INSTALLATION
MANUAL
Manual Brel Bi-Directional Rollerblind motor
BTE 50
Read the manual before you begin the
installation. If these instructions are not
followed, this may lead to defects and
injury in which warranty can't be claimed.
www.brel-home.com
Visit our website for more manuals and information
BTE 50
Scan the QR code here for the manual to
download & view instructional videos
M O T O R S
EN NL DE FR
Advertisement
Table of Contents
Related Manuals for brel-motors BTE 50
Summary of Contents for brel-motors BTE 50
- Page 1 M O T O R S INSTALLATION MANUAL Manual Brel Bi-Directional Rollerblind motor BTE 50 Read the manual before you begin the installation. If these instructions are not followed, this may lead to defects and injury in which warranty can’t be claimed.
- Page 2 Wiring/Installing the motor/Compatible with hub Technical data of the motor/Reach/Charging the motor Functions remote control Warning Do not operate the motor BREL-Motors declares that this in humid surroundings. motor has been manufactured according to the guidelines of the CE standard 1999/5/EC...
-
Page 3: Installing The Motor
Page 3 Wiring Li-ion battery Charging point Antenne Installing the Motor These assemblies are usually already done in the factory Attach the crown and wheel to the motor and place the clip on the shaft of the motor so that the wheel is fixed to the motor. - Page 4 = 20 meter Charging the motor If charging the BTE 50 only use a charger with Micro-USB plug (5V) The battery is empty when the motor light flashes red. The light flashes green while charging. The battery is fully charged when the light stops blinking and lights-up continuously.
-
Page 5: Establishing Connection
Channel+ C+ There are 2x P2 buttons, no matter which one you press. Scan the QR code here for the manual to download & view instructional videos BTE 50 Step 1 Setting up the first remote/channel The remote control can transmit 15 channels and therefore control multiple blinds. - Page 6 Page 6 Step 3 Adjusting the direction of rotation (Only if the direction of rotation is not correct) Only possible if no end positions are set. until Press UP and DOWN button The direction of rotation of simultaneously, until the product moves. the motor is OK.
-
Page 7: Additional Settings
Page 7 Additional settings Adjusting the top position Option A If adjustment is not possible, go to Resetting factory settings. until STOP STOP until Press at the same time STOP Go to the new Press at the same time top position. and UP until the motor moves. -
Page 8: Changing Batteries
Page 8 Additional settings P1 button Can be used without a transmitter as an operating button. 1x P1 The product moves up, stops or goes down when pressed P1 Press 1x P1 on the motor. Switching off the receiver The Receiver Press and hold P1 until the product moves up and down for the 2nd time.
