Introduction

In This Chapter

This chapter includes the following sections:

A Word of Thanks

Congratulations on choosing the 9003 Dual 3G/HD/SD Reclocking Distribution Amplifier. The 9003 is
part of a full line of modular conversion gear for broadcast TV environments. The Cobalt Digital line
includes video decoders and encoders, audio embeders and de-embeders, distribution amplifiers,
format converters, and much more. Cobalt openGear
conversion and distribution needs now and well into the future.
Should you have questions pertaining to the installation or operation of your 9003, please contact us at
the numbers listed on the back cover of this manual. We are happy to help with any questions regarding
this or any other of our cards.

Overview

The 9003 is a high quality two channel, Dual 3G/HD/SD Reclocking Distribution Amplifier. It is
capable of equalizing and reclocking two channels in HD or SD.
The card has two 3G/HD/SD-SDI inputs, labeled "SDI Input 1" and "SDI Input 2". The card has two
sets of four SDI outputs labeled "SDI output A" and "SDI output B". The outputs of the four BNCs in
each set always emit the same data.
There are four routing modes available on the card.
1) Input 1
2) Input 1
3) Input 2
