shower is
ready to use.
6. Press the remote or active button on the controller to
turn the shower off.
8
Adjustable Head
Vita™ Head
To avoid water dripping from the shower head after
use, we advise to tilt the head back to allow residual
water to drain out.
The above recommendation applies to both adjustable
and fixed shower heads.
Rotate the spray plate lever clockwise or anticlockwise
to select the desired spray pattern.
To select the preferred height for the shower head,
squeeze the side levers together to allow the handset
holder to move up or down the rail.
Angular adjustment is made by carefully but firmly
pulling forwards or pushing back the shower head
against the ratchet in the holder.
Removing the shower head: With the hose still
attached, disengage the pivot clip by pushing in the
outer grey button located on the front of the shower
head (near to the hose connection). Remove the
spigot from the bottom of the handset by using the
hose to pull clear. To reattach: Ensure the hose washer
is in the correct position, tighten the threaded spigot
into the hose using a suitable spanner, taking care not
to over-tighten. Reinsert the spigot into the handset
and engage the pivot clip prior to placing the handset
into the handset holder.
1. Inner
2. Middle
3. Outer
