Assembly and Operating Instructions
max. 180 kg
~ 90 Min.
127 kg
L 211 | W 82 | H 188
FSUKCVET2519.01.01
SKU: CVET2519
Crosstrainer
FX10.5 Pro

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Crosstrainer FX10.5 Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Taurus Crosstrainer FX10.5 Pro

Summary of Contents for Taurus Crosstrainer FX10.5 Pro

  • Page 1 Assembly and Operating Instructions max. 180 kg ~ 90 Min. 127 kg L 211 | W 82 | H 188 FSUKCVET2519.01.01 SKU: CVET2519 Crosstrainer FX10.5 Pro...
  • Page 2 FX10.5...

  • Page 3: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console display Button functions Powering on the crosstrainer Standby mode MANUAL (Manual programs) 3.5.1 Quick-Start program 3.5.2 Target programs PROGRAM (Profi le programs) USER (User defi ned program) H.R.C.
  • Page 4 RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT FX10.5...
  • Page 5 European VAT Number: DE813211547 Disclaimer © TAURUS is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.

  • Page 6: About This Manual

    ABOUT THIS MANUAL Please carefully read the entire manual before installation and fi rst use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
  • Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.

  • Page 8: General Information

    GENERAL INFORMATION Technical Data LCD Display: Training duration in min. Speed in km/h Training distance in km Calories in kcal Incline Heart rate (using the hand pulse sensors or a chest strap) Watts Brake system: Electro-magnetic induction brake Resistance levels: Wattage Adjustable range in the watt programme: 10-350 W...

  • Page 9: Personal Safety

    Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 10: Electrical Safety

    Electrical Safety ⚠ DANGER In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...

  • Page 11: Set-Up Place

    Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts.

  • Page 12: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.

  • Page 13: Scope Of Delivery

    Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠...

  • Page 14: Assembly

    Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given.  NOTICE First loosely screw all parts together and check that they fi t properly. Tighten the screws using the tool only when you are instructed to do so.
  • Page 15 M8*1.25*120L M8*1.25*70L M8*1.25*55L M8*1.25*35L D15.4*D8.2*2T D25*D8.5*2T...
  • Page 16 Step 2: Assembling the console mast Connect the console cable in the mast (101) with the console cable in the main frame (102). Connect the signal cable in the mast (178) with the signal cable in the main frame (179). ATTENTION In the following step please pay attention that you don't clamp the cables between the frames.
  • Page 17 Step 3: Mounting the arms Screw the left arm (12L) onto the console mast (11) with two Allen screws (6). Screw the right arm (12R) onto the console mast (11) with two Allen screws (6). Only hand tighten the screws in place. M8*1.25*20L step3...
  • Page 18 Step 4: Mounting the pedals Mount the right and left pedal poles (14R/14L) on their respective sides of the main frame (1), each with two washers (73), one Allen screw (72) and one locking nut (74) (see fi g. 4-1). Mount the right and left pedal mounts (15R/15L) on their repsective arm (12R/12L), each with two washers (73), one Allen screw (72) and one locking nut (74) (see fi g.
  • Page 19 Step 5: Mounting the handles Screw the right and left handles (13R/13L) onto the respecitve arm (12R/12L), each with three curved washers (9), three Allen screws (8) and three locking nuts (10) (see fi gs. 5-1 & 5-2). Only hand tighten the screws in place.
  • Page 20 Step 6: Mounting the console Connect the console cable from the console (100) with the console cable from the console mast (101) (see fi g. 6-1). Connect the fi rst hot-key cable from the console (106) with the fi rst hot-key cable from the console mast (108) and the second hot-key cable from the console (107) with the second hot- key cable from the console mast (109) (see fi g.
  • Page 21 Step 7: Mounting the covers Screw the front cover (99) under the console (19) onto the console mast (11) with two screws (96) and hand tighten the screws in place. Clip the rear cover (98) onto the front cover (99) (see fi g.
  • Page 22 ST4.2*15L M5*0.8*12L step7 FX10.5...
  • Page 23 Step 8: Alignment of the feet If the fl oor is uneven, you can stabilize the equipment by turning the two setting screws under the main frame. Lift the equipment on the desired side and rotate the setting screws under the main frame. Rotate the screws clockwise in order to remove them and to raise the equipment.
  • Page 24 Step 9: Connecting the equipment to the mains supply ATTENTION The equipment must not be connected to a multiple socket, otherwise it cannot be guaranteed that the equipment will be supplied with suffi cient power. Technical errors can result. Plug the power plug into a wall outlet that complies with the instructions in the chapter on electrical safety.

