Before Connection

Version of the host machine

CAUTION:
Be sure to perform this procedure after checking that
the host machine's firmware (MN-CONT) is Ver.40.01
or higher.
If the host machine's firmware (MN-CONT) version is
old, upgrade to Ver.40.01 or higher before performing
the procedure.

Installing the License

Be sure to take out the license certificate included in the
package and obtain the license key in advance. Make the
setting of this equipment by the Web browser in the Control
Panel.
Register the license by the following procedure.
1. Log in to the host machine as an administrator
(mode).
Factory default password is as follows.
• System administration division ID: 7654321
• System administration password: 7654321
NOTE:
When [System Manager Information Settings] is set, it is
required to log in as a system manager in accordance with
instructions from the user administrator.
2. Select Settings/Registration > [Management
Settings] > [License/Other] > [Register License].
3. Enter the license key of the Web browser.
Example: 8888-7777-6666-5555-4444-3333
4. Press [Start] > [OK].
5. Turn OFF and then ON the main power switch to
determine the registration.
The IP addresses for
communication between the host
machine and server are set
automatically
1. Enter service mode (Level 1), and set the setting
value to "3".
• COPIER > OPTION > INT-FACE > IMG-CONT
2. Exit the Service Mode.
Check Item When Turning OFF
the Main Power
Check that the main power of the host machine is OFF.
1. Turn OFF the main power switch of the host
machine.
2. Check that the display in the Control Panel and the
lamp of the main power are turned off, and then
disconnect the power plug.
Check When Connecting the
Power Plug to an Outlet
1. When connecting the power plug of this equipment to an
outlet, be sure to use an outlet of a system different from
that of the host machine.
2. Be sure to install this equipment near an outlet so that
the power plug can be disconnected right away in case
of emergency, and do not put anything around the power
plug.
Securing Space for
Installation
A space of 200 mm or more is required from the back of this
equipment.
200 mm or more

Checking the Contents

NOTE:
Power Cord: The connector has a different shape
depending on locations. Use the correct power code to
match the location/area of installation. Make sure not to
leave unused power code at the site.
65
7. INSTALLATION PROCEDURE
Equipment
Rear
Front
