- Page 1 Power Par Series User Manual Order codes: Power Par 36 - EQLED112 Power Par 54 - EQLED113...
-
Page 2: Safety Advice
NO USER SERVICEABLE PARTS. pulling the power-cable. • This lighting fixture is for professional use only - it is • Make sure that the available mains supply voltage is not designed for or suitable for household use. The between 100~240V AC, 50/60Hz. product must be installed by a qualified technician in accordance with local territory regulations. The safety of • Make sure that the power cable is never crimped or the installation is the responsibility of the installer. The damaged. Check the equipment and the power cable fixture presents risks of severe injury or death due to fire periodically. hazards, electric shock and falls. • If the equipment is dropped or damaged, disconnect the • Warning! Risk Group 2 LED product according to mains power supply immediately and have a qualified EN 62471. Do not view the light output with optical engineer inspect the equipment before operating again. instruments or any device that may concentrate the beam. • WARRANTY: One year from date of purchase. OPERATING DETERMINATIONS If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and/or property. www.prolight.co.uk Power Par Series User Manual... - Page 3 Power consumption 165W 02 - Hanging bracket 10 - Fan Power supply 100~240V, 50/60Hz adjustment knob 03 - LED display Fuse F3A 250V 04 - Function buttons Dimensions 290 x 265 x 100mm In the box: 05 - IEC power input Weight 1.5kg 1 x fixture, 06 - IEC power output Order codes EQLED113 1 x power cable 07 - Fuse: F3A 250V & 1 x user manual 08 - 3-Pin DMX input www.prolight.co.uk Power Par Series User Manual...
- Page 4 000-255 Speed (slow-fast)/Sensitivity (low-high) RGB colour mix mode: In this mode you can set the fixture to any colour and any brightness. Pr-- To access the colour mix mode press “MENU” until the display shows on the LED display. Pr00 Press the “ENTER” button and use the “UP” and “DOWN” buttons to select r--- Press the “ENTER” button to show with 3 digits after on the LED display. Press the “ENTER” button to confirm. The represents red, = green and = blue. The 3 digits after are the brightness setting from For example: If you set all to zero, your unit will have no LEDs lit up (blackout). r000 r255 If you set to and and to zero, your unit will show only red LEDs. Press the “ENTER” button to confirm the setting and move to the next colour. To exit out of any of the above options, press the “MENU” button. www.prolight.co.uk Power Par Series User Manual...
- Page 5 SLav To set the other units in slave mode, press the “MENU” button on the rear of the unit to show on the LED display and press the “ENTER” button to confirm the setting. The units will now run in sequence with the master unit. To exit out of any of the above options, press the “MENU” button. Menu system Built-in program mode Pr00 - RGB colour mix mode Pr00 - Pr13 r000~r255 R G000~G255 G b000~b255 B Pr01 - R Pr02 - G Pr03 - B pr04 - RG Pr05 - RB Pr06 - GB Pr07 - RGB Pr08 - Colour fade in-out (3 colours) Pr09 - Colour fade in-out (7 colours) Pr10 - Colour fade Pr11 - Colour fade in-out (7 colours) & colour fade Pr12 - Colour change (3 colours) Pr13 - Colour change (7 colours) Slave mode SLAV Sound active mode SOUd Sens 000~ 100 DMX mode Address setting A001~A512 www.prolight.co.uk Power Par Series User Manual...
-
Page 6: Dmx Setup
DATA cable (DMX cable) requirements (for DMX operation): This fixture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit. Your unit and your DMX controller require a standard 3-pin XLR connector for data input/output, see image below. Further DMX cables can be purchased from all good sound and lighting suppliers or Pro Light Concepts dealers. Please quote: CABL10 – 2m CABL11 – 5m CABL12 – 10m Also remember that DMX cable must be daisy chained and cannot be split. www.prolight.co.uk Power Par Series User Manual... - Page 7 5-pin XLR (socket) 3-pin XLR (socket) Pin 1: GND (screen) Pin 1: GND (screen) Pin 2: Signal (-) Pin 2: Signal (-) Pin 3: Signal (+) Pin 3: Signal (+) Pin 4: N/C Pin 5: N/C www.prolight.co.uk Power Par Series User Manual...
- Page 8 Operating instructions & WEEE notice Correct Disposal of this Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed of with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. www.prolight.co.uk Power Par Series User Manual...
