Summary of Contents for Taurus SEBR7156
- Page 1 Assembly and Operating Instructions max. 200 kg ~ 120 Min. 198 kg L 150 | W 206 | H 231 SEBR7156.01.01 SKU: SEBR7156 Taurus Elite Half Rack V2...
- Page 2 Half Rack V2...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 Half Rack V2...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions Article weight (gross, incl. packaging) approx.: 238 kg Article weight (net, excl. packaging) approx.: 198 kg Packaging dimensions (L x W x H) approx.: 230 cm x 80 cm x 40 cm Set-up dimensions (L x W x H) approx.: 150 cm 206 cm x 231 cm Maximum user weight (pull up bars): 200 kg... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. - Page 11 SEBR7156 PACKING LIST Manual Toolkit Part no. Description Qty. Part no. Description Qty. Underframe Triangle plate Upright support Bottom connection panel Front pull up bar Short plate horn Rear pull up bar Long plate horn Nameplate brace Band rod J hook (L)
- Page 12 Tool kit Hexagon Bolt M10*110 4pcs Hexagon Bolt M10*25 8pcs Hexagon Bolt M10*100 12pcs Flat Washer Ø10 72pcs Hexagon Bolt M10*95 16pcs Locknut M10 32pcs Fork wrench 14-17# 2 pcs Half Rack V2...
-
Page 13: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g. - Page 14 Step 1: Assembly of the Upright Supports and Underframes NOTICE Do not tighten the bolts and nuts completely yet. Leave room for adjustments. Attach two upright supports (2) to each underframe (1) with four M10*25 bolts and four Ø10 flat washers (34). Attach two triangle plates (11) to each of the front upright supports (2) and underframe (1) with four M10*100 bolts (30), eight Ø10 flat washers (34) and four M10 lock nuts (36).
- Page 15 REAR FRONT...
- Page 16 Step 2: Assembly of the Front and Rear Pull up Bars NOTICE Do not tighten the bolts and nuts completely yet. Leave room for adjustments. Attach the front pull up bar (3) to the front upright supports (2) with a total of four M10*95 bolts (32), eight Ø10 washers (34) and four M10 lock nuts (36).
- Page 17 Step 3: Assembly of the Nameplate Braces Attach the nameplate braces (5) to the upright supports (2) with four M10*95 bolts (32), eight Ø10 flat washers (34) and four M10 lock nuts (36) each. Now tighten all bolts and nuts with the tools, beginning at the bottom.
- Page 18 Step 4: Assembly of the Accessories NOTICE The accessories can be used interchangeably. The plate horns (13 & 14) can be used to store 50 mm weight plates. Weight plates are not included in the scope of delivery. Remove the pre-assembled M10*25 bolts (31) and Ø10 big washers (35) from the short plate horns (13) and long plate horns (14).
- Page 19 REAR FRONT...
- Page 20 Step 5: Anchoring the Rack to the Ground (Optional) You have the option to anchor the rack to the ground. This step is not mandatory. Required tools, bolts and dowels are not included in the scope of delivery. ࣑ ATTENTION Not every type of flooring is suitable for anchoring.
-
Page 21: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 22: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Safety can only be guaranteed if you check the equipment regularly for wear and damage. Replace damaged or worn components immediately. -
Page 23: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Screw connections Legend: C = clean;... -
Page 24: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For training equipment like smith machines, weight benches or racks this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat but it could be also additional weights, handles, foot straps for leg exercises or triceps ropes. -
Page 25: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / strength training equipment Model Name: Elite Half Rack V2 SKU: SEBR7156... -
Page 26: Parts List
Parts List Name Qty. Underframe Upright support Front pull up bar Rear pull up bar Nameplate brace J Hook (L) J Hooks (R) Spotter Catcher Arm (L) Spotter Catcher Arm (R) Pull pin Triangle plate Bottom Connection Panel Short plate horn Long plate horn Band rod Landmine... - Page 27 M10*95 Hex bolt M10*110 Hex bolt Φ10 Flat Washer Φ10 Big Washer M10 Nylon lock Nut M10*25 Hex Bolt T-Bar Row Handle...
-
Page 28: Exploded Drawing
Exploded Drawing Half Rack V2... -
Page 29: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 30 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.
-
Page 31: Contact
CONTACT TECHNIK TEKNIK OG SERVICE TECHNIQUE & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 189 530984 +49 4621 4210-945 +49 4621 42 10 933 �� +49 4621 4210-698 �� �� info@fitshop.dk info@fitshop.fr �� technik@sport-tiedje.de ��... - Page 32 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA The Sport-Tiedje Group is Europe’s largest http://www.powerhouse-fitness.co.uk/ specialist for home fitness equipment with www.powerhouse-fitness.co.uk/blog/ currently 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. https://www.facebook.com/powerhousefitness.co.uk Powerhouse Fitness is part of the Sport-Tiedje Group.
- Page 33 Notes...
- Page 34 Notes Half Rack V2...
- Page 36 Taurus Elite Half Rack V2...
