- Page 1 ITEM NO. SCBSD0550 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 1/16...
- Page 2 MAINTAINANCE AND WARNING Keep furniture away from heat. Do not clean furniture with harsh cleansers or polish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean spills(Mix 1:10 soap to water) Do not place furniture under direct sunlight, material will possibly fade over time.
- Page 3 overview 3 16...
- Page 4 PARTS LIST 4/16...
- Page 5 HARDWARE LIST SPARE Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment.
- Page 6 Connect the part 8,9 with part 10. Align the hole in part 8 and 9 to the hole in part 10 as the picture show. screw in the screw L and tighten by screwdriver R. Connecting the part 11 to the finished part in step 1. Align the groove in part 8,9 and 10.
- Page 7 Preparing the part 7 1) Align the hole in part 7 as the picture show, screw in the cam bolt A and tighten by screwdriver R. 2) Align the hole in part 7 to the hole in part F, screw in the screw G with part I and tighten by screwdriver R.
- Page 8 Prepare the part 1 1) Align the hole in part 1 , insert the part D (wooden dowel) into the hole by hand; 2) Align the hole in part 1, screw in the cam bolt A into the hole and tighten by screwdriver R. Prepare the part 3 and 4 Align the hole in part 3 and 4, screw in the cam bolt A into the hole and tighten by screwdriver R.
- Page 9 ASSEMBLY INSTRUCTIONS Assemble the part 1,3,4, and 14 1) Align the hole in part 14 to the cam bolt A in part 3 and 4, insert the cam bolt A , then put the NUT B into the hole as the picture show, screw and tighten the nut by screwdriver R.
- Page 10 INSTALL part 6 1) Align the groove in part 1, 3,5 insert and slide the part 6 into the groove as the picture show.repeat the same way to finish the rest of part 6 in part 1, 4,5. 2) Align the hole in part 3 and 4, insert the part D into the hole by hand. Connect part 2 to the finished part in step 9.
- Page 11 Connect the part 12 and part 13 Align the hole in part 13 to the hole in part 12, screw in the screw Q and tighten by Allenkey K. Don't fully tighten the screw Q! Assemble the legs to the cabinet. 1) Align the hole in part 2 to the hole in part 12 and 13, screw in the screw P , then, 2) Fully tighten screw P in sequence by Allenkey K after all 6...
- Page 12 Assemble part H to finished part in step 12. 1) Turn the cabinet upwards as the picture show; 2)Put the part H in the pisition as the picture show, then screw in the screw E and fully tighten by screwdriver R. 12 16...
- Page 13 Assemble drawer to the cabinet 1) Find the moving part in male metal slider in drawer sides(pre-assmbled ), be sure the moving part is in the back of metal slider as the picture show; 2) Find the moving part in female metal slider in the cabinet side(pre-assembled), be sure the moving part is in the front of metal slider as the picture show.
- Page 14 Assemble part M 1）Align the hole in part M to the part 1 as the picture show, screw in the screw E and tighten by screwdriver R. 2）Use the adjust nail to keep the cabinet level in case wabbling. 14 16...
- Page 15 Install the anti-collapse device. 1. Mark the position on the wall, this should be same as the position of M where are on the back of panel 1; Drilled and insert the expandable screw O by hammer; 2.Assemble the part M on the wall. Align the hole in the part M to the expandable screw O,Screw in screw L and tighten with screwdriver R.
- Page 16 We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive replacement...