  • Page 25: Operating Instructions

    OPERATING INSTRUCTIONS  NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Always start your training with low intensity and increase evenly and gently. End your training with a cool-down phase.
  • Page 26 Display of the current incline level (0-10) INCLINE Set the incline with the incline buttons (0-10) in 1 level increments LEVEL Display of the current resistance level WATTS Display of the Watt value (0 -999) Display of your heart rate (0-230) PULSE Set a heart rate target with the rotary knob (0-30-230) in singluar increments...

  • Page 27: Button Functions

    Button functions BUTTON DESCRIPTION Increasing the setting value or resistance level Rotary knob Decreasing the setting value or resistance level Setting confi rmation BODY FAT Body fat test RECOVERY Heart rate test on your recovery condition Returns you to the previous training mode while making settings or RESET selecting an option.

  • Page 28: Powering On The Crosstrainer

    Powering on the crosstrainer The console starts automatically as soon as the crosstrainer is plugged into the mains supply. Various components will light up. Choose a user profi le (U1 - U4). Enter in your gender (SEX), age (AGE), height (HEIGHT) and weight (WEIGHT). You will proceed onto the main menu.

  • Page 29: Manual (Manual Programs)

    MANUAL (Manual programs) Under MANUAL you can choose between the Quick-Start program and one of the target programs. For target programs, settings for time (TIME), distance (DISTANCE), caloires (CALORIES) or heart rate (PULSE) are possible. 3.5.1 Quick-Start program In the main menu, select MANUAL and confi rm your choice with a single push of the rotary knob.

  • Page 30: Program (Profi Le Programs)

    Training with multiple target values In the main menu select MANUAL and confi rm your choice with a single push of the rotary knob. Select your target value for time, calories, distance and/or heart rate with the rotary knob and confi rm your choice with a single push of the rotary knob.

  • Page 32: User (User Defi Ned Program)

    USER (User defi ned program) There are 16 segments available in user defi ned programs. In the main menu select USER and confi rm your choice with a single push of the rotary knob. Select the resistance level of each segment and confi rm each value with a single push of the rotary knob.

  • Page 33: Heart Rate Controlled Programs)

    H.R.C. (Heart rate controlled programs) ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can aff ect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. There are three heart rate programs available to choose from.

  • Page 34: Watt (Watt Program)

    WATT (Watt program) In the main menu select WATT and confi rm your choice with a single push of the rotary knob. Using the rotary knob, select a Watt value and confi rm your setting with a single push of the rotary knob.

  • Page 35: Body Fat (Body Fat Analysis)

    3.11 BODY FAT (Body fat analysis) Choose your user profi le (U1-U4). To start the body fat analysis, in the main menu press the BODY FAT button and hold on to the hand pulse sensors.  NOTICE Should you not properly grip the hand pulse sensors, the display will show the error code E-1. ...

  • Page 36: Wireless Connection And Fitness Apps

    3.12 Wireless Connection and Fitness Apps This console is equipped with a wireless connection interface. Please take note that your mobile device needs to be compatible with the wireless connection interface of the treadmill. To use training apps you will have to activate the wireless connection function on your mobile device (tablet or smart phone) and start the fi tness app.

  • Page 37: Storage And Transport

    STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location.

  • Page 38: Troubleshooting, Care And Maintenance

    TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may aff ect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.

  • Page 39: Error Codes And Troubleshooting

    Eliminate sources of interference (e.g. Sources of interference in mobile phone, WLAN, lawn mower the room and vacuum cleaner robot, etc..) unsuitable chest strap Use a suitable chest strap (see “RECOMMENDED ACCESSORIES“). Wrong position of chest No pulse display strap Reposition chest...

  • Page 40: Maintenance And Inspection Calendar

    Maintenance and Inspection Calendar To avoid damage from sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specifi ed intervals: Part Weekly Monthly Quarterly Display console Slide rails* Lubrication of slide rails and moving parts*...

  • Page 41: Recommended Accessories

    RECOMMENDED ACCESSORIES To make your training experience even more effi cient and pleasant, we recommend that you add suiting accessories to your fi tness equipment. For elliptical cross trainers this could for example be a fl oor mat, which makes your fi tness equipment stand more securely and also protects the fl oor from sweat or silicone spray to keep moving parts in good shape.

  • Page 42: Ordering Spare Parts

    The serial number of your equipment is unique. It’s located on a white sticker. The exact position of this sticker is shown in the following illustration. Serial number: Brand / Category: Taurus / Elliptical cross trainer Model Name: FX10.5 Pro SKU: CVET2519...

