Board Installation
Use the following steps to install the card in the frame:
Warning
This completes the procedure for installing the card in the frame.
9003 Owner's Manual • • • • (V 1.7)
1.
Refer to the frame product manual to ensure that the frame is properly installed
according to instructions.
Heat and power distribution requirements within a frame may dictate
specific slot placement of cards. Cards with many heat-producing
components should be arranged to avoid areas of excess heat build-up,
particularly in frames using convection cooling.
Note:
This card is default set with remote control set to disabled. If DashBoard or a
Cobalt Remote Panel is to be used with card, enable remote control on card as described in
Card Control and Status on the next page before installing card.
2.
After selecting the desired frame installation slot, hold the card by the edges and
carefully align the card edges with the slots in the frame. Then, fully insert the card
into the frame until the rear connection plugs are properly seated on the midplane and
rear modules.
Page 11
