- Page 1 Cobalt Digital Inc. 9001 3G/HD/SD SDI Reclocking Distribution Amplifier Owner’s Manual 9001-OM Version: 1.8...
- Page 2 The material in this manual is furnished for informational use only. It is subject to change without notice and should not be construed as a commitment by Cobalt Digital Inc. Cobalt Digital Inc assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
- Page 3 To reduce the risk of fire, replacement fuses must be the same type and rating. Only use attachments/accessories specified by the manufacturer. 9001 Owner’s Manual • • • • (V 1.8) Page 3...
- Page 4 If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration. You can also contact Cobalt Digital for more information on the environmental performances of our products. 9001 Owner’s Manual • • • • (V 1.8) Page 4...
-
Page 5: Table Of Contents
Warranty and Repair Policy..................... 17 Ordering Information 9001 and Related Products ...................... 19 Contact Us Contact Cobalt Digital Inc....................... 20 Visit us at the Cobalt Digital Inc. website................20 9001 Owner’s Manual • • • • (V 1.8) Page 5... -
Page 6: Introduction
The 9001 is a high quality 3G/HD/SD Reclocking Distribution Amplifier. It is capable of equalizing and reclocking an SDI signal in 3G, HD, or SD. The 9001 can equalize and reclock an incoming SDI signal using up to 300m of cable at 270Mbps, up to 120m of cable at 1.485Gbps, and 80m at 3Gbps. -
Page 7: Functional Block Diagram
Functional Block Diagram Supported Serial Rates The 9001 will reclock 270 Mbps, 1.485 Gbps, and 3 Gbps signals. Signals of other rates will be equalized and distributed to the outputs, and the reclocker will be bypassed. Documentation Terms The following terms are used throughout this guide: •... -
Page 8: Installation And Setup
Unpack each card you received from the shipping container, and check the contents against the packing list to ensure that all items are included. If any items are missing or damaged, contact your sales representative or Cobalt Digital directly. 9001 Owner’s Manual • • • • (V 1.8) Page 8... -
Page 9: Rear Module Installation (Optional)
Using a Phillips driver and the supplied screw, fasten the REAR MODULE panel to the frame back plane. Do not over tighten. This completes the procedure for installing the rear module in a 20-slot frame. 9001 Owner’s Manual • • • • (V 1.8) Page 9... -
Page 10: Board Installation
Then, fully insert the card into the frame until the rear connection plugs are properly seated on the midplane and rear modules. This completes the procedure for installing the card in the frame. 9001 Owner’s Manual • • • • (V 1.8) Page 10... -
Page 11: Cable Connections
Cable Connections This section provides instructions for connecting cables to 9001 rear modules. Connect the input and output cables according to the following diagram. Split rear module RM20-9001-A/S and RM20-9001- B/S allow two cards to be installed in adjacent slots. B/S versions are available in DIN1.0/2/3 and HDBNC versions. -
Page 12: Card Control And Status
This card is default set with remote control set to disabled. If DashBoard or a Cobalt Remote Panel is to be used with card, enable remote control on card before installing card. 9001 Owner’s Manual • • • • (V 1.8) Page 12... -
Page 13: Remote Control
Using the Menus You must first install the DashBoard Control System software on your computer. Refer to the DashBoard User Manual for software installation procedures and for using the DashBoard interface. 9001 Owner’s Manual • • • • (V 1.8) Page 13... - Page 14 Control 1.4835/1.485Gbps the input rate and reclock 270 Mbps Enables or Disables Reclocker On/Off Reclocking on all outputs. Describes the current input Lock Status rate 9001 Owner’s Manual • • • • (V 1.8) Page 14...
- Page 15 >10 dB at 1.5 GHz - 3.0 GHz Video Outputs Signal Level 800 mV nominal Jitter (wideband) HD: < 0.2 UI Total Power Consumption 2 Watts Specifications are subject to change without notice. 9001 Owner’s Manual • • • • (V 1.8) Page 15...
-
Page 16: Service Information
Module Exchange Exchanging a suspect module with a module that is known to be working correctly is an efficient method for localizing problems to indivitriple modules. 9001 Owner’s Manual • • • • (V 1.8) Page 16... -
Page 17: Warranty And Repair Policy
(1) year. Cobalt Digital Inc.'s (“Cobalt”) sole obligation under this warranty shall be limited to, at its option, (i) the repair or (ii) replacement of the product, and the determination of whether a defect is covered under this limited warranty shall be made at the sole discretion of Cobalt. - Page 18 If required, a temporary replacement module will be made available at a nominal charge. Any shipping costs incurred will be the responsibility of you, the customer. All products shipped to you from Cobalt Digital Inc. will be shipped collect.
-
Page 19: Ordering Information
Ordering Information 9001 and Related Products ® Your 9001 3G/HD/SD SDI Reclocking Distribution Amplifier is a part of the openGear family of ® products. Cobalt Digital offers a full line of openGear terminal equipment including distribution, conversion, monitoring, synchronizers, encoders, decoders, embedders, and de-embedders, as well as analog audio and video products. -
Page 20: Contact Us
Visit us at the Cobalt Digital Inc. website. http://www.cobaltdigital.com • Online catalog • Related products and full product lines • Trade show information • Dealer information • Cobalt Digital Inc. news 9001 Owner’s Manual • • • • (V 1.8) Page 20...
