- Page 1 QUARTZ BATH ™ INSTALLATION GUIDE...
- Page 2 COMPONENTS (HP/COMBI) Mains fed and separately pumped water systems only Quartz™ Bath Installation Guide 02...
- Page 3 COMPONENTS (GRAVITY PUMPED) Gravity stored water systems only Quartz™ Bath Installation Guide 03...
-
Page 4: Safety Information
If the maximum hot water temperature is likely See www.aqualisa.co.uk/guarantee for details. to rise above 65ºC then a Thermostatic Blending Valve must be used. Installation of the pumped Quartz Smart Valve (for gravity stored systems) ™ The Quartz Smart Valve is supplied factory ™... - Page 5 BOILERS, SEASONAL INLET TEMPERATURE performance minimise the number of elbows used. CHANGE WILL AFFECT THE QUARTZ SMART If long pipe runs are unavoidable on the outlet, use VALVE OUTLET FLOW RATE RESULTING IN ™...
- Page 6 In addition to the guide below, it is essential that the important information (overleaf) is read and understood and that you have all the necessary components before commencing installation. The Quartz™ bath system is supplied with universal fixings intended to secure the Quartz Smart Valve™ to a suitable surface. DIGITAL TV INTERFERENCE...
- Page 7 All pipe work should be run in 15mm pipe. All pipe work should be supported. For externally pumped gravity fed installations, 22mm pipe work should be run as close to the Quartz Smart ™ Valve as possible before reducing down to 15mm.
- Page 8 ™ Run a pipe from the mixed water outlet of the Quartz Smart Valve to the proposed siting for the bath fill outlet. To ensure optimum performance use the minimum amount of elbows.
- Page 9 Connect the outlet pipe to the mixed water outlet on the Quartz Smart Valve . Using pipe ™ clips as appropriate, ensure that all pipe work is perpendicular to the Quartz Smart Valve i.e. not putting any strain on the fittings. To ensure optimum performance use the minimum amount of elbows.
- Page 10 In order to fill your bath as quickly and efficiently as possible, we recommend the ‘ECO’ settings are not used. • When making any adjustment to the Quartz Smart Valve™ settings the power MUST be isolated. • Quartz™ Bath Installation Guide 10...
- Page 11 ™ Reinstate the electrical supply to the Quartz Smart Valve . Press the ‘Start/Stop’ button on the bath controller to turn the bath on. Run the bath at maximum temperature (factory pre set to 45ºC). If required, maximum temperature adjustment can be made with a flat bladed screwdriver using the ‘MAX TEMP...
- Page 12 SYSTEM LAYOUT DIAGRAMS Typical gravity system installation Typical gravity system installation (compatible with pumped Quartz Smart Valve Typical gravity system installation (compatible with pumped Quartz Smart Valve NB: THE BASE OF THE QUARTZ (compatible with pumped Quartz Smart Valve SMART VALVE...
- Page 13 Hot water cylinder Typical thermal storage unit system installation Typical thermal storage unit system installation (compatible with standard Quartz Smart Valve Typical thermal storage unit system installation (compatible with standard Quartz Smart Valve (compatible with standard Quartz Smart Valve Bath...
- Page 14 The bath overflow filler is suitable for baths up to a maximum thickness of 24mm. • Installation videos are available on our website www.aqualisa.co.uk/installation-videos or alternatively, scan the QR codes on the reverse of this guide. Carefully unscrew and remove the overflow filler outlet from the body assembly and set aside.
- Page 15 PTFE thread tape MUST be used to guarantee a watertight seal. • Connect the flexible hose to the blended supply pipe ensuring suitable non restrictive double check valves (not supplied) are fitted in line with current Water Supply Regulations. Quartz™ Bath Installation Guide 15...
- Page 16 WASTE PIPE EXTENSION KIT If required for larger baths, a 900mm waste pipe conversion kit is available from the Aqualisa Customer Service Department. Please contact our Customer Service Department on 01959 560010. • Unscrew the clamping nut and remove the waste pipe from the waste assembly.
- Page 17 5. Press the ‘Start/Stop’ button on the bath controller to stop the bath filling, when at the desired depth. The Quartz™ bath system has a maximum run time of 12 minutes as a precaution to prevent overflow. The bathfill can be stopped at anytime by pressing the ‘Start/Stop’ button.
- Page 18 Cleaning and maintenance should not be undertaken by children without supervision by a person responsible for their safety. It is imperative that descaling is carried out in accordance with the manufacturer’s instructions, substances that are not suitable for plastics and electroplated surfaces must not be used. • Quartz™ Bath Installation Guide 18...
- Page 19 Please note that calls may be recorded for training and quality purposes. The company reserves the right to alter, change or modify the product specifications without prior warning. ™ Trademark of Aqualisa Products Limited. Part No: 703950 Issue 02 Nov 18...
