Summary of Contents for Gold Medal Cheddar Easy
- Page 1 Instruction Manual Cheddar Easy Model No. 2703-00-010 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2023 Gold Medal Products Co. Part No. 110178...
-
Page 2: Table Of Contents
Cheddar Easy Model No. 2703-00-010 Table of Contents SAFETY PRECAUTIONS ........................... 3 INSTALLATION INSTRUCTIONS ........................5 Inspection of Shipment ............................5 Manual ..................................5 Model Description ..............................5 Items Included with this Unit ........................... 5 Setup ................................... 5 Electrical Requirements ............................. 6 Before You Plug In Machine .......................... -
Page 3: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215... - Page 4 039_080614 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 5: Installation Instructions
To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862. Model Description 2703-00-010: Cheddar Easy, 8 gallon capacity. Items Included with this Unit Blade Scraper... -
Page 6: Electrical Requirements
We recommend this equipment be on a dedicated and protected circuit. Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 7: Operating Instructions
Cheddar Easy Model No. 2703-00-010 OPERATING INSTRUCTIONS Controls and Their Functions POWER SWITCH Two position, ON/OFF lighted rocker switch - supplies power to the tumbler drive motor. With this switch in the ON position, the blending pot will continually roll. -
Page 8: Care And Cleaning
Cheddar Easy Model No. 2703-00-010 Care and Cleaning DANGER Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. DO NOT clean appliance with a water jet or steam cleaner. Always unplug the equipment before cleaning or servicing. -
Page 9: The Following Sections Are For Qualified Service Personnel Only
Cheddar Easy Model No. 2703-00-010 THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. Make sure all machine switches are in the OFF position before plugging the equipment into the receptacle. -
Page 10: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... -
Page 11: Exterior Cabinet View
Wheels for Parts Breakdown. 14, 15, 16 *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly qualified persons in order to avoid a hazard. Unit Exterior - Bottom View... -
Page 12: Motor And Drive/Idler Wheels - Safety Labels
Cheddar Easy Model No. 2703-00-010 Motor and Drive/Idler Wheels – Safety Labels 2703-00-000 General image shown for 13, 13a 6, 7, 8 parts reference only. Safety Labels Power Cord Label Unit Labels Part Number Item Part Description 2703-00-010 IDLER WHEEL... -
Page 13: Wiring Diagram
Cheddar Easy Model No. 2703-00-010 Wiring Diagram Model No. 2703-00-010 gmpopcorn.com Page 13... -
Page 14: Warranty
No claim under this warranty shall be honored in the event that components in the unit at the time of the claim were not supplied or approved by Gold Medal Products Co. This warranty is effective only when electrical items have been properly attached to city utility lines only at proper voltages.
