- Page 1 Instruction Manual Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2023 Gold Medal Products Co. Part No. 110028...
-
Page 2: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215 gmpopcorn.com... - Page 3 039_080614 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 4: Installation Instructions
To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862. Model Description 2703-00-000: Cheddar Easy All-In-One Cheese Corn Shop, 8 gallon capacity. Items Included with this Unit 4 Cup Glass Beaker... -
Page 5: Electrical Requirements
We recommend this equipment be on a dedicated and protected circuit. Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 6: Controls And Their Functions
Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 OPERATING INSTRUCTIONS Controls and Their Functions TUMBLER SWITCH Two position, ON/OFF lighted rocker switch - supplies power to the tumbler drive motor. With this switch in the ON position, the blending pot will continually roll. - Page 7 1. Place the Blending Pot on all the rollers securely (the Blending Pot has an 8 gallon capacity). 2. Fill the Cheese Measure with 3 cups of Gold Medal Products Co. Cheddar Pure Gold (Item No. 2327) and place on the warming plate.
-
Page 8: Care And Cleaning
Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 Care and Cleaning DANGER Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. DO NOT clean appliance with a water jet or steam cleaner. Always unplug the equipment before cleaning or servicing. -
Page 9: Maintenance Instructions
Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. -
Page 10: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... - Page 11 Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 Cabinet Exterior Front and Controls View Diode Assembly (includes Diode and Wiring shown) reference Wiring Diagram for placement. Data Plate 5, 6* For Labels, see Safety *Remove Cover Plate on bottom of unit Labels section.
- Page 12 Wheels Section for parts breakdown. 16, 17, 18 *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly qualified persons in order to avoid a hazard. Unit Exterior - Bottom View gmpopcorn.com...
- Page 13 Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 Cabinet Rear and Bottom View – Parts List Part Number Item Part Description 2703-00-000 SCREW #8-32X3/8 PAN HD PH 74141 COVER PLATE 111203 HEAT LAMP 250W, 115/125V 47139 LIGHT SHIELD 111276...
- Page 14 Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 Motor and Drive/Idler Wheels 2703-00-000 General image shown for 13, 14 6, 7, 8 parts reference only. Part Number Item Part Description 2703-00-000 IDLER WHEEL 17506 111230 1/2"X1-1/2" SHOULDER BOLT 111210 3/8"...
-
Page 15: Safety Labels
Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 Safety Labels Unit Labels Power Cord Label Part Number Item Part Description 2703-00-000 TUMBLER LABEL 111209 BURN HAZARD LABEL 111282 WARNING, MAX LAMP 250W 54010 WARNING LABEL CORD 68720 Accessories Part Number... -
Page 16: Wiring Diagram
Cheddar Easy All-In-One Cheese Corn Shop Model No. 2703-00-000 Wiring Diagram Model No. 2703-00-000 gmpopcorn.com Page 16... -
Page 17: Warranty
No claim under this warranty shall be honored in the event that components in the unit at the time of the claim were not supplied or approved by Gold Medal Products Co. This warranty is effective only when electrical items have been properly attached to city utility lines only at proper voltages.
