Digi Connect EZ Mini User Manual page 533

User authentication
5. (Optional) Enable Authoritative to prevent other authentication methods from being
attempted if TACACS+ login fails.
6. (Optional) For Group attribute, type the name of the attribute used in the TACACS+ server's
configuration to identify the Connect EZ authentication group or groups that the user is a
member of. For example, in
plus.conf file is groupname, which is also the default setting in the Connect EZ configuration.
7. (Optional) For Service, type the value of the service attribute in the the TACACS+ server's
configuration. For example, in
the sample tac_plus.conf file is system, which is also the default setting in the Connect EZ
configuration.
8. (Optional) Enable Command authorization, which instructs the device to communicate with
the TACACS+ server to determine if the user is authorized to execute a specific command. Only
the first configured TACACS+ server will be used for command authorization.
9. (Optional) Enable Command accounting, which instructs the device to communicate with the
TACACS+ server to log commands that the user executes. Only the first configured TACACS+
server will be used for command accounting.
10. Add TACACS+ to the authentication methods:
a. Click Authentication > Methods.
b. For Add method, click .
c. Select TACACS+ for the new method from the Method drop-down.
Authentication methods are attempted in the order they are listed until an authentication
response, either pass or fail, is received. If Authoritative is enabled (see above), non-
authoritative methods are not attempted. See
methods for information about rearranging the position of the methods in the list.
11. Click Apply to save the configuration and apply the change.

Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the
Connect EZ local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
Digi Connect EZ Mini User Guide
Terminal Access Controller Access-Control System Plus (TACACS+)
TACACS+ user configuration, the group attribute in the sample tac_
TACACS+ user configuration, the value of the service attribute in
Rearrange the position of authentication
533
