Symmons Duro SK3610PO Operation & Maintenance Manual

SK3610PO
Pull-Out Kitchen Faucet
Operation & Maintenance Manual
Model Numbers
☐
SK3610PO
Compliance
-ASME A112.18.1/CSA B125.1
-NSF/ANSI/CAN 61: Q<1, NSF/ANSI 372
WARNING: This product can expose you to
chemicals including lead, which is known to the
state of California to cause cancer, birth defects, or
other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
Dimensions
F F G G
Notes:
1) Hoses removed for clarity.
2) Dimensions subject to change without notice.
Symmons Industries, Inc.
Copyright © 2023 Symmons Industries, Inc.
Duro®
Pull-Out Kitchen Faucet
c
■ ■
31 Brooks Drive
■
Feature Highlights
• Pull-Out Kitchen Faucet shall include single hole
mount configuration
• Ceramic cartridge
• Braided hose connections
• Standard 1.0 gpm (3.8 L/min) flow rate
• Faucet shall be made from metal construction
• Plated in standard polished chrome finish
Warranty
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
J J
■
Braintree, MA 02184 Phone: (800) 796-6667
■
symmons.com gethelp@symmons.com
Measurements
Deck Thickness Ref.
F
Max. 2-1/2", 64 mm
Hole Size
G
Min. Ø 1-3/8", 35 mm
Max. Ø 1-1/2", 38 mm
To Backsplash
J
4", 102 mm
■
Fax: (800) 961-9621
■ ■
ZV-3747 REV 0 060623
