- Page 1 Assembly Instructions max. 150 kg ~ 30 Min. 13 kg L 129 | W 43 | H 36 DFFB50.01.04 Art. No. DF-FB50 DARWIN weight bench FB50...
- Page 2 FB50...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 FB50...
- Page 5 Dear customer, thank you for choosing Darwin fitness equipment. With Darwin fitness equipment we offer first class home sports equipment at a great price point. Darwin exercise bikes and strength machines are easy to use, have a space-saving design and look really good. With our equipment we want to support you in reaching your athletic goals, no matter if you want to lose weight or train for the national triathlon.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions Article weight (gross, incl. packaging): 14.75 kg Article weight (net, without packaging): 13 kg Packaging dimensions (L x W x H): 120 cm x 31 cm x 18 cm Set-up dimensions (L x W x H): 129 cm x 43 cm x 36 cm Folded dimensions (L x W x H): 120 cm x 43 cm x 18 cm... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. - Page 11 2 - Support frame (1x) 3 - Base frame (2x) 1 - Main frame (1x) 5 - Carriage (1x) 6 - Right backrest frame (1x) 4 - Foot tube (1x) 8 - Backrest support (1x) 9 - Backrest cushion (1x) 7 - Left backrest frame (1x) 10 - Seat cushion (1x)
- Page 12 Hardware pack 11 - Knob (2x) 12 - Small cover (2x) 13 - Big cover (4x) 14 - Carriage sleeve 16 - M10*180mm 17 - M10*100mm 15 - Backrest frame cap (2x) hex bolt (2x) hex bolt (1x) (4x) 20 - M8*50mm 18 - M10*75mm 19 - M8*20mm 21 - M10 washer...
-
Page 13: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g. - Page 14 Step 3: Assembly of the Backrest Frames and Backrest Support NOTICE Two bushings (24) are pre-assembled to the main frame (1). Attach the right and left backrest frames (6 & 7) to the main frame (1) with one bolt (16), two washers (21) and one locknut (23).
-
Page 15: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 16: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 17: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Screw connections Cushions Legend: C = clean;... -
Page 18: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 19: Ordering Spare Parts
ORDERING SPARE PARTS Serial Number and Model Name In order to provide you with the best possible service, please have the model name, article number, serial number, exploded drawing and parts list ready. The corresponding contact options can be found in chapter 9 of this operating manual. NOTICE The serial number of your equipment is unique. -
Page 20: Parts List
Parts List Name Qty. Main Frame Support Frame Base Frame Foot Tube Carriage Right Backrest Frame Left Backrest Frame Backrest Support Backrest Cushion Seat Cushion Knob Small Cover Big Cover Carriage Sleeve Backrest Frame Cap M10*180mm Hex Bolt M10*100mm Hex Bolt M10*75 Bolt M8*20mm Hex Bolt M8*50mm Hex Bolt... -
Page 21: Exploded Drawing
Exploded Drawing... -
Page 22: Warranty
WARRANTY Training equipment from Darwin® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. Error Descriptions Your fitness equipment is developed for long-term, high-quality training. - Page 23 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
