Soyal AR-888-PBI-S Manual

SOYAL
ACCESS & INDUSTRIAL CONTROL
Installation
AR-888-PBI-S: Touchless Infrared Button
Product (US/EU) 2
1
Connector Table / Dip_switch
3 Dip_switch
LED status
2
adjustment
J2 J1
Connector:
CN1
1
Function Cable
LED R(Optional)
1
LED G(Optional)
2
N.C. 3 Purple White DC24V / 1A
Relay COM 4
N.O. 5 Blue White DC24V / 1A
6
Power
7
Controller has built-in resistor and connected to +5VDC,
external power supply current must be exceeding 20mA
+5V
Wiring Diagrams
Electric Strike
or
Electric Bolt
Magnetic Lock
N.O.
N.C.
COM
GND
Controller
POWER
9-24VDC
Touchless Infrared Button
Terminal Cables 3 Tools
Bottom Cover
CN1
1 Connector
LED R
LED G
N.C.
COM
N.O.
V+
V-
Color Description
Orange Red LED negative
Green Green LED negative
White DC24V / 1A
Red DC 9-24V
Black DC 0V
LED R
LED G
N.O.
COM
N.C.
V+
V+
GND GND
V-
PB
V+
V+
GND
AR-888-PBI-S
Flat Head Hex Socket Allen key (2MM / 48*15MM)
Screw: M3x8
2 Dip Switch Setting
ON RSN
1 2 3 4
Output Format
No. SW1 SW2 Description
※ 1 OFF OFF No Delay
2 OFF ON Delay 3 Seconds
3 ON OFF Delay 6 Seconds
4 ON ON Toggle Mode
LED status adjustment
3
Standby
Motion
mode
NC NO
J1(LED G)
J2(LED R)
(Example #2)
Door Sensor
AR-MS-101-A
AR-MS-101-C
POWER
9-24VDC
POWER
9-24VDC
LED R
＊The Wiring Diagram of LED
LED G
N.C.
COM
N.O.
V+
V- Type A
AR-888-PBI-S
Request To Exit
Type C
Easy Install Kit (By Order)
4
A.
MPLA-888XA18/19 (US / EU)
Sensing Distance Adjustment
No. SW3 SW4
※ 1 OFF OFF
2 OFF ON
3 ON OFF
4 ON ON
Standby mode
1 LED G(Green)
LED R(RED)
※2
LED GR
3
(Green/RED)
4
--
N.C.
N.O.
COM
V+
GND
R/G Door Status Indication
The magnetic circuit will be turned on
when getting closed to the switch.
(closed circuit).
The magnetic circuit will be turned off
after removed the magnet. (open circuit)
Double contact–NO. / COM
Trigger LED R when door open
Trigger LED G when door closed
Triple contact - NO. / NC. / COM
V230315
※Default Value
Description
1: Max. range 10cm
2: Medium range
3: Short range
4: Min. range 2cm
※Default Value
Motion
LED R(RED)
LED G(Green)
--
LED GR
(Green/RED))
LED R
LED G
N.C.
COM
N.O.
V+
V-
Request
To Exit
