- Page 1 SCCL0360...
- Page 2 A1x1 A2x1 A3x1 A4x1 A5x1 170LBS...
- Page 3 OVERVIEW...
- Page 4 x 30 x 30 x 12 STEP 1:Preparing the panel B and C. 1.Align the hole in the panel B and C , insert wooden dowel #3 into the pre-drilled holes. 2.Align the hole in the panel B and C, screw in and tighten the cam bolt #1 by screwdriver #7.
- Page 5 STEP 2:Connect the panel B with panel D and E. Align the hole in Step 3:Repeat Step 2 way to connect panel C with D and E. then the panel D and E, insert cam bolt #1 and wooden dowel #3 in stick the hardware #5 on the bottom of panel C and B as the picture panel B into panel D and E, insert and tighten the nut #2 by show.
- Page 6 STEP 5: Attach the panel F to the cabinet as the picture show. STEP 4: Attach the panel A and G to the finished parts in step 3. Align the hole in the panel F, screw in cam bolt 1# by screwdriver #7. Insert the panel G into the groove in panel B, C and E.
- Page 7 Step 7:Preparing the drawer frame. STEP 6:Preparing for panel A1,A3. screw in and tighten the cam 1.Assemble the panel A1,A2 and A3. Align the hole in the panel A2, bolt#1 into the hole in panel A1 and A3 by screwdriver#7. insert the cam bolt #1 on pane A1 , A3 into the holes in panel A2.
- Page 8 Step 8:slide in the panel A4 into the groove of A1,A2,and A3., then STEP 9:Unfold the basket and put on fabric cover. attach the panel A5 to the panel A1, A3. last, put the drawer into the cabinet as the picture show.
- Page 9 STEP 10:Put the part H into cabinet as the picture show. Install the anti-collapse set. Your cabinet is ready to use.
