The Menu System
The following table and sections describe the menus, items, and parameters available from the
DashBoard Control System software for the card.
Table 3. DashBoard Menus
Menu
Card Info
(Read-only)
Control
9003 Owner's Manual • • • • (V 1.7)
Item Parameters
Product CDI-9003
Manufacturer Cobalt Digital Inc.
############
Serial Number
Temperature
Input Current
Input Voltage
Remote Control Enabled/Disabled
In 1 Out A, In 2 Out B
In 1
Routing
In 2
Fail-Safe
Automatic
2.967/2970 Gbps
Rate A
1.5835/1.585Gbps
270 Mbps
Lock Status A
Automatic
2.967/2970 Gbps
Rate B
1.5835/1.585Gbps
270 Mbps
Lock Status B
Description
Displays the Silicon Serial
Number of the card.
Temperature of on card
sensor
Current consumed from
+12V rail
Measured voltage of +12V
rail
This shows whether the
remote is enabled (S1-1
on the board is up)
Routes outputs A & B
from either their
Out A & B
respective inputs, or both
Out A & B
from one of the two
inputs.
This forces the reclocker
to only run at the
specified rate.
"Automatic" means the
reclocker will detect the
input rate and reclock it.
Describes the current
input rate
This forces the reclocker
to only run at the
specified rate.
"Automatic" means the
reclocker will detect the
input rate and reclock it.
Describes the current
input rate
