Soyal AR-829E Manual

SOYAL
ACCESS CONTROL SYSTEM
Contents
1 Products 2
Installation
A. B.
1
Notice
1.Tubing: The communication wires and power line should NOT be bound in the same conduit or tubing.
Use AWG 22-24 Shielded Twist Pair to avoid star wiring.
2.Wire selection:
3.Power supply: Don't equip reader and lock with the same power supply. The power for reader may be unstable when the lock is activating, that may make the
reader malfunction.
The standard installation: Door relay and lock use the same power supply, and reader use independent power supply.
Connector Table
1
8
2
7 7
3
6 6
4 P4
5 5
5
P1
4 4 P2
6
3 3
7
2 2
1 1
P3
3 2 1
Chinese Font Expansion Module
MIFARE (13.56MHz)
EM (125kHz)
Front Panel & Indicator
Power
(Green)
Busy
(Red)
Alarm
(Green)
®
User Guide 3 Terminal Cables
4
2
3
5
Cable: P1
Wire Application Wire Color
Door Relay 1 Blue White
2 Purple White
Common-COM-Point 3 White
Door Sensor 4 Orange
Exit Switch 5 Purple
Alarm Relay 6 Gray
Power 7 Thick Red
8 Thick Black
Cable: P3
Wire Color
Wire Application
Tamper Switch 1 Red
2 Orange
3 Yellow
Standard
Optional
OK / Error
(Green)
Receive
(Green)
Alarm
(Red)
AR-829E
P1 P2 P3 P4
Connected to the lithium battery to provide power to the memory.
Use a screwdriver to screw the mounting plate to the wall.
Pull cables ends through the access hole in the mounting plate.
Attach AR-829E to the mounting plate and install screws (supplied) into the
holes at the bottom with the allen key (supplied).
Apply power. LED (green) will light up.
Cable:
Description
Wire Application
(N.O.)DC24V1Amp
Networking
(N.C.)DC24V1Amp
(COM)DC24V1Amp
Wiegand
Negative Trigger Input
Negative Trigger Input
N.O./N.C. Optional
(by jumper)
Buzzer
DC 12V
LED
DC 0V
Cable:
Description
Wire Application
N.C.
Arming Setting
Switch
COM
Alarm Input
N.O.
Serial Port
Arming LED
(Red)
/ Send
(Red)
Copyright by SOYAL Technology Co., Ltd.. All rights reserved.
4 Tools
P2
Wire Color Description
1 Thick Green RS-485 (B-)
2 Thick Blue RS-485 (A+)
3 Blue WG DAT: 1 Inpu
ABA Clock Input
4
Green WG DAT: 0 Input
ABA Data Input
5 Pink Buzzer Output 5V/100mA, MAX
6 Brown LED Green Output 5V/20mA, MAX
7 Yellow LED Red Output 5V/20mA, MAX
P4
Wire Color Description
1 Red
ON
2 Orange
3 Yellow loop1
4 Green loop2
5 Blue loop3
6 Purple Serial output (Transistor open
collector) (4800, N, 8, 1)
Arming output
7 Gray
(Active low)
V091119
5 Relay
AR-821RB
Pulse type
Latch type
OFF
(Alarm) Sensor
(Alarm) Sensor
(Alarm) Sensor
