- Page 1 TAPS INSTALLATION AND USER GUIDE...
-
Page 2: Table Of Contents
Water Supply and Building Regulations. This product is suitable for domestic use only. GUARANTEE Aqualisa products are supplied complete with a 1 year guarantee that can be upgraded by registering this product with Aqualisa. For details see: www.aqualisa.co.uk/guarantee... -
Page 3: Flushing
Minimum inlet pressure: 0.2 bar Maximum inlet pressure: 5 bar (Recommended 3 bar) For optimum performance hot and cold pressures should be equal. A suitable PRV is available from Aqualisa, if required. N.B. Not suitable for mixed water supplies, i.e. gravity hot/cold mains. -
Page 4: Installation
INSTALLATION The product must not be used with a hot water supply temperature of over 65ºC. The hot supply should be on the left when viewed from the front of the product. CLEANING Whilst modern plating techniques are used in the manufacture of these fittings, the plating will wear if not cleaned properly. -
Page 5: Ranges
RANGES AQUALISA CENTRAL™ AQUALISA UPTOWN™ AQUALISA DOWNTOWN™... -
Page 6: Deck Mounted Bath Filler And Bath Shower Mixer Tap
DECK MOUNTED BATH FILLER AND BATH SHOWER MIXER TAP INSTALLATION In addition to the guide below it is essential that the important information section is read and understood and that you have all the necessary components before commencing installation. Failure to install the product in accordance with these instructions may adversely affect the guarantee terms and conditions. - Page 7 Aqualisa Uptown™ Deck Washer Handset Fixing Washer 1.25m Hose Fixing Nut * Aqualisa Uptown™ model shown for illustrative purposes. ** Handset and hose are only supplied with Bath Shower Mixer models. The handset supplied is dependant on the model purchased.
-
Page 8: Wall Mounted Handset Holder
Using the backplate as a template, mark and prepare two holes in the desired location using the fixings provided. NOTE: For Aqualisa Central™ and Aqualisa Downtown™ models, choose the orientation that you wish the handset holder to face and ensure the backplate is fixed to suit. - Page 9 WALL MOUNTED HANDSET HOLDER COMPONENTS AQUALISA CENTRAL™ MODEL DESCRIPTION Wall Plugs Backplate Wall Screws Handset Holder AQUALISA UPTOWN™ MODEL DESCRIPTION Cover Plate Wall Plugs Backplate Allen Key Wall Screws Handset Holder Grub Screws AQUALISA DOWNTOWN™ MODEL DESCRIPTION Wall Plugs Backplate...
-
Page 10: Small Pillar Tap
SMALL PILLAR TAP INSTALLATION In addition to the guide below it is essential that the important information section is read and understood and that you have all the necessary components before commencing installation. Failure to install the product in accordance with these instructions may adversely affect the guarantee terms and conditions. - Page 11 Fixing Washer Fixing Plate Fixing Nut Click Clack Waste * Aqualisa Uptown™ model shown for illustrative purposes CLICK CLACK WASTE INSTALLATION Ensure the sealing ring is in position on the waste. Pass it through the basin. Tighten with the base nut.
-
Page 12: Large Pillar Tap
LARGE PILLAR TAP INSTALLATION In addition to the guide below it is essential that the important information section is read and understood and that you have all the necessary components before commencing installation. Failure to install the product in accordance with these instructions may adversely affect the guarantee terms and conditions. - Page 13 Fixing Washer Fixing Plate Fixing Nut Click Clack Waste *Aqualisa Uptown model shown for illustrative purposes. CLICK CLACK WASTE INSTALLATION Ensure the sealing ring is in position on the waste. Pass it through the basin. Tighten with the base nut.
-
Page 14: General Maintenance
GENERAL MAINTENANCE Cleaning the bath / shower mixer headworks 1. Before carrying out any maintenance, ensure the mains water supply is isolated. Once isolated, turn the taps on to release internal pressure. If unsure contact a qualified tradesman. 2. Carefully remove the cap, loosen the grub screw using an allen key, then remove the tap knob. -
Page 15: General Cleaning
6. Refit the headworks DO NOT OVERTIGHTEN. 7. Re-fit the locking nut, (o-ring), cover ring and tap knob. Tighten the grub screw and fit the cap. GENERAL CLEANING Whilst modern plating techniques are used in the manufacture of these fittings, the plating will wear if not cleaned properly. The safest way to clean your product is to wipe with a soft damp cloth. -
Page 16: Troubleshooting
TROUBLE SHOOTING Symptom Possible Cause Remedy Water dripping Water retention due to scale build up. Clean shower head and/or spout from shower head flow straightener. or spout. Failing to close fully, possibly due to Remove on/off headworks waterborne debris. and check. Refer to General Maintenance section before dismantling. - Page 17 NOTES...
- Page 18 NOTES...
- Page 19 NOTES...
- Page 20 Please note that calls may be recorded for training and quality purposes. The company reserves the right to alter, change or modify the product specifications without prior warning. ™ Trademark of Aqualisa Products Limited. Part No: 705116 Issue 1 Aug 20...
