PoE Fault - Yellow LEDs
This indicates one of the following problems is presents and the port (from 1 to 4) is not powered:
On yellow • Short-circuit to line
• The required power exceeds the available limit
Off The PoE port is working correctly
PoE Max - Yellow LED
On yellow
This indicates that the available PoE power is less than 7W
Yellow blinking
This indicates that the Max PoE LED was active during the previous two minutes
Off
The PoE ports are functioning normally
Green Ethernet Ports LEDs Indication (Ports from 1 to 8)
On green
Port connection is working correctly
Green blinking
Indicates data transmission/reception
Off
No connection

7.2 8-PORT SWITCH TECHNICAL CHARACTERISTICS Ref.1039/44

SWITCH POWER SUPPLY
Power voltage: ........................................................................................................................................................................... 1.2 A @ 100 - 240 V~ 50/60 Hz
Output current: ...................................................................................................................................................................................................0.8 A @ 48 V
SWITCH
Input current: ....................................................................................................................................................................................................1,25 A @ 48 V
Total number of ports: ................................................................................................................................................................................................. 4 + 4 PoE
Power voltage POE: ...........................................................................................................................................................................48 V
Total maximum power output: ................................................................................................................................................................53 W max on all ports
Operating modes: ........................................................................................................................................Fast Ethernet at 100Mbps / Ethernet at 10 Mbps
Working temperature: ................................................................................................................................................................................................... 0 ÷ 40 °C
Dimensions (L x H x D): ................................................................................................................................................................................ 236 x 102 x 27 mm

8 KEY TO SYMBOLS

Symbol Explanation
Direct current power voltage
~
Alternating input voltage
See the installation manual of the device
DANGER - High Voltage
DANGER - Components critical to personal safety present

9 SIMPLIFIED EU DECLARATION OF CONFORMITY

Hereby, URMET S.p.A. declares that the radio equipment types: KIT IP WITH ALPHA AND FULL MAX Ref. 1060/623 are in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: www.urmet.com
48
(15.4 W per PoE)
DS1060-156
