Read the manual before you begin the installation. If these instructions are not followed,
this may lead to defects and injury in which warranty can't be claimed.
warning:
Children cannot recognize the dangers of electrical equipment and may therefore not work with it.
It is important to follow this instruction for your own safety.
1. Do not operate the motor in humid surroundings.
2. The motor must be installed correctly.
3. Keep the antenna in a good condition and do not shorten. The antenna should not come into contact
with other metal parts otherwise it will reduce the effect.
4. The motor must be protected from direct moisture influences.
_______________________________________________________________________________
Functions remote control
Works with all BREL transmitters:
__________________________________________________________________________________
Technical data of the motor
•
Motor voltage:
•
Charge voltage:
•
Maximum ampere charger:
•
Power:
•
Torque:
•
Speed:
•
Amperage:
•
Moisture and dust:
•
Storage capacity is up to 20 channels:
•
Working temperature of the motor:
o
Heavy use:
o
Normal use: -20℃ tot +70℃
______________________________________________________________________________
Reach
L1 = 100 meter
BREL motors is part of:
Manual Brel Radio Tubular motor
Type MLE
MLE15-0.3
MLE16-0.3
DC 8V
DC 8V
DC 5V
DC 5V
2 A
2 A
5 W
3.6 W
0.3 Nm
0.3 Nm
30 rpm
50 rpm
0.6 A
0.78 A
IP44
IP44
-10℃ tot +40℃
L2 = 25 meter
MLE25-1.1 MLE28-2 MLE35-3
DC 8V
DC 12V
DC 5V
DC 5V
2 A
2 A
8 W
15 W
1.1 Nm
2 Nm
28 rpm
28 rpm
0.94 A
1.25 A
IP44
IP44
Page 1
MLE35-10
DC 12V
DC 12V
DC 12.6V DC 12.6V
2 A
2 A
26 W
26 W
3 Nm
10 Nm
28 rpm
9 rpm
2.20 A
2.20 A
IP44
IP44
Advertisement
Related Manuals for brel-motors MLE Series
Summary of Contents for brel-motors MLE Series
- Page 1 Page 1 BREL motors is part of: Manual Brel Radio Tubular motor Type MLE Read the manual before you begin the installation. If these instructions are not followed, this may lead to defects and injury in which warranty can’t be claimed. warning: Children cannot recognize the dangers of electrical equipment and may therefore not work with it.
- Page 2 Page 2 If charging the MLE15, MLE25, only use a charger with Micro-USB plug (5V) The battery is fully charged when the light stops blinking and lights-up continuously. For charging in the UK the MLE16 and MLE28 and MLE35 only use the DC-213 ( 12.6V ). For Europe use DC-212.
- Page 3 Page 3 ______________________________________________________________________________ Step 2 Change direction Variant A If the direction is right, skip step 2 and proceed to step 3. Press P1 until 1x 2x P2 Hold down the P1 button until the motor Press 2x on the P2 button. Press the button down.
- Page 4 Page 4 _______________________________________________________________________________ Additional settings Option A Delete limit position Deleting the limit position can be done in two ways: When step 1, setting up the first channel also the limit setup will be removed. 1x P2 1x P2 Each time you press a key you hear a beep. The limit positions are now removed from the memory.
- Page 5 Page 5 _______________________________________________________________________________ Option F Speed control - Increase the speed of the motor. - Reduce the speed of the motor. + STOP simultaneously +STOP simultaneously Push up and stop simultaneously, until the motor moves. Press down and stop simultaneously, until the motor moves. If the motor is not moving, it is already in the highest or lowest speed.