  • Page 43: Parts List

    Parts List Name Supplier Part No. Specifi cation Qty. Main frame 747S1-3-1000-BA2 Front stabilizer 747S0-3-2100-BA1 Hex bolt M8*1.25*120L 50108-5-0120-F5 Spring washer D15.4xD8.2x2T 55108-2-1520-FA Hex bolt M8*1.25*70L 50108-5-0070-F4 Allen bolt M8*1.25*20L 54008-5-0020-F0 Flat washer D16*D8.5*1.2T 55108-1-1612-FA Allen bolt M8*1.25*50L 50308-5-0050-F3 Curved washer D22xD8.5x1.5T 55108-3-2215-FA Nylon nut...
  • Page 44 Left chain cover 734.4*878.2*98.1 747S0-6-4501-B0 Right chain cover 734*878.2*105.2 747S0-6-4502-B0 Left front chain cover 459.7*225.5*87.2 747S0-6-4529-B1 Right front chain cover 459.7*225.5*93.8 747S0-6-4530-B1 Front decorative cover 168.9*175.2*170.8 747S0-6-4523-B0 Upper decorative cover 639*313.7*176.5 747S0-6-4520-B0 Rear decorative cover 217.5*177.1*144.6 747A2-6-4521-B0 Round cover D632.9*36.7 747S0-6-4506-B0 Side cover 148*130.3*16.1...
  • Page 45 Moving wheel D70*43 73800-6-3886-B3 Bearing 6002 ,2RS,SKF 58006-6-1043-00 Moving wheel cover 162*136.2*87 747S0-6-3897-B0 Front handlebar protective cover(black) 240.5*127.8*59 747S0-6-3780-B0 Rear handlebar protective cover(black) 240.5*127.8*50 747S0-6-3781-B0 Bearing 6004 ,2RS,SKF 58006-6-1052-00 Sleeve(2) D25.4*D20.2*44L 747S0-6-2788-00 Front foot cover(left)(black) 152.3*91.1*46.7 747S0-6-3775-B0 Front foot cover(right)(black) 152.3*91.1*60 747S0-6-3776-B0 Bushing...
  • Page 46 Nylon nut M8*1.25*8T 55208-1-2008-CA Cross screw ST4.2*15L 52842-2-0015-F0 Cross bolt M5*0.8*12L, 52605-5-0012-F0 Computer bracket(front) 196.4*109.5*49.1 747S0-6-2592-B0 Computer bracket(rear) 196.3*109.5*96.4 747S0-6-2593-B0 Upper computer cable 300L 747S0-6-2572-00 Middle computer cable 900L 747S0-6-2587-00 Lower computer cable 1050L 747S0-6-2573-00 Connecting cable 350L 820S0-6-3177-00 Sensor cable 500L 805S0-6-2576-00 Round magent...
  • Page 47 Rear cover 766.7*169.6*144.3 747A2-6-4514-B0 D6*26.5*7.7 71600-6-4586-60 Cross screw ST4*1.41*12L 52804-2-0012-F0 Rear stabilizer 747A2-3-2112-BA2 Hex bolt M8*1.25*55L 50108-5-0055-F3 Hex bolt M8*1.25*35L 50108-5-0035-F3 Buff er D20*10L*M8*1.25 55308-4-0010-BB Bushing D19.15x(D25.6x32) 58002-6-1051-B0 xL(17+3) Allen bolt M8*1.25*20L 50308-5-0020-UF0 Sliding beam 747A2-3-5100-BA4 Ball cap D38*31L 55338-1-0031-B8 Square cap 25*50*12L 55312-2-2550-B8...

  • Page 48: Exploded Drawing

    Exploded Drawing FX10.5...

  • Page 49: Warranty

    WARRANTY Products from Taurus® is subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 50 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.

  • Page 51: Contact

    CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER CARE �� �� �� +49 4621 4210-900 80 90 16 50 +44 141 737 2249 or +44 141 876 3972 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk customercare@fi tshop.co.uk �� technik@fi tshop.de ��...
  • Page 52 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA The Fitshop Group is Europe’s largest specialist for https://www.fi tshop.co.uk home fi tness equipment with currently 70 stores www.fi tshop.co.uk/blog and one of the world’s most renowned online mail order companies for fi tness equipment. Powerhouse Fitness is part of the Fitshop Group.
  • Page 53 Notes...
  • Page 54 Notes FX10.5...
  • Page 56 Crosstrainer FX10.5 Pro...
